S+S Regeltechnik HYGRASGARD AFTM-LQ-CO2-Modbus User manual

14
GHYGRASGARD®AFTM- ⁄ KFTM - LQ - CO2- Modbus
Rev. 2018 - V22 GB
The maintenance-free microprocessor-controlled on-wall or duct sensor with Modbus connection with/without optional display is an all-in-one device used
for detecting all relevant measured values, such as humidity, temperature, CO2 concentration and air quality (VOC), thus enabling effective monitoring
and control of the entire room climate. It measures CO2in the range from 0...5000 ppm, VOC in one of three selectable sensitivity levels LOW / MEDIUM
/ HIGH, temperatures in the range from –35...+80 °C as well as relative air humidity of 0...100 % r.H. Relative humidity (% r.H.) is the quotient of water
vapour partial pressure divided by the saturation vapour pressure at the respective gas temperature. A digital, long-term stable sensor as a measuring
element for relative humidity and temperature guarantees exact measurement results. The CO2content of the air is measured using an optical NDIR
sensor (non-dispersive infra-red technology). The detection range of the sensors is calibrated for standard applications such as monitoring residential
rooms and conference rooms. Room ventilation on an as-needed basis, improved well-being and customer benefit, increased comfort as well as reduced
operating costs through energy conservation are just some of the benefits of employing the AERASGARD®CO2. The above explanations demonstrate that
there are applications for CO2measurements, for VOC measurements, but from our perspective, above all, for a
combination of both measurands. The
crucial factor in this respect is that both of these measurands are not convertible into each other and derivations
to or from one another cannot be made.
An NDIR - CO2measuring instrument measures selectively and cannot detect any VOCs; a VOC mixed gas sensor cannot detect CO2molecules.
TECHNICAL DATA
Power supply: 24 V AC ⁄ DC (± 10 %)
Power consumption: < 4.8 W ⁄ 24 V DC typical; < 6.8 VA ⁄ 24V AC typical; peak current 200 mA
Data points: temperature, relative humidity, air quality (VOC), carbon dioxide (CO2), atmospheric pressure
HUMIDITY
Sensors: digital humidity sensor with integrated temperature sensor, low hysteresis, high long-term stability
Sensor protection:
plastic sinter filter, Ø 16 mm, L = 35 mm, exchangeable (optional metal sinter filter, Ø 16 mm, L = 32 mm)
Measuring range, humidity: 0...100 % r. H.
Operating range, humidity: 0...95 % r. H. (non-precipitating air)
Deviation humidity: typically
± 2.0 % (20...80 % r. H.) at +25 °C, otherwise ± 3.0 %
TEMPERATURE
Measuring range, temperature: –35...+80 °C
Operating range, temperature: –10...+60°C
Deviation, temperature: ± 0.2 K at +25 °C
AIR QUALITY (VOC)
VOC sensor: VOC sensor (metal oxide) with automatic calibration (VOC = volatile organic compounds)
VOC measuring range: 0...100 % air quality; with reference to calibration gas; multi-range switching VOC sensitivity low, medium, high
VOC measuring accuracy: ± 20 % final value (with reference to the calibration gas)
Service life: > 60 months (under normal load conditions)
CARBON DIOXIDE (CO2)
CO2 sensor: Optical NDIR sensor (non-dispersive infra-red technology) incl. atmospheric air pressure compensation (up to 1100 mbar)
with automatic and manual calibration
CO2measuring range: 0...5000 ppm
CO2measuring accuracy: ± 30 ppm ± 3 % of measured value
CO2
temperature dependence: ± 5 ppm ⁄ °C or ± 0.5 % of measured value ⁄ °C (whichever is the greater)
Pressure dependence: ± 0.13 % ⁄ mm Hg
Long-term stability: < 2 % in 15 years
Gas exchange: by diffusion
Bus parameters:
In the absence of current delivery (under currentless conditions) can be configured and addressed via DIP switch!
