Stamina Avari Fitness A550-043 User manual

When calling for parts or
service, please specify
the following number :
Model#: A550-043
CAUTION:
Weight on this product should not exceed 250 lbs.
This Product is Distributed Exclusively by
2040 N. Alliance, Springeld, MO 65803
Customer Service
1 [phone]
www.staminaproducts.com
Product May Vary Slightly From Pictured.
!WARNING !
Exercise can present a
health risk. Consult a
physician before beginning
any exercise program with
this equipment. If you feel
faint or dizzy, immediately
discontinue use of this
equipment. Serious bodily
injury can occur if this
equipment is not assembled
and used correctly. Serious
bodily injury can also occur
if all instructions are not
followed. Keep others and
pets away from equipment
when in use. Always make
sure all bolts and nuts are
securely tightened prior to
each use. Follow all safety
instructions in this manual.
STAMINA PRODUCTS
MADE IN CHINA
© 2013 Stamina Products, Inc.
2013, 04
Owner's
Manual
Compact Elliptical Trainer

TABLE OF CONTENTS
Safety Instructions ...................................... 2
Before You Begin ........................................ 4
Equipment Warning, Caution & Notice Labels ... 5
Hardware Identication Chart .................... 6
Assembly Instructions ................................ 7
Set Up Instructions ................................... 10
Operational Instructions ........................... 11
Storage ....................................................... 13
Maintenance ............................................... 13
Conditioning Guidelines ........................... 14
Warm-Up and Cool-Down ......................... 15
Product Parts Drawing .............................. 16
Parts List .................................................... 17
Warranty ..................................................... 19
Notes ........................................................... 20
Fax/Mail Ordering Form ............................ 22
2
1. Read all warnings and cautions posted on the AVARI® Compact Elliptical Trainer.
2. The AVARI® Compact Elliptical Trainer should only be used after a thorough review of the Owner’s
Manual. Make sure that it is properly assembled and tightened before use.
3. We recommend that two people be available for assembly of this product.
4. Keep children away from the AVARI® Compact Elliptical Trainer. Do not allow children to use or
play on the AVARI® Compact Elliptical Trainer. Keep children and pets away from the AVARI®
Compact Elliptical Trainer when it is in use.
5. It is recommended that you place this exercise equipment on an equipment mat.
6. Set up and operate the AVARI® Compact Elliptical Trainer on a solid level surface. Do not position
the AVARI® Compact Elliptical Trainer on loose rugs or uneven surfaces.
7. Make sure that adequate space is available for access to and around the AVARI® Compact Elliptical
Trainer.
8. Before using, inspect the AVARI® Compact Elliptical Trainer for worn or loose components, and
securely tighten or replace any worn or loose components prior to use.
9. Consult a physician prior to commencing an exercise program. If, at any time during exercise, you
feel faint, dizzy, or experience pain, stop and consult your physician.
10.Followyourphysician’srecommendationsindevelopingyourownpersonaltnessprogram.
11.Alwayschoosetheworkoutwhichbesttsyourphysicalstrengthandexibilitylevel.Knowyour
limits and train within them. Always use common sense when exercising.
12. Do not wear loose or dangling clothing while using the AVARI® Compact Elliptical Trainer.
13. Never exercise in bare feet or socks; always wear correct footwear, such as running, walking, or
crosstrainingshoes.Besurethattheytwell,providefootsupportandfeaturenon-skidrubbersoles.
14. Be careful to maintain your balance while using, mounting, dismounting, or assembling the AVARI®
Compact Elliptical Trainer, loss of balance may result in a fall and serious bodily injury.
15. To maintain your balance, always mount or dismount the AVARI® Compact Elliptical Trainer from
the lowest foot pedal. Refer to the detail instructions on page 12.
16.Keepbothfeetrmlyandsecurelyonthepedalcapswhileexercising.
17.Thisunitisnotequippedwithafree-wheel.Pedalspeedshouldbereducedinacontrolledmanner.
18. The AVARI® Compact Elliptical Trainer should not be used by persons weighing over 250 pounds.
19. The AVARI® Compact Elliptical Trainer should be used by only one person at a time.
20. The AVARI® Compact Elliptical Trainer is for consumer use only. It is not for use in public or
semipublic facilities.
SAFETY INSTRUCTIONS
!WARNING This product contains a chemical known to the State of California to cause
cancer and birth defects or other reproductive harm.
Consult your physician before starting this or any exercise program. This is
especially important if you are over the age of 35, have never exercised before,
are pregnant, or suffer from any health problem. This product is for home use
only. Do not use in institutional or commercial applications. Failure to follow
all warnings and instructions could result in serious injury or death.
To reduce the risk of serious injury, read the following Safety Instructions
before using the AVARI® Compact Elliptical Trainer.
!WARNING
!WARNING

