Sportline Solo 925 Operating and maintenance manual

SOLO 925
HEART RATE + CALORIE MONITOR
SOLO 925
when printing out or making PDF – PRINT AT 145%
fili l4545
SP5139IS01RODRA.indd 1SP5139IS01RODRA.indd 1 5/18/10 4:26 PM5/18/10 4:26 PM

TABLE OF CONTENTS
INTRODUCTION 1
HOW TO USE THIS MANUAL 1
ACTIVATING THE WATCH FROM POWER DOWN MODE 1
WARNINGS & CAUTIONS 2
CARE & MAINTENANCE 3
CUSTOMER SUPPORT 3
WATCH FUNCTIONS 4
KEYS AND THEIR FUNCTIONS 5-6
ACQUIRING HEART RATE 7
POWER DOWN MODE 8
VIEWING THE BACKLIGHT 8
HEART RATE LOCK 8
MAIN OPERATING MODES 9
when printing out or making PDF – PRINT AT 145%
SP5139IS01RODRA.indd 2SP5139IS01RODRA.indd 2 5/18/10 4:26 PM5/18/10 4:26 PM

SOLO 925 Heart Rate + Calorie Monitor
TABLE OF CONTENTS
SETTING & OPERATING THE WATCH
SETTING TIME & DATE 10
SETTING TARGET HEART RATE ZONE 11
ACTIVATING & VIEWING TARGET HEART RATE ZONE 12
SETTING DAILY ALARM 13
OPERATING THE CHRONOGRAPH 14
SETTING & OPERATING THE COUNTDOWN TIMER 15-16
OPERATING CALORIES/EXERCISE TIMER 17
SETTING & VIEWING DUAL TIME ZONE 18
RANGES & SPECIFICATIONS 19
REPLACING THE WATCH BATTERY 20
BATTERY SAFETY INFORMATION 21
TROUBLE SHOOTING 22
WARRANTY 23
final size 4 x 10.89
SP5139IS01RODRA.indd 3SP5139IS01RODRA.indd 3 5/18/10 4:26 PM5/18/10 4:26 PM

1
Congratulations on your purchase of a Sportline Personal Fitness Monitor. Please keep in mind; your
watch is a sensitive technical instrument. With proper care and maintenance, it will last for many
years. However, improper care and handling can cause the various sensors to be damaged and to stop
functioning.
HOW TO USE THIS MANUAL
Sportline Personal Fitness Monitors have many unique features and functions. Please read all sections
of this manual carefully and become fully familiar with the operation of the watch before using it in
the field.
Proper setup and operation will greatly enhance the watches usefulness and your enjoyment.
The manual is divided into sections outlining each of the major functions of the watch. A drawing of
the watch screen that represents the starting point or other important screens for each operational
process are shown adjacent to the instructions for the process; important keys are shown indicating
PRESS & HOLD and PRESS.
The steps for the programming or operation are adjacent to the screen illustration. Key points and
important information are shown in highlighted blocks.
ACTIVATING THE WATCH FROM POWER DOWN MODE
PLEASE NOTE: Your watch was originally shipped in Power Down Mode to conserve battery life.
To deactivate Power Down mode: PRESS & HOLD ANY KEY for 5 seconds (see page 8 for more
information on Power Down mode).
INTRODUCTION
when printing out or making PDF – PRINT AT 145%
SP5139IS01RODRA.indd 1SP5139IS01RODRA.indd 1 5/18/10 4:26 PM5/18/10 4:26 PM

