StarTech.com 6P6G-PCIE-SATA-CARD User manual

Quick-Start Guide
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
Manual Revision: June 17, 2021
Product Diagram (6P6G-PCIE-SATA-CARD)
Front View
Port Function
1SATA Ports x 6 • Connect SATA Stoage Devices to the PCIe SATA
Card using a SATA Cable
2PCIe x4 Connector • Connect the PCIe SATA Card to the PCIe Slot in
the Computer
Product Information
For the latest product information, technical specications, manuals, and Declarations
of Conformance, please visit:
www.startech.com/6P6G-PCIE-SATA-CARD.
Package Contents
• PCIe SATA Card x 1
• Full-Prole Bracket (Installed) x 1
• Low-Prole Bracket x 1
• Quick-Start Guide x 1
Requirements
• Computer with an available PCIe slot (x4/8/16)
• Phillips Head Screwdriver
• SATA Cables
6 Port SATA 6Gbps PCIe Controller Card
Hardware Installation
Warning: PCIe Cards can be damaged by static electricity. Make sure that the
Installer is properly grounded before they open the Computer Case or touch the
PCIe SATA Card. The Installer should wear an Anti-Static Strap when installing any
computer component. If an Anti-Static Strap is not available, discharge any built-up
static electricity by touching a large Grounded Metal Surface for several seconds.
Only handle the PCIe SATA Card by its edges and do not touch the gold connectors.
Installing the Low-Prole Bracket
By default the Full-Prole Bracket is attached to the PCIe SATA Card. Depending on
the system conguration it may be necessary to remove the Full-Prole Bracket to
replace with the Low-Prole Bracket (included).
1. Remove the 2x Phillips Head Screws securing the Full-Prole Bracket, using a
Phillips Head Screwdriver.
2. Remove the Full-Prole Bracket and replace with the Low-Prole Bracket
(included).
3. Install the 2x Phillips Head Screws removed in step 1 and tighten, using a Phillips
Head Screwdriver.
Installing the Card
1. Turn o the Computer and any Peripheral Devices that are connected
(e.g. printers, external hard drives, etc.).
2. Unplug the Power Cable from the rear of the Computer and disconnect any
Peripheral Devices that are connected.
3. Remove the Cover from the Computer Case.
Note: Consult the documentation that came with the Computer for details about
how to do this safely.
4. Locate an open PCIe Slot (x4/8/16) and remove the corresponding Metal Cover
Plate from the rear of the Computer Case. In most instances, the Metal Cover Plate
is attached to the rear of the Computer Case with a single Phillips Head Screw.
Save this Phillips Head Screw for the next step.
5. Gently insert the PCIe SATA Card into the open PCIe Slot (x4/8/16) and fasten the
Bracket to the rear of the Computer Case, using the Phillips Head Screw from
step 4.
6. Connect a maximum of 6 SATA Storage Devices to the SATA Ports of the PCIe
SATA Card using SATA Cables.
7. Replace the Cover from the Computer that was removed in step 3.
8. Reconnect all of the Peripheral Devices that were disconnected in step 2.
9. Reconnect the Power Cable to the rear of the Computer.
2