3
To help you get started, we have pre-assembled most of your
AVARI® Compact Elliptical Trainer at the factory with the exception
of those few parts left unassembled for shipping purposes.
Simply follow the few assembly instructions set forth in this manual.
With regular workouts, you will be getting your body into shape
and be on your way to achieving a happier and healthier lifestyle.
Should you have any questions,
please call our Customer Service Department toll-free number,
1 [phone]
Monday - Thursday, 7:30 A.M. - 5:00 P.M., Central Time.
Friday, 8:00 A.M. - 3:00 P.M., Central Time.
TELEPHONE
CUSTOMER SERVICE
Tel: [phone]
FAX
CUSTOMER SERVICE
Fax: [phone]
MAIL
STAMINA PRODUCTS, INC.
ATTN: Customer Service
P.O. Box 1071
Springeld, MO. 65801-1071
ONLINE
CUSTOMER SERVICE
[email protected]
www.staminaproducts.com
To enact your warranty, please register your product
by going to register.staminaproducts.com
Call Us First
www.staminaproducts.com
1(800) 375-7520
Customer Service
THANK YOU FOR PURCHASING THE
AVARI® Compact Elliptical Trainer

THE FOLLOWING TOOLS ARE INCLUDED FOR ASSEMBLY : Wrench
Allen Wrench (6mm)
BEFORE YOU BEGIN
4
Crank
Base
Right Pedal Cap
Right Cover
Left Pedal Arm
Roller
Tension Knob
Meter
Endcap
Endcap
Main Frame
Rear Stabilizer
Oval Endcap
Warning Label
Upright
Handlebar
Foam Grip
Foam Grip
Handlebar Post
Adjustment Knob
Left Pedal Cap
Thank you for choosing the AVARI® Compact
Elliptical Trainer.We take great pride in producing
this quality product and hope it will provide many
hours of quality exercise to make you feel better,
look better, and enjoy life to its fullest.
It's a proven fact that a regular exercise program
can improve your physical and mental health.
Too often, our busy lifestyles limit our time and
opportunity to exercise. The AVARI® Compact
Elliptical Trainer provides a convenient and
simple method to begin your journey of getting
your body in shape and achieving a happier and
healthier lifestyle.
Before reading further, please review the
drawing below and familiarize yourself with the
parts that are labeled.
Read this manual carefully before using the
AVARI® Compact Elliptical Trainer.
Although Stamina constructs its products with
thenestmaterialsandusesthehigheststandards
of manufacturing and quality control, there can
sometimes be missing parts or incorrectly sized
parts. If you have any questions or problems with
the parts included with your AVARI® Compact
Elliptical Trainer,please do not return the product.
Contact us FIRST!
If a part is missing or defective, please go to
staminaproducts.com under the Service section
and order the part needed, or call us toll free
at1-800-375-7520 (intheU.S.). OurCustomer
Service Staff is available to assist you from 7:30
A.M. to 5:00 P.M. (CentralTime) Monday through
Thursdayand8:00A.M.to3:00P.M.(Central
Time)onFriday.
Be sure to have the name and model number of
the product available when you contact us.

