Splitvolt Splitter Switch SPS 01-011 Setup guide

Splitvolt™ Splitter Switch™
QuickStart User Guide
Models: SPS 01-011, SPS 02-022, SPS 01-031, SPS 02-032
Thank you for choosing the Splitvolt™ Splitter Switch™! Charging your electric vehicle (EV)
just got easier! Share and automatically switch full power between your EV charger and
clothes dryer using your existing, standard dryer wall socket. Avoid the cost, complexity and
time of having an electrician install a dedicated circuit, and instead utilize your existing home
wiring with Splitvolt. This new category of product saves you thousands of dollars in rewiring
costs. Just plug it in, and Splitvolt monitors, displays, and switches full 24-amp power
on-demand between attached devices, providing the fastest possible safe charging on a
standard 30-amp circuit, at a fraction of the cost of installing a new, dedicated circuit in your
home.
Please read this manual before use.
Contact information
Splitvolt, Inc. inf[email protected]
3250 Victor Street, Unit B www.splitvolt.com
Santa Clara, CA 95054
Copyright © 2020 Splitvolt, Inc. All rights reserved.

Splitvolt Splitter Switch
QuickStart User Guide
Models covered in this guide
Model
SKU
UPC
Wall Plug Pigtail
Connector
(Male)
Dryer Socket
Connection
(L, Female)
EV Socket
Connection
(R, Female)
SPS 01-011
SPS-01-011-30A
-00
850019012200
NEMA 10-30
NEMA 10-30
NEMA 10-30
SPS 02-022
SPS-02-022-30A
-00
850019012217
NEMA 14-30
NEMA 14-30
NEMA 14-30
SPS 01-031
SPS-01-031-30A
-00
850019012224
NEMA 10-30
NEMA 10-30
NEMA 14-50
SPS 02-032
SPS-02-032-30A
-00
850019012331
NEMA 14-30
NEMA 14-30
NEMA 14-50
Pick the right model based on your wall socket, dryer plug, and EV socket type according to
the table above. You can reference the socket-type images in the diagram below to
determine which type you have.
Features and capabilities
●Automated power switching between dryer and EV power sockets
●Full-color display screen and LED status lights
●Real-time voltage, current, temperature, kWh, and status indicators
●Integrated 25-amp circuit breaker with easy reset for added protection
●Supports standard 30-amp dryer circuits (maximum 24-amp NEC safe charging rate)
●Compatible with common 3rd-party electric vehicles and chargers
●Supports common household dryer (10-30 and 14-30) and charger (10-30, 14-30, and
14-50) plug types
●The NEMA 14-50 plug is for convenient access to common charger plugs; the maximum
safe charging rate on the socket is 24 amps
●Integrated wall-mount screw holes and 4 ft (1.3 m) pigtail plug for easy installation
●UL/CE safety certifications: in process, not yet received
2
Splitvolt, Inc.

Get to know your Splitvolt Splitter Switch
●Circuit breaker with on/off positions
●3-line LCD display
●Present power use in Watts
●Total power used over time in kWh
●Voltage and current in amperes (amps)
To reset statistics over time, press and hold the flat reset button on the right side of
the screen for 5 seconds
●LED indicator: ON indicates EV charger (EVSE) has power
●Left outlet: for electrical appliance (dryer)
●Right outlet: for EV charger
Specifications
Maximum Load
240V ~60Hz 24A AC
Nominal Intended Power
North American 220-240V AC, ~60Hz
Dust and Water protection
Indoor Use Only
Case Flammability Safety Rating
UL-94 V0
Full Safety Agency Certification
Pending
LED Indicator (Lit)
EV Socket Power On
Unit Weight
6.7 lb (3.04 kg)
Unit Dimensions
12" x 8.5" x 4" (30.5 x 21.6 x 10.2 cm)
Package Dimensions
14" x 13" x 7" (35.5 x 33 x 17.8 cm)
Package Shipping Weight
8.5 lb (3.9 kg)
Warranty
1 Year
Quick start
1. Plug the SPS into the wall outlet
3
Splitvolt, Inc.

