JB950 JOHNNY G SPIRIT BIKE
OWNER’S MANUAL

Johnny G by Spirit

3
www.johnnygspiritbike.com
TABLE OF CONTENTS
5 IMPORTANT SAFETY INSTRUCTIONS
15 WARNING LABELS AND COMMUNICATION STICKERS
16 SAFEGUARDS
17 REGISTER YOUR PURCHASE
18 JB950 ASSEMBLY INSTRUCTIONS
25 TESTING THE BIKE
26 INSTRUCTIONS
30 TRAINING INFORMATION
33 CONSOLE OPERATION
35 PAIRING HEART RATE DEVICE
52 MAINTENANCE MODE
65 GENERAL MAINTENANCE
68 CUSTOMER SUPPORT
Thank you for purchasing our product, please save these instructions. Please do not perform or attempt any
customizing, adjustments, repair or maintenance that is not described in this manual.

4
Johnny G by Spirit
Congratulations on your new JB950 Johnny G Spirit Bike and welcome to the Spirit Fitness family!
Thank you for your purchase of this quality JB950 Johnny G Spirit bike from Spirit Fitness. Your new JB950
was manufactured by one of the leading tness manufacturers in the world and is backed by one of the most
comprehensive warranties available. Through your dealer, Spirit Fitness will do all we can to make your
ownership experience as pleasant as possible for many years to come. If not purchased direct from Spirit
Fitness, the local dealership where you purchased this bike is your administrator for all Spirit Fitness warranty
and service needs. Their responsibility is to provide you with the technical knowledge and service personnel to
make your experience more informed and any difculties easier to remedy.
Please take a moment at this time to record the name of the dealer, their telephone number, and the date of
purchase below to make any future, needed contact easy. We appreciate your support and we will always
remember that you are the reason that we are in business.
Yours in Health,
Spirit Fitness
NAME OF DEALER _____________________________________
DEALER PHONE # _____________________________________
PURCHASE DATE _____________________________________

5
www.johnnygspiritbike.com
IMPORTANT SAFETY
INSTRUCTIONS
WARNING
This chapter includes precautions and tness
safeguards for the installation and use of the Johnny
G Spirit Bike. Please read this chapter carefully
before installing or using your equipment. Safety
instructions are provided in the following languages
(in the order shown):
• English, Dutch, French, German, Italian, Portuguese,
Spanish, Swedish, Chinese, Japanese
USER SAFETY PRECAUTIONS
These safety notes are directed to you as the
owner of the Johnny G Spirit Bike. Please train all
your users and tness staff to follow these safety
instructions. DO:
• Do encourage each of your users to discuss their
health program or tness regimen with a healthcare
professional.
• Do stop operating your bike if you feel dizzy or faint.
• Do perform regular preventative maintenance.
• Do exercise slowly until you reach a level of comfort.
DO NOT:
• Do not let unsupervised children operate the bike.
• Do not use without proper athletic shoes.
• Do not use in rainy weather outdoors, or in an enclosed
pool environment.
• Do not drop or insert any object, hands, or feet into any
opening or within the area of the ywheel.
• Do not attempt to remove any shrouds or modify the
bike.
WARNING:
• Your Johnny G Spirit Bike is designed for aerobic
exercise in a commercial or consumer environment.
• Please check with your physician prior to beginning any
exercise program.
• Do not push yourself to excess. Stop if you are feeling
faint, dizzy, or exhausted. Use common sense when
biking.
• Read the owner’s manual in its entirety before operating
the bike.
• Failure to obey this warning can result in injury or death.
SPIRIT FITNESS®and the Spirit Fitness logo are
registered trademarks of Dyaco International.

