STA-RITE 14935-0100 User manual

TWO POSITION SLIDE VALVES
FOR POOL FILTERS
O W N E R’ S M A N U A L
INSTALLATION, OPERATION & PARTS
PLASTIC SLIDE VALVE MODEL
2" – 14935-0100
2" – 14935-0300
Sta-Rite Pool/Spa Group
293 Wright Street, Delavan, WI 53115
International: 262-728-5551, FAX: [phone]
www.starite.com
Union City, TN • Delavan, WI • Mississauga, Ont. • Murrieta, CA
©2005 , Sta-Rite Industries S390 (Rev. 3/22/05)
This manual should be furnished to
the end user of this valve; its use will
reduce service calls and chance of
injury and will lengthen valve life.
4152 0302

2
TWO POSITION SLIDE VALVE
To avoid unneeded service calls, prevent possible injuries, and get the most
out of your filter, READ THIS MANUAL CAREFULLY!
Table of Contents
Safety Instructions ........................................................................................2
Outline Dimensions .....................................................................................3
General Information.....................................................................................3
Operation ....................................................................................................4
Maintenance ................................................................................................4
Repair Parts List ........................................................................................5-6
Performance Curves .....................................................................................7
Warranty......................................................................................................8
READ AND FOLLOW ALL
INSTRUCTIONS!
This is the safety alert symbol. When you see this symbol on your sys-
tem or in this manual, look for one of the following signal words and
be alert to the potential for personal injury.
warns about hazards that will cause death, serious personal
injury, or major property damage if ignored.
warns about hazards that can cause death, serious personal
injury, or major property damage if ignored.
warns about hazards that will or can cause minor personal
injury or property damage if ignored.
NOTICE indicates special instructions not related to hazards.
Carefully read and follow all safety instructions in this manual and on equip-
ment. Keep safety labels in good condition; replace if missing or damaged.
Incorrectly installed or tested equipment may fail, causing
severe injury or property damage.
Read and follow instructions in owner's manual when installing
and operating equipment. Have a trained pool professional per-
form all pressure tests.
1. Do not connect system to a high pressure or city water system.
2. Use equipment only in a pool or spa installation.
3. Trapped air in system can cause explosion. BE SURE all air is out of system
before operating or testing equipment.
4. Do not pressure test with air.
Before pressure testing, make the following safety checks:
•Check all clamps, bolts, lids, and system accessories before testing.
•Release all air in system before testing.
•Tighten Sta-Rite trap lids to 30 ft. lbs. (4.1 kg-cm) torque for testing.
•Water pressure for test must be less than 25 PSI (172 kPa).
•Water Temperature for test must be less than 100oF. (38oC).
•Limit test to 24 hours. After test, visually check system to be sure it is ready
for operation. Remove trap lid and retighten hand tight only.
NOTICE: These parameters apply to Sta-Rite equipment only. For
non-Sta-Rite equipment, consult manufacturer.

3
6"
5-7/16 "
2" Slip
2" Slip
2" Slip
27-7/8"
22-3/8"
9-15/16"
9-3/8"
5-3/4"
4127 0202
5-7/16 "
2" Slip
2" Slip
2" Slip
27-7/8"
22-3/8"
9-15/16"
4151 0302
7-13/16"
6-9/16"
4-15/16"
OUTLINE DIMENSIONS
Figure 1 - Model 14935-0100 dimensions. Figure 2 - Model 14935-0300 dimensions.

