Stanley K1700 User manual

K1700 & K2300
WoodPelletBoilerStove
Installation and Operating Instructions
Read these instructions carefully before installing, using and servicing the stove.

2
Table of Contents
1SETTING THE LANGUAGE FOR THE FIRST TIME. ................................................................................................................. 3
2STANLEY PELLET STOVE WARRANTY.................................................................................................................................. 4
3PACKAGE CONTENT........................................................................................................................................................... 5
3.1 UNPACKING THE FREE-STANDING FIRE ..................................................................................................................................... 5
4SAFETY PRECAUTIONS....................................................................................................................................................... 5
4.1 FOR YOUR SAFETY,WE RECOMMEND THAT: .............................................................................................................................. 6
5TECHNICAL SPECIFICATIONS.............................................................................................................................................. 7
6INSTALLATION OF THE BOILER PELLET STOVE.................................................................................................................... 9
6.1 ASSEMBLY OF REMOVABLE PARTS ......................................................................................................................................... 10
7INSTALLATION REQUIREMENTS ....................................................................................................................................... 11
7.1 INSTALLATION OF DUCTS AND FUME EXTRACTION SYSTEMS:......................................................................................................... 11
7.2 INSTALLATION WITHOUT A CHIMNEY...................................................................................................................................... 11
7.3 INSTALLATION WITH A CHIMNEY ........................................................................................................................................... 12
7.4 HYDRONIC INSTALLATION ................................................................................................................................................... 13
8FUEL ................................................................................................................................................................................ 13
9USE OF THE BOILER PELLET STOVE................................................................................................................................... 14
9.1 REMOTE CONTROL AND DISPLAY .......................................................................................................................................... 15
9.2 DISPLAY INFORMATION SUMMARY........................................................................................................................................ 16
9.2.1 Menu ................................................................................................................................................................. 16
9.2.2 Water temperature............................................................................................................................................. 16
9.2.3 Date/Time.......................................................................................................................................................... 16
9.2.4 Timer.................................................................................................................................................................. 18
9.2.5 Sleep.................................................................................................................................................................. 19
9.3 CONFIGURATION MENU ..................................................................................................................................................... 19
9.4 USER INFO ..................................................................................................................................................................... 22
10 START-UP ........................................................................................................................................................................ 23
10.1 STOP ........................................................................................................................................................................ 23
10.2 TURNING OFF THE STOVE ............................................................................................................................................... 23
10.3 INSTRUCTIONS FOR REMOVING THE SIDE COVERS ................................................................................................................. 23
10.3.1 Remove side covers........................................................................................................................................ 23
10.3.2 Pellet reservoir lid .......................................................................................................................................... 24
10.4 FILLING THE PELLET RESERVOIR ........................................................................................................................................ 24
11 MAINTENANCE................................................................................................................................................................ 25
11.1 CLEANING THE STOVE ................................................................................................................................................... 25
11.2 ADDITIONAL CLEANING ................................................................................................................................................. 27
11.3 CLEANING THE GLASS .................................................................................................................................................... 28
12 ALARMS / FAILURES / RECOMMENDATION LIST.............................................................................................................. 29
12.1 ALARMS .................................................................................................................................................................... 29
12.2 -FAILURES ................................................................................................................................................................. 29
13 EXPLODED VIEW.............................................................................................................................................................. 30
14 INSTALLATION DIAGRAMS.............................................................................................................................................. 31
14.1 CENTRAL HEATING INSTALLATION DIAGRAM........................................................................................................................ 31
14.2 INSTALLATION DIAGRAM FOR CENTRAL HEATING AND DHW USING A CYLINDER THERMOSTAT ......................................................... 31
14.3 SYMBOLS................................................................................................................................................................... 32