2
SOLO 925 Heart Rate + Calorie Monitor
WARNING: Before starting any exercise program or performing any vigorous physical activity, we
strongly suggest you visit your doctor for a complete physical and to discuss your plans.
CAUTION: Your watch is designed to be water resistant to a static pressure of 5 ATM and can be worn
while showering and light swimming. However, we recommend that extensive use of the unit in the
water be avoided whenever possible. Care should be taken not to press any keys while the unit is
submerged as this can force moisture past the key seals and damage the unit.
CAUTION: Avoid exposing your watch to extreme conditions for a prolonged period of time.
CAUTION: Avoid rough usage or severe impacts to your watch.
DO NOT use hand cream as it will insulate the signal between the skin and sensor contacts.
DO NOT use the fingertips where the skin is dry and thick. For those with extremely dry skin, moisten
fingers and wrist with tap water or a conductive gel.
CLEAN the Back Cover occasionally by using a damp cloth. Then wipe dry to remove any residual
grease.
CLEAN your skin and fingers with soap and water for a better signal transmission.
AVOID doing awkward motions during measurement. It may create inaccurate heart rate readings.
WARNINGS & CAUTIONS
final size 4 x 10.89
SP5139IS01RODRA.indd 2SP5139IS01RODRA.indd 2 5/18/10 4:26 PM5/18/10 4:26 PM

3
CARE & MAINTENANCE
• NEVER attempt to disassemble or service your unit.
•DO NOT expose the unit to extreme heat, shocks, magnetic fields, electrical noise, strong vibration
or long-term exposure to direct sunlight.
• DO NOT drop or step on the watch.
• TO CLEAN THE UNIT: wipe with a lightly moistened cloth. Apply mild soap to the area if there are
stubborn stains or marks. Do not expose the unit to strong chemicals such as gasoline, cleaning
solvents, acetone, alcohol or insect repellents, as they may damage the unit’s seal, case and/or
finish.
• STORE the unit in a dry place when you are not using it.
CUSTOMER SUPPORT
If you experience any problems with this product or have questions, please first contact our Customer
Service Team at 1-866-694-4575. We are ready to help.
when printing out or making PDF – PRINT AT 145%
SP5139IS01RODRA.indd 3SP5139IS01RODRA.indd 3 5/18/10 4:26 PM5/18/10 4:26 PM

4
SOLO 925 Heart Rate + Calorie Monitor
WATCH FUNCTIONS
TIME
• Time/Day/Date/Month
• Dual Time Zone
• 12-/24-hour formats
• Daily Alarm
HEART RATE
• ECG Accurate Heart Rate
• Automatic or User-Programmable Target
Heart Rate Zone
CALORIES
• Calorie Consumption
• 100-hr Exercise Timer
CHRONOGRAPH
• 100-hr
• 1/100 second resolution
COUNTDOWN TIMER
• 100-hr
• 1-second resolution
OTHER
• EL Backlight System
• Water Resistant 50m (165ft)
final size 4 x 10.89
SP5139IS01RODRA.indd 4SP5139IS01RODRA.indd 4 5/18/10 4:26 PM5/18/10 4:26 PM

5
KEYS AND THEIR FUNCTIONS
RESET KEY
START/STOP KEY
LIGHT KEY
MODE KEY
HEART RATE SENSOR
HEART RATE SENSOR
when printing out or making PDF – PRINT AT 145%
SP5139IS01RODRA.indd 5SP5139IS01RODRA.indd 5 5/18/10 4:26 PM5/18/10 4:26 PM

6
SOLO 925 Heart Rate + Calorie Monitor
MODE KEY
• Scroll through operating modes
• Advance through variables in setting
sequence
• PRESS & HOLD: Enter/Exit the
programming sequence
START/STOP KEY (S/S)
• Start/Stop Chronograph
• Start/Stop Calories/Exercise Timer
• Start/Stop Countdown Timer
• Increase setting values during
programming sequence
RESET KEY (R)
• Reset Calories/Exercise Timer,
Chronograph & Countdown Timer
• Decrease setting values during
programming sequence
• PRESS & HOLD: Activate/deactivate
Heart Rate Lock in Time mode
HEART RATE SENSOR
• TOUCH & HOLD: Activates Heart Rate
LIGHT KEY
• Activates (EL) backlight system
KEYS AND THEIR FUNCTIONS
final size 4 x 10.89
SP5139IS01RODRA.indd 6SP5139IS01RODRA.indd 6 5/18/10 4:26 PM5/18/10 4:26 PM

