SQ Professional gems LUMINATE User manual

INSTRUCTION MANUAL
PLEASE READ THESE INSTRUCTIONS CAREFULLY BEFORE USE
gems
LUMINATE
BLENDER & GRINDER
SQIM 5942-5943-5944-5945-5946-5956-5957-7207 27-04-2021 V15 | SQ Professional Ltd © 2021 All rights reserved

2
Due to sharp parts and potential hazards, this appliance should not be used by children
under 16 years old unless supervised by an adult.
Please keep the appliance and mains cable out of the reach of children. This is not a toy!
If used by persons with reduced physical, sensory or mental capabilities, instruction and
supervision must be given to understand the use of the appliance and the hazards involved.
Always disconnect the appliance from the power socket if it is left unattended and before
assembling, disassembling or cleaning.
If the mains cable is damaged, it must be replaced by qualified persons
in order to avoid any hazards.

3
FEATURES
1 Measuring cup
2 Lid
3 Grinding mill cover
4 Grinding mill
5 Glass blending jug
6 Rubber sealing ring
7 Cutting blade
8 Jug base
9 Motor unit
10 Rotary switch
11 Assembled blender
12 Assembled grinder
13 Assembled jug base unit
SHARP BLADES!
9
10
11
12
13
1
2
3
4
5
6
7
8

4
IMPORTANT SAFEGUARDS
Do not use the appliance in a bathroom, near water,
or outdoors. Do not operate the appliance with wet
hands or bare feet.
Do not immerse any of the parts (appliance, mains
cable, plug) in water or other liquids during use to
protect from fire, electric shock and personal injury.
Do not use the appliance if it is damaged or
malfunctioning.
Do not leave the appliance unattended whilst in use.
Use and store it out of reach of children.
Keep hands and utensils out of the blending jug
6
while blending to reduce the risk of severe injury. A
spatula may be used but only when the appliance is
not running.
• This appliance is intended for household use only.
• Do not use this appliance for any other purpose than its
intended use.
• Ensure that the appliance is always placed on a firm and
flat surface, away from any edges of the worktop. Do not
place the appliance onto a metal tray or metal surface
whilst in use. Do not place the appliance on, or near, a
hot gas or electric burner or in a heated oven.
• Keep the appliance and mains cable away from the
edges of worktops and out of reach of children. Route
the mains cable so it does not overhang, and cannot be
tripped over or caught.
• Do not let the mains cable run across an open space,
such as between a low power socket and a table, or
across any hot area, such as a cooker. Heat may damage
the mains cable.
• The connections on both sides of the mains cable
(the appliance and the power socket) should never
be strained. If the mains cable is damaged it must be
replaced by a qualified person or service to avoid any
hazards.
• This appliance must not be operated by an external timer
or a remote control system.
• The jug base
8
should always be kept dry. Before
washing and drying disconnect the power supply;
ensure that the jug base
8
is completely dry before you
reconnect the appliance to power supply.
• To reduce the risk of injury, never attach the cutting
blade
7
directly onto the motor unit
9
without the
glass blending jug
5
properly attached.
• Ensure the lid
2
or grinding mill cover
3
are securely in
place and the glass blending jug
5
or grinding mill
4
is correctly inserted into the motor unit
9
before
operating the appliance.
• Do not switch on the appliance when it is empty. Ensure
there is the at least a minimum amount of liquid or solid
ingredients in the glass blending jug
5
or grinding mill
4
.
• Always close the lid
2
or have the grinding mill cover
3
in place before you switch the appliance on. Do not open
the lid
2
or grinding mill cover
3
whilst the appliance
is running.
• Switch off the appliance and unplug from the power
socket before changing attachments or approaching
parts that move while in use. Unplug the appliance when
not in use.
• Ensure that the appliance has come to a complete stop
before cleaning and storing away. Keep the attachments,
motor unit
9
, mains cable, and plug away from sources
of heat. Store in a dry place.
• Use the glass blending jug
5
or grinding mill
4
only
with the motor unit
9
supplied (and vice versa) and do
not tamper with the connector in any way.
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE
BEFORE FIRST USE
All parts that come in touch with food are to be
thoroughly cleaned before being used for the first
time (see section on Cleaning).
Ensure that the rotary switch
10
is in the position 0and plug
it into the power socket.

5
ASSEMBLY OF THE GLASS BLENDING JUG OR GRINDING MILL
The blades are extremely sharp. Handle carefully!
• Place the rubber sealing ring
6
on the cutting blade
7
as shown in image A.
• Insert the blade unit with the rubber sealing ring
6
into
the jug base
8
. image B
• Mount the glass blending jug
5
onto the jug base unit
13
.
Turn the jug base unit
13
clockwise until it is securely
attached. image C
• Make sure that the motor unit
9
is switched off (turn
the rotary switch
10
to the 0 setting).
• Place the assembled glass blending jug
5
or grinding
mill
4
onto the motor unit
9
and align the grooves.
Push down until securely engaged. image D
A
C D
BOPERATING INSTRUCTIONS
• Assemble the blender
11
or grinder
12
and ensure that
the rotary switch
10
is turned to 0. Remove the lid
2
or
the grinding mill cover
3
.
• BLENDER: Place the ingredients into the glass blending
jug
5
and attach the lid
2
by pressing down firmly.
Pour the liquids through the opening in the lid
2
then
insert the measuring cup
1
and turn it anti-clockwise
until it is locked.
• For best results do not fill the glass blending jug
5
above the 1L marking, especially if using liquid
ingredients.
• GRINDING MILL: Place the ingredients into the grinding
mill
4
. Attach the grinding mill cover
3
and turn it
counter-clockwise until it locks.
• Turn the rotary switch
10
to desired speed to switch the
appliance on.
SPEED SETTINGS
1LOW SPEED - for light blending of liquid ingredients
2HIGH SPEED - for heavy blending with solid
ingredients and thicker liquids.
PULSE SHORT BURSTS OF VERY HIGH SPEED - for rough
blending of solid ingredients and thicker liquids,
ice crushing, grinding and short, powerful pulse
movements. The dial does not permanently engage
in the PULSE setting; you must hold the dial in
position or turn repeatedly to the PULSE setting.
After using the blender
11
or the grinder
12
, always turn
the rotary switch
10
back to the 0 setting and disconnect
the mains cable from the power socket. To remove the glass
blending jug
5
just lift it straight up.