Bus interface: RS 485, galvanically isolated, bus termination can be activated via DIP switch. Up to 32 devices possible in one segment.
In case of a greater number of devices, RS 485 transceivers must be used.
Bus protocol: Modbus (RTU-Mode), address range 0...
247 selectable
Baud rate: 9600, 19200, 38400 Baud
Status indicator: Green LED = Telegram valid / red LED = Telegram error
Signal filtering: 4 s / 32 s
Ambient temperature: –10...+60 °C
Response time: < 2 minutes
Electrical connection: 0.2 - 1.5 mm2, via push-in terminal
Enclosure: plastic, UV-stabilised, material polyamide, 30 % glass-globe reinforced,with quick-locking screws (slotted ⁄
Phillips head combination), colour traffic white (similar to RAL 9016),,enclosure cover for display is transparent!
Enclosure dimensions: 126 x 90 x 50 mm (Tyr 2)
Cable gland: 2x M 16x 1.5; including strain relief, exchangeable
Protective tube:
KCO2 / KLQ - CO2 / KFTM - CO2 / KFTM - LQ - CO2- Modbus (Patent No. DE 10 2014 010 719.1):
PLEUROFORM
TM, material: polyamide (PA6), with torsion protection, vmax = 30 m/s (air), Ø 20 mm,
without filter: NL = 202.5 mm, with plastic sinter filter: NL = 235 mm (optional with metal sinter filter: NL = 227 mm)
AFTM - CO2 / AFTM - LQ - CO2- Modbus:
in stainless steel, Ø 16 mm, with plastic sinter filter: NL = 55 mm (optional with metal sinter filter: NL = 47 mm)
Process connection: channel sensors using a flange (included in the scope of delivery), on-wall sensors using screws
Protection class: III (according to EN 60 730)
Protection type: IP 65 (according to EN 60 529) enclosure only! (PLEUROFORM IP30)
Standards: CE-conformity, electromagnetic compatibility according to EN 61 326, EMC directive 2014 ⁄ 30 ⁄ EU
Optional:
three-line display with illumination, cutout approx. 70 x 40 mm (W x H),
to display the actual humidity, actual temperature, air quality and / or the actual CO2content

15
GHYGRASGARD®AFTM- ⁄ KFTM - LQ - CO2- Modbus
Rev. 2018 - V22 GB
Zero point calibration
The sensors are pre-set and calibrated at the factory.
Each measuring channel has a separate offset potentiometer
for subsequent adjustment of the measurement.
The adjusting range is ± 10% of the measuring range.
The Modbus interface can be used to program an
alternative output
variable
instead of the standard display.
In this case, the first line indicates the value while the second line
indicates the corresponding unit
statically .
The index in the third line indicates the display type:
Index 1 = CO2content in ppm
Index 2 = air quality (VOC) in %
Index 3 = temperature in °C
Index 4 = relative humidity in % r.H.
Index 5 = atmospheric pressure in hPa
By default, the display indicates the following measurements with the
corresponding units
cyclically and consecutively:
CO2 content in ppm, air quality (VOC) in %,
temperature in °C, relative humidity in % r.H.
Backlighting is provided for improved legibility.
The Modbus interface allows the display to be
individually configured,
both in the 7 segment range and in the dot-matrix range.
Display
standard
Display
alternative output variables
Display - individually
programmable
Schematic diagram
offset
°C
r.H.
VOCCO²
mode address
12345678
ON DIPA
123456
ON DIPB
zero
CO²
VOC
1
2
3
4
1
2
3
4
B
A
GND
U+
B
A
GND
U+
Plug for
display
DIP A: Bus address
DIP B: Bus parameters
(Baud rate, parity ...)
Telegram indicator
Reception (LED green)
Error (LED red)
LED (internal status)
Offset correction
Reset button
offset
°C
r.H.
