SPORTSPOWER SW-003 User manual

!
WARNINGS!
- Misuse and abuse of this product can result in injury.
- Read instructions before assembly or using this product. Retain Instructions.
- Always inspect product before use, checking for worn, defective or missing parts.
- The single swing is suitable for age 3-8 years with maximum user weight of 45 kg(99 lbs).
- The nursery swing is suitable for ages 12-36 months with maximum user weight of 25 kg(55 lbs).
- Do not stand on the swing.
- Adult supervision at all times.
- Only for outdoor and domestic use.
Tips : It will take 2 people around 45 mins to assemble this product.
2-IN-1 SWING
USER AND ASSEMBLY MANUAL
For Customer Service, please call 1-866-632-1718 or visit www.partsnservice.com
Monday – Friday 9:00 AM – 5:00 PM Eastern Time
Sportspower Ltd
Level 20, Parkview Centre 7 Lau Li Street, Causeway Bay, Hong Kong
Save this instruction manual for future reference

P. 1
Before you start...
• We suggest you spend some time reading this guide before follow-
ing the simple step-by-step assembly instructions.
•
• When assembling this product be aware of the safety of yourself
and others.
• Because of the size of this product we suggest that you assemble
it in the area intended for use.
• Some assembly steps will be easier with two people. Seek assistance
when lifting large or heavy items.
• Assemble this product on a clean, flat and level surface e.g. the
cardboard packaging.
• Keep any tools provided or spare fittings for future use. Only use
the tools specified.
• Tighten all parts by hand first before tightening again with tools.
• Consider where the product is placed in relation to the sun to avoid
overexposure to the heat, which may cause hazard such as dizziness.
Your product is warranted against defects in material and workmanship.
Extended warranty is also offered to those customers registering their
products at www.sportspowerltd.net within 14 days from the date of
purchase. Please refer to our warranty policy at the back of this manual for
details.
If you experience any problems with your product, do not return to the store.
For customer service, please call 1-866-632-1718 Monday-Friday
9:00am-5:00pm Eastern Time. If you are unable to reach us at this number
for any reason, please visit www.partsnservice.com
Do not discard any of the packaging until you have checked that are
parts and hardware are included. When discarding the packaging,
please consider others and the environment.

P. 2
WARNING. FOR DOMESTIC USE ONLY.
Please check to ensure all parts are present before you
start the assembly of this unit. If any missing parts,
please properly store the product away and contact our
customer service representtives for assistance.
Assembly by adult(s) required. Do not allow children
under 3 nearby during assembly to avoid choking hazard
from small parts.
Constant adult supervision is required during use of this
product.
At the start of assembly, do not tighten bolts/nuts
completely so as to allow some possible adjustment.
After all major components are assembled, go back over
all bolts and nuts and properly tighten all of them before
using this product.
The single swing is suitable for age 3-8 with maximum
user weight of 45kg.
The nursery swing is suitable for ages 12-36 months
with maximum user weight of 25kg.
The equipment is designed for outdoor domestic use
only and is not permitted for hiring or commercial use.
Adult supervision is required at all times while the swing
is in use. Never leave children unattended during play.
Do not use the equipment in any manner other than
intended.
Please retain these instructions for future reference
The product should not be installed over concrete,
asphalt or any other hard surfaces. The equipment
should be placed on a level surfaces at least 2 m from
any structure or obstruction such as a fence, garage,
house, overhanging branches, laundry lines or
electrical wires.
Do not use the equipment until it has been fully
assembled and anchored, and all the components are
properly secured. All the chains/ropes/cables cannot be
looped back on themselves.
Never allow children to disembark from the play
equipment whilst it is still in motion.
Ensure that children are not facing the sun whilst using
the equipment.
Do note attach items to the equipment that are not
specially designed for use with this product, including
but not limited to cables, shipping ropes and chains as
they may cause strangulation hazards.
Never allow children to walk too close to, in front of,
behind or in between the equipment whilst in use,
always keep children a safe distance from the product
whilst in use.
Do not allow reckless playing, such as jumping off,
standing on seats or climbing ropes.
Do not allow children to use when the swing seat is wet.
Instruct children to avoid swinging the empty swing and
not twist the swing chain or loop them over the top
support bar since this may reduce the strength of the
chain or rope.
Do not allow children to climb on the structure of the
swing (eg legs, top bar, cross bars and other parts).
Instruct child to sit in the centre of the swing with their
full weight in the center of the seat.
Ensure that children wear suitable clothing whilst using
this equipment. Never allow children to wear loose
clothing, neck ties, scarves, drawstrings or loose
jewellery.
Top Tips before you start
Read and followall instructions
Please remove all packaging and packing tags/ wires
before allowing your child to use. Please take note: As an
extra precaution, check this product regularly for signs of
wear or damage.
Protective surfacing: One of the most important things
you can do to reduce the likelihood of serious head
injuries is to install Shock-Absorbing Protective
Surfacing (over the ground) under and around your
play equipment. We recommend you use loose-fill
materials such as wood mulch/chips, engineered wood
fibre, shredded/recycled rubber mulch or sand gravel.
The surfacing will also compact, displace, and settle, and
should be periodically refilled. Carpeting and thin mats
are generally not adequate protective surfacing, check
and maintain the depth of the loose-fill surfacing material,
Maintain the right amount of loose-fill material. Do not
install loose fill surfacing over hard surfaces such as
concrete or asphalt.
IMPORTANT - Please read these instructions fully before assembly or use.
SAFETY INFORMATION