7
ACQUIRING HEART RATE: FINGER TOUCH
Heart rate may be acquired from any operating mode (not in any Setting Sequence).
1. With the watch attached to your wrist, TOUCH & HOLD the HEART RATE SENSOR (anywhere on the
metal top plate of the watch) with your index finger.
2. Continue TOUCHING & HOLDING until heart rate displays.
3. Once Heart Rate is acquired, RELEASE THE SENSOR. Heart Rate will continue to display for a period
of approximately 5 seconds.
NOTE: The Monitor displays both actual heart rate (in beats per minute) and percent of estimated maximum heart
rate .
ACQUIRING HEART RATE
when printing out or making PDF – PRINT AT 145%
SP5139IS01RODRA.indd 7SP5139IS01RODRA.indd 7 5/18/10 4:26 PM5/18/10 4:26 PM

8
SOLO 925 Heart Rate + Calorie Monitor
MAIN OPERATING MODES
POWER DOWN MODE/RESET
Power Down mode allows you to conserve battery life by deactivating the unit when the monitor is not
being used for long periods of time. To activate Power Down mode:
1. In Time mode, PRESS & HOLD the MODE, STOP/START & RESET keys for approximately 3 seconds.
The display will go blank.
2. To deactivate Power Down mode and resume normal operation, PRESS & HOLD ANY KEY for
approximately 3 seconds.
VIEWING THE BACKLIGHT SYSTEM
The Sportline Solo 925 is equipped with an electroluminescent (EL) Backlight System for viewing the
display in low light conditions. To operate the Backlight:
PRESS the LIGHT key. Backlight will illuminate for approximately 5 seconds.
NOTE: Excessive use of Backlight System may significantly reduce battery life.
HEART RATE LOCK
To deactivate finger Touch Heart Rate (when you don’t want to accidentally acquire heart rate):
1. PRESS & HOLD the RESET key for 3 seconds in Time mode (see page 9, Main Operating Modes).
The Heart icon will disappear in the upper left of the display indicating Heart Rate Lock is active.
2. To deactivate Heart Rate Lock, PRESS & HOLD the RESET key for 3 seconds.
final size 4 x 10.89
SP5139IS01RODRA.indd 8SP5139IS01RODRA.indd 8 5/18/10 4:26 PM5/18/10 4:26 PM

9
MAIN OPERATING MODES
The Sportline Solo 925 has 7 main operating modes: Time, Target Heart Rate Zone, Alarm,
Chronograph, Countdown Timer, Calories/Exercise Timer and Dual Time Zone. Scroll through main
modes by PRESSING the MODE key. Acquire Finger Touch Heart Rate by TOUCHING & HOLDING the
HEART RATE SENSOR in any operating mode.
PRESS
MODE
PRESS
MODE
PRESS
MODE
PRESS
MODE
PRESS
MODE
TIME TARGET HR ZONE ALARM CHRONOGRAPH
COUNTDOWN TIMERCALORIES/
EXERCISE TIMER
DUAL TIME ZONE
when printing out or making PDF – PRINT AT 145%
SP5139IS01RODRA.indd 9SP5139IS01RODRA.indd 9 5/18/10 4:26 PM5/18/10 4:26 PM