3
14.4 E LECTRICAL DIAGRAM OF THE B OILER PELLET STOVE .............................................................................................................. 32
14.5 R EMOTE SWITCHED CONNECTION . ................................................................................................................................... 33
15 PERFORMANCE GRAPHS FOR THE UPSO 15-55 CIAO CIRCULATING PUMP ...................................................................... 33
FIGURE 8 –PERFORMANCE GRAPHS FOR THE CIRCULATING PUMP........................................................................................... 33
16 LIFE CYCLE OF A BOILER PELLET STOVE ............................................................................................................................ 33
17 ANNEXES......................................................................................................................................................................... 34
Thank you for purchasing a Waterford Stanley Wood pellet Stove.
Please read this manual carefully and retain it for future reference.
These products fulfil the requirements of the Construction Products Regulation and have
been approved with the CE conformity mark;
The Boiler pellet stoves are manufactured in compliance with the EN 14785:2008 Standards
WATERFORD STANLEY bears no responsibility for any damage to the stove if it is installed
by non-qualified personnel;
WATERFORD STANLEY is not responsible for any damage to stoves not installed and used
in compliance to the instructions included in this manual;
All local regulations, national and European standards, must be observed when installing,
operating and servicing the stove;
Whenever you need assistance, you should contact your stove’s supplier or installer. You must
have the wood pellet stove serial number located on the identification plate.
The product must be commissioned by a Waterford Stanley approved service engineer.
1 Setting the Language for the first time.
To set the Language to English on the controller.
Press the menu button until “set”is displayed beside the menu button.
Press the “+”button 4 times , display shows “configura.......”.
Press the set button twice until abbreviation for languages in the top and centre of the screen.
Press the “+”button until abbreviation “EN”is displayed.
Press the Menu button to set the language to English.

4
2 STANLEY PELLET STOVE WARRANTY
CONDITIONS OF WARRANTY
Your Stanley pellet stove is guaranteed against any part that fails (under normal operating conditions) as
detailed in the following table with timelines specified from the date of installation of the appliance. If the
stove is not installed within six months of date of purchase, the warranty will commence six months from
the date of purchase.
Warranty
Period Parts Covered (Parts & Labour unless Stated)
Up to 1
Year
·Refractory materials (supply only)
·Rope seals, glass seals and cement seals.
·Surface Finish on Seno models.
·Grates and fire bars.
·Ceramic glass is covered for Thermal breakage (supply only).
·Rust (if reported before installation)
·Aesthetic Damage (provided reported on date of receipt)
·
Electrical
components under normal operation.
Up to 2
Years
·All external casings & enamel finishes (excluding impact damage or
damage caused by overfiring). Pictures of damage must be submitted to
WS Service Department.
Up to 3
Years
·Boiler - A Leaking Boiler Report must be conducted by an Authorised
Stanley Service Engineer and submitted to WS Service Department for
review.
All warranty claims must be reported to the Waterford Stanley Service Department and must be submitted with the product serial
number (located on the data plaque at the rear of the product), date of purchase, proof of purchase (if requested) and details of the
specific nature of the problem.
The warranty is given only to the original consumer/purchaser only and is non- transferable. The appliance must be installed by a
suitable qualified person and installed as per the requirements of the manual. Failure to comply with the Installation requirements
or Building Regulations will void your warranty. Waterford Stanley reserve the right to replace any part due to manufacturing
defect that fails within the warranty period under the terms of the warranty. The stove must be used for normal domestic purposes
only and in accordance with manufacturer's operation instructions.
LIMITS OF LIABILITY
The warranty does not cover:
·Special, incidental or consequential damages, injury to persons or Property, or any other consequential loss.
·Any issue caused by negligence, misuse, abuse or circumstances beyond Waterford Stanley’s control.
·Any issue with wear and tear, modification, alteration, or servicing by anyone other than an authorized service engineer.
·Installation and operational related problems such as draught related issues external to the stove, inadequate venting or
ventilation, excessive flue offsets, negative air pressure caused by insufficient burning of improper fuel.
·Damage caused to the stove while in transit.
·Discolouration due to over firing, damage caused by impact, damage to baffles caused by over firing and fading of
surface finish on casting.
·Stress fractures on bricks.
·Rust on cast iron parts unless reported prior to stove being installed.
·Aesthetic damage, rust & missing parts on stoves purchased off display.
·Electrical components where voltage variations are in excess of 10% of nominal 230V
Note: Adequate clearance must be maintained around the appliance to ensure the ease of part removal in the possible event of
their damage/failure. Waterford Stanley are not responsible for any costs incurred in the removal of items installed in the vicinity
of the appliance that must be moved to facilitate a part replacement.