6
Johnny G by Spirit
VOORZORGSMAATREGELEN
Deze veiligheidsaantekeningen zijn aan u
gericht als eigenaar van de Johnny G Spirit Bike.
Gelieve uw gebruikers en uw per- soneel voor
conditietraining volledig bekend te maken met deze
veiligheidsinstructies. Doe het volgende:
• Moedig elk van uw gebruikers aan hun
gezondheidspro-gramma of conditietherapie met een
professioneel uit de gezondheidszorg te bespreken.
• Stop het gebruik van uw bike als u zich duizelig of
een auwte voelt.
• Voer regelmatig preventief onderhoud uit.
• Oefen langzaam totdat u een comfortniveau heeft
bereikt.
• Gebruik de bike alleen voor zijn bedoelde gebruik,
zoals in deze handleiding staat beschreven.
Doe het volgende NIET:
• Laat kinderen zonder toezicht de bike niet bedienen.
• Niet zonder gymschoenen gebruiken.
• Niet buiten bij regenachtig weer gebruiken, of in
dichte ruimte met een zwembad.
• Laat geen enkel voorwerp in de bike vallen en steek
uw handen of voeten in geen enkele opening van of
onder uw bike.
• Probeer geen omhulsels te verwijderen of uw bike te
wijzigen.
WAARSCHUWING:
• Uw Johnny G Spirit Bike is ontworpen voor
aërobische oefeningen in een commerciële of
gebruiker-somgeving.
• Zie uw arts vóór het beginnen van een
oefenprogramma.
• Dwing uzelf niet tot buitensporige oefeningen. Stop als
u zich duizelig, uitgeput of een auwte voelt.
• Lees de gebruikershandleiding helemaal en
aandachtig door alvorens uw bike te bedienen.
• Nalaten deze waarschuwing op te volgen kan letsel
of overlijden tot gevolg hebben.

7
www.johnnygspiritbike.com
PRÉCAUTIONS
Ces consignes de sécurités s’adressent aux
propriétaires du Johnny G Spirit Bike. Veuillez
instruire tous vos utilisateurs et instructeurs à suivre ces
consignes. À FAIRE:
• Encouragez tous les utilisateurs à consulter un médecin
au sujet de leur programme de tness ou régime
d’exercice.
• Cessez d’utiliser le bike en cas d’étourdissement ou de
faiblesse.
• Exécutez régulièrement la maintenance préventive.
• Commencez l’exercice lentement jusqu’à ce que vous
atteignez un niveau confortable.
• Utilisez le bike uniquement de la manière prévue, telle
que décrite dans ce manuel.
À ÉVITER:
• Ne laissez pas des enfants utiliser le bike sans
sur-veillance.
• Ne l’utilisez pas sans porter de chaussures d’athlétisme.
• Ne l’utilisez pas en extérieur lors de temps pluvieux, ni
en intérieur dans une salle de piscine.
• Évitez de laisser tomber tout objet ou d’introduire les
mains ou pieds dans toute ouverture ou en-dessous du
bike.
• Ne tentez pas de retirer tout carter de protection ni de
modier le bike.
AVERTISSEMENT:
• Le Johnny G Spirit Bike est conçu pour l’exercice
aérobique dans un environnement commercial ou
privé.
• Veuillez consulter un médecin avant de commencer
tout programme d’exercice.
• Ne vous poussez pas au-delà de vos limites.
Arrêtez-vous si vous vous sentez faible, étourdi ou
épuisé Faites preuve de bon sens lorsque vous vous
entraînez.
• Lisez le guide de l’utilisateur en entier avant d’utiliser
le bike.
• Le non-respect de ces avertissements peut se traduire
par des blessures, voire la mort.

8
Johnny G by Spirit
VORSICHTSMASSNAHMEN
Die folgenden Vorsichtsmaßnahmen richten
sich an Sie als Besitzer des Johnny G Spirit
Bike. Bitte schulen Sie alle Ihre. Benutzer und
Ihr Fitness-Personal in der Beachtung dieser
Sicherheitsvorschrifte. GEBOTE:
• Legen Sie jedem Ihrer Benutzer nahe, sein
Gesundheits- oder Fitnessprogramm mit einem medi-
zinischen Fachmann zu besprechen.
• Beenden Sie den Betrieb Ihres bike, wenn Sie sich
schwindelig oder schwach fühlen.
• Führen Sie regelmäßige vorbeugende
Wartungsmaßnahmen durch.
• Trainieren Sie langsam, bis Sie eine gewisse
Komfortzone erreichen.
• Verwenden Sie den bike nur zum vorgesehenen, in
dieser Anleitung beschriebenen Zweck.
VERBOTE:
• Lassen Sie den bike nicht von unbeaufsichtigten
Kindern in Betrieb nehmen.
• Benutzen Sie das Gerät nicht ohne Sportschuhe.
• Benutzen Sie das Gerät bei regnerischen
Witterungsbedingungen nicht im Freien und nicht In
einer geschlossenen Schwimmbadumgebung.
• Lassen Sie keine Gegenstände in irgendwelche
Öffnun- gen oder unter den bike fallen und halten Sie
Hände und Füße von diesen Bereichen fern.
• Unternehmen Sie keinen Versuch, irgendwelche
Abdeckungen zu entfernen oder den bike zu modi-
zieren
ACHTUNG:
• Der Johnny G Spirit Bike ist für aerobische Übungen
in einer kommerziellen oder Verbraucherumgebung
vorgesehen.
• Bitte holen Sie vor Aufnahme eines jeden
Trainingsprogramms den Rat Ihres Arztes ein.
• Trainieren Sie nicht übertrieben hart. Hören Sie auf,
wenn Sie ein Schwäche-, Schwindel- oder
• Erschöpfungsgefühl verspüren. Lassen Sie sich beim
Schritttraining von Ihrer Vernunft leiten. Lesen Sie vor
Inbetriebnahme Ihres bike die Bedienungsanleitung
vollständig durch.
• Ein Missachten dieses Achtungshinweises kann
Verletzungen oder den Tod zur Folge haben.