5
Label is larger than actual size
This chart is provided to help identify the warning, caution, and notice labels on the AVARI®
Compact Elliptical Trainer.Please take a moment to familiarize yourself with all of the warning,
caution, and notice labels.
EQUIPMENT WARNING, CAUTION & NOTICE LABELS
WARNING LABEL(55)W1

Part Number and Description Qty
6
42 Carriage Bolt (M10 x 1.5 x 43mm) 2
45 Bolt, Button Head (M8 x 1.25 x 20mm) 4
59 Bolt, Button Head (M8 x 1.25 x 16mm) 7
49 Nylock Nut (M6 x 1) 2
51 Nylock Nut (M10 x 1.5) 2
40 Washer (M8 x ø26mm x 2mm thick) 3
75 Bolt, Hex Head (M6 x 1 x 33mm) 2
length
length
mm.
in.
INCHES
This chart is provided to help identify the hardware used in the assembly process. Place the washers or
theendsoftheboltsorscrewsonthecirclestocheckforthecorrectdiameter.Usethesmallscaleto
check the length of the bolts and screws.
NOTICE: The length of all bolts and screws, except those with flat
heads, is measured from below the head to the end of the bolt
or screw. Flat head bolts and screws are measured from the
top of the head to the end of the bolt or screw.
After unpacking the unit, open the hardware bag and make sure that you have all the following items.
Some hardware may be already attached to the part.
MILLIMETERS
0 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150
0 1/2 1 1/2 2 1/2 3 1/2 4 1/2 5 1/2 6
6 8 10 12
3/16" 1/4" 5/16" 3/8" 1/2"
HARDWARE IDENTIFICATION CHART
76 Arc Washer (M6) 2
77 Arc Washer (M8) 4

ASSEMBLY INSTRUCTIONS
7
STEP 1: Attach the REAR STABILIZER(2) to the MAIN FRAME(1) with CARRIAGE BOLTS(M10x1.5x43mm)
(42) and NYLOCK NUTS(M10x1.5)(51).
STEP 2: Attach the BASE(37) to the MAIN FRAME(1) with two WASHERS(M8xø26mmx2mm thick)(40)
and two BUTTON HEAD BOLTS(M8x1.25x16mm)(59) from the bottom side. Do not tighten the bolts.
Secure the BASE(37) to the MAIN FRAME(1) from the top side with a WASHER(M8xø26mmx2mm thick)
(40) and a BUTTON HEAD BOLT(M8x1.25x16mm)(59). Securely tighten all of the bolts.
STEP 3: Attach the LEFT PEDAL CAP(33) to the LEFT PEDAL ARM(3) with BUTTON HEAD BOLTS
(M8x1.25x20mm)(45). Repeat on the other side.
NOTE: The LEFT and RIGHT PEDAL CAPS(33, 34) have a raised lip on three sides. Attach the LEFT
and RIGHT PEDAL CAPS(33, 34) to the LEFT and RIGHT PEDAL ARMS(3, 4) so that the side
without the raised lip is on the outside.
Placeallpartsfromtheboxinaclearedareaandpositionthemontheoorinfrontofyou.Remove
all packing materials from your area and place them back into the box. Do not dispose of the packing
materials until assembly is completed. Read each step carefully before beginning. If you are missing
apart,pleasegotostaminaproducts.comtotheServicessectionandorderthepartneeded,e-mail
usat[email protected],orcallustollfreeat1-800-375-7520(intheU.S.).Our
CustomerServiceStaffisavailabletoassistyoufrom7:30A.M.to5:00P.M.(CentralTime)Monday
throughThursdayand8:00A.M.to3:00P.M.(CentralTime)onFriday.

