Zipp 60 & Zipp 30
Service Manual
2
SRAM LLC WARRANTY
Extent of Limited Warranty
Except as otherwise set forth herein, SRAM warrants its products to be free from defects in materials or workmanship for a period
of two years after original purchase. This warranty only applies to the original owner and is not transferable. Claims under this
warranty must be made through the retailer where the bicycle or the SRAM component was purchased. Original proof of purchase
is required. Except as described herein, SRAM makes no other warranties, guaranties, or representations of any type (express or
implied), and all warranties (including any implied warranties of reasonable care, merchantibility, or fitness for a particular purpose)
are hereby disclaimed.
Local law
This warranty statement gives the customer specific legal rights. The customer may also have other rights which vary from state to
state (USA), from province to province (Canada), and from country to country elsewhere in the world.
To the extent that this warranty statement is inconsistent with the local law, this warranty shall be deemed modified to be
consistent with such law, under such local law, certain disclaimers and limitations of this warranty statement may apply to the
customer. For example, some states in the United States of America, as well as some governments outside of the United States
(including provinces in Canada) may:
Preclude the disclaimers and limitations of this warranty statement from limiting the statutory rights of the consumer
(e.g. United Kingdom).
Otherwise restrict the ability of a manufacturer to enforce such disclaimers or limitations.
For Australian customers:
This SRAM limited warranty is provided in Australia by SRAM LLC, 133 North Kingsbury, 4th floor, Chicago, Illinois, 60642, USA. To
make a warranty claim please contact the retailer from whom you purchased this SRAM product. Alternatively, you may make a
claim by contacting SRAM Australia, 6 Marco Court, Rowville 3178, Australia. For valid claims SRAM will, at its option, either repair
or replace your SRAM product. Any expenses incurred in making the warranty claim are your responsibility. The benefits given by
this warranty are additional to other rights and remedies that you may have under laws relating to our products. Our goods come
with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a
major failure and for compensation for any other reasonably foreseeable loss or damage. You are also entitled to have the goods
repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure.
Limitations of Liability
To the extent allowed by local law, except for the obligations specifically set forth in this warranty statement, in no event shall
SRAM or its third party suppliers be liable for direct, indirect, special, incidental, or consequential damages.
Limitations of Warranty
This warranty does not apply to products that have been incorrectly installed and/or adjusted according to the respective SRAM
user manual. The SRAM user manuals can be found online at sram.com, rockshox.com, avidbike.com, truvativ.com, or zipp.com.
This warranty does not apply to damage to the product caused by a crash, impact, abuse of the product, non-compliance with
manufacturers specifications of usage or any other circumstances in which the product has been subjected to forces or loads
beyond its design.
This warranty does not apply when the product has been modified, including, but not limited to any attempt to open or repair
any electronic and electronic related components, including the motor, controller, battery packs, wiring harnesses, switches, and
chargers.
This warranty does not apply when the serial number or production code has been deliberately altered, defaced or removed.
This warranty does not apply to normal wear and tear. Wear and tear parts are subject to damage as a result of normal use,
failure to service according to SRAM recommendations and/or riding or installation in conditions or applications other than
recommended.
Wear and tear parts are identified as:
Dust seals
Bushings
Air sealing o-rings
Glide rings
Rubber moving parts
Foam rings
Rear shock mounting
hardware and main seals
Upper tubes (stanchions)
Stripped threads/bolts
(aluminium, titanium,
magnesium or steel)
Brake sleeves
Brake pads
Chains
Sprockets
Cassettes
Shifter and brake cables (inner
and outer)
Handlebar grips
Shifter grips
Jockey wheels
Disc brake rotors
Wheel braking surfaces
Bottomout pads
Bearings
Bearing races
Pawls
Transmission gears
Spokes
Free hubs
Aero bar pads
Corrosion
Tools
Motors
Batteries
Notwithstanding anything else set forth herein, this warranty is limited to one year for all electronic and electronic related
components including motors, controllers, battery packs, wiring harnesses, switches, and chargers. The battery pack and charger
warranty does not include damage from power surges, use of improper charger, improper maintenance, or such other misuse.
