spotzero ZTCII2000 Installation and operating instructions

USER MANUAL / INSTALLATION GUIDE
ZTCII2000 ZTCII3000
www.spotzerowater.com
1

TABLE OF CONTENTS
1. INTRODUCTION ......................................................................................................................3
CONGRATULATIONS .......................................................................................................................................4
SYSTEM REQUIREMENTS AND OPERATION GUIDELINES............................................................................4
ACRONYMS AND DEFINITIONS.......................................................................................................................6
UNIT SPECIFICATIONS ....................................................................................................................................7
2. INSTALLATIONANDCOMMISSIONING.................................................................................9
SPOT ZERO COMMISSIONING REPORT FORM ...........................................................................................10
STANDARD ITEMS INCLUDED WITH UNIT....................................................................................................11
STORAGE OR WINTERIZATION OF UNIT......................................................................................................15
3.OPERATION AND MAINTENANCE .......................................................................................18
ZTCII CONSUMABLE ITEMS...........................................................................................................................19
SPOT ZERO ZTCII TOUCHSCREEN NAVIGATION........................................................................................20
REMOTE TOUCH SCREEN SETUP................................................................................................................29
4.TROUBLESHOOTING............................................................................................................35
ABNORMAL PRODUCT FLOW........................................................................................................................36
DIVERSION VALVE BY-PASS.........................................................................................................................36
TEMPERATURE CORRECTION FACTORS FOR MEMBRANE.......................................................................37
IS MY SYSTEM WORKING PROPERLY?........................................................................................................38
5. ZTCII SYSTEM SPECIFICATIONS & PARTS........................................................................39
MODEL NUMBER SELECTION WORKBOOK..................................................................................................45
BURKERTDIVERSIONVALVE TECHNICAL DATA..........................................................................................50
6. WARRANTY INFORMATION.................................................................................................58
PRINCIPLES OF REVERSE OSMOSIS.............................................................................................................6
SYSTEMS STANDARD OPERATING PARAMETERS........................................................................................8
INSTALLATION PROCEDURE.................... ....................................................................................................12
ZTCII ONE LINE FLOW DRAWING....................................................................................................................16
ZTCII WIRING DIAGRAM..................................................................................................................................16
ZTC PRE-FILTER ASSEMBLY DRAWING.........................................................................................................40
BACTERIOSTATIC REMINERALIZER DRAWING............................................................................................41
ZTCII/XZII FW MOTOR PUMP ASSEMBLY DRAWING....................................................................................42
7" TOUCH SCREEN DRAWING........................................................................................................................43
INTERNAL/FILTER COMPONENTS................................................................................................................44
BRASS FW PUMP TECHNICAL DATA..............................................................................................................54
TROUBLESHOOTING GUIDE..........................................................................................................................36
2

1. INTRODUCTION
3

CONGRATULATIONS
Your Spot Zero™ reverse osmosis system is a durable piece of equipment, which, with
proper care, will last for many years. This User’s Manual outlines installation, operation,
maintenance and troubleshooting details vital to the sustained performance of your system.
Your system is designed to operate at a pressure of 80-150 psi, unless otherwise stated.
The recovery set for your system is between 50%-75%.
NOTE: Prior to operating or servicing the Spot Zero reverse osmosis system, this User’s
Manual must be read and fully understood. Keep it and other associated information for
future reference and for new operators or qualified personnel near the system.
SYSTEM REQUIREMENTS AND OPERATION GUIDELINES
PLUMBING
The membranes and high-pressure pumps used on Spot Zero systems require a continuous
and nonturbulent flow of water to the system with a minimum feed pressure of 20 psi during
operation, which does not exceed 105°F.
The tubing or piping used for the inlet of the feed water is 3/4" ID. The tubing or piping used
for the discharge of the concentrate is 1/2" O.D. and should be run to an open overboard
free and unrestricted
The tubing or piping used for the product is 3/8” O.D. and can be transported to the holding
tank or directly through a high-quality nylon tubing or PVC pipe or other FDA accepted
materials.
Material must not precipitate in the system. Be certain that all the components of the feed
water are soluble at the concentrations attained in the system.
CAUTION: Any restrictions or blockage in the overboard discharge line can cause back
pressure, which will increase the system’s operating pressure. This can result in damage to
the system’s components and possible leaks of components or tubing.
ELECTRICAL
The motors used on Spot Zero™ systems are pump and motor combinations. They are
available in single- phase 115 volt or 230-volt AC.
Please ensure that the electrical circuit supplying the system is compatible with the
requirements of the specific Spot Zero™ model.
4