ASSEMBLY INSTRUCTIONS
STEP 4: Install two AA batteries into the METER(22), the batteries are not included. See page 11 for
detailed battery installation instructions. Remove the GROMMET PLUG(81) from the HANDLEBAR(72).
Run the strap and the EXTENSION WIRE(80) through the HANDLEBAR(72) and slide the METER(22)
onto the plate on the HANDLEBAR(72). Clip the GROMMET PLUG(81) onto Connection Wire of
the METER(22). Push the excess wires into the HANDLEBAR(72) and secure with the GROMMET
PLUG(81).
STEP 5: Run the strap and the EXTENSION WIRE(80) through the HANDLEBAR POST(71). Insert
the HANDLEBAR(72) into the HANDLEBAR POST(71) and secure with HEX BOLTS(M6x1x33mm)
(75), ARC WASHERS(M6)(76), and NYLOCK NUTS(M6x1)(49). The HEX BOLTS(M6x1x33mm)(75)t
insidethehex-shapedholesintheHANDLEBAR POST(71).
STEP 6: Run the strap and the EXTENSION WIRE(80) through the UPRIGHT(68). Insert the
HANDLEBAR POST(71) into the UPRIGHT(68), and lock it in one of the adjustment holes with the
ADJUSTMENT KNOB(69). Remove the strap from the end of the EXTENSION WIRE(80).
NOTE: There are three adjustment holes on the HANDLEBAR POST(71) for adjusting the height of the
HANDLEBAR(72).
8
Hex-shaped
hole
Adjustment
hole
Remove the strap
after the assembly.
1. Refer to the illustration below. The EXTENSION WIRE(80) is connected to the Connection
Wire of the METER(22), and there is a strap attached at the lower end of the EXTENSION
WIRE(80).
2. Be careful not to damage the sensor wires when processing the following assembly steps.
NOTE:

ASSEMBLY INSTRUCTIONS
STEP 7
Connect the EXTENSION WIRE(80) to the SENSOR WIRE(23). Insert the UPRIGHT(68) into the MAIN
FRAME(1) and secure with BUTTON HEAD BOLTS(M8x1.25x16mm)(59) and ARC WASHERS(M8)(77).
9

LEVELING: Adjust the location of AVARI® Compact Elliptical Trainer to ensure AVARI® Compact
Elliptical Trainersitsontheoorwithoutrocking.
MOVING: Grasp the REAR STABILIZER(2) and UPRIGHT(68) to move the AVARI® Compact
Elliptical Trainer.Do not use the PEDAL ARMS(3,4) to move the AVARI® Compact
Elliptical Trainer. The PEDAL ARMS(3,4)willmoveandmaypinchyourhandorngers.
FUNCTION INSPECTION:
Visually inspect the AVARI® Compact Elliptical Trainer to verify that assembly is as shown in the above
illustration. Check the function of the AVARI® Compact Elliptical Trainer. Stand on the foot pedals. Slowly
move your highest foot forward and follow the natural path of the machine. Turn the crank slowly through
one complete revolution to verify that the drive train functions properly. Adjust the TENSION KNOB(21)
and verify that it functions properly.
CAUTION: Locate and read the WARNING LABEL(55) on the AVARI® Compact Elliptical Trainer.
Make sure that all users read the WARNING LABEL(55).
SET UP INSTRUCTIONS
10
Equipment Mat
Place the AVARI® Compact Elliptical Trainer in the area where it will be used. It is recommended that the
AVARI® Compact Elliptical Trainer be placed on an equipment mat. The maximum operation dimensions
of the AVARI® Compact Elliptical Trainer are approximately 29 inches long x 18.8 inches wide x 50.3
inchestall.(Thesedimensionsmayvaryuptooneinch.)Makesurethatadequatespaceisavailablefor
access to, passage around and emergency dismount from the AVARI® Compact Elliptical Trainer. A
minimum of 20 inches on at least one side and 20 inches either behind or in front of the AVARI® Compact
Elliptical Trainer is required for safe operation.

OPERATIONAL INSTRUCTIONS
11
USING THE FITNESS METER
1. Do not mix a new battery with an old battery.
2. Usethesametypeofbattery.Donotmixanalkalinebatterywith
another type of battery.
3. Rechargeable batteries are not recommended.
NOTE:
1. Open the Battery Door on the back of the meter.
2. The meter operates with two AA batteries, the batteries are not
included. Refer to the illustration to install or replace the batteries.
HOW TO INSTALL AND REPLACE BATTERIES:
FUNCTIONS:
Pedal movement or press the button.
Automatic shut off after four minutes of
inactivity.
POWER OFF :
POWER ON :
FUNCTION BUTTON:
Press to select the function value displays of TIME, DISTANCE,
and CALORIES.
Reset all functions to zero by pressing the button and holding
it down for four seconds.
AA Batteries
The meter will shut off automatically after four minutes of inactivity. All function values will
be kept. Press the button and hold it down for four seconds to reset all functions to zero.
NOTE:
Displays the total number of strides you have taken on upper display from zero to 9999
strides.
Lower display automatically scans each function of TIME, DISTANCE, and CALORIES
in sequence every six seconds.
Displays the time from one second up to 99:59 minutes.
Displays the distance from zero to 999.9 miles.
Displays the calories burned from zero to 9999 Kcal.
The calorie readout is an estimate for an average user. It should be used only as a
comparison between workouts on this unit.
COUNT:
SCAN:
TIME:
DISTANCE:
CALORIES:

OPERATIONAL INSTRUCTIONS
12
1. To maintain your balance, always mount or dismount the AVARI® Compact Elliptical Trainer from
the lowest foot pedal, refer to the following illustrations. Loss of balance may result in a fall and serious
bodily injury.
2. Grasp the HANDLEBAR(72) with both hands to help to maintain your balance while using the AVARI®
Compact Elliptical Trainer until you are familiar with the AVARI® Compact Elliptical Trainer.
PRECAUTIONS FOR USING
CORRECT INCORRECT
EXERCISE WORKOUT
To start using the AVARI® Compact Elliptical Trainer simply stand on the foot pedals with the front of
your shoes close to the front edge of the pedal cap. Move your highest foot forward and follow the natural
path of the machine.
For more stability, hold on to the HANDLEBAR(72) while stepping onto and off of the pedals. Start on a load
level that is comfortable until you are familiar with the machine. Once you are familiar with the elliptical and
comfortable with the resistance, adjust the load level as described below to achieve the workout desired.
FORWARD AND REVERSE
The AVARI® Compact Elliptical Trainer can be used in forward and reverse directions to vary the muscles
that you work. This will help you to stay motivated and achieve the best results. To change directions, simply
slow the pedals down until they stop, then pedal in the opposite direction.
LOAD LEVEL ADJUSTMENT
The load level of AVARI® Compact Elliptical Trainer can be
changed at any time during your workout. Adjusting your load level
will allow you to increase or decrease your intensity level.
To increase the load, turn the TENSION KNOB(21) clockwise. To
decrease the load, turn the TENSION KNOB(21) counterclockwise.

13
STORAGE
1. To store the AVARI® Compact Elliptical Trainer simply keep it in a clean dry place.
2. The minimum rest dimensions of the AVARI® Compact Elliptical Trainer are approximately 27.8 inches
long x 18.8 inches wide x 46.3 inches tall. These dimensions may vary. Please measure your AVARI®
Compact Elliptical Trainer if exact dimensions are needed.
3. Grasp the REAR STABILIZER(2) and UPRIGHT(68) to move the AVARI® Compact Elliptical Trainer.
Do not use the PEDAL ARMS(3,4) to move the AVARI® Compact Elliptical Trainer.
The safety and integrity designed into the AVARI® Compact Elliptical Trainer can only be maintained
when the AVARI® Compact Elliptical Trainer is regularly examined for damage and wear. Special
attention should be given to the following:
MAINTENANCE
NOTE: A standard crank extractor tool is required to remove the CRANKS(78) from the AXLE(79).
1. Adjust the TENSION KNOB(21) and verify that the Flywheel System provides tension. The Flywheel
System should provide many years of use.
2. Verify that the WARNING LABEL(55) is in place and easy to read. Call Stamina Products immediately
at 1-800-375-7520 for a replacement WARNING LABEL(55) if it is missing or damaged.
3. It is the sole responsibility of the user/owner to ensure that regular maintenance is performed.
4. Worn or damaged components shall be replaced immediately or the AVARI® Compact Elliptical
Trainer removed from service until repair is made.
5. Only Stamina Products supplied components shall be used to maintain/repair the AVARI® Compact
Elliptical Trainer.
6. Keep your AVARI® Compact Elliptical Trainer clean by wiping it off with an absorbent cloth after
use.

