STM32 TCPM Application
Introduction
This document describes the STM32 USB-PD (Power Delivery) Expansion Package for
STM32Cube, referenced as X-CUBE-USB-PD.
To discover all our MCU based solutions for USB Type-C™ and Power Delivery technology
please go to our landing page https://www.st.com/content/st_com/en/stm32-usb-c.html.
X-CUBE-USB-PD is a USB-IF certified Expansion Package and consists of libraries, drivers,
sources, APIs and application examples running on STM32F0 Series microcontrollers
acting as USB Type-C™ port manager (TCPM).
The provided example helps to develop applications based on USB-PD DRP (Dual Role
Power).
The core of the stack is delivered in library format while the open-source format device part
offers a high level of flexibility to match the design considerations.
This Expansion Package supports one hardware implementation:
•Standardized TCPM/TCPC solution for any STM32 microcontroller
– Ideal solution to upgrade legacy design based-on any STM32 with USB-C™
– Lowest memory footprint and easy porting within the Cortex®-M series
– USB-PD 2.0/3.0+PPS compliant, multi-port
– Tested with TCPC controller from On-SEMI FUSB307B. Refer to USB Type-C™
port manager (TCPM)/port controller (TCPC) evaluation board (DB3623).
www.st.com

Contents UM2063
2/18 UM2063 Rev 5
Contents
1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.1 Acronyms and abbreviations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.2 References . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2 USB-C™ PD architecture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.1 Architecture overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.2 Specific case of TCPM/TCPC architecture . . . . . . . . . . . . . . . . . . . . . . . . 8
3 USB-PD ST application setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
4 Examples description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
4.1 USB-PD DRP (TCPM/TCPC architecture) . . . . . . . . . . . . . . . . . . . . . . . . 12
4.1.1 Example setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
4.1.2 Application description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
4.1.3 Library initialization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
4.1.4 TCPM API description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
5 Memory footprint of the EVAL_FUSB307_DRP example . . . . . . . . . . . 15
6 Frequently asked questions (FAQs) . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
7 Revision history . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

UM2063 Rev 5 3/18
UM2063 List of tables
3
List of tables
Table 1. List of acronyms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Table 2. USB-PD - Dual role port memory footprint (in bytes) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Table 3. Document revision history . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

List of figures UM2063
4/18 UM2063 Rev 5
List of figures
Figure 1. USB Power Delivery architecture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Figure 2. USB Type-C™ port manager to USB Type-C™ port controller interface . . . . . . . . . . . . . . . 8
Figure 3. ST firmware architecture. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Figure 4. Project structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

UM2063 Rev 5 5/18
UM2063 Overview
17
1 Overview
This document describes how to use the USB-PD library supporting STM32 32-bit
microcontrollers based on Arm®(a) cores, for regular use and to create a customized
application.
It covers the following topics to ease the use of the library:
•USB-PD standard overview
•USB-PD library architecture
•USB-PD stack usage description
1.1 Acronyms and abbreviations
a. Arm is a registered trademark of Arm Limited (or its subsidiaries) in the US and/or elsewhere.
Table 1. List of acronyms
Term Meaning
API Application programming interface
CAD Cable detection module
CC Configuration channel
DFP Downstream facing port
DPM Device policy manager
DRP Dual role port
FW Firmware
HW Hardware
PD Power delivery
PE Policy engine
PRL Protocol layer
TCPC USB Type-C™ port controller
TCPCi USB Type-C™ port controller interface
TCPM USB Type-C™ port manager
UFP Upstream facing port
USB Universal serial bus
VDM Vendor defined messages

Overview UM2063
6/18 UM2063 Rev 5
1.2 References
•Universal Serial Bus Power Delivery Specification, Revision 3.0, Version 2.0, August
29, 2019
•Universal Serial Bus Type-C™ Cable and Connector Specification 2.0, August 2019
•Universal Serial Bus Type-C™ Port Controller Interface Specification, Revision 1.0,
Version 1.2, November 2016
•User manual Managing USB power delivery systems with STM32 microcontrollers
(UM2552)
•Application note USB Type-C™ Power Delivery using STM32xx Series MCUs and
STM32xxx Series MPUs (AN5225)
•ST wiki USBPD overview:
https://wiki.st.com/stm32mcu/wiki/USB_Power_Delivery_overview
•STM32CubeMonitor-UCDPD: https://www.st.com/en/product/stm32cubemonucpd