6
USEFUL TIPS
• To achieve the best results when pureeing solid
ingredients, place small portions into the glass blending
jug
5
one by one instead of placing a large quantity all
at once. Do not overload.
• When processing solid ingredients, cut them into small
pieces (2-3cm) first.
• When mixing solid ingredients start off first with a small
amount of liquid. Gradually add more of the liquid
through the opening in the lid
2
.
• If blending warm liquids or ingredients always ensure
that they are cooled down before blending. Do not fill
the glass blending jug
5
over 1L / 4 cups mark.
• Always stabilise the glass blending jug
5
or grinding mill
4
by placing your hand on top of the lid
2
or grinding
mill cover
3
when operating the appliance.
• For stirring solids or very thick liquid ingredients we
recommend that you use the blender
11
in PULSE mode
to prevent the blades from becoming stuck.
CLEANING
Never immerse the motor unit in water.
Wipe the motor unit
9
clean with a damp cloth and dry
immediately with a soft cloth to avoid scratches and water
marks on the surface.
LIGHT CLEANING
• BLENDER: empty the glass blending jug
5
and fill it half
way with tepid water and a mild detergent. Place the glass
blending jug
5
on the motor unit
9
and turn the rotary
switch
10
several times into the PULSE setting, holding for a
few seconds each time. Empty the glass blending jug
5
and
rinse until clean, then dry.
• GRINDING MILL:to clean the grinding mill
4
wipe inside
it with a damp cloth or sponge, using a tepid water
with some washing up liquid, if necessary. Remove any
stuck food remains with a small dish washing brush. Dry
immediately with a soft cloth.
THOROUGH CLEANING
Be careful when handling the blade inside the jug.
The blades are very sharp.
• BLENDER: Ensure that the grinding mill
4
or blending jug
5
is completely empty before you unscrew the jug base
unit
13
. Carefully detach the cutting blade
7
and wash
it. To remove the stuck food around the blades use a
small dishwashing brush.
• All parts except the motor unit
9
can be washed by
hand or in a dishwasher. Do not use harsh scourers and
aggressive or abrasive detergents.

7
GUARANTEE
The guarantee for this product is covered by SQ Professional
Limited. Any faults with this product arising through a
manufacturer defect will be covered for 1 year from the date
of purchase, subject to a valid vat receipt being presented.
This does not include faults or damage caused by misuse of
general wear and tear. SQ Professional Ltd will not be held
liable for general wear and tear, or eventual damages to
persons, animals or objects caused by incorrect installation
or deriving from improper, erroneous or unreasonable use.
Please contact customer services on 01992 716 070 or send
an e-mail to [e-mail], Monday to Friday
from 09:30 - 17:30.
This does not affect your statutory rights.
ENVIRONMENTAL
To reduce environmental and health problems
due to hazardous substances in electrical and
electronic goods, appliances marked with
the symbol below must not be disposed of
with unsorted municipal waste. Please repair,
reuse or recycle appropriately.
SPECIFICATIONS
Rated Voltage: 220-240V~
Frequency: 50/60Hz
Rated Power: 500W
Blending jug capacity: 1.5L
Grinding mill capacity: 100g
ELECTRICAL
The product must not be used without the fuse
cover fitted.
Should the power cable or the power plug become
damaged, arrange for these to be replaced by Customer
Service or a qualified person before continuing to use the
appliance. The appliance is fitted with a 10A fuse (BS1362) in
a 10A plug (BS1363).
AC 220-240V ~ 50/60Hz
SERVICE
The product is not user-serviceable. If it is not working, read
the instructions, check the plug fuse and main fuse/circuit
breaker. If it is still not working, consult your retailer.
If that does not solve the problem ring Customer Service –
they may be able to offer technical advice. Please have the
Model Number to hand, as they will not be able to help you
without it.
If you are advised to return the product to us, pack it
carefully, include a note with your name, address, day phone
number, and description of the problem.
If under a guarantee, say where and when it was purchased
and include a valid VAT receipt. Send it to SQ Professional Ltd.
All images are for illustration purposes only. Actual products may vary.

SCAN THE QR CODE TO EXPLORE
OUR FULL PRODUCT RANGE.
Voltage Business Centre, Units 1 - 3
6 Mollison Avenue, Eneld, EN3 7XQ
T: 01992 716 070 | F: 01992 700 538
E: [email protected]
WWW.SQPROFESSIONAL.COM
gems
LUMINATE
BLENDER & GRINDER