How you begin your exercise program depends on your physical condition. If you have been inactive for
several years or are severely overweight, start slowly and increase your workout time gradually. Increase
your workout intensity gradually by monitoring your heart rate while you exercise.
Initially you may only be able to exercise within your target zone for a few minutes; however, your aerobic
capacity will improve over the next six to eight weeks. It is important to pace yourself while you exercise
so you don't tire too quickly.
Measure your heart rate periodically during your workout by stopping the
exercise but continuing to move your legs or walk around. Place two or
threengersonyourwristandtakeasixsecondheartbeatcount.Multiply
theresultsbytentondyourheartrate.Forexample,ifyoursixsecond
heartbeat count is 14, your heart rate is 140 beats per minute. A six second
count is used because your heart rate will drop rapidly when you stop
exercising. Adjust the intensity of your exercise until your heart rate is at the
proper level.
wrist pulse
Remember to follow these essentials:
Have your doctor review your training and diet programs.
Begin your training program slowly with realistic goals that have been set by you and your physician.
Warm up before you exercise and cool down after you work out.
 Take your pulse periodically during your workout and strive to stay within a range of 60% (lower
intensity)to90%(higherintensity)ofyourmaximumheartratezone.Startatthelowerintensity,and
builduptohigherintensityasyoubecomemoreaerobicallyt.
If you feel dizzy or lightheaded you should slow down or stop exercising.
To determine if you are working out at the correct intensity, use a heart rate monitor or use the table
below. For effective aerobic exercise, your heart rate should be maintained at a level between 60%
and 90% of your maximum heart rate. If just starting an exercise program, work out at the low end of
your target heart rate zone. As your aerobic capacity improves, gradually increase the intensity of your
workout by increasing your heart rate.
CONDITIONING GUIDELINES
Target Heart Rate Zone Estimated by Age*
* For cardiorespiratory training benefits, the American College of Sports Medicine recommends
working out within a heart rate range of 55% to 90% of maximum heart rate. To predict the
maximumheartrate,thefollowingformulawasused:220-Age=predictedmaximumheartrate
20 years
25 years
30 years
35 years
40 years
45 years
50 years
55 years
60 years
65 years
70 years
Average Maximum
Heart Rate 100%
Age
110-180 beats per minute
107-175 beats per minute
105-171 beats per minute
102-166 beats per minute
99-162 beats per minute
97-157 beats per minute
94-153 beats per minute
91-148 beats per minute
88-144 beats per minute
85-139 beats per minute
83-135 beats per minute
200 beats per minute
195 beats per minute
190 beats per minute
185 beats per minute
180 beats per minute
175 beats per minute
170 beats per minute
165 beats per minute
160 beats per minute
155 beats per minute
150 beats per minute
Target Heart Rate Zone
(55%-90% of Maximum Heart Rate)
14

WARM-UP and COOL-DOWN
Warm-Up The purpose of warming up is to prepare your body for exercise and to minimize injuries.
Warm up for two to ve minutes before strength training or aerobic exercising. Perform activities that
raise your heart rate and warm the working muscles. Activities may include brisk walking, jogging,
jumping jacks, jump rope, and running in place.
Stretching    Stretching while your muscles are warm after a proper warm-up and again after your
strength or aerobic training session is very important. Muscles stretch more easily at these times
because of their elevated temperature, which greatly reduces the risk of injury. Stretches should be held
for 15 to 30 seconds. Do not bounce.
Suggested Stretching Exercises
Remember to always check with your physician before starting any exercise program.
Cool-Down The purpose of cooling down is to return the body to its normal, or near normal, resting
stateattheendofeachexercisesession.Apropercool-downslowlylowersyourheartrateandallows
blood to return to the heart.Your cool-down should include the stretches listed above and should be
completed after each strength training session.
Lower Body Stretch
Placefeetshoulder-width
apart and lean forward.
Keep this position for 30
seconds using the body as a
natural weight to stretch the
backs of the legs.
DONOTBOUNCE!
When the pull on the back of
the legs lessens, gradually
try a lower position.
Floor Stretch
Whilesittingontheoor,
open the legs as wide as
possible. Stretch the upper
body toward the knee on the
right leg by using your arms
to pull your chest to your
thighs. Hold this stretch 10
to 30 seconds.
DONOTBOUNCE!
Do this stretch 10 times.
Repeat the stretch with the
left leg.
Bent Over Leg Stretch
Standwithfeetshoulder-
width apart and lean forward
asillustrated.Usingthe
arms, gently pull the upper
body towards the right leg.
Let the head hang down.
DONOTBOUNCE!
Hold the position a minimum
of 10 seconds. Repeat
pulling the upper body to
the left leg. Do this stretch
several times slowly.
Bent Torso Pulls
Whilesittingontheoor,
have legs apart, one leg
straight and one knee bent.
Pull the chest down to touch
the thigh on the leg that is
bent, and twist at the waist.
Hold this position at least 10
seconds. Repeat 10 times
on each side.
15

