ST X-NUCLEO-OUT05A1 User manual

Introduction
The X-NUCLEO-OUT05A1 industrial digital output expansion board for STM32 Nucleo provides a powerful and flexible
environment for the evaluation of the driving and diagnostic capabilities of the IPS1025H single high-side smart power solid
state relay, in a digital output module connected to 2.5 A industrial loads.
The X-NUCLEO-OUT05A1 interfaces with the microcontroller on the STM32 Nucleo via 5 kV optocouplers driven by GPIO pins
and Arduino R3 connectors.
The expansion board can be connected to either a NUCLEO-F401RE or a NUCLEO-G431RB development board.
It is also possible to evaluate a system composed of up to four stacked X-NUCLEO-OUT05A1 expansion boards.
As an example, a system with four X-NUCLEO-OUT05A1 expansion boards allows you to evaluate a quad channel digital
output module.
Figure 1. X-NUCLEO-OUT05A1 expansion board
RELATED LINKS
For further details on configuration resistors, refer to UM2864
Getting started with X-NUCLEO-OUT05A1 industrial digital output expansion
board for STM32 Nucleo
UM2865
User manual
UM2865 - Rev 1 - March 2022
For further information contact your local STMicroelectronics sales office. www.st.com

1Getting started
1.1 Overview
The X-NUCLEO-OUT05A1 embeds the IPS1025H intelligent power switch (IPS), featuring overcurrent and
overtemperature protection for safe output load control.
The board is designed to meet application requirements in terms of galvanic isolation between user and power
interfaces. This requirement is satisfied by an optical isolation implemented through three optocouplers (ISO1,
ISO2, and ISO3) for signal forward to the device and FLT pins for feedback diagnostic signals.
The expansion board features:
• Based on the IPS1025H single high-side switch, which features:
– Operating range up to 60 V
– Low-power dissipation (RON(MAX) = 25 mΩ)
– Fast decay for inductive loads
– Smart driving of capacitive loads
– Under-voltage lock-out
– Overload and over-temperature protection
– PSSO24 package
• Application board operating range: 8 to 33 V/0 to 2.5 A
• Extended voltage operating range (J3 open) up to 60 V
• Green LED for output on/off status
• Red LEDs for overload and overheating diagnostics
• 5 kV galvanic isolation
• Supply rail reverse polarity protection
• EMC compliance with IEC61000-4-2, IEC61000-4-3, IEC61000-4-4, IEC61000-4-5, IEC61000-4-8
• Compatible with STM32 Nucleo development boards
• Equipped with Arduino UNO R3 connectors
• CE certified:
– EN 55032:2015 + A1:2020
– EN 55035:2017 + A11:2020
• RoHS and China RoHS compliant
1.1.1 Digital section
The digital section is associated with the STM32 interface and digital supply voltage to and from the X-NUCLEO-
OUT05A1 expansion board.
UM2865
Getting started
UM2865 - Rev 1 page 2/18

Figure 2. X-NUCLEO-OUT05A1 expansion board: digital interface section
Dotted green line indicates the whole digital interface section. Pink rectangles identify Arduino UNO R3 connectors
The four Arduino UNO R3 connectors:
•allow expansion board communication with the STM32 Nucleo development board microcontroller accessing
STM32 peripheral and GPIO resources;
• provide digital supply voltage between the STM32 Nucleo development board and the X-NUCLEO-
OUT05A1 expansion board, in either direction.
Normally, the STM32 Nucleo development board supplies the expansion board by a 3v3 or 5v0 generated by the
USB. You can select the preferred voltage on the expansion board via SW3 (3v3 closing pins 1-2; 5v0 closing
pins 2-3).
Alternatively, it is possible to supply the STM32 Nucleo development board by the expansion board. In this case,
an external supply voltage (7-12 V) should be connected to CN2 connector (not mounted by default) on the
expansion board and the ground loop should be closed by mounting D2 (enabling the reverse polarity protection)
or by closing J2 (without reverse polarity).
To supply the VIN voltage rail, it is necessary to:
• close jumper JP5 between pins 2 and 3 and open jumper JP1 on the NUCLEO-F401RE;
• open jumper JP5 between pins 1 and 2 and close jumper JP5 between pins 3 and 4 on the NUCLEO-
G431RB.
UM2865
Overview
UM2865 - Rev 1 page 3/18

