SRS Lighting DTL16-DIN User manual
( 1 / 4)
Instruction Manual
Models:
version 1.0 since 3 February 2020
ATTENTION!
This instruction manual contains important information about the installation and the use of
the equipment. Please read and follow these instructions carefully.
Always ensure that the power to the equipment is disconnected before opening the
equipment or commencing any maintenance wor .
DTL16-DIN_en_manual_M271.doc
IN LE Strip immer
TL16- IN
( 2 / 4)
IMPORTANT SAFETY INFORMATION
The following general safety precautions have to be observed during all phases
of operation, service, and the repair of this equipment. Failure to comply with
these precautions or with specific warnings in this manual violates safety
standards of design, manufacture, and the intended use of this equipment.
Do not operate in an explosive atmosphere!
Do not operate this equipment in the presence of flammable gases or fumes.
Operation of any electrical instrument in such an environment constitutes
a definite safety hazard. Device should be never placed near or over a heat
register or other source of heated air and it should not be installed or operated
without proper ventilation.
DMX connection
DMX connectors are located on top side of board. DATA LED is indicating
presence of DMX data stream on DMX input
Sample of system schematics:
( 3 / 4)
Device in se / service:
By default, Power LED indicates the device is on main power. When the Power
LED is off, chec the main power input.
When the DMX cable is connected to the device, LED mar ed as DATA OK go on.
If case of any problems, do not hesitate to contact us via email at rma@srs-
group.com or call us at +421244681417. Don’t worry; we will fix your problems
for sure.
Technical data
AC/DC Power inp t:
DC 12-36V, 160mA
AC 12-24V, 160mA
DMX Inp t / O tp t:
1x USITT DMX512 /RS485/ isolated up to 1000V
Size & Ho sing:
111 x 96 x 59mm, 6 module DIN plastic box
Top panel:
Weight:
0.25 g
Temperat re of se:
-30...+45°C
Warranty:
2 years
( 4 / 4)
DECLARATION OF CONFORMITY
According to g idelines 89/336 EEC and 92/31 EEC:
Name of prod cer: SRS Group s.r.o.
Address of prod cer: Rybnicna 38/B, SK- 83106 Bratislava, Slova Republic
Declares that the product
Name of prod ct: DTL16-DIN DIN LED Strip Dimmer
Type: DTL16-DIN
Corresponds to the following product specifications:
Safety: EN60065, resp. EN 60950
EMC: EN55103-1, resp. EN55103-2
Bratislava, 19 August 2012
Robert Sloboda
Copyright 2017 SRS Group, s.r.o. | Specifications subject to change without notice.
Document: DTL16-DIN_en_manual_M271.doc | Version 1.0 | Actual as of: 3 February 2020
SRS Gro p s.r.o.
Rybnicna 38/B | 831 07 Bratislava | Slova ia
Phone: +421 2 32 661 800
Email: sales@srs-group.com | www.srs-group.com
