StarTech.com 8STPATA2SATA3 User manual

Bi-Directional SATA/IDE Adapter Converter
PATA2SATA3
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l’utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l’uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
Packaging Contents
• 1 x SATA/ IDE converter adapter
• 1 x SATA cable
• 1 x SP4 to dual LP4 power Y-adapter cable
• 1 x Instruction Manual
Installation
IDE controller to SATA hard drive
1. Set the DIP switches on the adapter to either Master or Slave mode (see
DIP Switch Settings diagram).
2. Plug the 40-pin female IDE connector on the adapter directly into the
male 40-pin IDE connector on your motherboard or IDE/EIDE controller
card.
3. Connect a 7-pin SATA cable from the black “To Drive” connector to the
connector on the SATA hard drive.
4. Connect the SATA power from the computer power supply to the SATA
hard drive.
5. Connect an SP4 oppy power connector from the computer power
supply to the SP4 connector on the adapter. If one is not available use
the included LP4 to SP4 adapter cable to connect one of the LP4 molex
connectors from the power supply.
Instruction Manual
7-pin SATA
(To Drive)
7-pin SATA
(To Computer)
40-pin IDE
connector
4-pin SP4 oppy
power connector
SATA controller to IDE hard drive
1. The DIP switches do not matter in this mode.
2. Plug the 40-pin female IDE connector on the adapter, directly into the
40-pin male connector on the IDE/EIDE hard drive.
3. Connect a 7-pin SATA cable from the orange “To Computer” connector to
the 7-pin SATA connector on the motherboard or SATA controller card.
4. Connect an LP4 molex power connector from the computer power
supply to the hard drive.
5. Connect an SP4 oppy power connector from the computer power
supply to the SP4 connector on the adapter. If an SP4 connector is not
available, use the included LP4 to SP4 adapter cable to connect on of the
LP4 molex connectors from the power supply.
*actual product may vary from photos
System Requirements
• 40-pin IDE/EIDE or 7-pin SATA enabled computer system
• 3.5” IDE/EIDE or SATA hard drive
Manual Revision: 03/14/2017
For the most up-to-date information, please visit: www.startech.com

Consult the dealer or an experienced radio/TV technician for help.
Use of Trademarks, Registered Trademarks, and other Protected Names & Symbols
This manual may make reference to trademarks, registered trademarks, and other protected names and/or symbols of
third-party companies not related in any way to
StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an
endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual
applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body
of this document, StarTech.com hereby acknowledges that all trademarks, registered trademarks, service marks, and
other protected names and/or symbols contained in this manual and related documents are the property of their
respective holders.
Technical Support
StarTech.com’s lifetime technical support is an integral part of our commitment to provide industry-leading solutions.
If you ever need help with your product, visit www.startech.com/support and access our comprehensive selection of
online tools, documentation, and downloads.
Warranty Information
This product is backed by a two year warranty.
In addition, StarTech.com warrants its products against defects in materials and workmanship for the periods noted,
following the initial date of purchase. During this period, the products may be returned for repair, or replacement with
equivalent products at our discretion. The warranty covers parts and labor costs only. StarTech.com does not warrant
its products from defects or damages arising from misuse, abuse, alteration, or normal wear and tear.
Limitation of Liability
In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their ocers, directors, employees
or agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise),
loss of prots, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the
actual price paid for the product. Some states do not allow the exclusion or limitation of incidental or consequential
damages. If such laws apply, the limitations or exclusions contained in this statement may not apply to you.
FCC Compliance Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment o and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation. Changes or modications not expressly approved by StarTech.com
could void the user’s authority to operate the equipment.
Industry Canada Statement
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe [B] est conforme à la norme NMB-003 du Canada.
CAN ICES-3 (B)/NMB-3(B)
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two
conditions:
(1) This device may not cause interference, and (2) This device must accept any interference, including interference
that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence.
L’exploitation est autorisée aux deux conditions suivantes:
(1) l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement.
Specications
Connectors
1 x 40-pin IDE Female
1 x 7-pin SATA Male (orange)
1 x 7-pin SATA Male (black)
1 x 4-pin SP4 Floppy Power Male
Chipset Sunplus SPIF223A
Operating Temperature 0°C ~ 70°C (32°F ~ 158°F)
Storage Temperature -40°C ~ 150°C (-40°F ~ 302°F)
Humidity 90% RH
Dimensions 61.0mm x 50.0mm x 11.0mm
Maximum Data Transfer
Rates
SATA: 1.5Gb/s
IDE: 133 Mb/s