10
SOLO 925 Heart Rate + Calorie Monitor
SETTING & OPERATING THE WATCH
SETTING TIME AND DATE
In this Programming Sequence, you will program the Time & Date functions.
1. In Time mode, PRESS & HOLD the MODE key to enter the programming
sequence. The variable being adjusted will flash on and off.
2. Reset Seconds to zero (00) by PRESSING the START/STOP (S/S) or RESET (R)
key. Advance to Set Minutes by PRESSING the MODE key.
3. Adjust Minutes by PRESSING S/S (to increase) or R(to decrease). Set Minutes
and advance to Set Hour by PRESSING the MODE key.
4. Adjust Hour by PRESSING S/S or R. Set Hour and advance to Set Year by
PRESSING the MODE key.
5. Adjust Year by PRESSING S/S or R. Set by PRESSING MODE.
6. Adjust Month by PRESSING S/S or R. Set by PRESSING MODE.
7. Adjust Day by PRESSING S/S or R. Set by PRESSING MODE.
8. Adjust date format (month - day or day - month) by PRESSING S/S or R. Set
Format by PRESSING MODE.
9. Adjust 12/24-hour format by PRESSING S/S or R. Set Format by PRESSING
MODE.
10. Turn Key Beep ON or OFF by PRESSING S/S or R. Set by PRESSING MODE.
11. PRESS & HOLD the MODE key to exit the Programming Sequence & resume
Operating mode.
ADJUST: S/S or R
SET: MODE
final size 4 x 10.89
SP5139IS01RODRA.indd 10SP5139IS01RODRA.indd 10 5/18/10 4:26 PM5/18/10 4:26 PM

11
SETTING & OPERATING THE WATCH
SETTING HEART RATE TARGET ZONE
The Sportline Solo 925 uses your age and gender to calculate a healthy Target Heart
Rate Zone. You can also program your own upper and lower ranges. To set Target
Heart Rate Zone:
1. In Heart Rate Target Zone mode, PRESS & HOLD the MODE key to enter the
programming sequence. The variable being adjusted will flash on and off.
2. Adjust Age (in years) by PRESSING the START/STOP (S/S) or RESET (R) key. Advance
to Set Gender by PRESSING the MODE key.
3. Select Gender (M=male, F=female) by PRESSING the START/STOP (S/S) or RESET (R)
key. Set Gender by PRESSING the MODE key.
4. To allow the watch to calculate your Target Heart Rate Zone, PRESS & HOLD
the MODE key to exit the programming sequence & resume operating mode. To
manually program your Target Heart Rate Zone, PRESS & HOLD the MODE key to
advance to set Upper Zone Limit.
5. Adjust Upper Zone Limit (H) by PRESSING the START/STOP (S/S) or RESET (R) key.
Advance to Lower Zone Limit by PRESSING the MODE key.
6. Adjust Lower Zone Limit (L) by PRESSING the START/STOP (S/S) or RESET (R)
key. PRESS & HOLD the MODE key to exit the programming pequence & resume
operating mode.
ADJUST: S/S or R
SET: MODE
when printing out or making PDF – PRINT AT 145%
SP5139IS01RODRA.indd 11SP5139IS01RODRA.indd 11 5/18/10 4:26 PM5/18/10 4:26 PM

12
SOLO 925 Heart Rate + Calorie Monitor
SETTING & OPERATING THE WATCH
ACTIVATING AND VIEWING THE TARGET HEART RATE ZONE
The Sportline Solo 925 allows you to deactivate the Target Heart Rate Zone (this will
not effect Heart Rate or Calories reading). To turn this feature On or Off:
1. In Target Heart Rate Zone mode, PRESS the START/STOP key.
2. If the Target Heart Rate Zone is deactivated (oF in display), your heart rate will
display in beats per minute (actual heart rate) only.
3. If the Target Heart Rate Zone is activated (on in display), your heart rate will
display in beats per minute (actual heart rate) and percent of maximum heart rate
(relative heart rate).
HR ZONE
DEACTIVATED
HR ZONE
ACTIVATED
final size 4 x 10.89
SP5139IS01RODRA.indd 12SP5139IS01RODRA.indd 12 5/18/10 4:26 PM5/18/10 4:26 PM