5
3 Package content
- Boiler pellet stove model K1700 & K2300
- Side covers, top front cover and bottom front cover
- Instruction Manual &Power cable
3.1 Unpacking the free-standing fire
When unpacking the stove, please refer to the illustrations below. First remove the retractable bag containing the cardboard box
(Figure 1-a). Then pull the cardboard box out (Figure 1-b) by lifting it and remove the bag containing the free-standing
fire stove (Figure 1-c) and the Styrofoam plates. Finally, unscrew the four parts securing the stove to the wood pallet (Figure 1-
d and -e).
a) b) c)
d) e)
Figure 1 –Unpacking the free-standing fire stove
4 Safety precautions
Waterford Stanley is not liable for any damages to the stove if the specified precautions, warnings and operating procedures are
not followed.
Stoves manufactured by Waterford Stanley are easy to operate and special attention was given to their components in order to
protect users and installers against accidental damages.
The stoves must only be installed by an authorised engineer, who should supply the client with a relevant statement of conformity
and who shall be liable for the final installation and consequent product good operating conditions.
This stove must be used according to its intended use as specified by the manufacturer. The manufacturer is excluded from all
liability, by contract or by tort, caused by injury to people, animals or property arisingfrom misuseor faulty installation or servicing.
After removing the packaging, verify the contents to check their integrity and completeness. If the content of the package
fails to correspond to that indicated in point 1, contact the salesperson from whom you purchased the stove.
All the stove's components guarantee its operation and energy efficiency and should only be replaced with original parts provided
by an authorised technical assistance centre.
The stove must be serviced at least once a year by the installation engineer. This manual is provided with the
product. Please keep it close to the stove.

6
4.1 For your safety, we recommend that:
·Make sure you fully read and understand this instruction manual before using the boiler pellet stove as a biomass heating stove.
·
·Make sure that the hydronic/ plumbing circuit was correctly assembled and connected to the water supply before turning on the
boiler pellet stove.
·
·The boiler pellet stove is not intended for use by children or persons with reduced physical, sensory or mental capabilities,
·
·or lack of experience or knowledge, unless they are under supervision or have been instructed concerning the use of the stove.
·
·Do not touch the stove when barefoot or if any part of your body is wet or humid;
·
·Do not tamper with safety or adjustment features without the manufacturer's authorization;
·
·Do not cover or reduce the size of the vents at the installation area;
·
·The boiler pellet stove requires a clear space around the stove for proper combustion, so possible air tightness of the location or
any existing air extractionsources in the room may prevent the stove proper operation;
·The existence of vents is a requisite for proper combustion;
·
·Do not leave the packing materials near children;
·
·During normal operation, Free Standing Fire stove's door must not be opened;
·
·Some parts of the stove may overheat during normal operation, so avoid direct contact with parts such as the door handle and
glass;
·
·Check the existence of any obstructions on the fume duct before turning on the stove after a long period of inactivity;
·
·This boiler pellet stove is intended for residential use in protected areas. Safety systems may turn off the stove. If this occurs,
contact the technical assistance. In any circumstances should you attempt to interfere with the safety systems;
·
·The boiler pellet stove is a biomass heating stove equipped with an electric fume extractor. The occurrence of any power failure
during its use may prevent fume extraction and the room will be filled with smoke. For this reason, you should have a natural
fume extraction system, like a chimney, available;
·
·During operation, NEVER turn off the free-standing fire stove by disconnecting the electric plug. The fume extractor on
the free-standing pellet fire stove is electric so disconnecting the power plug will prevent the extraction of combustion fumes;
·
·Your stove must be disconnected from the mains for servicing. Before doing this, the stove must be totally cooled down (if
operating before);
·
·Never touch the interior of the stove without disconnecting it from the power mains;
·
·The maximum temperature of the water that can be set by the user (water set-point temperature) is 85°C. In the event of a
temperature of 90ºC being reached, the boiler pellet stove automatically disconnects, and the respective alarm is activated.