4
GENERAL
Inspect valve upon receipt and file claim with carrier if parts are damaged or
missing.
Use the Model 14935-0100 valve only on Sta-Rite Model S200BP-2S and
S240BP-2S sand filters. Do not attempt to use it on other Sta-Rite filters; the
ports do not match.
Use the Model 14935-0300 valve only on Sta-Rite Model S7MD60 and
S7MD72 DE filters, and on Models SR-300-2U and SR-360-2U sand filter
models.
Mating halves of unions are on the matching filter models.
OPERATION
Valves are two position valves. Valve handle must be fully extended or fully
depressed. There is no in between, or throttling, position. Connect center
port to pump.
With valve stem extended, (Figure 3), pump water is directed to top
filter port. Bottom filter port is open to bottom valve port. Top valve port (to
waste) is idle.
NOTE: Lock the handle with lock pin provided.
With valve stem depressed, (Figure 4), pump water is directed to bottom fil-
ter port. Top filter port is open to top valve port (to waste).
NOTE: Lock the handle with lock pin provided.
MAINTENANCE
Filter Control Valve (Slide Valve):
Turn Pump OFF Before Proceeding.
1. Inspect bi-yearly. Check for ease of operation. If handle is difficult to
move, follow steps 2 through 6 below.
2. Disassemble valve:
A. Remove three screws in index plate.
B. Remove piston assembly using a straight upward pull. Rotate assem-
bly slightly for easy removal.
3. Inspect all O-Rings (Index Plate and Piston) for nicks, cuts, cracks, etc.
Replace if necessary.
4. Inspect valve seating areas for grooves, nicks, etc. Remove any corrosion
by sanding with No. 400 wet or dry emery cloth, using it wet.
NOTICE: Sand lightly so as not to destroy the seating area.
5. Lubricate O-Rings with Aqua-Lube1grease or petroleum jelly, before
reassembling valve.
6. Reassemble valve:
A. Insert piston assembly into valve body.
B. Replace three screws loosely.
C. Lift the valve handle into “FILTER” position. This will center the
index plate with the piston shaft and valve bore.
D. Tighten three screws securely.
E. Place the piston assembly in the “BACKWASH” position. It should
slide easily. If not, repeat the procedure above until the piston
moves freely.
Offset Adapters:
The offset adapters are assembled tight to the valve body with Silicone RTV
(Silastic #732). They should not loosen up or leak. If they do loosen or leak,
unscrew them completely, clean the threads and apply Silastic #732 to both
male threads (on the valve) and female threads (on the adapters). Retighten
the adapters until the adapters bottom on the valve body. Be sure you keep
the 6” distance between the port centers.
Figure 3 – “Filter” Position.
Water flow pattern shown with
valve handle in fully extended
position.
INLET
OUTLET
Effluent
(Filter Out)
Influent
(Filter In) From
Pump
To Waste
Return to
Pool
4128 0202
Lock Pin
Assembly
Figure 4 – “Backwash” Position.
Water flow pattern shown with
valve handle in fully depressed
position.
Normal
INLET
Normal
OUTLET
Effluent
(Filter Out)
Influent
(Filter In)
From
Pump
To Waste
Return to
Pool
4129 0202
Lock Pin
Assembly

5
Winterizing For Freezing Climates:
Place valve handle in an intermediate position, between “FILTER” and
“BACKWASH” positions.
CONNECTING SLIDE VALVE
TO FILTER SYSTEM
NOTICE: Filter ports and valve ports are furnished with union connections,
matching the connections of the filter ports. DO NOT use pipe sealants on
union collar (nut).
Use care before assembly not to damage union sealing surfaces or O-Ring.
Install union O-Rings in groove; tighten union collar hand tight.
FOR SLIP FITTINGS: Use correct solvent/cement when fitting piping or adapters
to slide valve. The valve body is ABS plastic, thus any good quality ABS to PVC
solvent can be used, such as Weld-On #793 or #710. Use P-70 (purple) primer
on PVC components only. Allow a minimum of four hours drying time prior to
pressure testing or operation. If ABS adapters are glued into valve ports in lieu
of PVC fittings, use Weld-On Solvent #771, #1707 or #773.
To avoid serious personal injury or property damage, follow
cement manufacturer’s instructions exactly.
FOR THREADED FITTINGS: Use Plasto-Joint Stik2only. Other substances
may degrade plastic and create poor joints and leaks.
NOTICE: Do not overtighten.
1Far Best Co., Los Angeles, CA
2Lake Chemical Co., Chicago, IL
Performance Curves for 2" Plastic Two Position Slide Valve,
Models 14935-0100 and 14935-0300
NOTE: Curves represent total loss of both halves of valve (double pass thru valve).
60 80 100 120 140 160
00
5
10
15
20
Flow in Gallons Per Minute
(Liters per Minute)
Pressure Loss in Feet (Meters)
Pressure Loss in P.S.I. (kPa)
25
2.16
4.32
6.49
8.65
4131 0202
10.81
(Filter Position)
(Backwash Position)
(378)
(14.9)
(18.7)
(44.7)
(59.6)
(74.5)
(530) (606)
(454)
(303)(227)
(1.5)
(3)
(4.6)
(6.1)
(7.6)