VOCCO²
mode address
12345678
ON DIPA
123456
ON DIPB
zero
CO²
VOC
1
2
3
4
1
2
3
4
B
A
GND
U+
B
A
GND
U+
Plug for
display
DIP A: Bus address
DIP B: Bus parameters
(Baud rate, parity ...)
Telegram indicator
Reception (LED green)
Error (LED red)
LED (internal status)
Offset correction
Reset button

16
GAERASGARD®AFTM - LQ - CO2- Modbus
Rev. 2018 - V22 GB
WS-03
Weather and sun
protection hood
(optional)
ACO2-Modbus
ALQ - CO2-Modbus
without filter
(standard)
AFTM - CO2- Modbus
AFTM - LQ - CO2- Modbus
with metal sinter filter
(optional)
AFTM - CO2- Modbus
AFTM - LQ - CO2- Modbus
with plastic sinter filter
(standard)
AERASGARD
®
ACO2- Modbus On-wall sensor for CO2content, Deluxe
AERASGARD
®
ALQ - CO2- Modbus On-wall sensor for CO2content and air quality (VOC), Deluxe
AERASGARD
®
AFTM - CO2- Modbus Multifunctional on-wall sensor
for humidity, temperature and CO2content, Deluxe
AERASGARD
®
AFTM - LQ - CO2- Modbus Multifunctional on-wall sensor
for humidity, temperature, CO2content and air quality (VOC), Deluxe
Type ⁄ WG02 Measuring Range
Humidity Temperature CO
2
Display
VOC
Item No.
ACO2-Modbus
ACO2 MODBUS – – 5000 ppm –1501-7110-6001-200
ACO2 MODBUS DISPLAY – – 5000 ppm – ■1501-7110-6071-200
ALQ - CO2-Modbus
ALQ-CO2 MODBUS – – 5000 ppm 0...100 % 1501-7111-6001-200
ALQ-CO2 MODBUS DISPLAY – – 5000 ppm 0...100 % ■1501-7111-6071-200
AFTM - CO2-Modbus
AFTM-CO2 MODBUS 0...100 % r.H. –35...+80 °C 5000 ppm –1501-7116-6001-200
AFTM-CO2 MODBUS DISPLAY 0...100 % r.H. –35...+80 °C 5000 ppm – ■1501-7116-6071-200
AFTM - LQ - CO2-Modbus
AFTM-LQ-CO2 MODBUS 0...100 % r.H. –35...+80 °C 5000 ppm 0...100 % 1501-7118-6001-200
AFTM-LQ-CO2 MODBUS DISPLAY 0...100 % r.H. –35...+80 °C 5000 ppm 0...100 % ■1501-7118-6071-200
Note: This unit
must not be used as safety-relevant device!
Accessories
SF-M Metal
sinter filter, Ø 16 mm, L = 32 mm, exchangeable stainless steel V4A (1.440 4) 7000-0050-2200-100
WS-03 Weather and sun protection hood , 200 x 180 x 150 mm, stainless steel 7100-0040-6000-000

17
GAERASGARD®KFTM - LQ - CO2- Modbus
Rev. 2018 - V22 GB
MFT - 20 - K
Mounting flange,
plastic
KCO2-Modbus
KLQ - CO2-Modbus
without filter
(standard)
KFTM - CO2- Modbus
KFTM - LQ - CO2- Modbus
with metal sinter filter
(optional)
KFTM - CO2- Modbus
KFTM - LQ - CO2- Modbus
with plastic sinter filter
(standard)
AERASGARD
®
KCO2- Modbus Duct sensor for CO2content, Deluxe
AERASGARD
®
KLQ - CO2- Modbus Duct sensor for air quality (VOC) and CO2content, Deluxe
AERASGARD
®
KFTM - CO2- Modbus Multifunctional duct sensor
for humidity, temperature and CO2content, Deluxe
AERASGARD
®
KFTM - LQ - CO2- Modbus Multifunctional duct sensor
for humidity, temperature, air quality (VOC) and CO2content, Deluxe
Type ⁄ WG02 Measuring Range
Humidity Temperature CO
2
Display
VOC
Item No.