This warranty shall not cover damages caused by the use of parts of different manufacturers.
This warranty shall not cover damages caused by the use of parts that are not compatible, suitable and/or authorised by SRAM for
use with SRAM components.
This warranty shall not cover damages resulting from commercial (rental) use.
3
Table of Contents
Rear Hub Service ........................................................................................................................................................................ 5
Tools Needed for Service .................................................................................................................................................................................................................. 5
Replacement Parts ............................................................................................................................................................................................................................... 5
Disassembly............................................................................................................................................................................................................................................. 6
Assembly .................................................................................................................................................................................................................................................. 8
Front Hub Service...................................................................................................................................................................... 11
Tools Needed for Service ..................................................................................................................................................................................................................11
Replacement Parts ...............................................................................................................................................................................................................................11
Disassembly............................................................................................................................................................................................................................................12
Assembly .................................................................................................................................................................................................................................................13
Wheel Build & Spoke Replacement........................................................................................................................................15
Tools Needed for Service .................................................................................................................................................................................................................15
Wheel Build Tips...................................................................................................................................................................................................................................15
Replacement Parts ..............................................................................................................................................................................................................................15
Zipp 30 and Zipp 60...........................................................................................................................................................................................................................15
Rear Wheel Lacing .............................................................................................................................................................................................................................16
Front Wheel Lacing.............................................................................................................................................................................................................................17
4
SAFETY FIRST!
We care about YOU. Please, always wear your safety glasses and
protective gloves when servicing Zipp products.
Protect yourself! Wear your safety gear!
5
Rear Hub Service
You can service your hub while the hub is still in the wheel. However, if your spokes or rim are damaged, you can remove the
hub from the wheel which will make servicing your hub easier. To remove the hub, use a spoke wrench to detension the spokes,
then use a pair of metal snips to cut the spokes, remove the hub from the wheel, and remove the spoke ends from the hub (not
pictured).
Tools Needed for Service
Safety glasses
Nitrile Gloves
5 mm hex wrench
20 mm cone wrench
Enduro Universal Blind Hole Bearing Puller Set
17 mm Blind Hole Bearing Puller slotted attachment
Wheels Manufacturing Press-1 Sealed Bearing Press Kit
(2) 6903 Adapters from Press-1 Kit
Lithium-based grease
Grease brush
Replacement Parts
Hub bearings
Driver body
Driver body pawls
Driver body leaf springs
Driver body seal
End cap
Washer
For part numbers, please refer to the Zipp Spare Parts Catalog in the Support section of www.zipp.com.
Rear Hub
Hub shell
Axle
Driver body
Washer
End cap
Hub bearing
Spacer
Hub bearing
Driver body seal
6
Disassembly
1
Insert a 5 mm hex wrench into the drive side end cap while
holding the non-drive side end cap with a 20 mm cone wrench.
Hold the 5 mm wrench in place and turn the 20 mm cone
wrench counter-clockwise to remove the non-drive side end
cap.
The drive side end cap is attached to the axle and cannot be
removed.
2
Remove the driver body assembly from the hub shell.
3
Remove the axle, by hand, from the driver body.
5 mm 20 mm
7
4
Locate and remove the flat washer from in between the driver
body and hub shell bearing. Discard if replacing or set it aside
until the hub is ready for reassembly.
5
Insert the 17 mm Blind Hole Bearing Puller slotted attachment
through the non-drive side bearing. Align the attachment with
the bottom of the bearing, and tighten it inside the bearing.
Do not over tighten the slotted attachment. For more detailed
assembly and usage, see your bearing puller's manufacturer's
instructions.
Thread the bearing puller rod into the attachment. Grip the
handle and forcefully pull out to remove the bearing from the
hub shell.
Remove the spacer from the hub shell; discard if replacing or
set it aside until the hub is ready for reassembly.
Remove the bearing from the bearing puller. Repeat this
process to remove the drive side bearing.
6
Use your fingers or a pick to carefully remove the pawls and
leaf springs. If any of the pawls or leaf springs exhibit signs of
damage, replace all of them. Otherwise, remove any grease on
the pawls and leaf springs with a clean rag.