9
www.johnnygspiritbike.com
PRECAUZIONI
Queste note precauzionali sono dirette a voi,
come proprietario dello Johnny G Spirit Bike. Siete
pregati di istruire i vostri uten- ti e il vostro personale
all’osservanza di queste precauzioni. DA FARE:
• Incoraggiate i vostri utenti a discutere il loro
programma di salute o di tness con uno specialista
dell’healthcare.
• Interrompete l’uso dello bike se avete giramenti di
testa o se vi sentite mancare.
• Eseguite periodicamente servizi di manutenzione.
• Utilizzate lo bike soltanto per l’uso è a cui è destina-
to, come descritto nel manuale.
DA NON FARE:
• Non consentite a bambini di usare lo bike senza la
supervisione di un adulto.
• Non utilizzate lo bike senza scarpe atletiche.
• Non utilizzate lo bike all’esterno in condizioni
piovose o in un ambiente con piscina interna.
• Non lasciate cadere oggetti sullo bike e non inserite
oggetti, mani o piedi in qualsiasi apertura esterna o
sotto lo bike.
• Non cercate di rimuovere le coperture o di
modicare lo bike.
AVVERTENZE:
• Lo Johnny G Spirit Bike è stato realizzato per esercizi
di aerobica in un ambiente pubblico o privato
adeguato.
• Prima di iniziare un programma di esercizio sico,
consultate il vostro medico.
• Non eccedete i vostri limiti. Fermatevi se vi
sentite mancare, se avete giramenti di testa o se
vi sentiteesausti. Usate buon senso nell’utilizzo
dell’attrezzatura.
• Leggete il Manuale dell’utente interamente prima di
utilizzare lo Spinner.
• La mancata osservanza di queste avvertenze può
comportare lesioni gravi o morte.

10
Johnny G by Spirit
PRECAUÇÕES
Estas notas de segurança destinam-se a você,
proprietário do bike Johnny G Spirit Bike. Treine
todos os usuários e o pessoal da academia para
que sigam estas instruções de segurança. O QUE
FAZER:
• Incentive todos os usuários a discutirem seu programa
de saúde ou sistema de condicionamento físico com
um prossional da área de saúde.
• Pare o funcionamento do bike se sentir tontura ou
ertigem.
• Efetue a manutenção preventiva regular.
• Faça exercícios lentamente até atingir um grau de
con-forto.
• Use o bike apenas de acordo com a nalidade para
que se destina, conforme descrito neste manual.
O QUE NÃO FAZER:
• Não deixe crianças sem supervisão operarem o bike.
• Não use sem os sapatos esportivos apropriados.
• Não utilize em ambientes externos quando o tempo
estiver chuvoso, nem em um ambiente fechado de
pisci-na interna.
• Não deixe cair nem insira nenhum objeto, mãos ou
pés em qualquer abertura ou sob o bike.Não tente
remover nenhum degrau nem modicar seu bike.
ADVERTÊNCIA:
• Seu Johnny G Spirit Bike foi projetado para exercícios
aeróbicos em um ambiente comercial ou próprio do
consumidor.
• Consulte seu médico antes de começar qualquer
programa de exercícios.
• Não se esforce demais. Pare se sentir tontura,
vertigem ou exaustão. Tenha bom senso ao fazer o
exercício. Leia todo o Manual do Proprietário antes
de operar o seu bike.
• Deixar de observar esta advertência pode resultar em
ferimentos ou morte.

