ST Quadrat LUX-top LS User manual

PRODUCT INFORMATION
LADDER PROTECTION
LUX-top® LS
FOR FIXING A LEANING LADDER AGAINST
TILTING SIDEWAYS OR OUTWARDS
You´re safe up
here with us

ST QUADRAT Fall Protection S.A. · 45, rue Fuert · L-5410 Beyren · Tel.: [phone]
[email protected] · www.st-quadrat.lu stq_prduktinfo_LS_03_18_gb
LUX-top® LS LADDER PROTECTION
Ladder protection for flat roofs for attaching onto
the attic cover
Ladder protection for steep roofs for attaching onto
the rafters or eaves board
TYPE
LS I
TYPE
LS III
TYPE
LS II
TYPE
LS IV
TECHNICAL DATA
TECHNICAL DATA
TECHNICAL DATA
TECHNICAL DATA
ATTACHMENT MATERIAL
ATTACHMENT MATERIAL
ATTACHMENT MATERIAL
ATTACHMENT MATERIAL
Material: W1.4301 / AISI 304
Dimensions: 450 x 80 x 3 mm
Material: W1.4301 / AISI 304
Dimensions: 260 x 256 x 6 mm
Material: W1.4301 / AISI 304
Dimensions: 520 x 260 x 6 mm
Material: W1.4301 / AISI 304
Dimensions: 260 x 256 x 6 mm
> 4 pcs. special rivets and 1 pc. sealing strip
> 2 pcs. concrete anchor bolts M12 A4
> 4 pcs. wood construction screws Ø 8.0 mm
> 4 pcs. wood construction screws Ø 8.0 mm
> 6 pcs. special rivets and
3 pcs. sealing strips
LUX-top® LS I
LUX-top® LS III
LUX-top® LS II
LUX-top® LS IV
LADDER PROTECTION
Ladder protection for flat roofs for attaching onto
the façade (timber or concrete construction)
Ladder protection for flat roofs for attaching onto
the sandwich façade elements