7
5 Technical specifications
Table 1 –Technical specifications
FEATURES K1700
K2300
Stoves
Weight
202 219
Kg
Height
1150 1210
mm
Width
600 665
mm
Depth
655 730
mm
Diameter of the fume discharge pipe
100 100
mm
Reservoir capacity
30 45
Kg
Maximum heating capacity
384 520
m³
Maximum overall thermal power (fire
14,2 / 3 18,8 / 3,3
kW
Minimum thermal power (fire insert/boiler)
4,3 / 0,8 4,3 / 0,8
kW
Minimum fuel consumption
1,1 1,1
Kg/h
Maximum fuel consumption
3,9 5,1
Kg/h
Rated electrical current
134 134
W
Electric power at start-up (<10 min.)
434 434
W
Rated voltage
230 230
V
Nominal frequency
50 50
Hz
Thermal yield at rated thermal power 91,1 89,2 %
Thermal yield at reduced thermal power 93,8 93,8 %
Combustion gas flow (max.)
14,8 18,8
g/s
Combustion gas flow (min.)
6,9 6,9
g/s
Max. gas temperature
128 153
ºC
Min. gas temperature
66 66
ºC
CO emissions at rated thermal power
0,02 0,02
%
CO emissions at reduced thermal power
0,02 0,024
%
Draught in the chimney
12 12
Pa
Stove water volume
22 22
W
Sound level max.
49,1 49,1
dB(A)

8
Tests performed using wood pellets with a heating capacity of 4.9 kWh/kg.
The above information was obtained during product homologation tests performed at independent laboratories
accredited for pellet stove tests.
Front Rear
Side Top
Figure 2 –Dimensions of the K1700
Front Rear
Side Top
Figure 3 –Dimensions of the K2300
Figure 5 –Hydraulic connections of the K1700 Figure 6 –Hydraulic connections of the K2300

9
6 Installation of the boiler pellet stove
Before installing, please perform the following steps:
·Upon receipt, check the product for completeness and to determine that is does not show any damage signs. Any damages
or defects should be checked before the stove is installed.
·The stove is equipped with four adjustable height feet at the base which allow for a simple adjustment when installed on a
unlevel surface.
Figure 7 –Adjustable feet
·Remove the instruction manual from the package and hand it over to the client.
·Connect a 100mm diameter flue between the combustion gas output and the outgoing fume extraction duct of the building
(e.g. chimney) –check location diagrams under no. 4.
·If a pipe is used for combustion air inlet from the outside, it shall be no longer than 60cm horizontallyor present offsets (such
as bends);
·Perform the hydronic installation
·Connect the 230VAC power cable to a grounded socket.
·The surface of the stove where the hot air outlet is located must be facing the area to be heated.