11
www.johnnygspiritbike.com
PRECAUCIONES
Estas notas de seguridad están dirigidas a usted
como el dueño de Johnny G Spirit Bike. Por favor
instruya a todos sus usuar- ios y personal de
entrenamiento para que sigan estas instrucciones de
seguridad. LO QUE SE DEBE HACER:
• Dígale a cada uno de sus usuarios que discuta su
programa de salud o régimen de ejercicio con un
profe-sional de la salud.
• Deje de operar su bike si se siente mareado o como
que va a desmayarse.
• Lleve a cabo mantenimiento preventivo a intervalos
reg-ulares.
• Haga ejercicio lentamente hasta que alcance un nivel
en el que se sienta cómodo.
• Utilice el bike solamente para lo que fue diseñado,
como se describe en este manual.
LO QUE NO SE DEBE HACER:
• No permita que los niños operen su bike sin
super-visión.
• No lo use sin zapatos atléticos.
• No lo utilice afuera en la lluvia ni en un ambiente
cerra- do donde haya una piscina.
• No lo deje caer ni inserte objetos. manos o pies en
ninguna apertura de su bike ni debajo de él.
• No intente quitar ninguna cubierta o recubrimiento ni
modicar su bike.
ADVERTENCIA:
• Su Johnny G Spirit Bike está diseñado para el
ejercicio aerobic en un ambiente commercial o de
consume.
• Por favor consulte con su médico antes de iniciar
cualquier programma de ejercicio.
• No haga un esfuerzo excesivo. Deténgase si se siento
mareado, exhaust o como si fuera a desmayarse. Use
su sentido común al hacer ejercico.
• Lea completamente el Manual del dueño antes de
operar su Spinner.
• El no cumplir con esta advertenicia puedo resultar en
una lesión o en la muerte.

12
Johnny G by Spirit
FÖRSIKTIGHETSÅTGÄRDER
Dessa säkerhetsanmärkningar är riktade till dig
i egenskap av ägare av Johnny G Spirit Bike
manufactured by Spirit Fitness alla användare och
all personal att följa dessa säkerhetsanvisningar.
MAN SKA:
• Uppmuntra alla användare att konsultera sitt hälso-
progam eller sin träningsregim med en läkare.
• Sluta använda bike om man känner sig yr eller
svim- färdig.
• Utföra regelbundet underhåll i förebyggande syfte.
• Motionera långsamt tills man når en komfortnivå.
• Endast använda bike för dess avsedda användning,
enligt beskrivning i denna handbok.
MAN SKA INTE:
• Låta barn använda bike utan uppsikt.
• Använda bike utan sportskor.
• Använda bike utomhus i fuktigt väder eller i ett innes-
lutet bassängområde.
• Tappa in eller föra in något föremål, händer eller
fötter i någon öppning, eller under bike.
• Försöka att avlägsna några skyddskåpor eller att
modi- era bike.
VARNINGAR:
• Din Johnny G Spirit Bike är avsedd för aerobisk träning
i kommersiella eller konsumentinriktade miljöer.
• Konsultera din läkare innan du inleder något
träningsprogram.
• Driv inte dig själv för hårt. Sluta om du känner dig
yr, svimfärdig eller utmattad. Använd Spinner med
sunt förnuft. Läs igenom hela handboken innan du
använder Spinner.
• Underlåtelse att iaktta dessa varningar kan medföra
skada eller dödsfall.

