OWNER’S MANUAL
Centrifugal Pumps
©2004, Sta-Rite Industries PRINTED IN U.S.A. S150 (Rev. 2/23/04)
293 Wright Street, Delavan, WI 53115
“C” and “CC” Series
Installation/Operation/Parts
For further operating, installation,
or maintenance assistance:
Call 1-262-728-9181

Safety 2
READ AND FOLLOW
SAFETY INSTRUCTIONS!
This is the safety alert symbol. When you see this symbol on your
pump or in this manual, look for one of the following signal words and be
alert to the potential for
personal injury:
warns about hazards that will cause serious personal injury,
death or major property damage if ignored.
warns about hazards that can cause serious personal injury,
death or major property damage if ignored.
warns about hazards that will or can cause minor personal
injury or property damage if ignored.
The label NOTICE indicates special instructions which are important but
not related to hazards.
Carefully read and follow all safety instructions in this manual and
on pump.
Keep safety labels in good condition.
Replace missing or damaged safety labels.
Motor normally operates at high temperature and will be too
hot to touch. It is protected from heat damage during operation by an
automatic internal cutoff switch. Before handling pump or motor, stop
motor, and allow it to cool for 20 minutes.

Ta b le of Contents 3
Page
General Safety ....................................................................................................2
Warranty..............................................................................................................3
Installation........................................................................................................4-5
Maintenance ....................................................................................................5-7
Troubleshooting .................................................................................................8
Repair Parts ..................................................................................................9-11
LIMITED WARRANTY
Sta-Rite Industries warrants to the original consumer of the products listed below, that they will be free from
defects in material and workmanship for the Warranty Period from the date of original installation or manufacture
as noted.
Product Warranty Period
Water Systems Products – jet pumps, whichever occurs first:
small centrifugal pumps, submersible pumps 1 year from date of original installation, or
and related accessories 2 years from date of manufacture
Hydro-Flow Filters 1 year from date of purchase
Signature 2000 Fibrewound Tanks 5 years from date of original installation
Pro-Source Steel Pressure Tanks 5 years from date of original installation
Pro-Source Epoxy-Line Tanks 3 years from date of original installation
Sump/Sewage/Effluent Products 1 year from date of original installation, or
2 years from date of manufacture
Our warranty will not apply to any product that has been subject to negligence, misapplication, improper instal-
lation or maintenance. In the event a three phase submersible motor is operated with single phase power
through a phase converter, or if three-leg ambient compensated, extra-quick trip overload relays of recom-
mended size are not used, our warranty is void.
Buyer’s only remedy and Sta-Rite Industries’ only duty is to repair or replace defective products (at Sta-Rite
Industries’ choice). Buyer agrees to pay all labor and shipping charges associated with this warranty and to
request warranty service through the installing dealer as soon as a problem is discovered. If warranty service is
requested more than 30 days after the Warranty Period has ended, it will not be honored.
STA-RITE INDUSTRIES SHALL NOT BE LIABLE FOR ANY CONSEQUENTIAL, INCIDENTAL, OR CONTIN-
GENT DAMAGES WHATSOEVER.
THE FOREGOING WARRANTIES ARE EXCLUSIVE AND IN LIEU OF ALL OTHER EXPRESS WARRANTIES.
IMPLIED WARRANTIES, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OF MER-
CHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, SHALL NOT EXTEND BEYOND THE WAR-
RANTY PERIOD PROVIDED HEREIN.
Certain states do not permit the exclusion or limitation of incidental or consequential damages or the placing of
limitations on the duration of an implied warranty, therefore, the limitations or exclusions herein may not apply.
This warranty sets forth specific legal rights and obligations, however, additional rights may exist, which may
vary from state to state.
Supersedes all previous publications.
Sta-Rite Industries, 293 Wright St., Delavan, WI 53115