PRE-FILTRATION
Spot Zero™ systems are supplied with a 1-micron sediment pre-filter (part # 252404005) that
filters out most particles over 1-micron, a GAC/KDF (part # 252404004) Cartridge that removes
chlorine, chloramine, VOCs and heavy metals. CAUTION: a traditional carbon block filter must
not be used as it will not remove chloramines and will cause permanent membrane damage.
Pre-Filters should be changed every 100 hours and/or whenever there is a pressure difference
of 15 psi or more between the pressure readings before and after the filter. The pump must
NEVER be run dry. Operating the pump without sufficient feed water will damage the pump.
ALWAYS feed the pump with filtered water. The pump is susceptible to damage from sediment
and debris.
NOTE: THE SZ10KDF2 CARTRIDGE MUST BE FLUSHED OUTSIDE OF SYSTEM BEFORE
OPERATING TO REMOVE CARBON DUST.
You can head to www.spotzero.com/support to see demo videos. Do not attempt to clean used
filter cartridges. The SZ10KDF2 is rated to absorb chlorine, chloramine, heavy metals, etc. up to
18,000 gallons of feed water, which is the equivalent to approximately 100 hours of runtime.
CAUTION: If the pre-filter becomes clogged and the water flow to the pump is
reduced or interrupted, cavitation will occur. This will damage the pump.
5

ACRONYMS AND DEFINITIONS
ACRONYM/SYMBOLS
DEFINITION
FWF
FRESH WATER FLUSH
RO
REVERSE OSMOSIS
PSI
POUNDS PER SQUARE INCH
GPM
GALLONS PER MINUTE
GPD
GALLONS PER DAY
TDS
TOTAL DISSOLVED SOLIDS
PPM
PARTS PER MILLION
TCF
TEMPERATURE CORRECTION FACTOR
LP SWITCH
LOW PRESSURE SWITCH
HP SWITCH
HIGH PRESSURE SWITCH
Φ
PHASE
SW
SEA WATER
FW
FRESH WATER
PRINCIPLES OF REVERSE OSMOSIS
HOW FRESH WATER IS PRODUCED
Reverse Osmosis or “RO” is a process where freshwater water is produced by pumping
saltwater through a semi-permeable membrane.
OSMOSIS
Osmosis is a naturally occurring process where a weak solution will cross a semi-permeable
membrane to mix with a highly concentrated solution. For example, a freshwater solution will
naturally want to mix with a saltwater solution.
REVERSE OSMOSIS
To reverse this process work is put into the system using a pump. The pump causes pressure
to build up on the saltwater side of the membrane. This pressure forces water across the semi-
permeable membrane. The membrane is designed to allow the water molecules to pass while
preventing the salt and other solids from doing so. Fresh water is collected on the other side
of the membrane as a result.
6

UNIT SPECIFICATIONS
ZTCII MODEL
2000
3000
FW Configuration
(Spot Zero)
1 Vessel
2 Vessels
Feed Water Source
Fresh Water
Fresh Water
Rated Production Dock Water
gpd (lpd)
2000(7571)
3000(11356)
Rejection and Flow Rates
FW Nominal TDS Rejection %
(Spot Zero)
95%
95%
FW Minimum Concentrate Flow
gpm (lpm)
1 (3.7)
1(3.7)
Connections
FW Feed inch
(Spot Zero)
3/4”
3/4”
Product inch
3/8” QC 9.5mm
3/8” QC 9.5mm
Concentrate inch
1/2” QC 12.7mm
1/2” QC 12.7mm
Membranes
FW Membrane Per Vessel
1
1
FW Membrane Size
4041
4041
Pumps
FW Pressure Pump Type
Vane
Vane
FW RO Motor amps
5.1
5.1
Electrical
Voltage
230V 50/60Hz 1Φ
230V 50/60Hz 1Φ
Weight lb. (kg)
108(49)
116(53)
7

