Stairmaster 7000PT Domestic Silver Quick start guide

STM_7000PT_exp_ 9-25-08 1
Stairmaster 7000PT Domestic Silver
SEE DETAIL
SEE DETAIL
DETAIL A
A
D
2 8
9
3
10
11
13
19
18
15
16
14
110 Rivnut in frame
Console
Display board
Procesor board
109 Overlay kit (Silver)

2 STM_7000PT_exp_ 9-25-08
Stairmaster 7000PT Domestic Silver
TRANSMISSION ASSEMBLY
WHEEL ASSEMBLY
TRANSMISSION ASSEMBLY MOUNTINGTO FRAME
TRANSMISSION CHAIN ASSEMBLY
5.
23
24
25
26
27
28
29
30
31
32
33
41
35
36
34
37
38
39
40
42
34 43
40
29
40
29
33 52
50
39
50
51
49
53
44
45
47
54
55
57
56
22
21
20
46
48

STM_7000PT_exp_ 9-25-08 3
Stairmaster 7000PT Domestic Silver

4 STM_7000PT_exp_ 9-25-08
Stairmaster 7000PT Domestic Silver
Plastic Rivets
Plastic Rivets
Panel
Panel
Plastic Rivets
2 x 113
2 x 112
8 x 114

STM_7000PT_exp_ 9-25-08 5
Stairmaster 7000PT Domestic Silver
111
101

7000PT,WBOM,SILVER,DOM.,SM200103
REF PART # DESCRIPTION REF PART # DESCRIPTION
2 SM25583 ASSY,CONSOLE,C40,NLS GREY 60 SM27268 ASSEMBLY,CHAIN,STEP DRIVE,7000
3 SM27791-03 WIREFORM,MAGAZINE HOLDER 61 SM10037-03 ADJUSTER,BEARING,STEPMILL,N/F
5 SM27783-03 WIREFORM ASSY, WATER BOTTLE, BLACK 62 SM25862 (CS) Kit,Pillow Block,HW,7000PT
6 SM25244 SCREW,.250-20X.50 BUTTON HD CP 63 SM22427 SCREW,SET,SOCKET,.250-28 X .25
7 SM25454 Console Bolt Kit (4) 64 SM20012 BEARING,PILLOW BLOCK
8 SM40070-001 PCBA, DISPLAY, CJ40 66 SM22848 PLATE,BEARING,STEPMILL,V2 (After 9/00)
9 SM27130 PCB ASSY,C40 PROCESS(M128)NON- 68 SM25578 ASSY,HANDRAIL,LH,NLS GREY
10 SMQ36271-001 FOAM,PAD 70 SM25579 ASSY,HANDRAIL,RIGHT,NLS GREY
11 SM25492 (CS) ASSY,FRAME,MAIN,7000PT,GREY 72 SM25495 (CS)PANEL,MAIN-DCL,RT,7000PT,GREY
13 SM20017 LEVELER, LEG 73 SM22086 RIVET,PANELS, PLASTIC
14 SM25496 (CS) Kit, Step Shaft,HW,7000PT 75 SM25858 PANEL,INS,RH,7000 PT,NLS GREY
15 SM22849 SHAFT,STEP,7000 PT,V2 77 SM25859 PANEL,INS,LH,7000 PT,NLS GREY
16 SM25493 (CS)ASSY,STEP W/TREAD,3 HOLES, GREY 78 SM24757 RIVET,PLASTIC,PERM.,7000 PT
18 SM21363 FASTENER,CHRISTMASTREE,PLASTIC 80 SM25494 (CS)PANEL,TOP,PF W/DCL,7000PT,GREY
19 SM21398 TREAD,STEP,3 HOLES,7000 PT 82 SM25573 PANEL,BACK, NLS GREY
20 SM20205 ALTERNATOR,PRESTOLITE,1992 84 SM25575 PANEL,BOTTOM, NLS GREY
21 SM21164 (CS)ASSY,ALT,STEPMILL 86 SM25577 ASSY,PANEL,MAIN,LH,NLS GREY
22 SM23830 (CS)ASSY,ALT W/POLY-V PULLEY 87 SM22213 WASHER,FINISHING,.375