1.1.2 Power section
The power section involves the power supply voltage (CN1, pins 4 and 5 for VCC, pin 3 for GND), load connection
(a load can be connected between pins CN1.1 and CN1.3 or CN1.2, and CN1.3; both output pins are connected
to the single output channel as shown in Section 2 Schematic diagrams) and electromagnetic compatibility
(EMC) protection.
Figure 3. X-NUCLEO-OUT05A1 expansion board: power section components
1. Overtemperature red LED
2. Overload red LED
3. IPS1025H
4. Output channel - green LED
5. Output and power supply connector
1
2
3
4
5
For EMC:
•The SM15T39CA transient voltage suppressor (TR1), enabled by closing J3, is placed between VCC and
GND tracks to protect the IPS1025H against surge discharge on the supply rail path up to ±1 kV/2 Ω
coupling;
• in common mode surge testing, two single-layer capacitors (C1 and C2 - not included) must be soldered at
the predisposed locations;
• the IPS1025H output stages do not require additional EMC protections with respect to the IEC61000-4-2,
IEC61000-4-3, IEC61000-4-4, IEC61000-4-5, IEC61000-4-8 standards.
UM2865
Overview
UM2865 - Rev 1 page 4/18

1.2 Hardware requirements
The X-NUCLEO-OUT05A1 expansion board is designed to be used with the NUCLEO-F401RE or NUCLEO-
G431RB STM32 Nucleo development boards.
To function correctly, the X-NUCLEO-OUT05A1 must be plugged onto the matching Arduino UNO R3 connector
pins on the STM32 Nucleo board as shown below.
Figure 4. X-NUCLEO-OUT05A1 and STM32 Nucleo stack
1.3 System requirements
To use the STM32 Nucleo development boards with the X-NUCLEO-OUT05A1 expansion board, you need:
•a Windows PC/laptop (Windows 7 or above)
• a type A to mini-B USB cable to connect the STM32 Nucleo board to the PC when using a NUCLEO-
F401RE development board
• a type A to micro-B USB cable to connect the STM32 Nucleo board to the PC when using a NUCLEO-
G431RB development board
• the X-CUBE-OUT5 firmware and software package installed on your PC/laptop
1.4 Board setup
Step 1. Connect the micro-USB or mini/USB cable to your PC to use the X-NUCLEO-OUT05A1 with NUCLEO-
F401RE or NUCLEO-G431RB development board
UM2865
Hardware requirements
UM2865 - Rev 1 page 5/18

Step 2. Download the firmware (.bin) onto the STM32 Nucleo development board microcontroller through
STM32 ST-LINK utility, STM32CubeProgrammer and according to your IDE environment as detailed in
the table below.
Table 1. NUCLEO-F401RE development board supported IDEs - bin files
NUCLEO-F401RE
IAR Keil STM32CubeIDE
EWARM-OUT05_06-
STM32F4xx_Nucleo.bin
MDK-ARM-OUT05_06-
STM32F4xx_Nucleo.bin
STM32CubeIDE-OUT05_06-
STM32F4xx_Nucleo.bin
Table 2. NUCLEO-G431RB development board supported IDEs - bin files
NUCLEO-G431RB
IAR Keil STM32CubeIDE
EWARM-OUT05_06-
STM32G4xx_Nucleo.bin
MDK-ARM-OUT05_06-
STM32G4xx_Nucleo.bin
STM32CubeIDE-OUT05_06-
STM32G4xx_Nucleo.bin
Step 3. Connect the IPS1025H device supply voltage via CN1 (see Section 1.1.2 Power section).
Step 4. Provide the digital supply voltage (see Section 1.1.1 Digital section).
Step 5. Connect the load on the output connector (see Section 1.1.2 Power section).
Step 6. Reset the example sequence using the black push button.
Step 7. Push the STM32 Nucleo blue button to select the example provided in the firmware package.
1.5 Multiple board configuration
It is also possible to evaluate a four channel digital output module by stacking four X-NUCLEO-OUT05A1 with
shared or independent supply rail and independent loads.
In this case, the four expansion boards (board 0, 1, 2, 3 as shown in the table below) must be properly configured:
for board 1, 2 and 3, it is necessary to unsolder three resistors for each board from the default position and solder
them back in the alternate positions according to the following table.
Table 3. Configuration of a stack of four expansion boards
Board no. IN1 FLT1 FLT2
Board 0 R101 R103 R114
Board 1 R102 R104 R117
Board 2 R115 R116 R107
Board 3 R120 R119 R118
UM2865
Multiple board configuration
UM2865 - Rev 1 page 6/18