P. 3
1x1 Beam 2x2 Leg Tube 3x2 Leg Tube 4x4 Leg Tube
6x4 Leg Tube
5x2 Rail 7x4 Anchor 8x1 Single Swing Seat
9x1 Nursery Swing
Seat
Ex8 (Φ8.5 x Φ19mm) Fx32 (Φ6.5 x Φ14mm)
Ix16 (Φ6.5 x Φ10mm)
Hx4 (Φ8.5 x Φ13.5mm)
Jx4 (M8) Kx16 (M6) Lx1 (10&13mm) Mx1 (4mm)
10 x4 Plastic Cap Ax2 (M8)
Dx4 (M6x42mm)
Bx8 (M6x38mm)
Cx4 (M6x53mm)
CONTENTS

P. 4
1
2
3
X 2
3
2
3
2
1
step 1
ASSEMBLY
● Insert Legs (2) and (3) into Beam (1) as shown in FIGURE1.
● Please note the order of Legs (2) and (3) need to be inverse on the two sides of the
beam.
FIGURE 1

P. 5
step 2
ASSEMBLY
3
2
3
4
4
4
4
2
1
4
K
F
BFI
X 4
I
B F K
x4x4 x8 x4
● Insert Legs (4) into (2) and (3).
● Secure with B,F,I and K in the sequence shown in FIGURE 2.
FIGURE 2

P. 6
step 3
ASSEMBLY
3
2
3
4
4
4
4
5
5
2
1
4
10
5IK
F
D
F
X 4
I
D F K
x4x4 x8 x4
● Attach Plastic Cap (10) to each side of Rail (5) Secure Rail to Legs (4) on both sides
of the swing using D,F,I and K in the sequence shown in FIGURE 3.
FIGURE 3

P. 7
step 4
ASSEMBLY
● Secure the swing to Beam (1) using A, E, H, and J in the sequence shown in
FIGURE 4.
FIGURE 4
9
1
A
E
E
H
J
1
X 4
H
A E J
x4x4 x8 x2
For Nursery Swing Seat
(See steps 6 and 7 for Single Swing Seat)

P. 8
step 5
ASSEMBLY
CONSTANT ADULT SUPERVISION REQUIRED AT ALL TIMES DURING USE.
Note: Lock the seat belt tightly over the child shown in FIGURE 5.
FIGURE 5
For Nursery Swing Seat
(See steps 6 and 7 for Single Swing Seat)

P. 9
step 6
ASSEMBLY
For Single Swing Seat
I
B F K
x4x4 x8 x4
● Attach Legs (6) to (4) using B,F,I and K in the sequence shown in FIGURE 6.
FIGURE 6
4
4
4
4
6
6
6
6
4
K
F
BFI
X 4

P.10
step 7
ASSEMBLY
For Single Swing Seat
FIGURE 7
H
A E J
x4x4 x8 x2
J
E
H
A
E
1
X 4
8
1
● Secure the swing to Beam (1) using A, E, H and J in the sequence shown in FIGURE 7.