17 mm
Pawl
Leaf Spring
8
7
Use your fingers to remove the driver body seal. Inspect the
driver body seal for signs of damage or wear. If there are any
signs of damage or wear, replace it. Otherwise, remove any
grease on the driver body seal with a clean rag.
Assembly
1
Press the driver body seal, with the smooth side facing the
driver body, over the leaf spring and pawl carrier.
The driver body seal must be fully seated against the thin
shoulder of the driver body.
2
Insert the leaf springs into the spring slots. Orient the long
edge of each spring along the inside of the carrier so that it
points clockwise.
3
Insert the pawls into the pawl slots. You may need to use a pick
to compress each leaf spring to assist with inserting the pawls.
Orient the cambered edge (the edge that is slightly more
curved) of each pawl along the outside of the carrier so that it
points counter-clockwise.
9
4
Insert the axle through the driver body.
5
Slide the flat washer over the axle until it rests on the leaf
spring and pawl carrier.
6
Install the spacer and a new bearing into the end of the hub
shell by hand.
Install the drive side bearing first.
7
Install a 6903 adapter onto the Wheels Manufacturing Press-1
Sealed Bearing Press tool. Slide the threaded rod of the
bearing press through the non-drive side end of the hub shell
and out of the drive side of the hub shell.
Twist the bearing press handle onto the threaded rod.
Turn the bearing press handle clockwise to press the bearing
into the hub until it is hand-tight.
Do not overtighten the bearing.
Repeat this process to install the other new bearing.
NOTICE
To prevent damage to the bearing, only use a bearing press
tool that contacts both the inner and outer races of the
bearing. Do not use a bearing press tool that contacts only one
race.
6903
10
8
Apply a small amount of lithium based grease (an amount
roughly half the size of a pea) to the driver body rachet ring.
9
Slide the driver body assembly through the drive side of the
hub shell. Use your fingers to compress the pawls to fully seat
and engage the pawls with the driver body ratchet ring.
NOTICE
The hub shell's floating spacer can become oset during hub
reassembly. If this occurs, use your finger to realign and center
the spacer.
10
Insert a 5 mm hex wrench into the drive side end cap. Hold the
wrench in place and gently thread the non-drive side end cap,
by hand, onto the axle until it bottoms out and stops turning.
Tighten non-drive side end cap to 5 N.m (45 in-lb).
For spoke installation, proceed to Wheel Lacing & Spoke
Replacement section (if necessary).
5 mm 5 N.m (45 in-lbs)
Spacer misaligned
Spacer correctly aligned
11
Front Hub Service
You can service your hub while the hub is still in the wheel. However, if your spokes or rim are damaged, you can remove the
hub from the wheel which will make servicing your hub easier. To remove the hub, use a spoke wrench to detension the spokes,
then use a pair of metal snips to cut the spokes, remove the hub from the wheel, and remove the spoke ends from the hub (not
pictured).
Tools Needed for Service
Safety glasses
Nitrile Gloves
(2) 5 mm hex wrenches
Enduro Universal Blind Hole Bearing Puller Set
Wheels Manufacturing Press-1 Sealed Bearing Press Kit
(2) 6803 Adapters from Press-1 Kit
Replacement Parts
Hub bearings
End cap
For part numbers, please refer to the Zipp Spare Parts Catalog in the Support section of www.zipp.com.
Front Hub
Hub shell
Spacer
Axle
Hub bearing
Hub bearing
End Cap
12
Disassembly
1
Insert a 5 mm hex wrench into both end caps. Hold the drive
side wrench in place and turn the non-drive side end cap
counter-clockwise to remove it.
The drive side end cap is attached to the axle and cannot be
removed.
2
Remove the axle, by hand, from the hub shell.
3
Insert the 17 mm Blind Hole Bearing Puller slotted attachment
through the non-drive side bearing. Align the attachment with
the bottom of the bearing, and tighten it inside the bearing.
Do not over tighten the slotted attachment. For more detailed
assembly and usage, see your bearing puller's manufacturer's
instructions.