2Schematic diagrams
Figure 5. X-NUCLEO-OUT05A1 circuit schematic (1 of 2)
31
22
CN2
691214110002
C2
4700pF
20
2
6
6
18
FLT1
3
(7V-12V NUCLEO supply voltage)
33
16
D8
33
MH2
M3 HOLE NOT PLATED
D1
PB0
PB9
IOREF
PA10
VCC
D6
4
26
17
2
1
R103 100
SM15T39CA
28
6
D7
14
TP2
5001
FIDUCIAL2
Fiducial
D13
27
3
IN1
29
35
1
5
3
D11
4
PA6
PA3
FLT2
R107 100
22
N.M.
DEFAULT
3
11
N.M.
D9
2
R102
ALTERNATE USE
FLT1
7
A2
5
3
21
+
5
7
19
30
34
VIN
2
7
4
10
5
default open
FLT1
R114 100
IN1
R101
OUT1
5
11
26
CN5
SSQ-110-04-F-S
25
PB6
VCC
FIDUCIAL3
Fiducial
R119 100
FLT2
N.M.
D15
TP4
5001
25
MH3
M3 HOLE NOT PLATEDA4
TR1
8
2
6
D10
5
24
13
AVDD
5
ST morpho connectors
(N.M.)
6
R118 100 FLT2
15
ALTERNATE USE
DEFAULT
IN1
N.M.
8
A3
OUT
FLT2
30
R104 100
IN1
2
1
12
FLT1
21
EARTH
1
4
IN1
D2
N.M.
default closed
24
37
7
PA1
PC0
PB5
PA0
8
ALTERNATE USE
ALTERNATE USE
ALTERNATE USE
ALTERNATE USE
ALTERNATE USE
ALTERNATE USE
PA8
5V
D3
3V3
N.M.
35
D5
19
D14
5v0
2
C1
4700pF
36
4
8
R115
N.M.
38
C10
100uF
23
MH4
M3 HOLE NOT PLATED
2
CN1
691137710005
J3
N.M.
2
10
MH1
M3 HOLE NOT PLATED
Analog supply
8-60 V
DEFAULT
ALTERNATE USE
N.M.
3
9
29
D1STPS1H100A
7
31
13
20
A0
1
FIDUCIAL4
Fiducial
Arduino connectors
TR2
ESDA15P60-1U1M
FLT1
3v3
9
default open
N.M.
R120 100
23
R116 100
14
CN7
SSQ-119-04-L-D
OUT
VCC
12
1
32
CN9
SSQ-108-04-F-S
27
PB4
PA5
PC7
PB10
PA9
PA2
PB3
NRST
PB8
PA7
1
34
IN1
D4
8
18
36
1
Alternate Nucleo supply
7-12 V
N.M.
FIDUCIAL1
Fiducial
J2
D0
37
N.M.
N.M.
N.M.
16
4
GND
D2
BAT48JFILM
28
1
FLT1
CN10
SSQ-119-04-L-D
N.M.
R117 100
15
38
D12
CN8
SSQ-106-04-F-S
9
4
J4
CN6
SSQ-108-04-F-S
N.M.
2
N.M.
A1
10
32
PA4
PC1
FLT2
1
C6
2.2uF
17
FLT2
6
VIN
A5
3
100
100
100
UM2865 - Rev 1 page 7/18
UM2865
Schematic diagrams