UM2063 Rev 5 7/18
UM2063 USB-C™ PD architecture
17
2 USB-C™ PD architecture
2.1 Architecture overview
The USB Power Delivery specification document defines the communicating layers of a PD
device (either provider or consumer) as shown in Figure 1.
Figure 1. USB Power Delivery architecture
A PD3.0-capable device is assumed to be made up of at least one port, which can
•sink power (a consumer), source power (a provider), or toggle between the two roles
(dual role power)
•optionally communicate via USB
•communicate using SOP Packets
•optionally communicate using SOP Prime packets.
Where USB products support USB Power Delivery protocols a USB DFP is initially a Source
and a USB UFP is initially a Sink, although USB-PD enables the Source/Sink and the
DFP/UFP roles to be swapped.
Note: There is only one Source port and one Sink port in each PD communication between port
partners.
MS41457V2
Provider
Protocol
Policy engine
Device policy manager
Consumer
Protocol
Policy engine
Device policy manager
CC-lines
Physical layerPhysical layer

USB-C™ PD architecture UM2063
8/18 UM2063 Rev 5
2.2 Specific case of TCPM/TCPC architecture
Implementation of USB-PD function may also be achieved in a TCPM/TCPC architecture,
with a standardized interface between USB Type-C™ port manager (TCPM) and a simple
USB Type-C™ port controller (TCPC) with the goal of easing USB Type-C™ Power Delivery
implementations.
Figure 2. USB Type-C™ port manager to USB Type-C™ port controller interface
TCPC interface (TCPCi) is using an I2C link and an alert pin. USB Type-C™ port controller
interface Specification (TCPCi) defines the interface between the TCPM and the TCPC(s).
In this architecture, one TCPM may be used to drive multiple TCPCs.
Protocol (PRL) functionalities are shared between TCPM and TCPC. TCPC must manage:
•GoodCRC management
•Retransmission
ST firmware architecture is described in Figure 3:

UM2063 Rev 5 9/18
UM2063 USB-C™ PD architecture
17
Figure 3. ST firmware architecture
•Device Policy Manager (DPM)
DPM’s role is to manage all the ports present in the application and to share the power
between them according to the capability of the connected port partners. Once the
negotiation of power has ended, an explicit contract is concluded between them.
DPM can manage VDM exchanges, to manage the alternate modes, only once an
explicit contract is established. This layer is the high level of the USB C power stack
and the place where the user defines the power strategy of its application.
•Policy Engine (PE) layer
The Policy Engine (PE) role is to drive the message sequences according to the sent
message and to its expected response. It allows negotiating power, establishing an
Explicit Contract for the power exchange.
The acceptance or the refusal of a request depends on the response of the DPM
towards a specific power profile.
The PE also handles the Vendor Defined Messages flow, allowing to discover, enter or

USB-C™ PD architecture UM2063
10/18 UM2063 Rev 5
exit specified modes according to those supported by both provider and consumer
sides.
•Protocol layer high (PRL layer high)
This layer’s role is to construct, transmit and receive messages from/to TCPC layers
to/from the PE layer.
It interacts with the TCPM layer to transmit messages to TCPC through the TCPCi
interface.
•Type-C™ protocol management (TCPM)
This layer must handle messages exchanged between PRL and TCPC layers. It
means the management of alerts raised by TCPC, wrap communications, and others.
•Type-C™ protocol controller (TCPC) component
This layer is used to define all the registers accesses linked to TCPC component used
for Type-C™
•Type-C™ protocol controller interface (TCPCi)
This layer manages all the I2C transactions between TCPM and TCPC and also
interruptions linked to alerts.
•TCPC hardware
This layer is responsible for sending and receiving messages across the CC wires.
The TCPC hardware implements the entire USB-PD PHY layer with BMC encoding.
The TCPC implements a portion of the protocol layer transmission state diagram.
– CRCReceiveTimer
– RetryCounter
– Messages that are received are passed to the TCPM via I2C
– BIST handling
Note: For more information about the USB Power Delivery protocol, refer to the official
specification document mentioned in Section 1.2.