PRODUCT PARTS DRAWING
16
FRONT
BACK

PART# PART NAME QTY
1 Main Frame 1
2 Rear Stabilizer 1
3 Left Pedal Arm 1
4 Right Pedal Arm 1
5 Pulley 1
 6 Bearing(6003) 2
7 Pulley Spacer 1
 8 CRing(16mm) 4
 9 Screw,RoundHead(M5x15mm) 1
 10 V-RibbedBelt 1
11 Flywheel 1
 12 Bearing(6000) 2
13 Flywheel Pulley 1
 14 FlywheelSpacer(ø10mmxø12mmx24mm) 1
15 Spacer Cap 2
 16 FlywheelShaftBolt(M10x1.5x82mm) 1
17 Eyebolt 1
18 Tension Bracket 1
19 Brake Brace 1
20 Spring 1
21 Tension Knob 1
22 Meter 1
23 Sensor Wire 1
24 Magnet 1
 25 SquarePlug(25mmx25mm) 1
26 Left Cover 1
27 Right Cover 1
28 Round Cap 1
 29 FlangeBolt(M8x1.25x15mm) 2
30 Crank Spacer 2
 31 LargeWasher(16.3x24mm) 4
32 Pedal Arm Bushing 4
33 Left Pedal Cap 1
34 Right Pedal Cap 1
 35 SquarePlug(30mmx30mm) 2
36 Roller 2
37 Base 1
38 Stand 1
39 Endcap 4
 40 Washer(M8xø26mmx2mmthick) 3
 41 OvalEndcap(30mmx60mm) 2
 42 CarriageBolt(M10x1.5x43mm) 2
 43 Bolt,ButtonHead(M6x1x13mm) 3
 44 Screw,RoundHead(M5x0.8x13mm) 2
 45 Bolt,ButtonHead(M8x1.25x20mm) 4
 46 Bolt,ButtonHead(M8x1.25x42mm) 2
 47 Screw,RoundHead(M3.4x8mm) 2
PARTS LIST
17

 48 Screw,RoundHead(M4x25mm) 10
 49 NylockNut(M6x1) 9
 50 NylockNut(M8x1.25) 2
 51 NylockNut(M10x1.5) 3
 52 Nut(M10x1.5) 1
 53 Washer(M10) 1
 54 WavyWasher(M16) 2
55 Warning Label 1
56 Wrench 1
 57 AllenWrench(6mm) 1
58 Manual 1
 59 Bolt,ButtonHead(M8x1.25x16mm) 7
 60 WavyWasher(M17) 1
 61 CRing(17mm) 1
 62 PUBushing 1
 63 SquarePlug(38mmx38mm) 1
64 Crank Cap 2
65 Large Tension Bracket 2
66 Double Eyebolt 1
67 Stabilizer Stand 1
 68 Upright 1
69 Adjustment Knob 1
70 Sleeve 1
71 Handlebar Post 1
72 Handlebar 1
73 Foam Grip 2
 74 RoundPlug(25.4mm) 2
 75 Bolt,HexHead(M6x1x33mm) 2
 76 ArcWasher(M6) 2
 77 ArcWasher(M8) 4
78 Crank 2
79 Axle 1
80 Extension Wire 1
81 Grommet Plug 1
 82 NylockNut(M5x0.8) 2
 83 Bolt,FlatHead(M6x1x15mm) 3
PART# PART NAME QTY
PARTS LIST
18