Figure 6. X-NUCLEO-OUT05A1 circuit schematic (2 of 2)
J7
OUT14
R11
2.2K
2
VCC
NC2
2 9
23
TP5
5001
OUT1
1
R4
0
IPD1
4
default closed
C
1
1
IN1
14
4
A
4
2
NC3
1
3
OUT9
150060RS75000
TP1
5001
OUT19
21
1
13
J10
17
150060RS75000
OUT13
DR2
3
223
DG1
8
default: CLOSE 1-2
3v3
OUT8
A
IN1
19
R3
22k
150060VS75000
R12
22k
6
ISO2
TLP383
2
SW2
con3-strip-male
18
4
OUT18
FLT2 OUT5
default closed
7
SW3
con3-strip-male
3
default: CLOSE 1-2
TP3
5001
A
5v0
ISO1
TLP383
3
R62.2K
OUT6
J5
default closed
C7 470pF
OUT12
J9
con6-2x3-strip-male
1
C5
0.1uF
2
default closed
J6
3
12
C3
0.1uF
R8
10k
6
FLT1
ISO3
TLP383
1
default:
closed
R10
0
C4
0.1uF
R1
27K
2
2
FLT1
default: CLOSE 1-2
16
C
15
OUT11
OUT20
OUT7
3
OUT15
20
U1
IPS1025H
2
1
3
R2
390
25 VCC
R5
0
R9
0
1
OUT17
GND
OUT16
SW1
con3-strip-male
10
DR1
C9 470nF
VCC
4
OUT10
2
VCC
R710k
5
VCC
FLT2
C
5
SW4
con3-strip-male
11
J8
J1
C8 47nF
default: CLOSE 1-2
3
24
UM2865 - Rev 1 page 8/18
UM2865
Schematic diagrams

3Bill of materials
Table 4. X-NUCLEO-OUT05A1 bill of materials
Item Q.ty Ref. Part/value Description Manufacturer Order code
1 0 C1 C2 4700 pF 1825 (4564 metric) 3000
V (3kV) ±10% X7R
Ceramic capacitors
(not mounted) Vishay Vitramon HV1825Y472KXHATHV
2 3 C3 C4
C5
0.1 µF 0805 (2012 metric) 100 V
±10% X7R Ceramic capacitors Würth Elektronik 885012207128
3 1 C6 2.2 µF 1206 (3216 metric) 100 V
±10% X7R Ceramic capacitor AVX Corporation 12061C225KAT2A
4 1 C7 470 pF 0603 (1608 metric) 50 V
±5% C0G/NP0 Ceramic capacitor Würth Elektronik 885012006061
5 1 C8 47 nF 0603 (1608 metric) 50 V
±10% X7R Ceramic capacitor
Murata
Electronics North
America
GCM188R71H473KA55D
6 1 C9 470 nF 0603 (1608 metric) 25 V
±10% X7R Ceramic capacitor Würth Elektronik 885012206075
7 0 C10 100 µF radial, can 100 V ±20% Ceramic capacitor
(not mounted) Würth Elektronik 860130878011
8 1 CN1 5 positions, side entry, 5 mm Terminal block Würth Elektronik 691137710005
9 0 CN2 2 positions, 7.4X7 pitch 3.5 mm,
side entry
Terminal block (not
mounted) Würth Elektronik 691214110002
10 1 CN5 TH 2.54 mm 10 ways, 1 row Samtec Inc.
4UCONN ESQ-110-14-T-S 17896
11 2 CN6 CN9 TH 2.54 mm 8 ways, 1 row Samtec Inc.
4UCONN ESQ-108-14-T-S 15782
12 0 CN7
CN10 38 positions, 0.1 mm, gold PCB
Connector
receptacles (not
mounted)
Any Any
13 1 CN8 TH 2.54 mm 6 ways, 1 row Samtec Inc.
4UCONN ESQ-106-04-T-S 15781
14 1 D1 STPS1H100A, SMA 100 V, 1 A power
Schottky rectifier ST STPS1H100A
15 0 D2 BAT48JFILM, SOD323
40 V, 350 mA
axial general
purpose signal
Schottky diode (not
mounted)
ST BAT48JFILM
16 1 DG1 0603 (1608 metric) 20 mA SMD Green LED Würth Elektronik 150060GS75000
17 2 DR1 DR2 0603 (1608 metric) 20 mA SMD Red LEDs Würth Elektronik 150060RS75000
18 3
ISO1
ISO2
ISO3
LSOP04, 5 kV Optoisolators Würth Elektronik 140109146000
19 8
J1 J2 J3
J4 J5 J6
J8 J10
JUMPER-con2-strip-male TH
2.54 mm Jumpers Würth Elektronik 61300211121
20 0 J7 JUMPER-con2-strip-male Jumper (not
mounted)
21 1 J9 con6-2x3-strip-male Connector header Würth Elektronik 61300621121
22 1 R1 27 K 0603 (1608 metric) 0.1 W,
1/10 W ±1% SMD Resistor Yageo RC0603FR-0727KL
UM2865
Bill of materials
UM2865 - Rev 1 page 9/18

