SQ Professional MINI BLITZ CHOPPER User manual

Before operating this unit, please read these instructions completely.
Instruction
Manual
MINI BLITZ CHOPPER

SQ Professional Ltd © 2016 All rights reserved
Mini Blitz Chopper - Operation Manual
Contents
2
Table of Contents
Important Safeguards ......................................................... page 3
Features ............................................................................. page 4
Before rst use ................................................................... page 5
Assembly ........................................................................... page 5
Chopping tips ..................................................................... page 5
Cleaning ............................................................................. page 6
Processing guide ................................................................ page 6
Wiring UK plugs .................................................................. page 7
Environmental protection ................................................... page 7
Servicing ............................................................................ page 7
Warranty ............................................................................ page 7

All images are for illustration purposes only. Actual products may vary.
IMPORTANT SAFEGUARDS
Mini Blitz Chopper - Operation Manual
3
IMPORTANT SAFEGUARDS
Warnings and important safety instruc-
tions appearing in this manual are not
meant to cover all possible conditions
and situations that may occur. Common
sense, caution and care must be exercised
when installing, maintaining, or operating
the appliance.
When using any electrical appliance, basic
safety precautions should always be ad-
hered to including the following:
1 Read all instructions before using the
appliance.
2 To protect against risk of electrical
shock never let the power unit, plug
or cord get wet. Do not put the unit in
water or any other liquids.
3 Do not let the cord hang over the edge
of the worktop or table, or get in touch
with hot surfaces. Do not place the ap-
pliance near hot surfaces, such as gas/
electric hobs or in a heated oven.
4 This appliance is not intended for use
by persons (including children) with
reduced physical, sensory or mental
capabilities, or lack of experience and
knowledge, unless they have been
given supervision or instruction con-
cerning use of the appliance by a per-
son responsible for their safety.
5 Children should not use this appliance.
Close supervision is necessary when
any appliances are used near children.
6 Never leave the appliance unatten-
ded whilst it is switched on.
7 Unplug from the mains socket when
the appliance is not in use, or before
tting or removing parts, and before
cleaning.
8 Avoid contact with moving parts. Keep
hands and utensils out of the bowl
whilst connected to the power supply.
Remove the blade unit before empty-
ing the bowl.
9 Do not operate any appliance with a
damaged cord or plug, or after the
appliance is dropped or damaged in
any manner. Return the appliance to
the nearest authorised service facility
for examination, repair or mechanical
adjustment.
10 The use of attachments is not recom-
mended by the manufacturer and may
carry a risk of injury to persons.
11 Do not use outdoors.
12 This appliance is not suitable for pro-
cessing very hard foods, such as ice
cubes, coee beans, hard spices, grind-
ing granulated sugar to caster sugar,
or processing hot liquids. Only process
small amount of food at a time.
13 Blades are sharp, handle with care.
Hold the blade 5at the top away from
the cutting edge, both when handling
and cleaning.
14 Ensure safety cover 3and motor
block 2are securely locked in place
before operating the appliance.
15 Do not switch on the appliance when it
is empty.
16 Do not use the appliance for any other
purpose than its intended use. SQ Pro-
fessional®will not accept any liability if
the appliance is subject to improper
use or failure to comply with these in-
structions.
SAVE THESE INSTRUCTIONS

SQ Professional Ltd © 2016 All rights reserved
Mini Blitz Chopper - Operation Manual
Features
4
FEATURES
1Button
Motor block
3Safety cover
4Sealing ring
5Blade
6Glass bowl
7Drive shaft
8Anti-slip rubber
base
Voltage:
220-240V ~ 50Hz
Power rating:
300W
Maximum capacity:
250g / 600ml
2

All images are for illustration purposes only. Actual products may vary.
OPERATION & USE
Mini Blitz Chopper - Operation Manual
5
Before rst use
1 Make sure your electricity supply
is the same as the one shown on
the underside of the power unit.
2 Remove all the packaging and
place the appliance on a dry, at,
heat-resistant, non-ammable
surface.
3 Wash and dry all the parts
thoroughly (see ‘Cleaning’).
Assembly
A Place the 8anti-slip rubber
base on a at, dry surface. Put
the 6glass bowl on the base.
BFit the blade 5on the drive
shaft 7. You can now place your
ingredients in the bowl.
B Ensure that the sealing ring 4
is attached to the safety cover
3and place the cover onto the
bowl.
C Insert the motor block 2into
the safety cover 3and allign.
The chopper will not operate
unless the motor block, safety
cover and the bowl are correctly
engaged.
Remove the safety cover, blade
and bowl after use for cleaning. All
parts except the motor block are
dishwasher safe.
Chopping tips
1 The capacity of the bowl is
600ml. Never exceed 200ml of
liquid or 350ml marking of dry
ingredients.
2 Best results are obtained by
chopping small quantities at one
time.
3 To ensure even processing, stop
the appliance and scrape down
any food with a plastic spatula.
4 Cut food such as carrots,
celeries, mushrooms, green
peppers, onions, etc. into small
pieces (1cm chunks) to obtain
uniform consistency.
5 To chop dry foods such as nuts,
bread crumbs, crackers, cookies,
etc. cut them in smaller pieces.
Ensure that the bowl, blade,
safety cover and the food are
thoroughly dry.
6 When processing heavy
ingredients, avoid running the
motor continuously for periods
over 30 seconds without resting.
7 Do not process raw or cooked
meat, cheese, coee beans,
chocolate pieces as this could
damage the chopper.
8 Beware of over processing some
ingredients. Stop and check the
consistency frequently.