Thread the rod of the bearing puller into the attachment. Grip
the handle and forcefully pull out to remove the bearing from
the hub shell.
Remove the spacer from the hub shell; discard if replacing or
set it aside until the hub is ready for reassembly.
Remove the bearing from the bearing puller. Repeat this
process to remove the non-drive side bearing.
5 mm
17 mm
13
Assembly
1
Install a new bearing and spacer into end of the hub shell by
hand.
Install the drive side bearing first.
2
Install a 6803 adapter onto the Wheels Manufacturing Press-1
Sealed Bearing Press tool. Slide the threaded rod of the
bearing press through the non-drive side end of the hub shell
and out of the drive side of the hub shell.
Twist the bearing press handle onto the threaded rod.
Turn the bearing press handle clockwise to press the bearing
into the hub until it is hand-tight. Do not overtighten the
bearing.
Repeat this process to install the other new bearing.
NOTICE
To prevent damage to the bearing, only use a bearing press
tool that contacts both the inner and outer races of the
bearing. Do not use a bearing press tool that contacts only one
race.
3
Insert the axle through the hub shell assembly.
NOTICE
The hub shell's floating spacer can become oset during hub
reassembly. If this occurs, use your finger to realign and center
the spacer.
6803
Spacer misaligned
Spacer aligned correctly
14
Insert a 5 mm hex wrench into the drive side end cap. Hold the
wrench in place and gently thread the non-drive side end cap
onto the axle until it bottoms out and stops turning. Tighten
non-drive side to 5 N.m (45 in-lb).
For spoke installation, proceed to Wheel Lacing & Spoke
Replacement section (if necessary).
4
5 mm 5 N.m (45 in-lbs)
15
Wheel Build & Spoke Replacement
This portion of the service guide covers general wheel build and spoke replacement. There are many different methods for spoke
tensioning; the following information provides the final spoke tension you should achieve using your preferred method for spoke
tensioning.
Tools Needed for Service
Safety glasses
Bladed spoke adjustment tool (ex. Park Tool®BSH-4)
Spoke wrench: Park Tool®SW-15 for internal spoke nipples
Spoke wrench: Park Tool®SW-40 for external spoke nipples
Tensiometer with tension conversion chart
Truing stand
Wheel Build Tips
•
1 cross lacing pattern
Lightly coat the threads of the replacement spokes with
Loctite®577.
• During the wheel build process, pre-stress the wheel by lightly
squeezing pairs of spokes to ensure the spokes seat properly in
both the hub and the rim.
• Zipp wheels use both radial and 1 cross spoke lacing patterns.
For 1 cross lacing patterns, the spokes that point rearward should
be installed on the bottom so they sit against the hub shell. The
spokes that point forward should be installed on the top.
• Control wheel roundness by tightening/loosening the drive side
spokes.
• Control wheel trueness by tightening/loosening the non-drive
side spokes.
• Use a bladed spoke adjustment tool to prevent the spokes from
twisting during adjustment.
Replacement Parts
For part numbers, please refer to the Zipp Spare Parts Catalog in the Support section of www.zipp.com.
Zipp 30 and Zipp 60
Use Sapim CX-Ray replacement spokes
Spoke Count Spoke Length Lacing Pattern Final Spoke Tension
Front Wheel
Drive side 9
Zipp 60: 246 mm
Zipp 30: 274 mm Radial Zipp 60: 110 ± 15 kgf (1079 N ± 147 N)
Zipp 30: 120 ± 15 kgf (1176 N ± 147 N)
Non-drive side 9
Rear Wheel
Drive side 10 Zipp 60: 236 mm
Zipp 30: 262 mm Radial Zipp 60: 110 ± 15 kgf (1079 N ± 147 N)
Zipp 30: 140 ± 15 kgf (1373 N ± 147 N)
Non-drive side 10 Zipp 60: 252 mm
Zipp 30: 278 mm 1 cross Zipp 60: 40 ± 20 kgf (392 N ± 196 N)
Zipp 30: 60 ± 20 kgf (588 N ± 196 N)
16
Rear Wheel Lacing
1. Start on the drive side of the wheel.
Zipp 60: Orient the wheel so that the serial number text in
the tire bed is upside down and the cassette driver body of
the rear hub is facing up.