Item Q.ty Ref. Part/value Description Manufacturer Order code
23 1 R2 390 0603 (1608 metric) 0.1 W,
1/10 W ±1% SMD Resistor Yageo RC0603FR-07390RL
24 2 R3 R12 22 k 0603 (1608 metric) 0.1 W,
1/10 W ±1% SMD Resistors Yageo RC0603FR-0722KL
25 4 R4 R5
R9 R10
0 0603 (1608 metric) 0.1 W, 1/10
W ±1% SMD Resistors
Panasonic
Electronic
Components
ERJ-3GEY0R00V
26 2 R6 R11 2.2 K 0603 (1608 metric) 0.1 W,
1/10 W ±1% SMD Resistors Yageo RC0603FR-072K2L
27 1 R7 100k 0603 (1608 metric) 0.1 W,
1/10 W ±1% SMD Resistor Yageo RC0603FR-07100KL
28 1 R8 10 k 0603 (1608 metric) 0.1 W,
1/10 W ±1% SMD Resistor Yageo RC0603FR-0710KL
29 3
R101
R103
R114
100 0603 (1608 metric) 0.1 W,
1/10 W ±1% SMD Resistors Yageo RC0603FR-07100RP
30 0
R102
R104
R107
R115
R116
R117
R118
R119
R120
100 0603 (1608 metric) 0.1 W,
1/10 W ±1% SMD
Resistors (not
mounted) Yageo RC0603FR-07100RP
31 4
SW1
SW2
SW3
SW4
con3-strip-male TH 2.54 mm Connector headers Würth Elektronik 61300311121
32 5
TP1 TP2
TP3 TP4
TP5
5001 0.100" diameter 0.180" L
(2.54 mm x 4.57 mm) Test points Keystone Electronics 5001
33 1 TR1 SM15T39CA, SMC C2 1500 W, 33.3 V
TVS in SMC ST SM15T39CA
34 0 TR2 ESDA15P60-1U1M, QFN-2L
High-power
transient voltage
suppressor (not
mounted)
ST ESDA15P60-1U1M
35 1 U1 IPS1025H, PSSO24
High-side switch
with smart driving
for capacitive loads
ST IPS1025H
36 13 - 2.54 mm Jumpers Würth Elektronik 60900213421
UM2865
Bill of materials
UM2865 - Rev 1 page 10/18

4References
Freely available on www.st.com:
1. IPS1025H datasheet
2. UM2864: "Getting started with X-CUBE-OUT5 industrial digital output software for STM32 Nucleo"
3. NUCLEO-F401RE datasheet
4. NUCLEO-G431RB datasheet
UM2865
References
UM2865 - Rev 1 page 11/18

5Board versions
Table 5. X-NUCLEO-OUT05A1 versions
Finished good Schematic diagrams Bill of materials
X$NUCLEO-OUT05A1 (1) X$NUCLEO-OUT05A1 schematic diagrams X$NUCLEO-OUT05A1 bill of materials
1. This code identifies the X-NUCLEO-OUT05A1 evaluation board first version.
UM2865
Board versions
UM2865 - Rev 1 page 12/18