KCO2-Modbus
KCO2 MODBUS – – 5000 ppm –1501-8110-6001-200
KCO2 MODBUS DISPLAY – – 5000 ppm – ■1501-8110-6071-200
KLQ - CO2-Modbus
KLQ-CO2 MODBUS – – 5000 ppm 0...100 % 1501-8111-6001-200
KLQ-CO2 MODBUS DISPLAY – – 5000 ppm 0...100 % ■1501-8111-6071-200
KFTM - CO2-Modbus
KFTM-CO2 MODBUS 0...100 % r.H. –35...+80 °C 5000 ppm –1501-8116-6001-200
KFTM-CO2 MODBUS DISPLAY 0...100 % r.H. –35...+80 °C 5000 ppm – ■1501-8116-6071-200
KFTM - LQ - CO2-Modbus
KFTM-LQ-CO2 MODBUS 0...100 % r.H. –35...+80 °C 5000 ppm 0...100 % 1501-8118-6001-200
KFTM-LQ-CO2 MODBUS DISPLAY 0...100 % r.H. –35...+80 °C 5000 ppm 0...100 % ■1501-8118-6071-200
Note: This unit
must not be used as safety-relevant device!
Accessories
SF-M Metal
sinter filter, Ø 16 mm, L = 32 mm, exchangeable, stainless steel V4A (1.440 4) 7000-0050-2200-100
MFT-20-K Mounting flange, plastic (included in the scope of delivery) 7000-0031-0000-000

18
BUS ADDRESS
Bus address
(binary coded, value selectable from 1 to 247)
MODBUS
DIP switch [A]
DIP 1 DIP 2 DIP 3 DIP 4 DIP 5 DIP 6 DIP 7 DIP 8
1 2 3 4 5 6 7 8
ON DIP A
128 64 32 16 8421
O N O N
OFF OFF OFF OFF OFF
O N
Example shows 128 +64 +1 = 193 as Modbus address.
The device address in the range of 1 to 247 is set at DIP switch [A].
For switch positions 1 to 8 see the table on the back!
Address 0 is reserved for broadcast messages.
Addresses greater than 247 must not be assigned and are ignored by the device.
The DIP switches are binary-coded with the following values:
DIP 1 =
128 ............ DIP 1 = ON
DIP 2 =
64 ............ DIP 2 = ON
DIP 3 = 32............ DIP 3 = OFF
DIP 4 = 16............ DIP 4 = OFF
DIP 5 = 8............ DIP 5 = OFF
DIP 6 = 4............ DIP 6 = OFF
DIP 7 = 2............ DIP 7 = OFF
DIP 8 =
1 ............ DIP 8 = ON The switch positions shown here results in the Modbus address 128 + 64 + 1 = 193
BUS PARAMETER S
Baud rate
(selectable)
DIP
1
DIP
2
MODBUS
DIP switch [B]
9600 baud O N
OFF
1 2 3 4 5 6
ON DIP B
19200 baud O N O N
38400 baud OFF O N
Reserved OFF OFF
Parity
(selectable)
DIP
3
Parity check
(on / off)
DIP
4
8N1 mode
(on / off)
DIP
5
Bus termination
(on/off)
DIP
6
EVEN
(numbered)
O N
Active
(1 stop bit)
O N Active O N Active O N
ODD
(numbered)OFF Inactive (no parity) (2 stop bits) OFF Inactive (default) OFF Inactive OFF
The baud rate (speed of transmission) is set at DIP switches 1 and 2 of DIP switch block [B].
Selectable are
9600 baud, 19200 baud , or 38400 baud – see table!
Parity is set at DIP switch 3 of DIP switch block [B].
Selectable are
EVEN or ODD – see table!
Parity check is activated via DIP switch 4 of DIP switch block [B].