2. Plug the dryer into the left outlet of the SPS
3. Plug the EV charger into the right outlet of the SPS
4. Set current to 24 amps on either your EV charger or vehicle
5. Switch the circuit breaker to the ON position
Optional wall mount
1. Position the SPS so that the plug reaches the wall outlet
2. Mark screw holes
3. Unplug the SPS
4. Use 5/16” or 8 mm drill bit to create drill holes
5. Push the supplied 5/16” x 1.5” (8 mm x 38 mm) anchors into the drill holes
6. Secure the SPS into anchors with supplied screws
Disclaimers
By purchasing this product, you acknowledge that it is an early-release version that has not yet received
UL/CE safety certification ratings.
This product is intended for indoor use and must be protected from moisture and the elements to maintain
safety, durability and operation.
Note that power is prioritized to your dryer, so special low-power dryer features (such as wrinkle guard) may
interfere with the operation of either your Tesla EV charger or your SPS unit, and therefore is not supported
or recommended.
This product is designed to operate at a maximum continuous electric vehicle charging rate of 24 amps on a
standard household 30-amp circuit, according to the National Electrical Code (NEC). Exceeding this rate can
lead to damage or risk of fire.
Set your EV charger or EV to a maximum charge rate of 24 amps.
1-year limited warranty
Splitvolt, Inc warrants that this product shall be free from defects in material, workmanship and assembly,
under normal use, in accordance with the specifications and warnings, for a period of one year from the
date of purchase. This warranty does not cover damages as a result of an accident; resulting from the use or
4
Splitvolt, Inc.

misuse of parts not manufactured or sold by Splitvolt, Inc; or resulting from modification of the Splitvolt
Splitter Switch.
These warranties extend only to the original purchaser of the product and are not transferable. To exercise
your rights under this warranty, you must provide proof of purchase in the form of an original sales receipt
that shows the product name and the date of purchase. These warranties apply only to natural purchasers
of Splitvolt Splitter Switch for personal, family, or household use, not to commercial, institutional, or
industrial purchasers. These warranties are valid only in the United States. In no event shall Splitvolt, Inc. be
liable for any direct, indirect, incidental, special, consequential, or multiple damages arising out of the use of
the Splitvolt Splitter Switch devices.
Troubleshooting
The following table identifies steps for troubleshooting the operation of the device. If you
are experiencing difficulty, please review the table below, check our website
(www.splitvolt.com), and then contact us if you are still unable to resolve.
Issue
Resolution
Splitter switch’s LED and LCD
are not turning on
Is power available?
1. Check that the wall socket has power
2. Check that the wall plug is plugged in fully
3. Check that the built-in breaker is in ON position
The wall socket seems to be
upside down
There is no universal orientation for NEMA plugs, so yours could be
upside down. Just plug it in anyway.
The pins on the cable do not
match my wall socket
It is possible that the wrong model was ordered. Please email
[e-mail] or call [phone] for assistance.
Not getting power from either
one of the sockets
Double-check all plugs are pushed in completely
Splitter switch is not turning off
the EV Socket when dryer is
running
1. Confirm what type of dryer you have. If you have a gas line
running into the dryer, you have a gas dryer (even if it is plugged into
a NEMA 10-30 or NEMA 14-30 plug). Please email
[e-mail] or call [phone] for assistance.
2. Turn off energy saver mode on your dryer. Does the splitter switch
turn off the EV socket? If so, you have a rare high-efficiency dryer
that downshifts to 120V during part of the cycle. Please email
[e-mail] or call [phone] for assistance.
Hear a buzzing sound coming
from splitter switch
Turn off the breaker and turn it back on. The contacts may have
become misaligned. Powering on/off will help it self-realign.
My Tesla has an alert saying
“Unable to AC charge – Unplug
and retry”
Simply unplug/replug-in the charger handle to the vehicle to continue
charging. NOTE: Some special high-efficiency sensor dryer settings
may cause multiple switching, triggering the Tesla charger power
protection fault to pause charging. For optimal convenience and
charging performance, it is recommended that Tesla users do not use
special low-power settings on their dryer while charging.
Need more help?
Please visit www.splitvolt.com,email [e-mail], or call [phone] for
assistance.
5