SYSTEMS STANDARD OPERATING PARAMETERS
Fresh Water RO Systems
Product
Flow
(gpm/lpm)
Concentrate
Flow
(gpm/lpm)
Recycle
Flow
(gpm/lpm)
(+/-10%)
Total Flow
(gpm/lpm)
Pump
Pressure
(psi/bar)
MAX
Concentrate
Pressure
(psi/bar)
MAX
Pre-filter Inlet
Pressure
Minimum
(psi/bar)
Pre-filter Inlet
Pressure
Maximum
(psi/bar)
Pre-filter Outlet
Pressure Minimum (psi/bar)
Pre-filter Outlet
Pressure
Maximum
(psi/bar)
Model/GPD
SZ/ZTCII/XZ (FW-RO) SERIES
GPD 2000
1.4/5.3
1.0/3.8
2.0/7.6
4.4/16.7
150/10.3
150/10.3
15/1
85/4
15/1
85/4
GPD 3000
2.0/7.5
1.0/3.8
2.0/7.6
5/18.9
150/10.3
150/10.3
15/1
85/4
15/1
85/4
SZ-HD/XZ-HD (FW-RO) SERIES
GPD 4000
2.7/10.2
1.5/5.7
2.0/7.6
6.2/23.5
150/10.3
150/10.3
15/1
85/4
15/1
85/4
GPD 5000
3.47/13.1
1.5/5.7
2.0/7.6
7.0/26.5
150/10.3
150/10.3
15/1
85/4
15/1
85/4
GPD 6000
4.16/15.7
2.0/7.6
2.0/7.6
8.2/31
150/10.3
150/10.3
15/1
85/4
15/1
85/4
Saltwater RO Systems
Product
Flow
(gpm/lpm)
Concentrate
Flow
(gpm/lpm)
Recycle
Flow
(gpm/lpm)
Total Flow
(gpm/lpm)
Pump
Pressure
(psi/bar)
Concentrate
Pressure
(psi/bar)
Pre-filter Inlet
Pressure
Minimum
(psi/bar)
Pre-filter Inlet
Pressure
Maximum
(psi/bar)
Pre-filter Outlet
Pressure
Minimum
(psi/bar)
Pre-filter Outlet
Pressure
Maximum
(psi/bar)
SE SERIES
GPD 350
.24/.9
2.26/8.6
N/A
2.5/9.5
N/A
850/58.6
15/1
85/4
15/1
85/4
GPD 600
.41/1.5
2.09/7.9
N/A
2.5/9.5
N/A
850/58.6
15/1
85/4
15/1
85/4
GPD 800
.55/2.0
1.95/7.4
N/A
2.5/9.5
N/A
850/58.6
15/1
85/4
15/1
85/4
GPD 1200
.83/3.1
1.67/6.3
N/A
2.5/9.5
N/A
850/58.6
15/1
85/4
15/1
85/4
SX/XTCII/XZ (SW-RO) SERIES
GPD 600
.41/1.5
3.79/14.3
N/A
4.2/15.9
N/A
850/58.6
15/1
85/4
15/1
85/4
GPD 1200
.83/3.1
3.37/12.8
N/A
4.2/15.9
N/A
850/58.6
15/1
85/4
15/1
85/4
GPD 1800
1.25/4.7
2.95/11.2
N/A
4.2/15.9
N/A
850/58.6
15/1
85/4
15/1
85/4
GPD 2200
1.52/5.75
2.68/10.1
N/A
4.2/15.9
N/A
850/58.6
15/1
85/4
15/1
85/4
SXII-HD/XZ-HD (SW-RO)SERIES
GPD 3600
2.5/9.46
5/18.9
N/A
7.5/28.4
N/A
850/58.6
15/1
85/4
15/1
85/4
GPD 4300
2.98/11.28
7.5/28.4
N/A
10.5/39.7
N/A
850/58.6
15/1
85/4
15/1
85/4
GPD 5000
3.47/13.13
7.0/26.5
N/A
10.5/39.7
N/A
850/58.6
15/1
85/4
15/1
85/4
CX SERIES
GPD 20000
13.88/52.54
46/174
N/A
60/227
N/A
850/58.6
15/1
85/4
15/1
85/4
Standard Parameters
Total Dissolved Solids for Fresh Water Systems (PPM) Product Water Side
90% less than feed water
Total Dissolved Solids for Sea Water Systems (PPM) Product Water Side
Less than 500 PPM
Temperature (F/C)
77/25
8