13
SETTING & OPERATING THE WATCH
SETTING DAILY ALARM
The Sportline Solo 925 features a Daily Alarm. To set Alarm:
1. In Alarm mode, PRESS & HOLD the MODE key to enter the programming sequence.
2. Adjust Hour by PRESSING START/STOP (S/S) or RESET (R). Set by PRESSING MODE.
3. Adjust Minutes by PRESSING S/S or R. Set by PRESSING MODE.
4. PRESS & HOLD the MODE key to exit the programming sequence and return to Time
mode.
5. Turn Alarm ON or Off by PRESSING the START/STOP (S/S) key. The Alarm icon
( ) will be visible in all operating modes when activated.
6. Turn Hourly Chime ON or Off by PRESSING the RESET (R) key. The Alarm icon ( )
will be visible in all operating modes when activated.
ADJUST: S/S or R
SET: MODE
when printing out or making PDF – PRINT AT 145%
SP5139IS01RODRA.indd 13SP5139IS01RODRA.indd 13 5/18/10 4:26 PM5/18/10 4:26 PM

14
SOLO 925 Heart Rate + Calorie Monitor
SETTING & OPERATING THE WATCH
START/STOP TIMING:
PRESS S/S
RESET:
PRESS R
OPERATING THE CHRONOGRAPH
To operate the Chronograph:
1. To START timing, PRESS the START/STOP (S/S) key.
2. To STOP timing, PRESS the S/S key.
3. To RESET the Chronograph, PRESS & HOLD the RESET (R) key.
final size 4 x 10.89
SP5139IS01RODRA.indd 14SP5139IS01RODRA.indd 14 5/18/10 4:26 PM5/18/10 4:26 PM

15
SETTING & OPERATING THE WATCH
SETTING THE COUNTDOWN TIMER
The Sportline Solo 925 is equipped with a 100-hour Countdown Timer. To set Timer:
1. PRESS & HOLD the MODE key in Timer mode.
2. Adjust Seconds byPRESSING START/STOP (S/S) or RESET (R). Set by PRESSING
MODE.
3. Adjust Minutes by PRESSING S/S or R. Set by PRESSING MODE.
4. Adjust Hours by PRESSING S/S or R. Set by PRESSING MODE.
5. PRESS & HOLD the MODE key to exit the Programming Sequence and return to
Timer mode.
ADJUST: S/S or R
SET: MODE
when printing out or making PDF – PRINT AT 145%
SP5139IS01RODRA.indd 15SP5139IS01RODRA.indd 15 5/18/10 4:26 PM5/18/10 4:26 PM

16
SOLO 925 Heart Rate + Calorie Monitor
SETTING & OPERATING THE WATCH
OPERATING THE COUNTDOWN TIMER
To operate the Timer:
1. To START timing, PRESS the START/STOP (S/S) key.
2. To STOP timing, PRESS the S/S key.
3. To RESET the Timer, PRESS & HOLD the Rkey.
START/STOP TIMING:
PRESS S/S
RESET:
PRESS R
final size 4 x 10.89
SP5139IS01RODRA.indd 16SP5139IS01RODRA.indd 16 5/18/10 4:26 PM5/18/10 4:26 PM

17
SETTING & OPERATING THE WATCH
OPERATING CALORIES/EXERCISE TIMER
The Sportline Solo 925 uses an advanced algorithm based on your age and gender
to estimate your maximum heart rate and calculate calories burned. The monitor
displays Total Exercise Time and Calories Burned (CA). To operate Calories/Exercise
Timer:
1. To START timing, PRESS the START/STOP (S/S) key.
2. To STOP timing, PRESS the S/S key.
3. To RESET the Exercise Timer, PRESS & HOLD the Rkey.
TIP: The more frequent heart rate readings are taken, the more accurate the
calories burned estimate will be.
START/STOP TIMING:
PRESS S/S
RESET:
PRESS R
when printing out or making PDF – PRINT AT 145%
SP5139IS01RODRA.indd 17SP5139IS01RODRA.indd 17 5/18/10 4:26 PM5/18/10 4:26 PM