13
www.johnnygspiritbike.com
注意事項
下述安全說明適用於您所擁有的 JOHNNY G
SPIRIT BIKE室內健身車。請培訓所有使用者與健
身人員遵守下述安全說明。 遵守事項:
• 鼓勵您的每個使用者在使用此健身車前，與專業的
醫療保健專業人員討論他們的健康計劃或健身方
案。
• 如果您感到頭暈或虛弱，請停止使用此健身車。
• 請定期進行預防性維護。
• 請緩慢且循序漸進使用此健身車，直至達到舒適程
度。
禁止事項:
• 請勿讓無人監管的兒童操作此健身車。
• 請勿在沒有穿著合適的運動鞋的狀況下使用此健身
車。
• 請勿在戶外陰雨天氣或封閉的泳池環境中使用此健
身車。
• 請勿讓任何物體、手或腳掉入或插入任何開口或飛
輪區域內。
• 請勿嘗試拆除任何鏈蓋或修改健身車。
警告:
• 您所擁有的Johnny G Spirit Bike室內健身車，專為商
業或消費環境中的有氧運動而設計。
• 在開始任何鍛煉計劃之前，請諮詢您的醫生。
• 請勿讓自己運動過量。 如果你感到昏厥，頭暈或疲
憊，請停止使用。 使用此健身車時要運用一般常
識。
• 在使用此健身車之前，請完整閱讀使用者手冊。
• 不遵守上述警告可能導致人身傷害或死亡。

14
Johnny G by Spirit
注意事項
これらの安全に関する注意事項は、JOHNNY G
SPIRIT BIKEのオーナーとしてお客様に向け示さ
れています。これらの安全に関する指示や注意
事項に従うように、すべてのユーザーやフィッ
トネススタッフをトレーニングしてください。
DO（行ってください）:
• 各ユーザーが各自の健康プログラムやフィットネ
スプログラムについて、必ず医療従事者や専門家
と相談する事を強く奨励します。
• 使用前、使用中にめまいや気分が悪いと感じた場
合は、直ちにバイクの使用をやめてエクササイズ
を中止してください。
• エクササイズバイクの定期的な予防メンテナンス
を行ってください。
• 行っているエクササイズが快適に感じるまではゆ
っくりと運動してください。
DO NOT（行わないでください）:
• 監督なしでの子供の自転車使用を禁止してくださ
い。
• 適切な運動靴なしで使用しないでください。
• 雨天時の屋外や屋内プールでの使用は避けてくだ
さい。
• フライホイールの開口部やその付近に物、手、
足、指等を落としたり、入れたり、触れたりしな
いようにしてください。
• カバーや覆いを取り外したり、このエクササイズ
バイクを改造しないでください。
警告:
• このJohnny G Spirit Bike社によって製造された、業
務使用目的または個人使用目的の有酸素運動用に
設計されたエクササイズバイクです。
• エクササイズプログラムを始める前に必ず医師に
ユーザー自身の健康状態を相談してください。
• 自分自身のレベルを超えた過度なエクササイズは
避けてください。わずかでも、体調不良やめまい
を感じたり、疲労を感じた場合は直ちにエクササ
イズを中止して、使用を止めてください。エクサ
サイズバイクの使用には適切な常識を適用する事
をお勧めいたします。
• エクササイズバイクを使用する前に、取扱説明書
すべてを読み理解してください。
• この警告に従わない場合は、重篤な事故、怪我や
死亡に繋がる可能性があります。

15
www.johnnygspiritbike.com
WARNING
LABELS AND
COMMUNICATION
STICKERS
The following pages show
examples of Johnny G Spirit Bike
warning labels and communication
stickers placed on the equipment as
part of the manufacturing process.
It is critical that owners maintain
the integrity and placement of these
stickers. If you nd any stickers
missing or damaged contact your
local dealer or distributor for a
replacement. NOTE: STICKERS
AND LABELS ARE NOT SHOWN
TO SCALE.
EXERCISE WARNING DECAL
SERIAL NUMBER DECAL
CE CERTIFICATION