2. INSTALLATION AND COMMISSIONING
9

System Information:
Model number -
Date of Commission -
Installed by -
Serial number -
Commissioned by-
Vessel hull number-
First step to commissioning a new system is to look over the install to be sure everything is installed correct. This check-
list must be gone through prior to powering up the system.
Have all plumbing connections have been made, and secured?
Have all plumbing lines been run to the correct locations?
Is the boost pump installed below the water line?
Has wire reinforced hose been used on the suction side of the boost pump?
Is raw water intake open?
Is the overboard open and free of obstructions?
Is the system voltage, hertz, and phase correct?
Is the circuit breaker sized properly with sufficient wire gauge?
Is the power cable connected to the power inlet terminals of the system?
Now power up the system,
Are all displays on and functional?
At this time follow the start-up procedure in the manual and operate the system for an hour at its rated capacity, then
record the following data.
System operating readings
Pre-filter inlet Pre-filter outlet psi
Concentrate pressure
psi
psi
gpm
Product flow gpm Product TDS ppm
Feed water TDS ppm Feed water temperature F or C
Hours on system hrs Amp draw Voltage
Location system was tested
Problems or other notes:
Concentrate flow
SPOT ZERO COMMISSIONING REPORT FORM
10

✓PART NUMBER DESCRIPTION QTY
KIT0005 ZTC Install Kit
J0003 Tubing, Nylon, 3/8" OD 50 ft.
J0004 Tubing, Nylon, 0.50 in. OD 50 ft.
B0021 Elbow 3/8" QC 4
B0020 Elbow 1/2" QC 4
B0019 Adapter 1/2" QC to 1/2" MNPT 2
B0030 Adapter 3/8" QC to 1/2" MNPT 2
D0047 TDS-EZ HAND HELD TESTER 1
B0059 Adapter 1/2" CTS Stem to 3/8" CTS 2
B0024 Reducer 1/2" QC Stem to 3/8" QC 2
B0058 Adapter 5/8" QC Stem to 3/8" QC 2
H5089 Install Kit 5/16" Hardware Set 1
B0013 Elbow 3/8" QC Stem to 3/8" QC 4
B0010 Elbow 1/2" QC Stem to 1/2" QC 4
E1018 Wrench for Big Clear 4.5" #10 & #20 1
B5001 Locking Clip, 3/8", Install Kit 20pc 1
B5002 Locking Clip, 1/2", Install Kit 20pc 1
H5065 Lubricant Silicone 6 grams 1
B0043 Ball Valve 3/8" QC 1
MN1003 ZTC Manual 1
AE0004 Bacteriostatic Remineralizer Assembly 1
B0048 RELEASE TOOL SET 1
B0052 Adapter 1/2" QC Stem to 15mm QC 1
B0053 Adapter 3/58" QC Stem to 15mm QC Stem 1
B0054 Elbow 15mm QC 1
B0055 1Elbow 15mm QC Stem to 15mm QC
STANDARD ITEMS INCLUDED WITH UNIT
1
11

INSTALLATION PROCEDURE
FEED WATER
1. Plumb the feed water from the dock into the pre-filter inlet pressure regulator fitting. 3/4”
FNPT or 1” MNPT custom connection from customer.
2. Tube Cutting and Installation Procedure
Cut the tube square and remove burrs
and sharp edges. Ensure the outside
diameter is free of score marks. For soft
or thin-walled tube, we recommend the
use of a tube insert.
Push the tube into the fitting, to the tube stop.
To disconnect, ensure the system is
depressurized, push the collet square
againstthe fitting. With thecollet held in this
position the tube can be removed.
Feed from Dock
12

3. From the pre-filter outlet fitting, run the white nylon 1/2” Spot Zero water tubing to the
feed from pre-filtration fitting.
4. From the “Overboard” discharge fitting, run the white nylon 1/2” Spot Zero water tubing
to a dedicated overboard fitting. Water must be allowed to run freely, without any
restrictions or blockage in the brine discharge line. Be sure that no back pressure exists
in the “Overboard” discharge line.
Note: There is an internal check valve in the brine discharge line in the system.
½” QC Tube To
Overboard
5. From the product to tank fitting, run the white nylon 3/8” Spot Zero water tubing to the
vessels freshwater tank.
½” QC Tube
3/8” QC
Tube
3/8” Tubing to Inlet
of Bacteriostatic
Remineralizer
Ship’s Fresh
Water Tank
13