6
REPAIR PARTS LIST
Plastic Valve
Models 14935-0100,
14935-0300
4130 0202
1
2
7
5
6
11
10
9
9A
8
12
14
13
9
3
4
4
• Not illustrated.
* Not sold separately.
** Model 14935-0100 uses offset adapters; Model 14395-300 uses straight adapters.
Key Model Model
No. Description Qty. 14935-0100 14935-0300
1Handle 1
2Spring Pin 1 Kit #14930-0031 Kit #14930-0031
3Lever Linkage 2
4Spring Pin 2
4Spring Pin 2
5Index Plate (includes O-Ring)* 1 Kit #14930-0032 Kit #14930-0032
6O-Ring (available Separately) 1 35505-1246 35505-1246
7Lock Pin Assembly 1 WC30-84 WC30-84
8Body Assembly 1 WC112-134P* WC112-134P*
9Union Adapter** 2 14935-0011 U11-199P
9A Union Collar 2 U11-200P U11-200P
10 O-Ring 2 U9-362 –
11 Elbow, 2" NPT x 2" Slip 1 32435-4389 32435-4389
12 O-Ring** 2 Kit #14930-0033 Kit #14930-0033
13 Molded Piston Assembly 1
14 Screw 6 37107-0085 37107-0085
*Index Plate O-Ring 1 35505-1116 35505-1116
** O-Ring (available Separately) 2 35505-1318 35505-1318
}}
}}
}}

7

CREATE A RECORD OF YOUR WARRANTY AT STA-RITE:
• Complete a warranty registration at www.staritepool.com by clicking on “Register Products” and selecting Sta-Rite Pool OR
• Complete bottom portion completely and mail within 10 days of installation to Sta-Rite, Attn.: Pool Warranty Dept., 293 Wright St., Delavan , WI 53115
Warranty Registration Card
Name
Address
City State Zip
Installation (or Purchase) Date
Product Purchased
Model Number
■■New installation ■■Replacement
Years pool has been in service ■■less than 1 ■■1-3 ■■3-5 ■■5-10
This product was purchased from:
Company name
Address
City State Zip
STA-RITE LIMITED WARRANTY
For technical information about this product, contact the installer or call Sta-Rite at 262-728-9181.
Visit www.staritepool.com
• for more information about Sta-Rite products listed above
• to locate a Sta-Rite dealer near you
Product Specific Warranties (from date of installation)
Product Limited
Family Warranty Exceptions
Filters 1 Year System 3 Tank Bodies - 10 Yrs
Filter Valves 1 Year
Pumps 1 Year
Heaters 2 Years *Commercial Application - 1 Yr
Controls 1 Year
Above Ground Systems 1 Year
Lights and Niches 1 Year Lamps and Bulbs - 90 Days
White Goods 1 Year
Maintenance Equipment 90 Days
Drainer/Utility Pumps 90 Days
Replacement Parts 90 Days
Cleaners: Lil Shark 1 Year
Cleaners: Calypso 1 Year
Cleaners: Pool Shark 2 Years Footpad and Seal Flaps - 1 Yr
Cleaners: Great White 2 Years
* Commercial and multi-family application.
Retain this warranty certificate in a
safe and convenient location for your records.
Pumps, filters, skimmers, underwater lights (excluding bulbs),
accessories and fittings manufactured by Sta-Rite are warranted
to be free of defects in material and/or workmanship for one (1)
year from the original date of installation.
The foregoing warranties relate to the original consumer purchas-
er (“Purchaser”) only. Sta-Rite Industries shall have the option to
repair or replace the defective product, at its sole discretion.
Purchasers must pay all labor and shipping charges necessary to
replace the product covered by this warranty. Requests for war-
ranty service must be made through the installing dealer. This
warranty shall not apply to any product that has been subject to
negligence, misapplication, improper installation or maintenance,
or other circumstances which are not in Sta-Rite’s direct control.
Failure to have product installed by a professional in compliance
with local codes will void any and all manufacturer’s warranties.
This warranty sets forth Sta-Rite’s obligation and Purchaser’s
exclusive remedy for defective products.
STA-RITE SHALL NOT BE LIABLE FOR ANY CONSEQUENTIAL,
INCIDENTAL OR CONTINGENT DAMAGES WHATSOEVER.
THE FOREGOING WARRANTIES ARE EXCLUSIVE AND IN
LIEU OF ALL OTHER EXPRESS WARRANTIES. IMPLIED
WARRANTIES, INCLUDING BUT NOT LIMITED TO THE
IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS
FOR A PARTICULAR PURPOSE, SHALL NOT EXTEND
BEYOND THE DURATION OF THE APPLICABLE EXPRESS
WARRANTIES PROVIDED HEREIN.
Some states do not allow the exclusion or limitation of incidental
or consequential damages or limitations on how long an implied
warranty lasts, so the above limitations or exclusion may not
apply to you. This warranty gives you specific legal rights and you
may also have other rights which vary from state to state.
Supersedes all previous publications.
S4877PS (Rev. 7/21/04)