Zipp 30: Orient the wheel so that the serial number text on
the rim wall is facing down, and the cassette driver body of
the rear hub is facing up.
2. Insert the threaded end of spoke 1into the first hole
to the
left
of the rim valve hole. Carefully thread a spoke nipple
onto the spoke, 1/2 turn. Install the head of spoke 1into
one of the spoke slots of the drive side hub flange.
3. Repeat this procedure for the remaining 9 drive side spokes,
following the illustrated drive side lacing pattern.
4. Carefully turn the wheel over so that the cassette driver
body is facing down.
5. Insert the threaded end of spoke 11 into the second hole
to the right
of the rim valve hole. Carefully thread a spoke
nipple onto the spoke, 1/2 turn. Install spoke 11 into the
hub flange spoke slot closest to the 3 o'clock position that
angles toward the valve hole
6. Insert the threaded end of spoke 12 into the fourth hole
to the right
of the rim valve hole. Carefully thread a spoke
nipple onto the spoke, 1/2 turn. Install spoke 12 into the
hub flange spoke slot closest to the 12 o'clock position that
angles to the right.
7. Repeat this procedure for the remaining 8 non-drive side
spokes. Refer to the spoke lacing diagram for the proper
spoke installation pattern.
8. Use a spoke wrench to turn each of the the drive side
spokes in 1/2 turn increments until the drive side spoke
tension is at approximately 30-40% of the final value:
45-60 kgf (441-588 N)
9. Install the wheel into a truing stand and check for
roundness. Tighten or loosen the drive side spokes until the
wheel is round.
10. Use a spoke wrench to turn each of the spokes in 1/2
turn increments to increase non-drive side spoke tension.
Continually check for roundness (vertical movement) and
trueness (side-to-side movement). Refer to the Wheel
Building Tips for ways to control roundness and truness.
11. Continue tightening both drive side and non-drive side
spokes in 1/8 - 1/4 turn increments until the final tension has
been acheived. Refer to the spoke chart for recommended
final tension measurements.
spoke nipple
drive side lacing pattern
valve hole
2
3
4
5
6
7
8
9
10
1
non-drive side lacing pattern
20 11
12
13
14
15
16
17
18
19
non-drive side spoke lacing diagram
20 11
12
13
14
15 16
17
18
19
17
Front Wheel Lacing
1. Orient the wheel so that the crescent of the hub logo is
facing the non-drive side of the wheel when assembled.
2. Insert the threaded end of spoke 1into the first hole
to the left
of the rim valve hole. Carefully thread a spoke
nipple onto the spoke, 1/2 turn. Loosen the endcap to allow
enough space for spoke installation. Install spoke 1into
one of the spoke slots of the hub flange.
3. Repeat this procedure for the remaining 8 spokes on this
side of the wheel, following the illustrated lacing pattern.
4. Carefully turn the wheel over.
5. Insert the threaded end of spoke 10 into the first hole
to the
left
of the rim valve hole. Carefully thread a spoke nipple
onto the spoke, 1/2 turn. Install spoke 10 into the hub flange
spoke slot closest to the 12 o'clock position.
6. Repeat this procedure for the remaining 9 spokes. Refer to
the spoke lacing diagram for the proper spoke installation
pattern.
7. Install the wheel into a truing stand. Use a spoke wrench to
turn each of the spokes in 1/2 turn increments to increase
spoke tension. Continually check for roundness (vertical
movement) and trueness (side-to-side movement).
8. Continue tightening both drive side and non-drive side
spokes in 1/8 - 1/4 turn increments until the final tension has
been acheived. Tighten the non-drive side endcap to 5 N.m
(45 in-lb). Refer to the spoke chart for recommended final
tension measurements.
10 11
12
13
14
15
16
17
18
radial lacing pattern
spoke nipple
valve hole
2
3
4
5
6
7
8
9
1
This manual suits for next models
1
Table of contents
Other SRAM Bicycle manuals