FEED FROM WATERMAKER
1. Connect the 3/8” product line from the water maker to the “WATER MAKER IN” fitting.
Always install a three-way valve in line with this, so the water can be diverted to the spot
zero system, or to the vessels fresh water tank.
From Water Maker
ELECTRICAL CONNECTIONS
1. Supply and connect specified power (115v or 230v) from the vessels panel to the ZTC panel.
Connect line 1 and line 2 to the terminals and connect the ground wire to theground terminal.
Be sure to confirm systems rated voltage before applying power.
NOTE: IT’S RECOMMENDED THAT A QUALIFIED ELECTRICIAN WIRE YOUR SYSTEM IN
ACCORDANCE WITH ABYC REQUIREMENTS.
WARNING: TO REDUCE THE RISK OF ELECTRICAL SHOCK, THE INCOMING
POWER SUPPLY MUST IN- CLUDE A PROTECTIVE GROUND.
PC BOARD DIP SWITCH SETTINGS
ZTCII DIP SWITCH SETTINGS
Spot Zero Touch Screen
SZ
CRL
Carel Touchscreen
XZ System (Boards connected
together via FWSW connections)
XZ
X/Z
Independent XTCII or ZTCII System
(Boards not connected together via
FWSW connections)
Color Graphics Touchscreen
CG
TXT
Text LCD Display
Fresh Water Board (Spot Zero)
FW
SW
Sea Water Board (Sea Exchange)
3/8” QC Tube
14

STORAGE
STORAGE OR WINTERIZATION OF UNIT
If the vessel will not be able to allow for fresh water flushing over the duration of the storage
period, themembrane vesselsmust have static water replaced with membrane storage chemical
solution. Membrane storage chemical part # is 252404263.
WINTERIZATION
Option 1: Winterization with membrane rack removal - The best practice for winterization is
to remove membrane rack and store with membrane storage chemical inheatedstorageclimate.
The remainderofthe system should be stored with propylene glycol from sea cock to overboard
to prevent freeze damage (propylene glycol can be purchased at most hardware or automotive
retailers).
Option 2: Winterization without membrane rack removal - If the system is going to be
exposed to freezing or near freezing temperature while being stored and the membrane rack
cannot be removed and stored in a heated climate, the following should be done. A 50% solution
of storage chemical and 50% propylene glycol should be run through the entire system from sea
cock to overboard andthen valveoff both seacock and overboard. Membrane storage chemical
part # is 252404263.
NOTE: PROPYLENE GLYCOL CAN BE PURCHASED AT MOST HARDWARE OR
AUTOMOTIVE RETAILERS
WARNING:DO NOT USE ETHYLENE GLYCOL, ONLY NON-TOXIC
PROPYLENE GLYCOL SHOULD BE USED.
RE-COMMISSIONING OF SYSTEM AFTER STORAGE OR WINTERIZATION
After storage or winterization, the system must be completely voided of all storage chemical and
or propylene glycol. To do this, follow the new system startup guide on page 33.
15

Bacteriostatic
Remineralizer
(P/N 252404141)
Feed From
Desalinator
Product
To Tank
3/8" OD
3/8" OD
1/2" OD
1/2" OD
1/2" OD
Feed From
Pre-Filtration
Membrane
Return
3/4" OD 1/2" OD
SPOT ZERO
Pre-Filter
(P/N 252404301)
To Ships Fresh
Water Tank
Overboard
Membrane
Supply
Membrane
Product FW
Feed Water Inlet
(Feed From Dock)
Notes: 1) The tubing or piping used for the inlet of the feed water is 3/4" I.D. 2) The tubing or piping used for the discharge of the concentrate is 1/2" O.D.
and should be run to an open over board in a free and unrestricted manner.'
3) A pressure relief valve is recommended in the "Feed from
Desalinator" set at 8 psi.
1/2" OD
SHIP
SUPPLIED
SHEET 1 OF 2
1/14/20
ES
UNLESS OTHERWISE SPECIFIED:
SCALE: 1:10
DWG. NO. PD0002
NAME
DATE
Q.A.
MFG APPR.
ENG APPR.
CHECKED
DRAWN
DIMENSIONS ARE IN INCHES TOLERANCES:
.015
FRACTIONAL
1/32
ANGULAR: MACH
1/2 BEND
1
TWO PLACE DECIMAL
.010
THREE PLACE DECIMAL
.005
PROPRIETARY AND CONFIDENTIAL THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF SPOT ZERO. ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF SPOT ZERO IS PROHIBITED.
DWG. REV C
ZTCII One Line Flow Drawing
16