Installation 4
SERIES C/CC CENTRIFUGAL PUMPS
The “C” and “CC” Series pumps are close coupled pumps with optional
traps. “CC” Series have cast iron volutes and adapters. “C” Series have
bronze volutes and adapters. Impellers on both series are bronze.
INSTALLATION
Location of Unit
Install pump as close to liquid source as possible, using short, simple
suction piping.
Piping should be as direct as possible; elbows and other fittings greatly
increase friction losses.
Allow service and maintenance access.
Mount on solid, rigid, vibration-free foundation.
Protect pump against flooding and excess moisture.
Piping
Pump is not self-priming. Unless liquid source level is above pump suc-
tion at all times, install a foot valve on suction pipe.
Support both suction and discharge piping independently near the pump
to avoid placing strains on pump. Start all piping at pump to avoid strains
left by a gap at last connection.
If possible, increase size of both suction and discharge piping if more
than short runs are required.
NOTICE: Never use a suction pipe smaller than the suction connection of
the pump.
NOTICE: If a reducer is necessary in the suction piping, always use an
eccentric reducer with the straight side on top.
NOTICE: BE SURE suction does not leak. Suction pipe must slope grad-
ually upward to the pump. Avoid any fittings which might cause an air
trap.
Install gate valve and union in suction and discharge lines. If complete
pump removal is required for service, close gate valves and disconnect at
unions.
Grounding the Motor
Can shock, burn or cause death.
Ground motor before working
on pump or motor.
Install, ground, wire and maintain this pump in accordance with the
National Electrical Code, Article 250, or applicable local Codes and
Ordinances.
Ground the pump permanently using a wire of size and type specified
by National or Local Electrical Code.
Connect ground wire first. Connect to ground first, then to motor termi-
nal provide. Do not connect motor to electrical power supply until unit is
permanently grounded. Any other sequence may cause serious shock
hazard. Do not ground to a gas supply line.
The motor grounding wire need not be larger than the wires supplying the
motor, provided the supply wires conform to the wiring date included in
this manual (see Table I, Page 5).
Hazardous
voltage

Installation / Maintenance 5
Wiring
NOTICE: For 575 volt installations, see motor nameplate. Consult a
licensed electrician for wiring information. Installation must meet code.
For 200, 230, and 460 volt installations, check fusing/wiring data chart
(Table I, below) before connecting pump to power source.
Check that voltage/frequency on motor nameplate are identical with volt-
age/frequency of incoming power supply.
NOTICE: Wire dual voltage motors correctly according to wiring diagram
on motor.
Check rotation of motor. Look through opening in adapter. Rotation
should be clockwise when viewed from the motor end. If not:
•Turn pump OFF and disconnect from power source.
•For three-phase motors, reverse any two leads to motor starter.
•For single phase motors, re-connect according to wiring diagram on
motor.
Priming the Pump
NOTICE: NEVER run pump dry. To run pump dry may damage seals.
To Prime:
1. If pump is installed below liquid source level, open gate valve in suc-
tion line and flood suction.
2. If pump is not installed below liquid source level, fill pump through a
tee installed in pump discharge and fitted with a priming plug in the
upright position.
Tighten priming plug securely after priming!
TABLE I - RECOMMENDED FUSING AND WIRING DATA - 60 CYCLE MOTORS
DIAMETER IN FEET FROM MOTOR TO METER (METERS)
BRANCH 0’(0) 101’(31) 201’(62) 301’(92) 401’(123)
MAX. FUSE* TO TO TO TO TO
MOTOR LOAD RATING 100’(30) 200’(61) 300’(91) 400’(122) 500’(152)
HP PHASE VOLTS AMPS AMPS
WIRE SIZE
31230 17.0 25 10 (5.5) 10 (5.5) 10 (5.5) 8 (8.4) 8 (8.4)
33200 11.0 15 14 (2) 14 (2) 12 (3) 10 (5.5) 10 (5.5)
33230 9.6 15 14 (2) 14 (2) 12 (3) 12 (3) 10 (5.5)
33460 4.8 15 14 (2) 14 (2) 14 (2) 14 (2) 14 (2)
51230 28.0 40 8 (8.4) 8 (8.4) 8 (8.4) 6 (14) 6 (14)
53200 17.5 25 10 (5.5) 10 (5.5) 10 (5.5) 8 (8.4) 8 (8.4)
53230 15.2 20 12 (3) 12 (3) 10 (5.5) 10 (5.5) 8 (8.4)
53460 7.6 15 14 (2) 14 (2) 14 (2) 14 (2) 14 (2)
*A Fusetron is recommended instead of a fuse in any motor circuit.
IMPORTANT: BE SURE lead wire opening on end of
motor is fully sealed when conduit or a pressure switch
is not used. Failure to seal it properly will allow dirt, rain,
bugs, etc. to enter back compartment of motor through
conduit opening and cause switch malfunction.