10
6.1 Assembly of removable parts
After the installation, the stove should be fitted with the removable covers.
- Top front cover
To install the top front cover, place it over the stove (Figure-8a) and then tighten the screws that secure it to the top panel of
the stove (Figure 8b).
8a) 8b)
Figure 13 –Assembly of the top front cover
- Bottom front cover
The bottom front cover can be assembled by removing the screws located on the bottom part of the stove. Then place the part in
the appropriate position (Figure 9-a) and replace and tighten the screws again (Figure 9-b)
9a) 9b)
Figure 14 –Assembly of the bottom front cover
- Side covers
To install the stove's side covers position the covers and insert them as illustrated, onto the existing supports.
Figure 10 –Assembly of side covers

11
7 Installation requirements
The minimum distance between the free-standing pellet fire stove and particularly flammable surfaces is specified in
Figure 11.
The top of the stove must be at least 100cm separated from the ceiling, especially in rooms with ceilings consisting of
flammable materials.
The base supporting the stove cannot be made of combustible material (e.g. carpet), so make sure you use an adequate
protection.
a) b)
Figure 11 –Clearances to combustibles: a) plan view of the stove's installation;
b) side view of the stove's installation
7.1 Installation of ducts and fume extraction systems:
·The exhaust pipe must have been designed for this purpose, in compliance to the location requirements andin accordance
with any applicable regulations.
·Important! An inspection-T with an airtight lid must be attached to the exhaust pipe of the stove to allow the regular
inspection of the system or discharge of heavy dust and condensates. As indicated in Figure 15, the exhaust pipe must be
assembled to allow cleaning and maintenance of the pipe by inserting inspection points.
·Under normal operating conditions, the combustion gas flow should create a draught of 12 Pa one meter above the chimney
neck.
·The stovemust be installed in a shared chimney
·Pipes outside the heated area must be suitably insulated
7.2 Installation without a chimney
The installation of the boiler pellet stove without a chimney should be performed as illustrated in Figure 16, with 100 mm diameter
flue pipe up to the Tee piece for the boiler model) directly outside and over the roof.
Double-walled stainless-steel insulated pipes must be used and properly fastened to avoid condensation.
A T-tube must be installed at the base of the pipe to allow periodic inspections and annual maintenance, as illustrated in
Figure 16.

12
Figure 12 –Side view of the installation without a chimney,
Failure to comply with these requirements may prevent the correct operation of the stove. Follow all the instructions
presented on the diagrams.
The pellet stove stoves operate with the combustion chamber in vacuum, so it is necessary to have a fume exhaust pipe to
extract combustion gases properly.
Fume duct material: The tubing must consist of 0.5 mm thick rigid stainless steel, with fastening joints attaching the different
sections and accessories.
Insulation: The fume ducts must be double-walled and insulated to make sure that fumes do not cool down going outwards,
which would cause an inadequate circulation and condensation that may damage the stove.
Windproof terminal: A windproof terminal must always be installed to avoid the backflow of fumes.
Draught in the chimney: The figures below show three standard diagrams, specifying adequate lengths and diameters. Any
other type of installation must guarantee a draught of 12 Pa (0.12mbars) measured when hot and at the maximum power.
Ventilation: Thestovemust haveadequateairforcombustionandtheroommust haveadequateair for ventilation,adequateairsupplymust be
providedinlinewithbuildingregulations. The boiler pellet stove has a circular pipe (Æ 50mm) that may be connected to the exterior of
the house. An outside air kit and adaptor from 50-100 is available to order from Waterford Stanley.
If the residence has an air exhaust system installed (e.g. kitchen extractor fan), a ventilation duct of suitable cross-
sectional area to accommodate the different exhaust stoves that exist in the house, must be installed.
The installation of the stove on locations near kitchen exhaust fans or fume extractors may prevent the stove from
operating properly.
7.3 Installation with a chimney
If the stove is to be installed in a chimney the stove is installed with a flue pipe of diameter 100 direct to the stove. The chimney
should be lined with a 125mm flexible liner suitable for use with solid fuel. If the chimney is too large, an 125mm mm-wide pipe
should beinstalled at the fume outlet.
A T-piece must be installed between the 100mm pipe and the 125mm flexi liner t to allow for periodic inspection and annual
maintenance. The installation must be completed with a windproof cowl recommended for use with pellet stoves.
We do not recommend that you use the stove in rough weather conditions that may seriously impact thedraught (particularly
with very strong winds).
If you do not use the stove for a long time, check it to make sure that the flue pipes are clear before lighting the fire.
Dia.
125m
Dia.
100mm