DP Tank
Level Sensor
(TL)
EGND
EGND
L2 BP
L1
L2 HP
L2
TDS
TL
PO/PP
CP
PF PI/RF CF
N2K
FWSW
DSPL
FWF/IS
CV
PV
DV
BPR
YEL
WHT
GRY
GRN
BLK
RED
SHIELD
WHT
BLK
RED
BLK
RED
BRN
RED
BLK
BRN
RED
BLU
WHT
RED
BLK
WHT
BLK
RED
BLK
WHT
RED
GRN
WHT
GRN
BLK
RED
BLK
RED
BLK
RED
BLK
RED
BLK
RED
WHT
BLK BLK
BRN
RED
B(-)
A(+)
GND
GND
+24VDC
B(-)
A(+)
GND
GND
+24VDC
EGND
EGND
L2
BP
L1
L2
HP
L2
FWSW
WHT
BLK
RED
System Enclosure
NEMA2K Bus
(Optional)
XTCII System
(Optional)
GND L2 L1
Inlet Power
Supply
L2
L2
L1
L1
GND
GND
Touch Panel
Optional Remote Touch Panel
ZTCII
Product
TDS
Pump
Pressure
(PO/PP)
Concentrate
Pressure
(CP)
Product
Flow
(PF)
Inlet Source
(FWF/IS)
Backpressure
Regulator
Valve
(BPR)
HP RO
PUMP
Product
Valve (PV)
Conc Vavle
(CV)
Recycle
Flow
(PI/RF)
Concentrate
Flow
(CF)
REVISIONS
REV.
DESCRIPTION
DATE
APPROVED
C
PRODUCT TDS WHITE/YELLOW AND GREEN/GRAY WIRES FLIPPED
10/13/2020
SHEET 1 OF 1
1/27/2020
ES
UNLESS OTHERWISE SPECIFIED:
SCALE: NTS
DWG. NO. ED1004
NAME
DATE
Q.A.
MFG APPR.
ENG APPR.
CHECKED
DRAWN
DIMENSIONS ARE IN INCHES TOLERANCES:
.015
FRACTIONAL
1/32
ANGULAR: MACH
1/2 BEND
1
TWO PLACE DECIMAL
.010
THREE PLACE DECIMAL
.005
PROPRIETARY AND CONFIDENTIAL THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF SPOT ZERO. ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF SPOT ZERO IS PROHIBITED.
ZTCII Wiring Diagram
DWG. REV C
17

3. OPERATION AND MAINTENANCE
18

ITEM NUMBER DESCRIPTION MAINTENANCE
FREQUENCY
252404301 Freshwater Double Stack Pre- Filter (Sediment + KDF)
4.5”x20” Every 100 Hours
252404005 Spot Zero Sediment Pre-Filter
4.5”x10” Every 100 Hours
252404004 Spot Zero Heavy Metal
Removal (KDF) 4.5”x10” Every 100 Hours
252404141 Bacteriostatic Remineralizer
Cartridge 2.5”x10” Every 100 Hours
252404006 Spot Zero Chemical Cleaning
Cartridge 4.5”x10”As needed when production becomes reduced
252404448 Spot Zero Freshwater Membrane Replacement for
4041 Housing
Every 1,000 Hours or
100,000 Gallons of Use
ZTCII CONSUMABLE ITEMS
19

SPOT ZERO ZTCII TOUCHSCREEN NAVIGATION
HOME SCREEN
From any screen the Spot Zero icon can be pressed to return to this home screen. There is also
a lot of information on this home screen that is important to the operation of this system. Some
of the images can be pressed to bring up different information and setting choices. Also, the
menu button can be pressed to access more information. This manual will go through these
options.
OPERATION PROCEDURES
The Spot Zero ZTCII is a fully automatic system. The capacity of the system is shown on the
membrane in center of the screen. It will operate when water is present and shut down when
water is no longer fed to the system. On the home screen the double pass processing tank
shows the water level present in the system. When the tank is full the unit will start to operate.
When the tank is emptied, the system will shut down.
System will turn ON System will turn OFF
HOME SCREEN MENU
20
