StarTech.com POESLT1G48V User manual

Quick-Start Guide
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
Manual Revision: June 18, 2020
Product Diagram (POESLT1G48V)
Front View
Side View
Component Function
1PWR LED
Indicator
• On - Power output is detected on Terminal Block Power
Output Port
• O - Power output is not detected Terminal Block Power
Output Port
2bt LED
Indicator
• On - POE IEEE 802.3bt and Power Source Equipment (PSE) is
detected on PoE Input Port
• O - POE IEEE 802.3bt and PSE is not detected on PoE Input
Port
3DIP Switches
1 and 2
• Select the desired output voltage for the Terminal Block Power
Output Port
4PoE Input
Port
• Connect PSE via RJ45 Terminated Network Cable
• Supported power input voltage range is 15W up to 90W
5Data Port • Connect a Non-PoE Device via RJ45 Terminated Network
Cable
60W Industrial-Grade Hardened 802.3bt PoE Splitter 10/100/1000Mbps (48VDC Max Output)
6
Terminal
Block Power
Output Port
• Provides power to Non-PoE Equipment
• Supported power input voltage range is 44-57V
7Grounding
Screw • Attach a Grounding Wire to protect Network Equipment
Requirements
For the latest requirements, please visit www.startech.com/POESLT1G48V.
• Power Source Equipment (ex. PoE Gigabit Switch, PoE Injector) x 1
• RJ45 Terminated UTP/STP Cat 5e (or better) Network Cable (sold separately) x 2
• Earth Ground Connection x 1
• Grounding Wire x 1
• (Optional - for power) Flat Head Screwdriver x 1
• (Optional - for mounting) Phillips Head Screwdriver x 1
• (Optional - for mounting) Screws x 2
Installation
Select DC Output Voltage using the DIP Switches
Toggle the DIP Switches up and/or down to select the output voltage of the Terminal
Block Power Output Port.
Grounding the PoE Extender
Connect a Grounding Screw to the Grounding Point on the PoE Splitter and to the
Earth Ground Connection.
Connecting the PoE Splitter
1. Connect a Network Cable to the PoE Output Port of the Power Source Equipment
and to the PoE Input Port on the PoE Splitter.
67
51 4 2 3
DIP1 DIP2 Output voltage / Output current
UP UP 48VDC / 1.5A (default)
DOWN UP 24VDC / 2.3A
UP DOWN 16VDC / 2.3A
DOWN DOWN 12VDC / 2.3A

FCC Compliance Statement
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC
rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated
in a commercial environment. This equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of
this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the
interference at his own expense.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any interference received, including interference that may cause
undesired operation.
Changes or modications not expressly approved by StarTech.com could void the user’s authority to operate the equipment.
Industry Canada Statement
This Class A digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe [A] est conforme à la norme NMB-003 du Canada.
CAN ICES-3 (A)/NMB-3(A)
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two
conditions:
(1) This device may not cause interference, and (2) This device must accept any interference, including interference that may
cause undesired operation of the device.
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L’exploitation
est autorisée aux deux conditions suivantes:
(1) l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi,
même si le brouillage est susceptible d’en compromettre le fonctionnement.
Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols
This manual may make reference to trademarks, registered trademarks, and other protected names and/or symbols of third-
party companies not related in any way to StarTech.com. Where they occur these references are for illustrative purposes only
and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which
this manual applies by the third-party company in question. StarTech.com hereby acknowledges that all trademarks, registered
trademarks, service marks, and other protected names and/or symbols contained in this manual and related documents are the
property of their respective holders.
PHILLIPS® is a registered trademark of Phillips Screw Company in the United States or other countries.
Warranty Information
This product is backed by a two-year warranty.
For further information on product warranty terms and conditions, please refer to www.startech.com/warranty.
Limitation of Liability
In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their ocers, directors, employees or
agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of prots,
loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the
product. Some states do not allow the exclusion or limitation of incidental or consequential damages. If such laws apply, the
limitations or exclusions contained in this statement may not apply to you.
Safety Measures
• If product has an exposed circuit board, do not touch the product under power.
Mesures de sécurité
• Si l’un des circuits imprimés du produit est visible, ne pas touchez le produit lorsqu’il est sous tension.
安全対策
• 製品に露出した状態の回路基盤が含まれる場合、電源が入っている状態で製品に触らないでください。
Misure di sicurezza
• Se il prodotto ha un circuito stampato visibile, non toccare il prodotto quando è acceso.
Säkerhetsåtgärder
• Rör aldrig vid enheter med oskyddade kretskort när strömmen är påslagen.
FR: startech.com/fr
DE: startech.com/de
ES: startech.com/es
NL: startech.com/nl
IT: startech.com/it
JP: startech.com/jp
StarTech.com Ltd.
45 Artisans Cres
London, Ontario
N5V 5E9
Canada
StarTech.com Ltd.
Unit B, Pinnacle 15
Gowerton Rd,
Brackmills
Northampton
NN4 7BW
United Kingdom
StarTech.com LLP
2500 Creekside
Parkwy
Lockbourne, Ohio
43137
U.S.A.
DIN Rail Mounting
1. Align the holes in the DIN Rail Bracket with the holes in the back of the PoE
Splitter.
2. Insert three Phillips Head Screws through the DIN Rail Bracket and into the PoE
Splitter.
3. Tighten the Phillips Head Screws using a Phillips Head Screwdriver.
4. Hang the top of the DIN Rail Bracket (the section with the two metal clips) onto a
Top Hat style DIN Rail.
5. Press the DIN Rail Bracket down and forward to lock the bottom section onto the
DIN Rail.
2. Connect a Network Cable to the Data Port on the PoE Splitter and to the Network
Port on the Non-PoE Equipment.
Powering the Non-PoE Equipment
Connecting and installing the Terminal Block must be completed by a licensed
Electrician.
Notes: Make sure that you turn o the Power Source before connecting the Power
Wire to the Terminal Block.
Do not exceed the recommend voltage as it may result in personal or product damage.
Connect the Power Wires from a DC Power Source (44 - 57V DC) to the Terminal
Block Connectors on the Switch. The terminals are marked on the exterior of the
Switch (connect the Positive Wire to V+ and the Negative Wire to V-).
• Secure the Wires by tightening the Screws in the Terminal Block with a Flat Head
Screwdriver
Mounting the PoE Splitter
Wall Mounting
1. Align the holes in the Wall Mount Brackets with the holes in the back of the PoE
Splitter.
2. Insert two Phillips Head Screws through each Wall Mount Bracket and into the PoE
Splitter.
3. Tighten the Phillips Head Screws using a Phillips Head Screwdriver (sold
separately).
4. Insert two Screws (sold separately) through the Wall Mount Brackets and into the
Mounting Surface.
5. Tighten the Screws using the appropriate Screwdriver.