SQ Professional Ltd © 2016 All rights reserved
Mini Blitz Chopper - Operation Manual
Cleaning
6
9 When preparing food for babies
or infants, always check that
the ingredients are thoroughly
blended before feeding.
10 Do not touch moving parts and
keep hands and utensils out of
the bowl when the appliance is
in operating mode to reduce risk
of severe injury to persons and
damage to the appliance.
Cleaning
The appliance should be thoroughly
cleaned and dried after every use.
1 Switch o and unplug the
appliance.
2 Handle the blade with great care
when removing it from the bowl -
it is extremely sharp.
3 Wash the bowl, safety cover and
blade in warm, soapy water then
dry all elements thoroughly.
Alternatively you can wash these
elements on the top rack of the
dishwasher.
4 Wipe the motor block with
a damp cloth and dry it
thoroughly.
Processing guide
FOOD MAX.
CAPACITY
PROCESSING TIME
SALAMI 130g 3 x 5 seconds
CHEESE 200g 4 x 15 seconds
ONION OR
GARLIC
150g Pulsing
CARROTS 200g 3 x 5 seconds
DRIED FRUIT 130g 4 x 15 seconds
ALMONDS 150g Coarse: 1 x 10 seconds
Medium: 2 x 10 seconds
Fine: 3 x 10 seconds
EGGS
(HARD BOILED)
150g 2 x 4 seconds
WALNUTS 150g 2 x 10 seconds
BREAD 100g 10 seconds
PARSLEY 50g 2 x 5 seconds

All images are for illustration purposes only. Actual products may vary.
SERVICE & WARRANTY
Mini Blitz Chopper - Operation Manual
7
Service
The product is not user serviceable. If
it is not working, read the instructions,
check the plug fuse and main fuse/
circuit breaker. If it is still not working,
consult your retailer. If that does not
solve your problem, ring Customer
Services - they may be able to oer
technical advice. If they advise you to
return the product to us, pack it care-
fully, include a note with your name,
address, day phone number, and de-
scription of the problem. If under a
guarantee, say where and when it was
purchased and include proof of pur-
chase. Send it to SQ Professional Ltd.
WARRANTY
THE WARRANTY FOR THIS PRO-
DUCT IS COVERED BY SQ PROFES-
SIONAL LIMITED. ANY FAULTS WITH
THIS PRODUCT ARISING THROUGH
A MANUFACTURER DEFECT WILL BE
COVERED FOR 1 YEAR FROM THE
DATE OF PURCHASE, SUBJECT TO A
VALID PROOF OF PURCHASE BEING
PRESENTED. THIS DOES NOT IN-
CLUDE FAULTS OR DAMAGE CAUSED
BY MISUSE OF GENERAL WEAR AND
TEAR. PLEASE CONTACT CUSTOMER
SERVICES ON 01992 716 070 OR
[email protected],
MONDAY TO FRIDAY FROM 09:30 -
17:30. THIS DOES NOT AFFECT YOUR
STATUTORY RIGHTS.
Wiring UK plugs
The product must be earthed. It has
a 13A BS1362 fuse in a 13A BS 1363
plug. To replace the plug, t the green-
yellow wire to or E, blue wire to N
and the brown wire to L. Fit the cord
grip. If in doubt, call an electrician.
Do not use a non-wireable plug
unless the fuse cover is in place. If
you remove the plug, dispose of it.
Environmental protection
To avoid environ-
mental and
health problems
due to hazard-
ous substances
in electrical
and electronic
goods, appliances marked with this
symbol must not be disposed of
with unsorted municipal waste, but
recovered, reused or recycled.

Voltage Business Centre, Units 1 - 3
6 Mollison Avenue, Eneld, EN3 7XQ
T: 01992 716 070 |F: 01992 700 538
[email protected]
www.sqprofessional.com