23 SM20202 BELT,POLY-V,200J6 88 SM22142 WASHER,FLAT .62 OD X .39 ID
24 SM21247 PULLEY,ALTERNATOR,POLY-V 89 SM24643 NUT,.375-16,HX JAM,NYLON INSRT
25 SM10860 BRACKET,TRANSMISSION,STEPMILL 90 SM22937 SCREW,.375-16 X 3.50,HX HD CAP
26 SM22075 WASHER,.312 USS FLAT 91 SM22323 CAP,FINISHING
27 SM22146 SCREW,.312-18X1.25,HEX HD CAP 92 SM22097 SCREW,.375-16X3.25,HEX HD CAP
28 SM22435 GROMMET,.25 ID x .44 OD 93 SM15034 GROMMET, .88
29 SM22038 WASHER,.312 94 SM23792 SADDLE, WIRE
30 SM22164 SCREW,.250-20X1.25,HEX HD CAP 95 SM21769 ASSY,MAIN CABLE,C2,V2,7000 PT
31 SM20547 BRACKET,TRANSMISSION, OUT 96 SM22933 ASSY,RELAY/RESISTOR,7000PT
32 SM22139 SCREW,.250 X .50,SELF TAPPING 97 SM25863 (CS) Kit,Relay/Resistor,Mounting HW,7000PT
33 SM25497 (CS) Kit,Transmission,Mounting HW,7000PT 98 SM21768 ASSY,MAIN POWER HARN.,V2,7000
34 SM22037 SCREW,SET,SOCKET,.250-20 X .38 99 SM25869 (CS) Kit,Power Connector,HW,7000PT
35 SM23427 SPROCKET, 12T 100 SM24640 SCREW,.375-16 X 1.75 HX HD CAP
36 SM22043 SCREW,.500-13X2.00,HEX HD CAP 101 SM25581-01 BRACKET,CONSOLE MOUNT,NLS GREY
37 SM20007 SPROCKET, IDLER 103 SM27831 ASSY CABLE, UPPER MAIN 7000
38 SM20693 ARM,IDLER,STEPMILL 109 SM25877 KIT,C40 OVERLAY,GRY
39 SM22042 NUT,.500-13,NYLON INSERT 110 SM21767 RIVNUT,.312-18 UNC
40 SM22036 NUT,.250-20,NYLON INSERT 111 SM23545 ASSY,PCB,RELAY,STEPMILL
41 SM10059 BRACE,TRANSMISSION,STEPMILL 112 002-0662 WELDMENT,BRACKET,HANDRAIL,FRON
42 SM20001 REDUCER, SPEED 113 002-0665 WELDMENT,BRACKET,HANDRAIL,BACK
43 SM24662 PULLEY,TRANSMISSN,POLY-V,7000 114 SM17579 SCREW,FH,10-32X.75,HEX DR, SS
44 SM23424-03 WLDMNT,SPRCKT,UPPER,STEPMILL PARTS NOT SHOWN ON DRAWING
45 SM23257 CHAIN,DRIVE,#40 X 41.50" LG REF PART # DESCRIPTION
46 SM23591 ASSY,SPEED REDUCER,STEPMILL,SV NS SM22869 MANUAL 7000TP C-40 (Send SM25971 also)
47 SM25439 LINK, MASTER, #40 NS SM23853 TOOL, REMOVAL, COVER FASTENERS
48 SM22434 ASSY,SPEED REDUCER,7000 PT,SV NS SM24381 POWER SUPPLY,PS-7,3-PIN
49 SM20114 SPACER, ALTERNATOR NS SM25971 MANUAL,ADDENDUM,OWNERS,7000PT
50 SM22091 WASHER,.50 SAE FLAT
51 SM22191 WASHER,SHOULDER,.38 I.D.
52 SM26669 SCREW,.500-13x4.50,HEX HD CAP
53 SM20808 PAD, RUBBER TRANSMISSION
54 SM22154 NUT, 5/16-18 SERRATED FLANGE
55 SM20036 WHEEL,TRANSPORT
56 SM20047 COTTER, HAIRPIN PLATED
57 SM22839 PIN,CLEVIS,.50 DIA. X 5.00
58 SM25498 (CS) Kit,Bearing plate,HW,7000PT
59 SM10205-03 WLDMNT,SPRCKT,LWR,STEP,W/B PWD
