StarTech.com AA2SPDIF User manual

AA2SPDIF
Stereo RCA to SPDIF and
Toslink Converter / Splitter
Instruction Manual

FCC Compliance Statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide rea-
sonable protection against harmful interference in a residential installation. This equip-
ment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio com-
munications. However, there is no guarantee that interference will not occur in a particu-
lar installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.•
Increase the separation between the equipment and receiver.•
Connect the equipment into an outlet on a circuit different from that to which the receiver•
is connected.
Consult the dealer or an experienced radio/TV technician for help.•
Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols
This manual may make reference to trademarks, registered trademarks, and other
protected names and/or symbols of third-party companies not related in any way to
StarTech.com. Where they occur these references are for illustrative purposes only and
do not represent an endorsement of a product or service by StarTech.com, or an en-
dorsement of the product(s) to which this manual applies by the third-party company in
question. Regardless of any direct acknowledgement elsewhere in the body of this doc-
ument, StarTech.com hereby acknowledges that all trademarks, registered trademarks,
service marks, and other protected names and/or symbols contained in this manual and
related documents are the property of their respective holders.

Instruction Manual
i
Instruction Manual
Table of Contents
Introduction .................................................................... 1
Features......................................................................................1
Package Contents .....................................................................1
Hardware Guide............................................................... 2
Front View...................................................................................2
Rear View....................................................................................2
Side View ....................................................................................3
Installation....................................................................... 3
Specifications.................................................................. 4
Technical Support........................................................... 5
Warranty Information...................................................... 5

Instruction Manual
1
Introduction
Thank you for purchasing a StarTech.com AA2SPDIF Analog to Digital
Audio Converter. This Analog to Digital Audio Converter is designed to
convert analog stereo audio signals from L/R input to Coaxial S/PDIF
and Toslink Optical outputs, simultaneously. The output digital audio
signal created is a 2-channel uncompressed LPCM (Linear Pulse Code
Modulation) with sampling rate at 48 KHz. Both Optical Fiber and Coaxial
cables connected to the outputs of the unit can run up to 5 meters while
providing reliable and lossless audio signal transmission. The AA2SPDIF
is compact and easy to install, making it ideal for home or professional
audio switching.
Features
Supports uncompressed 2-channel LPCM (Linear Pulse Code•
Modulation) digital audio signal output.
Supports output sampling rate at 48 KHz.•
Provides electromagnetic-noise-free transmission.•
Easy to install and simple to operate.•
Package Contents
1 x Analog RCA to Digital Coaxial and Toslink Converter•
1 x Instruction Manual•
1 x Power Adapter•

Instruction Manual
2
Hardware Guide
Front View
L/R Analog Audio Input Ports1.
Rear View
Coaxial Audio Output Port1.
Toslink (Optical Fiber) Output Port2.
1 2
1

Instruction Manual
3
Side View
Power Input Port1.
Installation
1
R/L
DVD Player
OR
Amplifier
A/V Receiver
Coaxial
Optical

Instruction Manual
4
Specications
Specification AA2SPDIF
Input Ports Stereo R/L
Output Ports 1 x TOSlink (Optical Fiber)
1 x Coaxial
Power Supply 5V/0.36~0.5A DC (US/EU
standards, CE/FCC/UL certified)
Dimensions (mm) 57(W) x 45.5(D) x 23.5(H)
Weight (g) 30
Operating Temperature Operating from 0°C ~ 48°C

Instruction Manual
5
Technical Support
StarTech.com’s lifetime technical support is an integral part of our commit-
ment to provide industry-leading solutions. If you ever need help with your
product, visit www.startech.com/support and access our comprehensive
selection of online tools, documentation, and downloads.
Warranty Information
This product is backed by a one year warranty.
In addition, StarTech.com warrants its products against defects in materi-
als and workmanship for the periods noted, following the initial date of
purchase. During this period, the products may be returned for repair,
or replacement with equivalent products at our discretion. The warranty
covers parts and labor costs only. StarTech.com does not warrant its
products from defects or damages arising from misuse, abuse, alteration,
or normal wear and tear.
Limitation of Liability
In no event shall the liability of StarTech.com Ltd. and StarTech.com USA
LLP (or their officers, directors, employees or agents) for any damages
(whether direct or indirect, special, punitive, incidental, consequential, or
otherwise), loss of profits, loss of business, or any pecuniary loss, arising
out of or related to the use of the product exceed the actual price paid
for the product. Some states do not allow the exclusion or limitation of
incidental or consequential damages. If such laws apply, the limitations or
exclusions contained in this statement may not apply to you.