Selectable are
active (1 stop bit) , or i nactive (2 stop bits) , i.e. no parity check – see table!
The
8N1 mode is activated via DIP switch 5 of DIP switch block [B].
The functionality of DIP switch 3 (parity) and DIP switch 4 (parity check) of DIP switch block [B] is therefore deactivated.
Selectable are 8N1
active or inactive (default) – see table !.
Bus termination is activated via DIP switch 6 of DIP switch block [B].
Selectable are
active (bus termination resistance of 120 Ohm), or inactive (no bus termination) – see table!
When bus parameters and bus address are changed at devices with
display , the respective settings are shown on the display for
approx. 30 seconds.
COMMUNICATION INDICATOR
Communication is indicated via two LEDs. Error-free received telegrams are signalized by the green LED lighting up, regardless of
the device address. Faulty telegrams or triggered Modbus exception telegrams are depicted by the red LED lighting up.
DIAGNOSTICS
An error diagnostic function is integrated
GHYGRASGARD®AFTM- ⁄ KFTM - LQ - CO2- Modbus
| Configuration Rev. 2017 - V14 GB intro

19
GHYGRASGARD®AFTM- ⁄ KFTM - LQ - CO2- Modbus
| Configuration Rev. 2017 - V14 GB intro
READOUT IN THE DISPLAY
By default, the display indicates the following measurements with the corresponding units cyclically and consecutively:
CO2 content in ppm, air quality (VOC) in %, temperature in °C, relative humidity in % r.H.
The Modbus interface can be used to program an alternative output variable instead of the standard display:
CO2 content in ppm, air quality (VOC) in %, temperature in °C, relative humidity in % r.H., atmospheric pressure in hPa
In this case, the first line indicates the value while the second line indicates the corresponding unit
statically .
The index in the third line indicates the display type, e.g. atmospheric pressure (see the table "Function 06 Write Single
Register").
Reading: 1013
Unit:
hPa
Index: 5
The Modbus interface allows the display screen to be individually configured, both in the 7 segment range and in
the dot-matrix range. This means that messages such as those from the PLC can be displayed.
For the
individual display , the register 4x0001 (physical value displayed) must contain the value 10.
The registers 4x0002 to 4x0019 contain information about the characters and segments to be displayed.
The dot-matrix area is also programmable in the default setting (register 4x0001 contains the value 0).
In this case, the current measured value is automatically displayed in the 7-segment area.
The two left-aligned positions are represented by the register 4x0003 (range -9...99). The value 0 switches
off the display of both positions. The display is only active if the register 4x0002 has positive values.
Composition of Segment Pattern (Register 4x0005)
Bit 0...... Dot A
Bit 1...... Dot B
Bit 2...... Dot C
Bit 3...... Dot D
Bit 4...... Dot DP1
Bit 5...... - -
Bit 6...... Dot E
Bit 7...... Dot DP2
Bit 8...... - -
Bit 9...... - -
Bit 10 .... - -
Bit 11 .... - -
Bit 12 .... - -
Bit 13 .... - -
Bit 14 .... - -
Bit 15 .... - -
Dot Matrix A H B I C J D K E L F M G N
Dot A Dot B Dot C Dot D Dot EDot DP1 Dot DP2

20
ASCII Code Table for Dot Matrix Display Area
ASCII Sign
32 Blank
33 !
34 “
35 #
36 $
37 %
38 &
40 (
41 )
42 *
43 +
44 ,
45 -
46 .
47 /
48 0
49 1
50 2
51 3
52 4
ASCII Sign
53 5
54 6
55 7
56 8
57 9
58 :
59 ;
60 <
61 =
62 >
63 ?