13
7.4 Hydronic Installation
* The chapter 14 (installation diagrams) contains the optional connection diagrams for central heating installations, with or
without water heating for household use;
* The boiler model pellet stove is equipped with a circulating pump, an expansion vessel (6 litre volume (in the K1700model)
or 10 litre volume (in the K2300 model) and a 3-bar safety valve;
* Operating pressure is between 1 and 1.5 bars;
* To empty the stove, attach a "T-tube" with a tap to the wastewater drain the safety valve (3 bar) outlet must also be connected to
the waste water drain;
*The heating fluid must consist of water with an anti-rust, non-toxic product added in the quantity recommended by the
manufacturer. If the stove installation or the fluid pipes are installed are likely to freeze, the installation engineer must add to the
circulating fluid the amount of antifreeze product recommended by the manufacturer, to avoid freezing at the estimated minimum
temperature.
8 Fuel
The boiler pellet stove must be operated exclusively with pellets. No other fuel may be used.
Use only pellets certified by standard EN 14961-2 grade A1, with a
6 mm diameter and measuring between 10 and 30 mm long.
The pellets must not have a moisture content in excess of 8% . To guarantee a good combustion, the pellets must maintain
these characteristics so they should be stored in a dry place.
The use of different pellets will reduce the efficiency of the stove and cause poor combustion.
You should always use certified pellets and must test a sample before buying large bulk loads.
The physical/chemical properties of the pellets (i.e. the calibre, friction, density and chemical composition) may vary within
specific tolerances and according to each manufacturer. Please note that this may cause alterations to the feeding process
and, consequently, the need for different doses (more or less pellets).
The stove allows the dose of pellets to be adjusted during start-up and at power levels by ± 25%
Warning : The stove must NOT be used as an incinerator

14
9 Use of the Boiler pellet stove
Recommendations
Before starting up the stove, please check the following:
·Guarantee that the stove is properly connected to the power mains using the 230VAC power cable.
Figure 13 –Electric power plug.
·Check to see whether the pellet reservoir is supplied with pellets. Inside the pellet reservoir is a safety grid to prevent
users from reaching the worm screw.
·Ensure that before each lighting the burner is clear
The stove's combustion chamber is made from iron plate and painted with high temperature-resistant paint, releasing
fumes during the first burning sessions due to paint curing.
Make sure that the hydraulic circuit was correctly assembled and is filled to the correct pressure.
You should check that there is sufficient ventilation in the room where the stove is installed, otherwise it will not work properly. You
should therefore check to see whether there are other heating air-consuming stoves in the room (e.g. gas stoves, fire pits,
extractors, etc.); these should not be used simultaneously with the stove.
The Boiler pellet stove stoves have a probe for measuring the room temperature. This probe is attached to the grid on the rear
panel (Figure 20). For a good reading of the room temperature, avoid the contact between the end of the probe and the
stove chassis. You may also attach the probeto the wall beside the stove.
Figure 14 - Room temperature probe

15
9.1 Remote control and display
Figure15 –Remote control and display
a) b) c)
a) Key to toggle between manual and automatic mode and exit menus (esc).
b) Key to access menus and confirmation key (ok).
c) Key to start/stop the stove and reset error messages.
d) e)
d) Key to scroll the menus to the left, o r to reduce the set point
e) Key to scroll menus to the right or increase the set point
20.5ºC
16:03
OFF
MODE
MENU
MAN
AUT
ESC
OK
ON
OFF
-
+

