StarTech.com DPBOOST User manual

Manual Revision: 09/05/2018
For the latest information, technical specications, and support for
this product, please visit www.StarTech.com/DPBOOST
FR: Guide de l’utilisateur - fr.startech.com
DE: Bedienungsanleitung - de.startech.com
ES: Guía del usuario - es.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
IT: Guida per l’uso - it.startech.com
DPBOOST
DisplayPort Signal Booster - 4K
*actual product may vary from photos

Instruction manual
FCC Compliance Statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment o and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation.
Changes or modications not expressly approved by StarTech.com could void the user’s
authority to operate the equipment.
Industry Canada Statement
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe [B] est conforme à la norme NMB-003 du Canada.
CAN ICES-3 (B)/NMB-3(B)
Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols
This manual may make reference to trademarks, registered trademarks, and other
protected names and/or symbols of third-party companies not related in any way to
StarTech.com. Where they occur these references are for illustrative purposes only and do not
represent an endorsement of a product or service by StarTech.com, or an endorsement of the
product(s) to which this manual applies by the third-party company in question. Regardless
of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby
acknowledges that all trademarks, registered trademarks, service marks, and other protected
names and/or symbols contained in this manual and related documents are the property of
their respective holders.

Instruction manual
i
Table of Contents
Product diagram ....................................................................................1
Front view .................................................................................................................................................... 1
Rear view...................................................................................................................................................... 1
Introduction............................................................................................2
Packaging contents.................................................................................................................................. 2
System requirements............................................................................................................................... 2
Installation ..............................................................................................3
Adjusting the signal amplication......................................................4
LED indicators.........................................................................................4
Specications..........................................................................................5
Technical support...................................................................................6
Warranty information............................................................................6

Product diagram
Instruction manual
1
Video In port
Power port
Status LED
Video Out port
Front View Rear view
Side view
+ Adjust
Control
button
- Adjust
Control
button

Instruction manual
2
Package contents
• 1 x DisplayPort signal booster
• 1 x power adapter
• 1 x USB power cable
• 4 x rubber feet
System requirements
• 1 x DisplayPort video source
• 1 x DisplayPort cable up to 50 ft. in length, to connect from your source to the
booster
• 1 x DisplayPort cable up to 15 ft. in length, to connect from the booster to your
display
• 1 x DisplayPort display

Instruction manual
3
Installation
Important installation notes:
• Maximum supported resolution varies depending on your extension distance.
• The DisplayPort cable connected to your display must be shorter than or equal to
the length of the cable connected to your video source.
• The maximum supported video source cable length is 50 ft. (15 m).
• The maximum supported display cable length is 15 ft. (5 m).
• Ensure your video source and display are turned o before you begin installation.
• Ensure the DisplayPort booster will be situated near an AC outlet or a USB power
source.
1. Determine where you’d like your video source to be located and set up your
DisplayPort video source as instructed by the documentation included with it.
2. Determine where you’d like your display to be located (within 65 ft. from your
video source) and set up your DisplayPort display for use as instructed by the
documentation included with it.
3. Connect a DisplayPort cable, up to 50 ft. in length (sold separately), to the output of
your video source and to the signal booster’s Video In port.
4. Connect a DisplayPort cable, up to 15 ft. in length (sold separately), to the signal
booster’s Video out port and to the DisplayPort input on your display.
5. Connect the USB power cable to the Power port on the DisplayPort booster and to
the power adapter, or other USB power source.
Note: If you’re using the included power adapter, connect the power adapter to
an AC power outlet.
6. Turn on your DisplayPort video source and your DisplayPort display. Your video
source will now be shown on the display.

Instruction Manual
4
Supported resolutions and cable lengths
Reference the table below for supported resolutions and cable lengths.
Cable length
from source
Cable length to
display
Total cable
length
Maximum
resolution
50 ft. (15 m) 15 ft. (5 m) 65 ft. (20 m) 1080p (60Hz) -
1920 x 1080
26 ft. (8 m) 16 ft. (5 m) 42 ft. (13 m) 4K (30Hz) -
3840 x 2160
16 ft. (5 m) 6 ft. (2 m) 22 ft. (7 m) 4K (60Hz) -
3840 x 2160
Change your signal equalization
using Adjust controls
The DisplayPort booster features an equalization switch with ten dierent settings. You
can use the switch to adjust the amplication of your DisplayPort signal, to ensure that
your DisplayPort signal is ideal, at all distances up to 65 ft. (20 m).
If you’re experiencing video issues, such as no display, a blinking display or other
imperfections after you’ve completed the installation steps, you can resolve these
issues by adjusting the signal amplication.
To adjust the signal amplication:
1. Press the + Adjust control button to cycle through positions above your current
setting.
2. Press the - Adjust control button to cycle through positions below your current
setting.
3. Reviewing your display at each position, and leave the switch in the position that
produces the best video performance.

Instruction Manual
5
The DisplayPort booster features an LED indicator that communicates the
booster’s operating status. Review the chart below to determine the signicance
of the LED’s behavior.
LED indicator
LED Behavior Signicance
Status LED
The LED
blinks green.
The signal booster has power, but
cannot establish a connection between
video source and display.
The LED
illuminates solid
green.
The signal booster has power and has
established a connection between the
video source and display.
The LED ashes
red.
One of the Adjust control buttons has
been pressed.

Instruction Manual
6
Specications
Warranty 2 years
Audio specications 7.1 surround sound
Maximum distance 65 ft. (20m) (Up to 1080p)
Maximum resolution 3840 x 2160 (60Hz) at up to 22 ft. (7 m)
3840 x 2160 (30Hz) at up to 42 ft. (13 m)
1020 x 1080 (60 Hz) at up to 65 ft. (20 m)
Supported resolutions 3840 x 2160 (4K), 1920 x 1080, 1680 x 1050, 1600 x 900,
1440 x 900,
1360 x 768, 1280 x 800, 1280 x 768, 1280 × 720
Connector(s) Input: 1 x DisplayPort (20 pin) Female
Output: 1 x DisplayPort (20 pin) Female
Indicators 1 x status LED
Environmental Operating temperature: 0°C to 40°C (32°F to 104°F)
Storage temperature: -10°C to 60°C (14°F to 140°F)
Humidity: 0% ~ 80%

Instruction manual
7
Technical support
StarTech.com’s lifetime technical support is an integral part of our commitment to
provide industry-leading solutions. If you ever need help with your product, visit
www.startech.com/support and access our comprehensive selection of online tools,
documentation, and downloads.
For the latest drivers/software, please visit www.startech.com/downloads
Warranty information
This product is backed by a two-year warranty.
StarTech.com warrants its products against defects in materials and workmanship
for the periods noted, following the initial date of purchase. During this period,
the products may be returned for repair, or replacement with equivalent
products at our discretion. The warranty covers parts and labor costs only.
StarTech.com does not warrant its products from defects or damages arising from
misuse, abuse, alteration, or normal wear and tear.