64 @
65 A
66 B
67 C
68 D
69 E
70 F
71 G
72 H
ASCII Sign
73 I
74 J
75 K
76 L
77 M
78 N
79 O
80 P
81 Q
82 R
83 S
84 T
85 U
86 V
87 W
88 X
89 Y
90 Z
91 [
93 ]
ASCII Sign
94 ^
95 _
96 \
97 a
98 b
99 c
100 d
101 e
102 f
103 g
104 h
105 i
106 j
107 k
108 l
109 m
110 n
111 o
112 p
113 q
ASCII Sign
114 r
115 s
116 t
117 u
118 v
119 w
120 x
121 y
122 z
123 {
124 |
125 }
129 ü
132 ä
142 Ä
148 ö
153 Ö
154 Ü
223 °
ASCII characters or control characters are displayed as spaces.
GHYGRASGARD®AFTM- ⁄ KFTM - LQ - CO2- Modbus
| Configuration Rev. 2017 - V14 GB intro

21
GHYGRASGARD®AFTM- ⁄ KFTM - LQ - CO2- Modbus
| Telegrams
TELEGRAMS
Function 04 Read Input Register
Register Parameter Data Type Value Range
3x0001 CO2 Sampling 4 s Signed 16 bit 350...5000 350...5000 ppm
3x0002 CO2 Filtering 32 s Signed 16 bit 350...5000 350...5000 ppm
3x0003 VOC Sampling 4 s Signed 16 bit 0...1000 0.0...100.0 % VOC
3x0004 VOC Filtering 32 s Signed 16 bit 0...1000 0.0...100.0 % VOC
3x0005 Temperature Sampling 4 s Signed 16 bit –350…800 –35.0...+80.0 °C
3x0006 Temperature Filtering 32 s Signed 16 bit –350…800 –35.0...+80.0 °C
3x0007 Relative humidity Sampling 4 s Signed 16 bit 0...1000 0.0...100.0 % r.H.
3x0008 Relative humidity Filtering 32 s Signed 16 bit 0...1000 0.0...100.0 % r.H.
3x0009 Atmospheric pressure Sampling 4 s Signed 16 bit 700…1100 700...1110 hPa
3x0010 Atmospheric pressure Filtering 32 s Signed 16 bit 700…1100 700...1110 hPa
Function 06 Write Single Register & Function 16 Write Multiple Register
Register Parameter (display) Data Type Value Range
4x0001 Physical parameter displayed Index on display Unsigned 8 bit 0…10 0…10
Standard display (cyclic):
VOC in %,
CO2 in ppm,
temperature in °C,
relative humidity in % r.H.
– 0 Default
setting
alternative display (static):
CO2 in ppm 1 1
VOC in % 2 2
Temperature in °C 3 3
Relative humidity in % r.H. 4 4
Atmospheric pressure in hPa 5 5
Freely configurable display –10
4x0002 7-Segment Value Signed 16 bit -999…9999 -999…9999
4x0003 7-Segment Value Signed 8 bit -9…99 -9…99
4x0004 –
4x0005 Segment Pattern Unsigned 16 bit See Binary Pattern
4x0006 Dot Matrix Character A Unsigned 8 bit 0…255 ASCII character
4x0007 Dot Matrix Character B Unsigned 8 bit 0…255 ASCII character
4x0008 Dot Matrix Character C Unsigned 8 bit 0…255 ASCII character
4x0009 Dot Matrix Character D Unsigned 8 bit 0…255 ASCII character
4x0010 Dot Matrix Character E Unsigned 8 bit 0…255 ASCII character
4x0011 Dot Matrix Character F Unsigned 8 bit 0…255 ASCII character
4x0012 Dot Matrix Character G Unsigned 8 bit 0…255 ASCII character
4x0013 Dot Matrix Character H Unsigned 8 bit 0…255 ASCII character
4x0014 Dot Matrix Character I Unsigned 8 bit 0…255 ASCII character
4x0015 Dot Matrix Character J Unsigned 8 bit 0…255 ASCII character
4x0016 Dot Matrix Character K Unsigned 8 bit 0…255 ASCII character
4x0017 Dot Matrix Character L Unsigned 8 bit 0…255 ASCII character
4x0018 Dot Matrix Character M Unsigned 8 bit 0…255 ASCII character
4x0019 Dot Matrix Character N Unsigned 8 bit 0…255 ASCII character

22
GHYGRASGARD®AFTM- ⁄ KFTM - LQ - CO2- Modbus
| Telegrams
Function 05 Write Single Coil
Register Parameter Data Type Value Range
