StarTech.com PEX1RISERF User manual

PEX1RISERF / PEX4RISERF
PEX8RISERF
PCI Express x1/x4/8 Left Slot Riser Adapter Card with 7cm Flexible Cable
Installation Guide
Packaging Contents
• 1xRiserCard
• 1xInstallationGuide
System Requirements
• PCIExpressenabledcomputersystemwithavailable
x1/x4/x8PCIeslot
• Serverchassisdesignedforrisercardapplications
ManualRevision:11/05/2010
Forthemostup-to-dateinformation,pleasevisitwww.startech.com
Installation
WARNING! PCI Express cards, like all computer
equipment,canbeseverelydamagedbystaticelectricity.
Besurethatyouareproperlygroundedbeforeopening
yourcomputercaseortouchingyourPCIExpresscard.
StarTech.comrecommendsthatyouwearananti-static
strap when installing any computer component. If an
anti-staticstrapisunavailable,dischargeyourselfofany
static electricity build-up by touching a large grounded
metal surface (such as the computer case) for several
seconds.AlsobecarefultohandlethePCIExpresscard
byitsedgesandnotthegoldconnectors.
1. Makesurethatyoursystemisunpoweredand
unpluggedandyouaregrounded.
2. Removethecoverofyoursystem(refertocomputer
systemdocumentation,ifnecessary)sothatthePCI
Expressexpansionslotopeningsonthemotherboard
areaccessible.
3. AlignthePCIExpressconnectorontherisercard
withanavailablePCIExpressslot.
4. Gentlyinsertthecardintotheemptyslot,making
sureitisseatedrmly.Fastenthecardtotheriser
cardmountingbracketonthecomputerchassis(refer
tocomputersystemdocumentation,ifnecessary).
5. InstallthedesiredPCIExpresscardintothe
PCIeslotontherisercardandfastensecurelyto
thecomputerchassis(refertocomputersystem
documentation,ifnecessary).
6. Replaceandfastenthecomputercover.
PEX1RISERF
PEX4RISERF
PEX8RISERF
*actualproductsmayvaryfromphotos

Warranty Information
Thisproductisbackedbyaoneyearwarranty.
Inaddition,StarTech.comwarrantsitsproductsagainstdefectsinmaterials
andworkmanshipfortheperiodsnoted,followingtheinitialdateofpurchase.Duringthisperiod,theproductsmaybereturnedforrepair,orreplacementwith
equivalentproductsatourdiscretion.Thewarrantycoverspartsandlaborcostsonly.StarTech.comdoesnotwarrantitsproductsfromdefectsordamages
arisingfrommisuse,abuse,alteration,ornormalwearandtear.
Limitation of Liability
InnoeventshalltheliabilityofStarTech.comLtd.andStarTech.comUSALLP(ortheirofcers,directors,employeesoragents)foranydamages(whetherdirect
orindirect,special,punitive,incidental,consequential,orotherwise),lossofprots,lossofbusiness,oranypecuniaryloss,arisingoutoforrelatedtotheuse
oftheproductexceedtheactualpricepaidfortheproduct.Somestatesdonotallowtheexclusionorlimitationofincidentalorconsequentialdamages.Ifsuch
lawsapply,thelimitationsorexclusionscontainedinthisstatementmaynotapplytoyou.
Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols
Thismanualmaymakereferencetotrademarks,registeredtrademarks,andotherprotectednamesand/orsymbolsofthird-partycompaniesnotrelatedinanywayto
StarTech.com.WheretheyoccurthesereferencesareforillustrativepurposesonlyanddonotrepresentanendorsementofaproductorservicebyStarTech.
com,oranendorsementoftheproduct(s)towhichthismanualappliesbythethird-partycompanyinquestion.Regardlessofanydirectacknowledgementelse-
whereinthebodyofthisdocument,StarTech.comherebyacknowledgesthatalltrademarks,registeredtrademarks,servicemarks,andotherprotectednames
and/orsymbolscontainedinthismanualandrelateddocumentsarethepropertyoftheirrespectiveholders.
Technical Support
StarTech.com’slifetimetechnicalsupportisanintegralpartofourcommitmenttoprovideindustry-leadingsolutions.Ifyoueverneedhelpwithyourproduct,
visitwww.startech.com/supportandaccessourcomprehensiveselectionofonlinetools,documentation,anddownloads.
Specications
PEX1RISERF PEX4RISERF PEX8RISERF
Bus Interface PCIExpress
(x1slotconnector)
PCIExpress
(x4slotconnector)
PCIExpress
(x8slotconnector)
Connectors x1PCIExpressslot x4PCIExpressslot x8PCIExpressslot
Flex Cable Length 7cm
Operating Temperature 0°C~60°C(32°F~140°F)
Storage Temperature 0°C~60°C(32°F~140°F)
Humidity 5%~95%RH
Dimensions (LxWxH) 179.0mmx100.0mmx15.0mm
Weight 30g 35g 45g