P. 11
step 8
ASSEMBLY
7
6
7
7
6
6
7
6
K
F
C
FI
6
7
X 4
I
C F K
x4x4 x8 x4
FIGURE 7
● Attach Anchor (7) to the base of all four Legs (6) using C,F,I and K in the sequence
shown in FIGURE 7.
IMPORTANT: AFTER COMPLETING ALL THE STEPS, GO OVER THE ENTIRE
UNIT AND TIGHTEN ALL BOLTS BEFORE ALLOWING CHILDREN TO USE.
For Nursery and Single Swing Seat

P.12
step 9
ASSEMBLY
7
6
X 4
● Position the anchors at 45 degree
angle and secure them fully into
the ground until the leg of the
swing is standing flat and stable
on the ground.
For Nursery and Single Swing Seat

P.13
step 10
ASSEMBLY
SEAT ADJUSTABLE GUIDE
THE LENGTH OF THE ROPE IS ADJUSTABLE FOR THE HEIGHT OF THE CHILD
THROUGH THE SEAT CONNECTOR.
TO ADJUST, LOOSEN THE KNOT ON THE SEAT CONNECTOR, PULL ROPE
THROUGH THE HOLES AND TIGHTEN AGAIN.
MAKE SURE THAT THE KNOTS ARE TIGHT AND THAT BOTH ROPES ARE
ADJUSTED SO THAT THE SEAT IS HORIZONTAL.
IMPORTANT: MINIMUM CLEARANCE BETWEEN THE FOOTREST/SEAT
AND THE GROUND SHOULD BE 35 CM.

CARE AND MAINTENANCE
P.14
•Nursery Swing is suitable for children between
ages 12-36 months with maximum weight of
25 kg(55 lbs).
•Single Swing is suitable for children between
3-8 years old with maximum weight of
45 kg(99 lbs).
•Do not allow more than one user at the same
time.
•Constant adult supervision required at all
times during use. Do not leave children
unattended.
•For domestic use only. Not for rental or
commercial use.
•Adult assembly required. Make sure to proper-
ly dispose of all packaging material and do not
allow children nearby during assembly due to
long cord(s)- strangulation hazard!
General
Inspect regularly for:
This 2-in-1 Swing was designed manufactured with quality materials and craftsmanship.
If correct care and maintenance is provided, it will provide users with years of exercise, fun
and enjoyment.

P.15
PRODUCT WARRANTY
SP-33-SW003-JD-20001
Sportspower Ltd warrants its products to be free from defects in material and workmanship
under normal use and service conditions for ninety (90) days after the date of purchase.
Extended warranty from 90 to 180 days will be offered to those customers registering their
products at www.sportspowerltd.net within 14 days from the date of purchase. The frame is
warranted for 12 months after the date of purchase.
This warranty coverage extends only to the original purchaser with a receipt and is
non-transferable. All products for which a warranty claim is made must be received by
SPORTSPOWER’S authorized service center, freight prepaid, and accompanied by sufficient
proof of purchase during the warranty period.
This limited warranty does not cover our products which: fail due to (1) normal wear; (2)
abuse and neglect; (3) improper maintenance; (4) unauthorized repairs or alterations or (5)
are used for commercial or other income producing purposes or (6) accidents and misuse.
All warranty repairs must be authorized by SPORTSPOWER Customer Service before
repairs are made.
IMPORTANT: A missing part is not considered the same thing as a defective part or
unit. If a part is missing, there is no need to return the entire unit to the store. In order
to obtain fast replacement parts or service as provided by this warranty, please call
the number below. Proof of purchase required.
For Customer Service, please call 1-866-632-1718 or visit www.partsnservice.com
Monday - Friday 9:00 AM - 5:00 PM Eastern Time
Sportspower Ltd.
Level 20, Parkview Centre, 7 Lau Li Street, Causeway Bay, Hong Kong