0x0001 Reset (Auto zero) CO2 Bit 0 0 / 1 OFF - ON
0x0002 Reset (Auto zero) VOC Bit 1 0 / 1 OFF - ON
0x0003 Automatic calibration (Automatic) CO2 Bit 2 0 / 1 OFF - ON
0x0004 Automatic calibration (Automatic) VOC Bit 3 0 / 1 OFF - ON
0x0005 VOC sensibility "low" Bit 4 0 / 1 OFF - ON
0x0006 VOC sensibility "medium" Bit 5 0 / 1 OFF - ON
0x0007 VOC sensibility "high" Bit 6 0 / 1 OFF - ON
Function 08 Diagnostics
The following sub function codes are supported
Sub Function
Code
Parameter Data Type Answer
00 Echo of transmission data
(Loopback)
Echo data
01 Restart Modbus
(Reset listen-only mode)
Echo telegram
04 Activation listen-only mode No answer
10 Delete counter Echo telegram
11 Counter bus telegrams Unsigned 16 bit All valid bus telegrams
12 Counter communication errors
(Parity, CRC, frame errors, etc.)
Unsigned 16 bit Faulty bus telegrams
13 Counter exception telegrams Unsigned 16 bit Error counter
14 Counter slave telegrams Unsigned 16 bit Slave telegrams
15 Counter telegrams without answer Unsigned 16 bit Broadcast messages (address 0)
Function 17 Report Slave ID
Composition of answer telegram
Byte No. Parameter Data Type Answer
00 Number of bytes Unsigned 8 bit 6
01 Slave ID (device type) Unsigned 8 bit 14 =
AERSGARD
®
MODBUS
02 Slave ID (device class) Unsigned 8 bit 60 = AERASGARD
®/
AERASREG
®
03 Status Unsigned 8 bit 255 = RUN, 0 = STOP
04 Version number (release) Unsigned 8 bit 1…9
05 Version number (version) Unsigned 8 bit 1…9 9
06 Version number (index) Unsigned 8 bit 1

23
GHYGRASGARD®AFTM- ⁄ KFTM - LQ - CO2- Modbus
| Installation Rev. 2015 - 1.0 GB intro
General layout of bus structure
Bus topology with terminating and bias resistors
Terminating resistor may only be installed at the ends of the bus line.
In networks with repeaters not more than two line terminations are allowed.
Line termination at the device can be activated via DIP switch 6.
The bias resistors for bus level definition in the resting state are usually activated at the Modbus master / repeater.
The maximum number of subscribers per Modbus segment is 32 devices.
When the number of subscribers is greater, the bus must be subdivided into several segments separated by repeaters.
The subscriber address can be set from 1 to 247.
For the bus line, a twisted-pair cable data line / power supply line and copper mesh wire shield must be used.
Therefore, the line capacitance should be less than 100 pF / m (e.g. Profibus cable).
Slave n
MODBUS
RTU-Master
RS-485
Line
termination
Line
termination
Active
branch
Passive
branch
Stub line
Trunk line
Stub line:
shorter 20m
Multiple branch n:
shorter 40m/n
General layout of bus structure
Slave 1 Slave 2
LA LA
Bus topology with terminating and bias resistors
A (D1) D+
5 V
Common
(GND)
B (D0) D–
Line
termination
Line
termination
Pull-down /
bias resistor
Pull-up /
bias resistor
MODBUS
RTU-Master
Slave 1 Slave 2

24
GImportant notes
Our “General Terms and Conditions for Business“ together with the “General Conditions for the Supply of Products and Services of the Electrical and
Electronics Industry“ (ZVEI conditions) including supplementary clause “Extended Retention of Title“ apply as the exclusive terms and conditions.