6Regulatory compliance information
Formal Notice Required by the U.S. Federal Communications Commission
FCC NOTICE
This kit is designed to allow:
(1) Product developers to evaluate electronic components, circuitry, or software associated with the kit to
determine
whether to incorporate such items in a finished product and
(2) Software developers to write software applications for use with the end product.
This kit is not a finished product and when assembled may not be resold or otherwise marketed unless all
required FCC equipment authorizations are first obtained. Operation is subject to the condition that this product
not cause harmful interference to licensed radio stations and that this product accept harmful interference. Unless
the assembled kit is designed to operate under part 15, part 18 or part 95 of this chapter, the operator of the kit
must operate under the authority of an FCC license holder or must secure an experimental authorization under
part 5 of this chapter 3.1.2.
Formal Product Notice Required by Industry Canada Innovation, Science and Economic Development
Canada compliance:
For evaluation purposes only. This kit generates, uses, and can radiate radio frequency energy and has not been
tested for compliance with the limits of computing devices pursuant to Industry Canada (IC) rules.
À des fins d'évaluation uniquement. Ce kit génère, utilise et peut émettre de l'énergie radiofréquence et n'a pas
été testé pour sa conformité aux limites des appareils informatiques conformément aux règles d'Industrie Canada
(IC).
Formal product notice required by EU
This device is in conformity with the essential requirements of the Directive 2014/30/EU (EMC) and of the
Directive 2015/863/EU (RoHS).
UM2865
Regulatory compliance information
UM2865 - Rev 1 page 13/18

Revision history
Table 6. Document revision history
Date Revision Changes
24-Mar-2022 1 Initial release.
UM2865
UM2865 - Rev 1 page 14/18

Contents
1Getting started ....................................................................2
1.1 Overview .....................................................................2
1.1.1 Digital section ...........................................................2
1.1.2 Power section ...........................................................4
1.2 Hardware requirements .........................................................5
1.3 System requirements ...........................................................5
1.4 Board setup ...................................................................5
1.5 Multiple board configuration......................................................6
2Schematic diagrams ...............................................................7
3Bill of materials....................................................................9
4References .......................................................................11
5Board versions ...................................................................12
6Regulatory compliance information ...............................................13
Revision history .......................................................................14
Contents ..............................................................................15
List of tables ..........................................................................16
List of figures..........................................................................17
UM2865
Contents
UM2865 - Rev 1 page 15/18

List of tables
Table 1. NUCLEO-F401RE development board supported IDEs - bin files ...................................6
Table 2. NUCLEO-G431RB development board supported IDEs - bin files...................................6
Table 3. Configuration of a stack of four expansion boards .............................................6
Table 4. X-NUCLEO-OUT05A1 bill of materials .....................................................9
Table 5. X-NUCLEO-OUT05A1 versions ......................................................... 12
Table 6. Document revision history .............................................................14
UM2865
List of tables
UM2865 - Rev 1 page 16/18

List of figures
Figure 1. X-NUCLEO-OUT05A1 expansion board...................................................1
Figure 2. X-NUCLEO-OUT05A1 expansion board: digital interface section .................................3
Figure 3. X-NUCLEO-OUT05A1 expansion board: power section components ...............................4
Figure 4. X-NUCLEO-OUT05A1 and STM32 Nucleo stack.............................................5
Figure 5. X-NUCLEO-OUT05A1 circuit schematic (1 of 2) .............................................7
Figure 6. X-NUCLEO-OUT05A1 circuit schematic (2 of 2) .............................................8
UM2865
List of figures
UM2865 - Rev 1 page 17/18

IMPORTANT NOTICE – READ CAREFULLY
STMicroelectronics NV and its subsidiaries (“ST”) reserve the right to make changes, corrections, enhancements, modifications, and improvements to ST
products and/or to this document at any time without notice. Purchasers should obtain the latest relevant information on ST products before placing orders. ST
products are sold pursuant to ST’s terms and conditions of sale in place at the time of order acknowledgment.
Purchasers are solely responsible for the choice, selection, and use of ST products and ST assumes no liability for application assistance or the design of
purchasers’ products.
No license, express or implied, to any intellectual property right is granted by ST herein.
Resale of ST products with provisions different from the information set forth herein shall void any warranty granted by ST for such product.
ST and the ST logo are trademarks of ST. For additional information about ST trademarks, refer to www.st.com/trademarks. All other product or service names
are the property of their respective owners.
Information in this document supersedes and replaces information previously supplied in any prior versions of this document.
© 2022 STMicroelectronics – All rights reserved
UM2865
UM2865 - Rev 1 page 18/18
