SSC-LUXon PALISO Quick reference guide

Assembly/operating instructions for SSC-LUXon PALISO garden socket with light
1. Intended use
This product: -can be installed indoors and outdoors -protection type IP44, suitable for use in damp areas
-must not be exposed to strong mechanical loads or heavy soiling -may not be operated after damp or dirty storage until
after a condition check -may not be changed or modied, otherwise the operating permit and conformity will expire with
immediate eect! It is not allowed to remove the type plate.
 If the aforementioned points are not observed, a short circuit or electric shock may occur! There is danger to life!
2. General safety instructions
The complete installation may only be carried out by an authorized electrician who is familiar with the applicable
guidelines. Hereinafter referred to as „qualied electrician“.
For safe handling of the product, the user must have read and understood the installation/operating instructions com-
pletely before using the device for the rst time.
 The product may only be used if it is alright. If the device or parts of it are defective, it must be repaired by a qualied
electrician.
 Only use lamps/light sources approved by the manufacturer. The max. lamp wattage in watts is not allowed be
exceeded.
 This product is not a toy and is not allowed be stored or used within the reach of children.
 Safe operation of the product is only guaranteed if these instructions are followed. Therefore, keep these assembly/
operating instructions. SSC-LUXon GmbH accepts no liability if the instructions given here are not followed or the lamp is
subjected to improper use.
3. Assembly & conguration
Caution: The connecting cable must be disconnected from the power supply before starting work (switch o the main
switch/fuse)! Only use parts which are supplied with the product or which are clearly marked as equipment! Otherwise the
product may not be suciently safe!
 The cable routing shown in the illustrations is for simplied purposes only. They in no way represent a recommenda-
tion for connection! The connection may only be carried out by a qualied electrician.
 When drilling, pay attention to cables and gas and water lines. Always route the cable so that it does not touch the light.
3.1 Assembly location
The product is suitable for indoor and outdoor installation. Do not cover the product under any circumstances, especially
not with insulating material, re hazard!
4. Operation, faults & disorders
 Caution: The connecting cable must be disconnected from the power supply before starting work (switch o the main
switch/fuse)!
What to do in case of error?
In the event of a fault, the unit must be switched o immediately. The product may only be operated if it functions fault-
lessly. The unit may only be put back into operation after it has been checked by a qualied electrician! This is the case if:
1. there is visible damage, 2. the product is not working corrctly, 3. there is smoke, steam, or audible crackling noises, 4.
overheating can be detected
Caution: There is a danger to life - repairs to the product or work on parts carrying mains voltage may only be carried
out by qualied electricians.
Avoidance of disturbances and re hazards:
It is not allowed to cover the product under any circumstances. Air circulation must be ensured. Nothing may be attached
or hung on the product, especially no decoration.
5 . C l e a n i n g & c a r e i n s t r u c t i o n s
The product may only be wiped dry or carefully with a slightly damp and lint-free cloth. The product is not allowed to be
removed for this purpose. Do not use abrasive or sharp objects or aggressive cleaning agents. Do not use solvents.
Assembly instructions PALISO garden socket with light
1. Disconnect the connecting cable from the power supply! Unscrew the cover counterclockwise to be
able to insert the G9 light source. Screw the cover back on clockwise. Fig.1
2. Loosen the two screws on the bottom and remove the bottom plate. Fig.2
3. Direct mounting e.g. on wooden substrates: Screw the base plate to the desired substrate with the
screws. Fig.3
3.1. Direct mounting e.g. on concrete or stone: Mark the drill holes and drill them. Insert the dowels
into the drill holes. Guide the supply line through the opening in the middle Screw the energy prole to
the desired surface with the screws & dowels. Fig.3 & 4
4. Pull the cable connection unit out of the enclosure. Use the auxiliary rail inside for this. Fig.3 & 4
Loosen the four screws of the cable connector box and remove the cover. Connect the connecting cable
to the column (luster terminal L, N & protective earth). Fig.7
5. Screw the cover back on with the four screws. Make sure that the seal does not slip. If necessary, x
the outgoing cable with the strain relief. Fig.7
6. Guide the cable connection unit with the auxiliary rail back into the enclosure and screw it back onto
the base plate from step 2.
7. Switch the connecting cable to voltage - The product is now ready for use. Fig.6
Type: Garden socket with light (G9 max. 12 W)
Voltage: 220-240 V / 50-60 Hz
Protection type:IP44
Sockets: 2
Material: Stainless steel / plastics
Operating temperature: -20°C - +40°C
Capacity: 16 A / max. 3680 W
Protection class: I
Can be used
indoors and
outdoors
Technical data PALISO garden socket with light
SSC-LUXon GmbH – Am Krozinger Weg 4, 79189 Bad Krozingen, Germany
E-Mail: [email protected]; Phone: +49 7633 - 988 3000
Notes, explanations & legend
Important information
Distance to illuminated objects
min. 0.5m
Protection class I
Installation only by qualied
electrician
Disconnect the device from the
mains power before starting
any work
Disposal instructions
Make sure to dispose
packaging in accordance
with the applicable guideli-
nes of your local authority.
Devices marked with
the crossed-out waste
garbage do not belong
in the household waste!
You are obliged to hand
in these devices at one of the free collection
points in your municipality. You can obtain
more information from your local authority,
the relevant town hall or a local or regional
waste disposal company.
 Keep packaging material and small parts
away from children and animals. Danger of
suocation!
Notes on use indoors & outdoors
 Protection type IP20 & IP23: Use only
indoors and dry, i.e. do not use in damp or
dirty rooms and in areas of high humidity.
 Protection type IP44 & IP65: Can be used
indoors and outdoors.
Onlineshop:
www.led-lichtraum.de
Satised with your product?
Then we look forward to your
product review in our online store,
on Amazon or eBay!