Stationary
Seat
Rotating
Seal
Spring
1419 1294
If Gear Puller is used,
place jackscrew here.
Rotating Seat will come off
with adapter/sealplate.
1420 1294
Figure 1
Figure 2
Maintenance 6
MAINTENANCE
Little or no maintenance to pump is required other than possible replace-
ment of shaft seal after a reasonable period of operation (see below).
Lubricate motor according to motor manufacturer’s instructions. Periodic
greasing is required for most motors.
PUMP STORAGE
Drain pump to prevent freezing.
Keep motor dry and loosely covered. Do not wrap with plastic sheeting;
trapped moisture could cause corrosion or insulation deterioration.
NOTICE: Agood rust inhibitor in the liquid end of cast iron pumps is rec-
ommended to prevent excessive corrosion.
PUMP START-UP AFTER STORAGE
Replace all drain plugs and close all drain valves in system.
Be sure all connections are tightly sealed.
After inital check is made, fill pump according to “Priming the Pump”
above.
SHAFT SEAL REPLACEMENT
NOTICE: The highly polished and lapped faces of the seal are easily
damaged. Follow instructions and handle the seal with care.
Be sure unit is grounded and power
disconnected before attempting any
work on pump or motor.
REMOVAL OF OLD SEAL
Refer to Figure 1 for Mechanical Seal parts identification.
1. Remove motor hold down bolts and bolts holding adapter/seal plate to
volute. Slide motor, adapter/seal plate and impeller backward to clear
volute.
2. Remove impeller screw and washer from end of shaft and slide
impeller off of shaft.
3. Unbolt adapter/seal plate from motor.
4. Use two screwdrivers (Figure 2) or bearing puller to carefully separate
motor from adapter/seal plate, bringing rotating half of seal off with
adapter/seal plate. Shaft sleeve may come off with seal.
5. Use hammer, if necessary, to drive shaft sleeve out of seal. Clean up
shaft sleeve with emery paper if necessary.
6. Place adapter/seal plate face down on bench and drive old stationary
half of seal out of adapter/seal plate by carefully tapping with screw-
driver and hammer (Figure 3).
7. Use a wire brush to thoroughly clean adapter/seal plate cavity. Be sure
all dust and grime are out of seal cavity before installing new seal.
Hazardous
voltage
If Gear Puller is used,
place jackscrew here.
Rotating Seat will
come off with
adapter/sealplate

Maintenance 7
INSTALLING NEW SEAL
1. NOTICE: Seal faces are highly polished and lapped. Handle with
care. Any mar, nick or scratch on seal face will cause it to leak.
BE SURE to install with polished faces toward each other.
2. Clean polished surface of ceramic seat with clean cloth.
3. Wet O-Ring around ceramic seat with liquid soap.
4. Press stationary (ceramic) half of seal cavity into cavity firmly and
squarely with thumb pressure. If it does not seat properly, remove and
place seal face up on bench. Re-clean adapter/seal plate cavity. Seal
should now seat correctly.
5. If seal does not seat after re-cleaning adapter/seal plate cavity, place
a cardboard washer over polished face of seal and carefully press
into place using a piece of 1” standard pipe as a press (Figure 4).
NOTICE: BE SURE you do not scratch seal face.
6. Dispose of cardboard washer and recheck seal face to be sure it is
free of dirt, foreign particles, scratches and grease.
7. Inspect shaft and shaft sleeve to be sure they are clean.
8. Re-install O-Ring, shaft sleeve and slinger on shaft.
NOTICE: Asmall amount of grease or Never-Seez under shaft sleeve
will help prevent shaft and sleeve from freezing together when pump
is in service.
9. Remount adapter/seal plate to motor, being careful not to scratch seal
face.
10. Apply liquid soap to inside diameter and outside face of rubber drive
ring on rotating half of seal.
11. Slide seal assembly onto shaft sleeve (sealing face first) far enough
so that seal spring is located on shaft sleeve.
NOTICE: Be careful not to nick carbon seal face when passing it
over end of shaft sleeve.
12. Slide impeller and gaskets onto shaft with key in position. Be sure to
maintain proper order as shown in Exploded View, Page 9.
13. Install washer and impeller screw on end of shaft and tighten screw
until it is snug. This should locate seal in place and bring seal faces
together.
14. Reinstall motor, adapter and impeller assembly on volute, using new
gasket.
15. Reinstall motor hold-down bolts.
16. Check all bolts for tightness.
1421 1294
1" Standard Pipe
Stationary Seat
Cardboard
Washer
(Supplied with seal)
1422 1294
Figure 3
Figure 4

Troubleshooting 8
SYMPTOM KEY NUMBERS FOR CAUSES
Pump does not deliver liquid 1, 2, 3, 4, 6, 10, 12, 14, 15, 20, 21
Pump delivers too little flow 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13, 15, 18, 20, 21, 27, 28
Delivery pressure too low 5, 12, 13, 14, 15, 18, 20, 27, 28
Pump loses prime after starting 2, 3, 5, 6, 7, 10
Pump needs too much power 13, 14, 15, 16, 17, 18, 21, 22, 24, 25, 27
Seal leaks 22, 24, 29, 30
Pump vibrates or is noisy 2, 3, 4, 8, 9, 10, 11, 19, 21, 22, 23, 24, 25, 26, 28, 29, 30,
31, 32, 33, 34
Motor bearings have short life 22, 24, 25, 26, 29, 30, 31, 32, 33, 34
Pump overheats and/or seizes 1, 4, 19, 20, 22, 25, 26, 29, 30
CAUSES
1. Pump not primed. 18. Viscosity of liquid different than design.
2. Pump or suction pipe not completely full of liquid. 19. Pump operating at very low capacity.
3. Suction lift too high. 20. Parallel operation of pumps unsuited for such operation.
4. Pump cavitating; increase suction pressure. 21. Foreign matter in impeller.
5. Excessive amount of air or gas in liquid. 22. Misalignment of pump or piping.
6. Air pockets in suction pipe. 23. Foundations not rigid.
7. Air leakage in suction pipe. 24. Shaft bent.
8. Foot valve too small. 25. Rotating part rubbing on stationary part.
9. Foot valve partially clogged. 26. Bearings worn.
10. Suction pipe inlet not sufficiently submerged. 27. Wear ring worn.
11.Impeller, suction or trap partially or completely 28. Impeller damaged.
plugged. 29. Shaft running off center due to worn bearings or
12. Speed too low. misalignment.
13. Voltage wrong or too low. 30. Impeller out of balance resulting in vibration.
14. Wrong direction of rotation. 31. Excessive grease in bearing causing high bearing
temperature.
15. System head too high for pump design. 32. lack of lubrication.
16. System head too low for pump design. 33. Dirt in bearings.
17. Specific gravity of liquid different than design. 34. Rust in bearings due to water getting into motor.
Read symptom describing problem below at left. Causes
for problems (bottom) are keyed to numbers at right.
Check pump for causes listed at right and correct those
that apply.
Hazardous voltage. Can shock, burn or
kill. Take all normal precautions for the voltage involved.

Repair Parts 9
1839 0695
5
4
3
2
1
6
7
1128 0695
7
3
4
5
2
1
6
8
9
Key Part
No. Description Cast Iron Bronze
1* Lock Handle C154-18D C154-18D
2Cover - 6” C30-30 C3-78DZZ
2Cover - 8” C3-105 C3-105D
2Cover - 11” C3-76 –
3O-Ring - 6” U9-46 U9-46
3O-Ring - 8” U9-171 U9-171
3O-Ring - 11” U9-105 –
4Strainer Basket - 6” C108-11P C108-11P
4Strainer Basket - 8” C108-34SS C108-34SS
4Strainer Basket - 11” C108-25SS –
5Suction Trap Body - 6” C53-5B C53-5D
5Suction Trap Body - 8” C53-21 C53-21D
5Suction Trap Body - 11” C53-8 –
6** Pipe Plug 1/4” U78-57DT U78-57DT
7Gasket, Flange C20-19 C20-19
8Capscrew, 3/8-16x1-3/4” – U30-77C
9Nut, Hex 3/8-16 – U36-38C
•Capscrew, 5/16-18x7/8” U30-61C(4) U30-61C(4)
Suction Trap Complete - 6” Pkg. #51 Pkg. #56
Suction Trap Complete - 8” Pkg. #98 Pkg. #99
Suction Trap Complete - 11” Pkg. #74 –
Quantity 1 unless otherwise noted ( ).
•Not illustrated.
*6” has 2 each; 8” & 11” have 4 each.
** 6” & 8” have 1 each; 11” has 2 each.
6” Suction Trap 8” and 11” Suction Trap
NOTICE:
Traps are not
included with pumps.

Repair Parts 10
1
2
5
3
4
6
7
8
9
10 12
11
17
18
13
14
16
21
22
23
6
15
1904 0795 CC P/S
19
20
CCMH-136 CCHH-137S
CCM2H-136 CMH-136 CCHH3-137S
CCM2H-136S CMH3-136 CCHH36-137
CCMH3-136S CCMH36-136 CCH2H-137S CHH-137
CCM2H3-136 CM2H-136 CCH2H3-137 CHH3-137
Key CCM2H3--136S CM2H3-136 CCH2H3-137S CH2H3-137
No. Description Qty. 3 HP 3 HP 3 HP 3 HP
1Motor 230V/60H/1 Ph. 1 C218-177 C218-177 C218-177 C218-177
1Motor 230/460V/60H/3 Ph. 1 C218-179 C218-179 C218-179 C218-179
1Motor 575V/60H/3 Ph. 1 – C218-290C C218-290C –
1Motor 200V/60H/1 Ph. 1 C218-191 C218-191 C218-191 C218-191
1Motor 200V/60H/3 Ph. 1 C218-178 C218-178 C218-178 C218-178
2Water Slinger-1 Ph. 1 C69-15 C69-15 C69-15 C69-15
2Water Slinger-3 Ph. (†) 1 C69-16 C69-16 C69-16 C69-16
3Key, Impeller 1 U65-42A U65-42A U65-42A U65-42A
4O-Ring 1 U9-265 U9-265 U9-265 U9-265
5Adapter 1 C2-81 C2-81D C2-81 C2-81D
6Lockwasher, 3/8” 8 U43-12ZP U43-12ZP U43-12ZP U43-12ZP
7Capscrew, 3/8-16x7/8” 4 U30-73ZP U30-73ZP U30-73ZP U30-73ZP
8Gasket 1 C20-77 C20-77 C20-77 C20-77
9Shaft Seal 1 U109-433SS U109-433SS U109-433SS U109-433SS
10 Shaft Sleeve 1 C23-58 C23-58 C23-58 C23-58
11 Gasket, Sleeve 1 C20-101 C20-101 C20-101 C20-101
12 Impeller 1 C105-224DD C105-224DD – –
12 Impeller (Silicon Brass) 1 C105-224DG C105-224DG C105-224DF C105-224DF
13 Gasket, Impeller 1 C20-100 C20-100 C20-100 C20-100
14 Washer, Impeller 1 C43-45SS C43-45SS C43-45SS C43-45SS
15 Washer, Stat-O-Seal 1 C43-46 C43-46 C43-46 C43-46
16 Screw, Impeller 3/8-16x3/4” 1 U30-72SS U30-72SS U30-72SS U30-72SS
17 Wear Ring Only 1 C23-40 C23-40 C23-40 C23-40
18 Volute Assembly (includes 18A & 20) 1 C201-174 C201-174D C201-174 C201-174D
18A Volute Assemby (Incl. 17 Only) 1 C101-167 C101-167D C101-167 C101-167D
19 Capscrew 5/16-18x3/4” 4 U30-62ZP U30-62ZP U30-62ZP U30-62ZP
20 Pipe Plug, 1/4” NPT, Hex Head 1 U78-941ZPV U78-941ZPV U78-941ZPV U78-941ZPV
21 Stud, 3/8-16x1-1/4” 4 U30-22SS U30-22SS U30-22SS U30-22SS
22 Nut, Hex 3/8x16 4 U36-38ZP U36-38SSW U36-38ZP U36-38SSW
23 Pipe Plug, 1/4” NPT 1 U78-57SSS U78-57SSS U78-57SSS U78-57SST
Model numbers with a “3” in them indicate a 3-Phase motor.
Model numbers with a “2” in them indicate a 200V motor.
NOTE: C Series with different hydraulic numbers (CCMH-93) are older models that use different parts.
Consult factory for older models.

1
2
5
3
4
6
7
8
9
10 12
11
17
18
13
14
16
21
22
23
6
15
1904 0795 CC P/S
19
20
Repair Parts 11
Model numbers with a “3” in them indicate a 3-Phase motor.
Model numbers with a “2” in them indicate a 200V motor.
(†) Model number CCH2J3-138S has no Water Slinger.
NOTE: C Series with different hydraulic numbers (CCMH-93) are older models that use different parts.
Consult factory for older models.
CCHJ-138
CCHJ-138S
CCHJ3-138S CHJ-138
CCHJ36-138 CHJ3-138
Key CCH2J3-138S CH2J3-138
No. Description Qty. 5 HP 5 HP
1Motor 230V/60H/1 Ph. 1 C218-180 C218-180
1Motor 230/460V/60H/3 Ph. 1 C218-182 C218-182
1Motor 575V/60H/3 Ph. 1 C218-292C –
1Motor 200V/60H/3 Ph. 1 C218-181 C218-181
2Water Slinger-3 Ph. (†) 1 C69-16 –
3Key, Impeller 1 U65-42A U65-42A
4O-Ring 1 U9-265 U9-265
5Adapter 1 C2-81 C2-81D
6Lockwasher, 3/8” 8 U43-12ZP U43-12ZP
7Capscrew, 3/8-16x7/8” 4 U30-73ZP U30-73ZP
8Gasket 1 C20-77 C20-77
9Shaft Seal 1 U109-433SS U109-433SS
10 Shaft Sleeve 1 C23-58 C23-58
11 Gasket, Sleeve 1 C20-101 C20-101
12 Impeller (Silicon Brass) 1 C105-224DE C105-224DE
13 Gasket, Impeller 1 C20-100 C20-100
14 Washer, Impeller 1 C43-45SS C43-45SS
15 Washer, Stat-O-Seal 1 C43-46 C43-46
16 Screw, Impeller 3/8-16x3/4” 1 U30-72SS U30-72SS
17 Wear Ring Only 1 C23-40 C23-40
18 Volute Assembly (includes 18A & 20) 1 C201-174 C201-174D
18A Volute Assemby (Incl. 17 Only) 1 C101-167 C101-167D
19 Capscrew 5/16-18x3/4” 4 U30-62ZP U30-62ZP
20 Pipe Plug, 1/4” NPT, Hex Head 1 U78-941ZPV U78-941ZPV
21 Stud, 3/8-16x1-1/4” 4 U30-22SS U30-22SS
22 Nut, Hex 3/8x16 4 U36-38ZP U36-38SSW
23 Pipe Plug, 1/4” NPT 1 U78-57SSS U78-57SSS

12