UM2063 Rev 5 11/18
UM2063 USB-PD ST application setup
17
3 USB-PD ST application setup
The USB-C™ Power Delivery library is provided in binary format, comes on top of the
STM32Cube HAL driver, and offers all the APIs required to develop a USB-PD application.
This section describes the USB-PD library middleware integration and illustrates how users
can develop their own power-delivery applications using this library.
The USB-PD library is developed following the Universal Serial Bus Power Delivery
Specification and Universal Serial Bus Type-C™ Cable and Connector Specification, refer to
Section 1.2, and this library is officially certified.
The STM32 USB-PD package contains:
•The USB-PD core stack and the device drivers
•An example with USB-PD DRP (TCPM/TCPC architecture) with ON Semiconductor
FUSB307 evaluation board
More details on the stack library can be found in the user manual regarding the
management of USB Power Delivery systems with STM32 MCUs and the wiki. For both
links, refer to Section 1.2.

Examples description UM2063
12/18 UM2063 Rev 5
4 Examples description
Figure 4. Project structure
4.1 USB-PD DRP (TCPM/TCPC architecture)
This project implements a USB-PD DRP application, suitable for the ON Semiconductor
FUSB307 evaluation board, based on the use of USB-PD libraries delivered in the X-CUBE-
USB-PD Expansion Package, and highlighting the TCPM/TCPC architecture.
4.1.1 Example setup
The USB-PD TCPM/TCPC designed for FUSB307 evaluation board application can be
found under Projects\STM32F072RB-Nucleo\Applications\USB_PD\EVAL_FUSB307_DRP
This application provides an example of USB Power Delivery implementation based on
TCPM/TCPC architecture. The application and USB-PD core stack are located on the
TCPM side and are running on the STM32F0xx Nucleo device on the ON Semiconductor
FUSB307 board. The application is driving the TCPC controller through the I2C link.

UM2063 Rev 5 13/18
UM2063 Examples description
17
4.1.2 Application description
When the application starts, USB-PD has the capability of operating as either a Source or
Sink.
When connecting to a USB-PD device (source or sink), the application must detect the type
of connected device, and adopt a corresponding suitable role, in order to trigger the power
negotiation:
•User must plug the USB-C™ cable on the dedicated connector.
•When the STM32 MCU side behaves as a Consumer (Sink mode), i.e. when
connected to a Source device, it waits for Power Capabilities message from the
attached provider. When a Source Capabilities message is received, the STM32 starts
the evaluation of the received capabilities and check if one of the received power
objects can meet its power requirement. The STM32 sends the Request message to
request the new power level from the offered Source Capabilities. Once the PS_RDY
message is received, the Explicit Contract is established.
•When the STM32 MCU side behaves as a Provider (Source mode), i.e. when
connected to a Sink device, it exchanges Power profiles with the connected device and
waits for Power Request message from the attached consumer. If the requested power
can be met, the STM32 MCU sends the Accept message followed by the PS_RDY
message. Explicit Contract is then considered as established.
4.1.3 Library initialization
To use and initialize the library, the user must follow the steps listed below.
1. Include the STM32 USB-C™ PD core stack library in your project. Select library type
according to his toolchain, and according to features required to be supported (PD2.0
or PD3.0, VDM supported or not). Available libraries for the USB-PD core stack
component, are available in the directory
\Middlewares\ST\STM32_USBPD_Library\Core\lib\. A second library has to be
selected for the USB-PD component depending upon the used hardware kit
(P-NUCLEO-USB001 or P-NUCLEO-USB002), in the directory
\Middlewares\ST\STM32_USBPD_Library\Devices\. For P-NUCLEO-USB001 specific
case, select device source code from
\Middlewares\ST\STM32_USBPD_Library\Devices\STM32F072\ directory.
2. Include the user application files in the application. Some examples of files are
available in the provided project examples in the firmware package. In provided
examples, user application files are:
–main.c: Program Main file, includes main and System Clock configuration
functions. The program main function configures the MCU clock (template
implemented in the systemClock_Config() function in the main.c file of each
project example). Then, main calls the USBPD_HW_IF_GlobalHwInit() function to
initialize the hardware interface layer and calls the USBPD_DPM_Init() function to

