StarTech.com PATA2SATA2 User manual

7-Pin Male SATA Data
Connectors
40-Pin Female IDE
Connector
Male SP4
Connector
Jumper
Connector
IDE to Dual SATA Converter
PATA2SATA2
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l’utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l’uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
Features
• Compatible With Ultra ATA 100/133 with Data transfer rate up to
1.5 Gbps (150 MBps)
• Compliant With Serial ATA 1.0 Specication
• Converts IDE to Serial ATA
• No Drivers required
• Supports ATAPI devices (CD/DVD drives, CD/DVD burners, etc... )
• Supports up to 2 channels and 2 devices
• With no jumpers, makes it easy for conguration
Package Contents
• 1 X IDE to SATA Converter
• 1 X Power Cable
• 2 X SATA Cable
Installation
The following steps outline the procedure to install the PATA2SATA2 IDE to SATA Drive Motherboard Adapter.
1. Power down the computer, and open the computer case to provide access to the motherboard.
2. Insert the PATA2SATA2 into an available 40-pin IDE slot on the motherboard.
3. Fasten the SATA Drive(s) to the computer case, as you would in a typical hard drive installation.
4. Connect the SATA Drive(s) to the computer power supply, using available SATA power connectors.
5. Connect the LP4 power connector on the LP4 to SP4 adapter to an available LP4 power connection on the computer power supply.
6. Connect the remaining end of the LP4 to SP4 adapter to the 4 pin power port on the PATA2SATA2.
7. Connect the SATA Drive(s) to the PATA2SATA2 SATA connectors using the SATA data cable(s).
8. Replace the computer case cover(s) and power on the computer.
Installation Guide
Manual Revision: 06/06/2011
For the most up-to-date information, please visit: www.startech.com

FCC Compliance Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment o and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver
is connected.
Consult the dealer or an experienced radio/TV technician for help.
Use of Trademarks, Registered Trademarks, and other Protected Names & Symbols
This manual may make reference to trademarks, registered trademarks, and other protected names and/or symbols of
third-party companies not related in any way to
StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an
endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual
applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body
of this document, StarTech.com hereby acknowledges that all trademarks, registered trademarks, service marks, and
other protected names and/or symbols contained in this manual and related documents are the property of their
respective holders.
Technical Support
StarTech.com’s lifetime technical support is an integral part of our commitment to provide industry-leading solutions.
If you ever need help with your product, visit www.startech.com/support and access our comprehensive selection of
online tools, documentation, and downloads.
Warranty Information
This product is backed by a lifetime warranty.
In addition, StarTech.com warrants its products against defects in materials and workmanship for the periods noted,
following the initial date of purchase. During this period, the products may be returned for repair, or replacement with
equivalent products at our discretion. The warranty covers parts and labor costs only. StarTech.com does not warrant
its products from defects or damages arising from misuse, abuse, alteration, or normal wear and tear.
Limitation of Liability
In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their ocers, directors, employees
or agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise),
loss of prots, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the
actual price paid for the product. Some states do not allow the exclusion or limitation of incidental or consequential
damages. If such laws apply, the limitations or exclusions contained in this statement may not apply to you.
Specications
Specications PATA2SATA2
Chipset Sunplus SATALink SPIF223A
Data Transfer Rate 150 MBps
Industry Standards Serial ATA 1.0
Connector Types
1 x IDE 40 pin Female
2 x SATA Data 7 pin Male
1 x SP4 Male