LIMITED WARRANTY
WARRANTY
MODEL A550-043
19
Stamina Products, Inc. warrants that this product will be free from defects in materials and workmanship
under normal use, service, proper assembly and proper operation for a period of 90 days on the
parts and one year on the frame from the date of the original purchase from an authorized retailer.
THIS WARRANTY SHALL NOT APPLY TO ANY PRODUCT WHICH HAS BEEN SUBJECT
TO COMMERCIAL USE, ABUSE, MISUSE, ALTERATION OF ANY TYPE OR CAUSE OR TO
ANY DEFECT OR DAMAGE CAUSED BY IMPROPER ASSEMBLY, REPAIR, REPLACEMENT,
SUBSTITUTION OR USE WITH PARTS OTHER THAN PARTS PROVIDED BY STAMINA PRODUCTS,
INC. Commercial use includes use of the product in athletic clubs, health clubs, spas, gymnasiums,
exercise facilities, and other public or semipublic facilities whether or not the product's use is in
furtheranceofaprotmakingenterprise,andallotherusewhichisnotforpersonal,family,orhousehold
purposes.
To implement this limited warranty, send a written notice stating your name, date, and place of purchase
and a brief description of the defect along with your receipt to Stamina Products, Inc. P.O. Box 1071,
Springeld Missouri, USA, 65801-1071, or email us at [email protected], or
call us at 1-800-375-7520. If the defect is covered under this limited warranty, you will be requested to
return the product or part to us for free repair or replacement at our option. NO ACTION FOR BREACH
OF THIS LIMITED WARRANTY MAY BE COMMENCED MORE THAN ONE (1) YEAR AFTER THE
DATE THE ALLEGED BREACH WAS OR SHOULD HAVE BEEN DISCOVERED. NO ACTION FOR
BREACH OF ANY IMPLIED WARRANTY MAY BE COMMENCED MORE THAN ONE (1) YEAR AFTER
DELIVERY OF THE PRODUCT TO THE PURCHASER. This limited warranty is not transferable. IF
ANY PART OF THE PRODUCT IS NOT IN COMPLIANCE WITH THIS LIMITED WARRANTY OR ANY
IMPLIED WARRANTY, THE REMEDY OF REPAIR OR REPLACEMENT IS THE EXCLUSIVE REMEDY
AVAILABLE TO YOU. In the event that the purchaser makes any claim under this limited warranty or any
implied warranty, the Warrantor reserves the right to require the product to be returned for inspection,
atthepurchaser'sexpense,totheWarrantor'spremisesinSpringeld,Missouri.Returnoftheenclosed
warranty registration card is not required for warranty coverage, but is merely a way of establishing the
date and place of purchase.
Stamina Products, Inc. SHALL NOT BE LIABLE FOR THE LOSS OF USE OF ANY PRODUCT, LOSS
OF TIME, INCONVENIENCE, COMMERCIAL LOSS OR ANY OTHER INDIRECT, CONSEQUENTIAL,
SPECIAL OR INCIDENTAL DAMAGES DUE TO BREACH OF THE ABOVE WARRANTY OR ANY
IMPLIED WARRANTY.
This limited warranty is the only written or express warranty given by Stamina Products, Inc. This
warrantygivesyouspeciclegalrights,andyoumayalsohaveotherlegalrightswhichvaryfromstate
to state. ANY OTHER RIGHT WHICH YOU MAY HAVE, INCLUDING ANY IMPLIED WARRANTY OR
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, IS LIMITED IN DURATION TO
THE DURATION OF THIS WARRANTY.
The laws in some jurisdictions restrict the rights of manufacturers and distributors of consumer goods
to disclaim or limit implied warranties and consequential and incidental damages with respect thereto.
If any such law is found to be applicable, the foregoing disclaimers and limitations of and on implied
warranties and consequential and incidental damages with respect thereto shall be disregarded and shall
be deemed not to have been made to the extent necessary to comply with such legal restriction.
Length of warranty (Updated 02-11-2012)
Accessories – 90 days
Retail value up to $250 – 90 days on parts, 1 year frame
Retail value $251 up to $750 – 90 days on parts, 3 years frame
Retail value $751 up to $1,000 – 90 days on parts, 5 years frame
Retail value $1,001 and up – 1 year on parts, 5 years on frame

NOTES
20