Examples description UM2063
14/18 UM2063 Rev 5
initialize the Device Policy Manager layer and all the communication layers (PE,
VDM, PRL, PHY).
–stm32f0xx_hal_conf.h: contains STM32F0xx HAL configuration file (such as
enabled IPs)
–stm32f0xx_hal_msp.c: contains hardware interface MSP functions (referred to by
HAL IP Initialization functions)
–stm32f0xx_it.c/stm32f0xx_it.h: provides definitions for all exceptions handlers and
peripherals interrupt service routines used in the application.
–usbpd_dpm_user.c/usbpd_dpm_user.h: contains USB-PD DPM user code,
including implementation of functions and callbacks required to fulfill USB core
stack API.
–usbpd_pwr_if.c/usbpd_pwr_if.h: contains a definition of power interface control
functions
–FreeRTOSConfig.h: contains application-specific definitions related to
FreeRTOS™ use.
3. In a FreeRTOS™ configuration, call to USBPD_DPM_Init() performs threads, message
queues creation and launches the RTOS Kernel (task scheduler).
Note: The USB-C™ PD library uses FreeRTOS™ to manage high-level layers.
4.1.4 TCPM API description
For a complete description of the USB-PD core stack callbacks to be implemented on the
DPM user side, refer to the CHM file provided in the Documentation directory of the
X-CUBE-USB-PD Expansion Package
(STM32F072xB_USBPD_CORE_RELEASE_User_Manual.chm), in particular to
USBPD_PE_Callbacks Struct reference description. For a complete description of the
USBPD core TCPM stack callbacks to be implemented on the TCPC component side, refer
to the CHM file provided in the Documentation directory of the X-CUBE-USB-PD Expansion
Package (STM32F072xB_USBPD_CORE_TCPM_RELEASE user manual), in particular to
TCPC_DrvTypeDef Reference description

UM2063 Rev 5 15/18
UM2063 Memory footprint of the EVAL_FUSB307_DRP example
17
5 Memory footprint of the EVAL_FUSB307_DRP
example
The values in Table 2 are calculated according to the following configuration:
•Compiler: IAR™ Embedded Workbench®for Arm®, Version 8.32.3
•Optimization: high size
•MCU: STM32F072RB
•ON-FUSB3-STM32 board
Table 2. USB-PD - Dual role port memory footprint (in bytes)
Software Flash memory RAM Description
GUI 7904 700
Responder for
STM32CubeMonitor-UCDPD
(STM32CubeMonUCPD)
graphical user interface
Application 5286 352 Application
USB-PD library 25592 72 PD3 Config1 stack
DRV 7334 364 TCPCi drivers for FUSB305
HAL 3912 40 STM32 HAL/LL drivers (Like Flash,
I2C, USART for debugging)
Debug 1550 1044 For Tracer debugging
(STM32CubeMonitor-UCPD)
FreeRTOS™ 4332 7028 FreeRTOS™ allocation and services
sideLib 2654 2904 IAR™ libraries
Device 960 76 For usbpd_pwr_if.c
Total 59554 12580 -

Frequently asked questions (FAQs) UM2063
16/18 UM2063 Rev 5
6 Frequently asked questions (FAQs)
How can I get the STM32 USB-PD library?
The library is provided for free download in a binary format, from www.st.com. The general
application note USB Type-C™ Power Delivery using STM32xx Series MCUs and
STM32xxx Series MPUs (AN5225) describes how to do power delivery with the STM32.
This firmware package for X-CUBE-USB-PD is located also on the gitub server:
https://github.com/STMicroelectronics/x-cube-usb-pd.
I want to use only the USB-C™ feature (cable detachment attachment and cable
orientation). Is this possible?
Yes, this is possible since the CAD (Cable attachment and detachment) module and the PD
communication are driven by two separate processes. You can call only the CAD process to
ensure cable detection.
Does the X-CUBE-USB-PD Expansion Package work on platforms different from
STM32F0?
The core stack is device-independent. The STM32F0 and STM32F4 are supported on the
device part in this delivery.
More information can be found in
https://wiki.st.com/stm32mcu/wiki/USB_Power_Delivery_overview

