AAnn eeaassyy--ttoo--iinntteeggrraattee,, iinnnnoovvaattiivvee kkiittcchheenn pprriinntteerr tthhaatt
ccaann ttaakkee tthhee hheeaatt..
The SP700 impact printer is the latest addition to Star
Micronics' robust line of printers. Built specifically to work in
environments where heat and humidity can erode the type on
the kitchen order, the SP700 is an ideal solution. This fast,
two-color printer offers crisp, easy to read type for quick
viewing, clamshell design for easy paper loading and an
embedded power supply for space efficiency.
The SP700 ships complete, right out of the box, with free,
feature - packed software included on CD:
•Ability to add graphics (logo,coupons)
•Invert Printing By Driver
•Ethernet Connection Set Up Utility
•Printer Memory Set Up Utility
•Virtual Serial Port (USB or Ethernet)
Thanks to Microsoft’s Digitally Signed Certification (WHQL),
the SP700 drivers features Star’s “intuitive” compatibility
for Microsoft® applications including:
•JavaPOS®
•Linux
•Mac® OSX
•OPOS®
WWhheenn TThheerrmmaall IIssnn’’tt AAnn
OOppttiioonn UUssee SSttaarr’’ss SSPP770000
SSPP770000
2-Co or Printing Wa Mount Bracket “Drop In & Print”
Paper Load
Optiona Buzzer A arm
•C amshe Design for Easy Paper Loading
•Embedded Power Supp y
•2-Co or, High-Qua ity Graphics Printing
•Spi -Proof & Heat-Resistant
•Swappab e Interfaces Avai ab e
•Wa Mount
•Externa Buzzer Option

Star Micronics America, Inc. • 1-800-782-7636 x107 • www.starmicronics.com ©2010 Star Micronics America, Inc.
All Rights Reserved. All trademarks are property of their respective owners. Specifications are subject to change without notice.
Features
The Ultimate Impact POS Solution!
Hardware
High Speed (4.7 LPS)
High Relability
Clamshell Splash Resistant Design
Embedded Power Supply
Two Color Capable
Recessed Cable Connections
Small Footprint
Paper Window
Swappable Communication Interfaces
“Drop In & Print” Paper and Ribbon Loading
Prints Up to 3 Copies At Once
Digitally Signed Drivers (WHQL)
Installation CD Included
Software
The Included Receipt Redesign Software
allows you to EASILY:
Add Images (Logos, Coupons and More)
Create a Virtual Serial Port for Legacy Applications
Configure an Ethernet Interface
Configure Memory Switch Settings
StarIO SD
Connectivity
Note: Connections in bbooddare supported;
grayed-out connection types may be
supported by specia request.
9 Pin Serial
25 Pin Serial
Parallel
USB
Powered USB
Ethernet
WiFi
Dual 9-Pin Serial/USB
Virtual Serial Port to USB
Virtual Serial Port to Ethernet
Virtual TCP/IP Port
Drivers
Windows®XP
Vista (32 bit / 64 bit)
Windows 7 (32 bit / 64 bit)
Server 2008 (32 bit / 64 bit)
CE
XP Embedded
POS for .NET
OPOS™
JavaPOS™
USB Vendor Class
Linux™CUPS
Mac OS X CUPS
What's Included
Cutter (SP742), Tear Bar (SP712) or Journal Model
5 ft. Power Cord
Embedded Power Supply
58mm Guide
Power Switch Cover
CD Including Drivers with Software Utilities
Setup Guide
Optional Accessories
Ticket Alarm Buzzer (BU01-24-A)
Wall Mount Bracket (WB-S700)
Vertical Stand it (VS-S700)
Putty or Gray Color Housing
Technical Specifications
Print Method: 9 Pin Impact Dot Matrix
Print Speed: 4.7LPS (13 Receipts Per Minute)
Paper Width: 70mm (standard) / 58mm
(With Paper Guide)
Paper Thickness: 0.06 - 0.08mm
Emulation: Star Mode, ESC/POS™
Buffer: 8 bytes
Power: 110 to 230 VAC
MCBF: 22 Million Lines
Cutter: 1 Million Cuts
Dimensions: W=160mm, H=152, D=245mm
Ribbons: RC700B = 3M Characters
RC700BR = 1.5M Characters, Black
.075M Characters, Red
Warranty US and Canada: 3-Year Limited Warranty, Plus Optional Extended Services Agreement Policies (Extend-A-Star and Swap-A-Star)
For Further Information Sales: 1-800-782-7636 x107
Technical Support: 1-800-782-7636 x105
Web: http://www.starmicronics.com
SP700 Specifications
2/25/10
