3One data IMC101B Series User manual

IMC101B Series
Industrial Media Converter
Quick Installation Guide
3onedata Co., Ltd.
Address: 3/B, Zone 1, Baiwangxin High Technology
Industrial Park, Xili, Nanshan District, Shenzhen
Website: www.3onedata.com
Tel: [phone]
Fax: [phone]
【Package Checklist】
Please check whether the package and accessories are intact
while using the media converter for the first time.
1
Industrial Media Converter
2
Quick installation guide
3
DIN-Rail mounting
attachment
4
AC power line (only for AC
device)
5
Certification
6
Warranty card
If any of these items are damaged or lost, please contact our
company or dealers, we will solve it asap.
【Product Overview】
This series are industrial media converters. For convenience,
the products of this series adopt the following number on the
left in this guide, please affirm the number of your product.
Model I. IMC101B-1F-P48 (1 100M copper port + 1 100M
fiber port, 1 9~48VDC power supply)
Model II. IMC101B-1F-P220 (1 100M copper port + 1 100M
fiber port, 1 100~240VAC/DC power supply)
Model III. IMC101B-1S-P48 (1 100M copper port + 1 100M
SFP slot, 1 9~48VDC power supply)
Model IV. IMC101B-1S-P220 (1 100M copper port + 1 100M
SFP slot, 1 100~240VAC/DC power supply)
【Panel Design】
Rear view, Bottom view and Top view
Front view and Side view
Model I, Model II
Model III, Model IV
1. DIN-Rail mounting kit
2. Grounding screw
3. Terminal block for power input
4. DIP switch
5. Power input status indicator
6. 10/100Base-T(X) 100M copper port
7. Ethernet port Link indicator
8. 100Base-FX 100M fiber port
9. 100Base-FX 100M SFP slot
【Mounting Dimension】
Unit: mm
Note before mounting:
Don't place or install the device in area near water or
moist, keep the relative humidity of the device
surrounding between 5%~95% without condensation.
Before power on, first confirm the supported power

supply specification to avoid over-voltage damaging the
device.
The device surface temperature is high after running;
please don't directly contact to avoid scalding.
【DIN-Rail Mounting】
The product adopts 35mm standard DIN-Rail mounting which
is suitable for most industrial scenes, mounting steps as
follows:
Step 1 Check if the DIN-Rail mounting kit is installed firmly.
Step 2 Insert the bottom of DIN-Rail mounting kit (one side
with spring support) into DIN-Rail, and then insert
the top into DIN-Rail.
Tips:
Insert a little to the bottom, lift upward and then insert
to the top.
Step 3 Check and confirm the products is firmly installed
on DIN-Rail, then mounting ends.
【Disassembling DIN-Rail】
Step 1 Device power off.
Step 2 After lift the device upward slightly, first shift out the
top of DIN-Rail mounting kit, and then shift out the
bottom of DIN-Rail, disassembling ends.
Note before powering on:
Power ON operation: First insert the power supply
terminal block into the device power supply interface,
and then plug the power supply plug contact and power
on.
Power OFF operation: First, remove the power plug,
and then remove the wiring section of terminal block.
Please pay attention to the above operation sequence.
【Power Supply Connection】
DC power supply
Model I and Model III provide 3-pin 7.62mm
pitch terminal block for 1 DC power input.
This power supply supports anti-reverse
connection Power supply range: 9 ～
48VDC. The pin definitions of power supply are shown as
follows:
Pin No.
1
2
3
Definition
V+
FG
V-
AC power supply
Model II and Model IV provide 3 7.62mm
pitch terminal block for 1 power input.
Power supply range: 100~240VAC/DC.
The pin definitions of power supply are
shown as follows:
Pin No.
1
2
3
Definition
N/-
GND
L/+
【DIP Switch Settings】
Provide 4-bits DIP switch for function setting,
where "ON" is enable valid terminal. DIP switches
definition as follows:
DIP
Definition
Operation
1
Jumbo frame
Set the DIP to ON to enable jumbo
frame function
2
Broadcast
storm
suppression
Set the DIP to ON to enable
broadcast storm suppression
function
3
LFP
Set the DIP to ON to enable LFP
function, when one end of the
DIP
Definition
Operation
copper port or fiber port
disconnects, close another port;
when the port is reconnected, open
another port.
4
Flow control
Set the DIP to ON to enable flow
control function
【Checking LED Indicator】
The device provides LED indicators to monitor the device
working status with a comprehensive simplified
troubleshooting; the function of each LED is described in the
table as below:
LED
Indicate
Description
PWR
ON
PWR is connected normally
OFF
PWR is disconnected or running
abnormally
Link/Act
(1-2)
ON
Ethernet port is connected
Blinking
The Ethernet interface is in a
network activity state.
OFF
Ethernet port is is connected
abnormally or disconnected
【Specification】
Panel
100M Copper Port
10/100Base-T(X), RJ45,
Automatic Flow Control, Full/half
Duplex Mode, MDI/MDI-X
Autotunning
100M fiber port
100Base-FX, optional SC/ST/FC
100M SFP
100Base-FX SFP slot
Indicator
Power supply indicator, interface
indicator
Switch Property
Backplane bandwidth
1G
MAC Address Table
2K
Power supply

Model I, Model III
9~48VDC, anti-reverse
connection
Model II, Model IV
100~240VAC/DC
Access terminal block
3-pin 7.62mm pitch terminal
blocks
Power consumption
Model I, Model III
No-load: 1.0W@24VDC
Full-load: 1.6W@24VDC
Working
environment
Working temperature
-40～75℃
Storage temperature
-40～85℃
Working humidity
5%～95% (no condensation)
Protection grade
IP40 (metal shell)