In addition, the following points are to be observed:
– Devices must only be connected to safety extra-low voltage and under dead-voltage condition. To avoid damages and errors at the device
(e.g. by voltage induction) shielded cables are to be used, laying parallel with current-carrying lines is to be avoided, and EMC directives are to
be observed.
– This device shall only be used for its intended purpose. Respective safety regulations issued by the VDE, the states, their control authorities,
the TÜV and the local energy supply company must be observed. The purchaser has to adhere to the building and safety regulations and has to
prevent perils of any kind.
– No warranties or liabilities will be assumed for defects and damages arising from improper use of this device.
– Consequential damages caused by a fault in this device are excluded from warranty or liability.
– These devices must be installed by authorised specialists only.
–
The technical data and connecting conditions of the mounting and operating instructions delivered together with the device are exclusively valid.
Deviations from the catalogue representation are not explicitly mentioned and are possible in terms of technical progress and continuous
improvement of our products.
– In case of any modifications made by the user, all warranty claims are forfeited.
– This device must not be installed close to heat sources (e.g. radiators) or be exposed to their heat flow. Direct sun irradiation or heat
irradiation by similar sources (powerful lamps, halogen spotlights) must absolutely be avoided.
– Operating this device close to other devices that do not comply with EMC directives may influence functionality.
– This device must not be used for monitoring applications, which serve the purpose of protecting persons against hazards or injury,
or as an EMERGENCY STOP switch for systems or machinery, or for any other similar safety-relevant purposes.
– Dimensions of enclosures or enclosure accessories may show slight tolerances on the specifications provided in these instructions.
– Modifications of these records are not permitted.
– In case of a complaint, only complete devices returned in original packing will be accepted.
These instructions must be read before installation and putting in operation and all notes provided therein are to be regarded!
Devices are to be connected under dead-voltage condition. Devices
must only be connected to safety extra-low voltage. Consequential
damages caused by a fault in this device are excluded from war-
ranty or liability. Installation of these devices must only be realized
by authorized qualified personnel. The technical data and connect-
ing conditions shown on the device labels and in the mounting
and operating instructions delivered together with the device are
exclusively valid. Deviations from the catalogue representation are
not explicitly mentioned and are possible in terms of technical pro-
gress and continuous improvement of our products. In case of any
modifications made by the user, all warranty claims are forfeited.
Operating this device close to other devices that do not comply with
EMC directives may influence functionality. This device must not be
used for monitoring applications, which solely serve the purpose of
protecting persons against hazards or injury, or as an EMERGENCY
STOP switch for systems or machinery, or for any other similar
safety-relevant purposes.
Dimensions of enclosures or enclosure accessories may show slight
tolerances on the specifications provided in these instructions.
Modifications of these records are not permitted.
In case of a complaint, only complete devices returned in original
packing will be accepted.
Notes regarding mechanical mounting and attachment:
Mounting shall take place while observing all relevant regulations
and standards applicable for the place of measurement
(e.g. such as welding instructions, etc.). Particularly the following
shall be regarded:
– VDE ⁄ VDI directive technical temperature measurements,
measurement set- up for temperature measurements.
– The EMC directives must be adhered to.
– It is imperative to avoid parallel laying of current-carrying lines.
– We recommend to use shielded cables with
the shielding being attached at one side to the DDC ⁄ PLC.
Before mounting, make sure that the existing thermometer‘s techni-
cal parameters comply with the actual conditions at the place of
utilization, in particular in respect of:
– Measuring range
– Permissible maximum pressure, flow velocity
– Installation length, tube dimensions
– Oscillations, vibrations, shocks are to be avoided (< 0.5 g)
Attention! In any case, please observe the mechanical and thermal
load limits of protective tubes according to DIN 43763 respectively
according to specific S+S standards!
GMounting and Installation
