Commissioning Instruction leaflet
Reeve 2 Batten
73535, 73536
www.saxbylighting.com
For your safety, always switch off the mains supply before changing lightbulbs, or cleaning.
Waste electrical products should not be disposed of with household waste. Please recycle where facilities
exist. Check with your Local Authority or retailer for recycling advice.
Recycling advice
Safety information
Saxby Lighting Ltd. BH23 3PE
We recommend cleaning with a soft dry cloth.
Do not use solvents or abrasive cleaners as these could damage the finish.
The LED module is protected by a shade. The shade cannot be replaced, if the shade becomes
cracked or damaged, this light fitting must be discarded
• Attachproducttomountingbracketsbypushinguntil
securely held.
• Replacefuse orcircuitbreaker andswitchon. Your
light is now ready for use.
Iss.2 06072017
• TheLEDmoduleinthisproductisnonreplaceable.
Fitting/replacing bulbs

Thankyouforpurchasingthislightfitting.Pleasereadtheinstructionscarefullybeforeusetoensuresafeand
satisfactory operation of this product. Please retain these instructions for future reference.
Warning
This light fitting is Double Insulated and
does not require connection to an Earth
circuit.
Please read these instructions carefully before
commencing any work.
Thisunitmustbefittedbyacompetentandqualified
electrician.
Install in accordance with IEE Wiring regulations and
currentBuildingRegulations.
Topreventelectrocutionswitchoffatmainssupply
before installing or maintaining this fitting. Ensure
other persons cannot restore the electrical supply
without your knowledge. If you are in any doubt,
pleaseconsultaqualifiedelectrician.
Thislightfittingshouldbeconnectedtoacircuitwitha
30mARCDfitted.
If replacing an existing fitting, make a careful note of
the connections.
Waste electrical products should not be disposed of
with household waste. Please recycle where facilities
exist. Check with your local authority or retailer for
recycling advice.
ThisproductisratedatIP65.
Theentireunitgetshotwhilstonforaperiodoftime.
TheseproductsshouldnotbefittedtoPIRcircuitsor
short duration timed switches.
Specification
Voltage: 240V 50Hz a.c.
Lamp: 45W LED Module - 4000lm
IP rating: 65
Layout
Installation
Wiring
Check that...
• Youhavecorrectlyidentifiedthewires.
• Theconnectionsaretight.
• No loose strands have been left out of the connection
block.
• Planthedesiredlayoutofthisfittingcarefully,
ensuring the cables will reach the distance between
the junction box and the light fitting.
• Avoidlocatinganycablesinpositionsthatwould
cause a hazard. Position cables and outdoor rated
junction boxes (not supplied) away from areas
where they may be at risk from being cut, trapped or
damaged.
• WerecommendthatyouuseH05RN-Fspecification
cable (not supplied) which is an outdoor grade,
rubbersheathedcable.Themainssupplycablemust
have a minimum cross sectional area of 1.0mm²
• Cablesmustbeprotectedusingsuitableconduitor
plastic trunking.
Existing fittings must be completely removed before
installation of a new product. Before removing the
existing fitting, carefully note the position of each set
of wires.
• Refertothediagrambelow.Decideonthelocation
of the product. Measure the distance between the
mounting bracket location slots, mark the location of
the fixing holes on the mounting surface.
• Drillholesandfitsuppliedwallplugs(suitablefor
masonry only - for other surfaces use appropriate
fixings).Fix mounting brackets in place.
• Wireasdetailedbelow.
Having correctly identified the wiring from your existing light fitting, connect to the approved outdoor rated or
approved double insulated terminal block in the following way:
