Stadium Mission User manual

Mission - Storage Table
Dimensions
Width - 45cm
Depth - 20cm
Height -45cm
Issue 1 - 29/04/2016
Important – Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts
email us at techstyle.spar[email protected]
Assembly Instructions - Please keep for future reference MS2084

1
Safety and Care Advice
Important – Please read these instructions fully before starting assembly
• Check you have all the
components and tools listed on
page 2.
• Remove all fittings from the
plastic bags and separate them
into their groups.
• Keep children and animals
away from the work area, small
parts could choke if swallowed.
• Make sure you have enough
space to layout the parts before
starting.
• Do not stand or put weight on
the product, this could cause
damage.
• Assemble the item as close
to its final position (in the same
room) as possible.
• Assemble on a soft level
surface to avoid damaging the
unit or your floor.
• Parts of the assembly will be
easier with 2 people.
• We do not
recommend the
use of power
drill/drivers for
inserting screws,
as this could damage the unit.
Only use hand screwdrivers.
• Dispose of all packaging
carefully and responsibly.
• Only clean using a damp cloth
and mild detergent, do no use
bleach or abrasive cleaners.
• From time to time check that
there are no loose screws on
this unit.
• This product should not be
discarded with household
waste. Take to your local
authority waste disposal centre.
Care and maintenance
Ruler - Use this ruler to help correctly identify the screws
Tools required
Crosshead screwdriver
(medium & large)
Flatblade screwdriver
(medium)
Small
hammer
Ruler/tape
measure
Eye
protection
(when using
a hammer
or glue)
0 5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100 110 115 120 125 130 135 140 145 150 155 160 165 170
105

Components - Panels
Please check you have all the panels listed below
2
Top
A
If you have damaged or missing components,
email us at [email protected]
Side x 2
BRail x 2
C
Base
D
Please check you have all the fittings listed below
Camlock bolt x 4 Screw x 8
b
Note: The quantities below are the correct amount to complete the assembly. In some cases more
fittings may be supplied than are required.
Components - Fittings If you have damaged or missing components,
email us at [email protected]
a
Camlock nut x 4
c

3
Assembly Instructions
Step 1
Assembly
a: Insert 4 x camlock
bolt ainto top A.
b: Attach 2 x rail Conto
1 x side Busing 2 x
screw bfor each.
c: Slide base Dinto
the assembled frame as
shown.
d: Attach 1 x side B
onto 2 x rail Cusing 4 x
screw b.
e: Attach top A
as shown. Insert 4 x
camlock nuts cand
rotate each clockwise for
about 1/4 to 1/2 a turn or
until the nut “connects”
with the bolt and is
secure.
Assembly is complete.
c:
b:
d:
e:
A
a
a
a
a
a:
B
b
B
A
c
C
c
If you need any help or have damaged or missing parts, email techstyle.spar[email protected]
Techstyle Spares, Stadium North, Tofts Farm Industrial Estate, Brenda Road, Hartlepool, TS25 2DH