16
9.2 Display information summary
9.2.1 Menu
Menu indicating that the stove power is "off", the room temperature in ºC and Time.
Selecting the operation mode: to select the operation mode, press the “mode”key to
select “Manu”for manual mode or “Auto”
Note: For boiler models manual mode is unavailable.
“Auto”mode: in this mode, the stove shall be turned on at maximum power until reaching a temperature of 1ºC above the
temperature selected (set point temperature). Upon reaching the set temperature, the stove changes to minimum operating
power.
The set-point temperature can be set between 5 and 35ºC by pressing the "-" key.
The "+" key allows the user to set the ventilation speed between 1-5 and automatic mode.
9.2.2 Water temperature
Press the Menu key twice to set the water temperature;
“Water Temp.”appears on the display. Press Set to adjust the set point.
·Heating temperature
To set the desired heating temperature press “set”. The display starts to flash. Press the “+”or “-“key to select the desired
temperature and then “ok”to confirm.
9.2.3 Date/Time
To set the date and time: press the Menu key twice followed by the “+”. “Day and Time”appears on the display. Press "set" to
see the “Time”menu.
"
20.5ºC 16:03
OFF
MODE
MENU
MAN
OK
OFF
-
+
Mode:AUTO Menu
Temp:30ºC Fan:5
MODE
MENU
MAN
OK
OFF
-
+
esc
Set
<
Data
e
Hora
>
MODE
MENU
MAN
AUT
ESC
OK
ON
OFF
-
+

17
·Year
To set the year press “set”. The display starts to flash. Press the “+”or “-”key to select the desired year and then “ok”to confirm.
Press "esc" to return to the " Date and Time " menu then "+" month menu. The Timer menu appears.
•
·Month
To set the month press “set”. The display starts to flash. Press the “+”or “-”key to select the desired month and then “ok”to
confirm. Press the "+" key to go to the " date " menu.
·Day of the month/ Date
To set the date press “set”. The display starts to flash. Press the “+”or “-”key to select the desired day and then “ok”to
confirm. Press the "+" key to go to the " day of the week " menu.
·Day
To set the day of the week press “set”. The display starts to flash. Press the “+”or “-”key to select the desired day and then
“ok”to confirm. Press the "+" key to go to the "Time." (Day Number) menu.
·Time
To set the time press “set”. The display starts to flash. Press the “+”or “-”key to select the desired time and then “ok”to
confirm. Press the "+" key to go to the "Minutes
·Minutes
To set the minutes press “set”. The display starts to flash. Press the “+”or “-”key to select the desired minutes and then
“ok”to confirm.

18
9.2.4 Timer
The stove is equipped with a timer that allows the stove to be turned on or off at a specified time.
Setting the timer/s
Step 1 Press the “set”button twice followed by the “+”button to display “chrono”
Step 2 Press the “set”button to display “enable”.
Step 3 Press the “+”button to scroll right, “load profile”is displayed.
Step 4 Press the “+”button to scroll right, “reset”is displayed.
Step 5 Press the “+”button to scroll right, “program 1”is displayed.
Step 6 Press the “set”button , “enable”is displayed.
Step 7 Press the “+”button to scroll right, “start”is displayed, Press the “set”button.
Step 8 Use “+”and “-“to adjust the “start”time. Followed by “ok to confirm.
Step 9 Press the “+”button to scroll right, “stop”is displayed, Press the “set”button.
Step 10 Use “+”and “-“to adjust the “stop”time. Followed by “ok ”to confirm.
Step 11 Press the “+”button to scroll right, “air temperature”is displayed, Press the “set”button.
Step 12 Use “+”and “-“to adjust the “air temperature”. Followed by “ok ”to confirm.
Step 13 Press the “+”button to scroll right, “air temperature”is displayed, Press the “set”button.
Step 14 Use “+”and “-“to adjust the “air temperature”. Followed by “ok ”to confirm.
Step 15 Press the “+”button to scroll right, “water temperature”is displayed, Press the “set”button.
Step 16 Use “+”and “-“to adjust the “water temperature”. Followed by “ok ”to confirm.
Step 17 Press the “+”button to scroll right, “fire”is displayed, Press the “set”button.
Step 18 Use “+”and “-“to adjust the “fire”. Followed by “ok ”to confirm.
Step 17 Press the “+”button to scroll right, “Days”is displayed, Press the “set”button.
Step 18 Use “+”and “-“and “set “buttons to select the days which the program will run on.
Step 19. Return to steps 6 and steps 2 and set both of these to “On”to enable Program 1.
Repeat for Programs 2-6 as required.
Note,
It is not possible to enable the timer until the programs are set.
Step 6 is to enable program 1.
Step 2 is to enable the timer function.