UM2063 Rev 5 17/18
UM2063 Revision history
17
7 Revision history
Table 3. Document revision history
Date Revision Changes
08-Jun-2016 1Initial release.
23-Jan-2017 2
Updated Section 1.2: References, Section 3.1: Overview, Section 3.2:
Features, Section 3.3: Library architecture, Section 3.4: Hardware
related components (for P-NUCLEO-USB001), Section 4: USB-PD
library programming guidelines, Section 4.2: Library initialization,
Section 4.3: USB-PD core stack library functions, Section 4.4: USB-PD
core stack, Section 6.1: Hardware description, Section 6.2: USB-PD
provider, Section 6.5: USB-PD consumer, Section 6.8: USB-PD
consumer DRP and Section 8: Frequently asked questions (FAQs).
Added Section 6.3: USB-PD provider (with CLI support), Section 6.4:
USB-PD provider (with VDM support), Section 6.6: USB-PD consumer
(with CLI support), Section 6.7: USB-PD consumer (with VDM support)
and Section 6.9: USB-PD Dual Port.
Updated Table 1: List of acronyms, Table 2: Use of different IPs,
Table 3: GPIOs used by Port0, Table 4: GPIOs used by Port1, Table 6:
DPM files, Table 7: USB-PD user functions, Table 8: USB-C™ PD
callbacks, Table 9: USB-PD - Provider memory footprint (in Bytes),
Table 10: USB-PD - Consumer memory footprint and Table 11: USB-
PD - Dual role port memory footprint.
Updated Figure 6: Project files.
09-May-2018 3
Updated Introduction, Section 1.2: References, Section 2.1:
Architecture overview, Section 3.1: Overview, Section 3.2: Features,
Section 3.3: Library architecture, Section 3.4: Hardware related
components (for P-NUCLEO-USB001), Section 4: USB-PD library
programming guidelines, Section 4.2: Library initialization, Section 4.4:
USB-PD core stack, Section 6.5.1: Example setup, Section 6.9.1:
Example setup, Section 7: Memory footprint and Section 8: Frequently
asked questions (FAQs).
Added Section 4.5: USB-PD device components.
Updated Figure 1: USB power delivery architecture, Figure 6: Project
files and Figure 7: USB-PD stack architecture (for P-NUCLEO-
USB001).
Updated Table 6: USB-PD - Provider memory footprint (in Bytes),
Table 7: USB-PD - Consumer memory footprint (in Bytes) and Table 8:
USB-PD - Dual role port memory footprint (in Bytes).
Removed former Table 6: DPM files, Table 7: USB-PD user functions
and Table 8: USB-C™ PD callbacks.
30-May-2018 4
Updated Introduction
Added Chapter 2.2: Specific case of TCPM/TCPC architecture,
Chapter 4.1: Description of available configurations,
Chapter 5: Atomic message sequencing and
Chapter 6.10: USB-PD DRP (TCPM/TCPC architecture)
10-Apr-2020 5
Updated Introduction
Former section 3 moved to Section 4.1.4: TCPM API description
Removed P-NUCLEO-USB001 and P-NUCLEO-USB002. The first is
obsolete, and the second is download-able from another page.

UM2063
18/18 UM2063 Rev 5
IMPORTANT NOTICE – PLEASE READ CAREFULLY
STMicroelectronics NV and its subsidiaries (“ST”) reserve the right to make changes, corrections, enhancements, modifications, and
improvements to ST products and/or to this document at any time without notice. Purchasers should obtain the latest relevant information on
ST products before placing orders. ST products are sold pursuant to ST’s terms and conditions of sale in place at the time of order
acknowledgement.
Purchasers are solely responsible for the choice, selection, and use of ST products and ST assumes no liability for application assistance or
the design of Purchasers’ products.
No license, express or implied, to any intellectual property right is granted by ST herein.
Resale of ST products with provisions different from the information set forth herein shall void any warranty granted by ST for such product.
ST and the ST logo are trademarks of ST. For additional information about ST trademarks, please refer to www.st.com/trademarks. All other
product or service names are the property of their respective owners.
Information in this document supersedes and replaces information previously supplied in any prior versions of this document.
© 2020 STMicroelectronics – All rights reserved