16
Johnny G by Spirit
SAFEGUARDS
The following tness safeguards and operating
precautions are directed to purchasers and users
of the Johnny G Spirit Bike. Club Managers should
ensure that members and tness staff are trained to
follow these same instructions. Failure to follow these
safeguards may result in injury or serious health risk.
• Ensure that the seat height adjustment knob is properly
secured and does not interfere with range of motion
during exercise.
• Children under the age of 13 should not ride the bike.
The bike mechanism and ergonomics are designed for
adult use only.
• Do not insert any object, hands or feet into any
openings, or expose hands, arms or feet to the drive
mechanism or other potentially moving part of the bike.
• The maximum weight for individuals riding the bike
should not exceed 350lbs /159kg.
• Do not dismount the bike until both the pedals and
ywheel have stopped completely. Failure to comply
may lead to loss of control and serious injury.
• If at any time you feel dizzy or have difculty
breathing, gradually stop pedaling and carefully
dismount the bike.
• Listen to your body, ride at a pace that feels right for
you.
• Keep children and pets away from the bike whenever
it's in use.
• Never turn the pedal crank arms by hand.
• Stay hydrated. Drink water throughout your ride as
needed.
• Stay in control by executing all movements at a slow
pace before attempting to increase your speed.
• Do not exercise at high speeds and intensity without
having initially established a baseline tness level and
obtaining a medical clearance from your physician.
Focus on form, posture and establishing a controllable
pace before attempting any high intensity short
duration sprints.
• Do not use the bike without proper footwear. Never
operate the bike with bare feet.
• Never place your feet in any position on the bike
other than the pedals.

17
www.johnnygspiritbike.com
RECORD YOUR SERIAL NUMBER
Please record the serial number of this tness product in the space provided below (serial number is located
on the center oor tube behind the crank.)
Serial Number:
REGISTER YOUR PURCHASE
Please mail your warranty registration card to the address below or call us at [phone] to get
your product registered:
Dyaco Commercial & Medical North America
18303 Bothell Everett Hwy.
Suite 210
Bothell, WA 98012
United States of America
Patent pending.

18
Johnny G by Spirit
JB950 PRE-ASSEMBLY
Use the following procedures to unpack and assemble your Johnny G Spirit Bike:
1. Position the shipping carton so the Heavy End is located at the bottom.
2. Cut the straps then lift the box over the unit and unpack. Remove all parts from the shipping carton and foam
inserts, and verify that all parts are included in your shipment.
3. Locate the hardware package. The hardware is separated into four steps. Remove the tools rst. Remove the
hardware for each step as needed to avoid confusion. The numbers in the instructions that are in parenthesis (#)
are the item number from the assembly drawing for reference.
NOTE: All tools required to assemble the bike are included within the packaging. If you are missing any of
the parts listed above, inspect the packing material and the box for items that may have been overlooked.
If parts are missing, or if you have any operational questions, please call your local Spirit Fitness’s Service
department or the distributor whom sold you the product. Please see the back of the manual for a listing of
international corporate ofces and locate the ofce nearest you. Have your serial number ready.
CAUTION: Damage to the bike during assembly is not covered as part of the limited Spirit Fitness
warranty. Take care not to drop or lean the bike on its side. Carefully stand the bike up in the normal
upright position on a stable surface so it will not tip over during assembly.
Protect the environment by not disposing of this product with household waste. Check your local authority
or approved waste center for recycling advice and facilities.

19
www.johnnygspiritbike.com
JB950 PRE-ASSEMBLY
TOOLS NEEDED:
#155. L M4 Allen Wrench (1 pc)
#157. 17mm Wrench (1 pc)
#158. 13/15 Wrench (1 pc)
#159. L M2.5 Allen Wrench (1 pc)
#167. 19mm Wrench (1 pc)

20
Johnny G by Spirit
JB950 STEP ONE
HARDWARE FOR STEP 1
PART TYPE DESCRIPTION QTY
165 SHORT HEX HEAD BOLT M12 x P1.25 x 20L 5
141 LONG HEX HEAD BOLT M10 × P1.5 × 55L 1
166 FLAT WASHER Ø12.7 x Ø26 x 2T 5
125 FLAT WASHER Ø10 × Ø25 × 1.5T 1
54 PEDALS SET PEDALS R/L 1
1. Assemble FRONT STABILIZER (2) to MAIN
FRAME (1) using THREE HEX BOLTS (165)
and THREE WASHERS (166) with 19MM
WRENCH (167).
2. Assemble REAR STABILIZER (3) to MAIN
FRAME (1) using TWO SHORT HEX BOLTS
(165),ONE LONG HEX BOLT (141), ONE
WASHER (125) and TWO WASHERS (166)
with 19MM WRENCH (167). The LONG HEX
BOLT (141) and WASHER (125) are used
in the center holeand tightened with 17MM
ALLEN WRENCH (157) .
3. Assemble PEDALS (54) to bike using 15MM
WRENCH (158). If using torque wrench,
tighten to 30-35 lbf•ft.