19
9.2.5 Sleep
The "Sleep" menu allows you to setup the time you want the stove to turn off.
Press "set". The display starts to flash. Select the desired time using the "-" and "+" keys. After choosing the time, press "ok" to
confirm. Press "esc" to return to the menu and "+" to go to the configuration menu.
9.3 Configuration menu
To change the configurations of the boiler pellet stove, press “set”.
The "Língua" (Language) menu appears allowing you to select the language.
·Language
To select the language, press “set”. Using the “+”or “-”keys, select the desired language (Pt –Portuguese; Nl –Dutch; Gr –
Greek; It –Italian; En –English; Fr –French; Es –Spanish; De –German). Press "ok" to confirm.
Press the "+" key to go to the "eco" menu.
·Eco mode
If the stove is equipped with a thermostat that operates exclusively based on the temperature, the "eco mode" can be enabled
to reduce the fuel consumption. In this mode, the stove operates at a set point temperature. The stove always runs at
maximum operating power until it reaches a temperature (1ºC) above the set point temperature. Upon reaching this
temperature, the stove starts operating at minimum operating power for a preset time period. After this time has elapsed, the stove
turns off. It remains off for another preset period of time. When the measured room temperature drops to a preset value, the
stove turns on again at the maximum operating power.
This operation is only available in automatic mode.
To activate the eco mode, press "set". The display starts to flash. Select "On" or "Off" using the "-" and "+" keys. Press "set" to
confirm the selection.
Press "esc" to return to the previous menu and "+" to go to the (Lighting) menu.
esc OFF Set
SLEEP
MODE
MENU
MAN
OK
OFF
-
+
esc 22:00 Set
SLEEP
MODE
MENU
MAN
AUT
ESC
OK
ON
OFF
-
+

20
·Lighting
To select lit screen, press “set”. The display starts to flash. Press the "+" or "-" key to select the time at which you want the
screen to light up, or choose "On" to keep the light on at all times. Press "ok" to confirm. Press the "+" key to go to the (Tones)
menu.
·Tones
To activate the key tone, press "set". The display starts to flash. Press the "+" or "-" key to select "On" or "Off". Press "ok" to
confirm. Press the "+" key to go to the "ºC/ºF"menu.
·Temperature stove (ºC/ºF)
To select ºC / ºF, press “set”. The display starts to flash. Press the “+”or “-”key to select “ºC”, “ºF”or “Auto”, and then “ok”to
confirm. Press the "+" key to go to the " Pellet" (Pellet Qty) menu.
·Pellet quantity
Press "set" to see the "(Temporary settings) menu.
- Temporary settings
This feature allows you to increase or decrease by 25% the quantity of pellets at start- up. Press "set". The display starts to
flash. Press "+" or "-" to increase or decrease (between -5 to +5), accordingly. Each stove must be multiplied by 5 to obtain
the correct percentage. Press "ok" to confirm. Press the "+" key to go to the " (Power settings) menu.
esc Off Set
<Eco >
MODE
MENU
MAN
OK
OFF
-
+
esc
<
Auto
Set
ºC
/
ºF
>
MODE
MENU
MAN
OK
OFF
-
+
