Spitzer LIGHTING CANOPY Series User manual

CANOPY SERIES
PARKING GARAGE CANOPY SQUARE
INSTALLATION MANUAL
SAFETY INFORMATION
BE SURE THE POWER IS OFF! RISK OF ELECTRICAL SHOCK: Always use the switch to power off. Do not perform
any operations while this unit is powered on. The electrical system you want to connect the device to must be
grounded. Read the instructions before using or powering this device. The safety instructions must remain with
the unit in case of transfer. Any damage to the device linked to an inappropriate use is excluded from support by
the warranty. Before connecting, make sure that the current and voltage are compatible with this device. We highly
recommend that all installations are made by QUALIFIED ELECTRICIAN. We are NOT responsible by any means for
the use or misuse of the following information. We are NOT responsible in whole or part for any harm or damage
that may or may not be caused. We reserve the right to revise the components of any product, due to part availability
or change ETL, CUL, UL standards without assuming any obligation or liability to modify any products previously
manufactured and without notice. These instructions do not cover all details of variations in equipment, nor do they
provide every possible contingency to be met. Turn off / unplug power when installing or service device.
WARNING: Read all saftey precautions and installation instructions carefully before installing or servicing this
xture. Failure to comply with these instructions could result in a potentially fatal electric shock, re, and/or
property damage.
• To prevent personal injury or product damage only licensed electricians should install
• To avoid electric shock or component damage disconnect power before attempting installation or servicing
• This product must be installed in accordance with the national electric code (NEC) and all applicable federal, state
and local electric codes and safety standards
• Disconnect product and allow cooling prior to servicing
• Any alteration or modication of this product is expressly forbidden as it may cause serious personal injury, death,
property damage and/or product malfunction
• To prevent product malfunction and/or electrical shock this product must be properly grounded
• This luminaire is designed to operate in ambient temperatures ranging from -22°F to 104°F and to be horizontally
mounted with the LEDs facing down
WARNING
FCC WARNING
WARNING: Changes or modications to this unit not expressly approved by the party responsible for compliance
could void the user authority to operate the equipment.
NOTES: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
PRE - INSTALLATION
•Carefully remove the fixture from the carton.
•Before beginning assembly, installation, or operation of product, make sure all parts
are present. Compare parts with package contents list and diagram on previous page.
If any part is missing or damaged, do not attempt to assemble, install or operate the
product. Contact customer service for replacement parts.
•Tools required for assembly (Not Included): screwdriver, phillips screwdriver, pliers,
electrical tape, wire cutters, safety glasses, ladder, wire stripper.
PENDANT INSTALLATION WITH 3/4” CONDUIT (Caution: Before beginning installation turn off the circuit breaker and light switch)
PRODUCT PARAMETER
INPUT VOLTAGE 120 -277V
DIMMING 1 - 10 VDC
MATERIAL ALUMINUM & PC
STEP 1 STEP 2
Loosen the screw on the
side of the light, removing
the bracket from the
canopy light by pulling it
slightly out, just leaving the
ring on the bracket.
Screw the conduit into the
hole on top of canopy light
installation done.
Connect the wires
threaded from conduit and
canopy, black wire for lime,
white for neutral, yellow
and green for ground.
STEP 3
www.spitzerlighting.com 702 Interchange Blvd., Newark, DE 19711 Specication is subject to change without notice 1/2
CARE AND MAINTENANCE
CAUTION: Before attempting to clean the xture, disconnect the power to the xture
by turning the breaker off or removing the fuse from the fuse box. This LED light
xture is made from quality materials that will last many years with minimum care
and maintenance. You may want to clean the xture with a soft cloth periodically.
To maintain the best appearance of the xture, do not use cleaners with chemicals,
solvents or harsh abrasives. Do not use liquid cleaner on the LEDs, LED driver, or
wiring inside the light xture.

CANOPY SERIES
PARKING GARAGE CANOPY SQUARE
INSTALLATION MANUAL
SURFACE MOUNT INSTALLATION W/J-BOX (Caution: Before beginning installation turn off the circuit breaker and light switch)
SURFACE MOUNT INSTALLATION (Caution: Before beginning installation turn off the circuit breaker and light switch)
www.spitzerlighting.com 702 Interchange Blvd., Newark, DE 19711 Specication is subject to change without notice 2/2
STEP 1
STEP 1
STEP 3
STEP 3
STEP 2
STEP 2
STEP 4
STEP 4
STEP 5
Loosen the screw on side
of the light, removing the
bracket from canopy light
by pulling it slightly out,
just leaving the ring on the
bracket.
Remove the lens and metal
plate by unscrewing the
screws.
Attach the canopy light
with the bracket by putting
the ring on clips again.
Connect the black wire
for line, white for neutral,
yellow and green for
ground.
Remove 1/2” plug from
direction you intend to
feed conduit.
Fix the bracket on J-box,
and put the wire through
the central hole for wiring
Cut off the wires through
from 3/4” hole and plug
the hole with provided
plug. Drill 4 holes on
edge of xture and x it
on the ceiling with using
appropriate screws.
Slide the canopy lights into
the bracket, and secure
the screw on side of the
light to prevent the light
from sliding out from the
bracket. Installation done.
Disconnect the wires came
3/4” hole and connect
the wires came from 1/2”
conduit with power supply.
(white for neutral, black for
line, yellow green/ green
for ground).
Replace the metal plate
and the lens, make sure
no wires are pinched when
replacing parts.
