StarTech.com ST10GSPEXNB User manual

Quick-Start Guide
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
Manual Revision: August 12, 2019 4:28 PM
Product Diagram (ST10GSPEXNB)
Port/LED/Connector Function
1Link Speed LED
• Indicates Link speed.
• Solid Amber = 10Gbps
• Solid Green = 5, 2.5, or 1Gbps
• O = 100Mbps
2Ethernet Port • Used to connect a network to the Network
Card.
3Link State/Activity LED
• Indicates Network Card Activity.
• Solid Green = Network port connected
• Flashing Green = Network port is active
4PCIe x4 Connector • Used to connect to a computers PCI Express
Slot.
Requirements
For the latest requirements, please visit www.startech.com/ST10GSPEXNB.
• PCI Express enabled computer with an available PCI Express slot (x4, x8, or x16)
• Operating systems:
• Windows® 10, 8.1, 8, 7, Windows Server® 2012, Windows Server 2008 R2
• Mac OSX 10.14, 10.13, 10.12
1-Port PCIe 10GBase-T | NBase-T Ethernet Network Card
1
Installation
Install the PCI Express Card
Warnings! PCI Express cards can be severely damaged by static electricity. Make sure
that you are properly grounded before you open your computer case or touch your PCI
Express card.
Only handle the PCI Express card by its edges and don’t touch the gold connectors.
1. Turn o your computer and any peripherals that are connected to it (for example,
printers, external hard drives, and so on).
2. Unplug the power cable from the back of your computer.
3. Disconnect any peripheral devices that are connected to your computer.
4. Remove the cover from your computer case. Consult the documentation that came
with your computer for details about how to do this safely.
5. Locate an open PCI Express slot and remove the corresponding metal cover plate
from the back of your computer case. Consult the documentation that came with
your computer for details about how to do this safely. This card works in PCI Express
slots of additional lanes (x4, x8, or x16 slots).
6. Gently insert the card into the open PCI Express slot and fasten the bracket to the
back of the case.
Note: If you install the card into a small form factor or a low-prole desktop system,
it may be necessary to replace the pre-installed standard prole bracket with the
included low-prole (half-height) installation bracket.
7. Place the cover back onto your computer case.
8. Reconnect the power cable to the back of your computer.
9. Reconnect all of the peripheral devices that you disconnected in step 3.
10. Turn on your computer and peripherals.
Install the Driver (Windows)
1. Using a web browser, navigate to www.startech.com/ST10GSPEXNB.
2. On the Product page, click the Support tab located in the middle of the screen.
3. In the Drivers and Downloads section, click on the driver link that corresponds with
the operating system running on the Host Computer.
4. Right click the zip folder that you downloaded from the website.
2
4
3

FCC Compliance Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment o and
on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation. Changes or modications not expressly approved by StarTech.com could void
the user’s authority to operate the equipment.
For the State of California
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Industry Canada Statement
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe [B] est conforme à la norme NMB-003 du Canada.
CAN ICES-3 (B)/NMB-3(B)
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions:
(1) This device may not cause interference, and (2) This device must accept any interference, including interference that may
cause undesired operation of the device.
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L’exploitation
est autorisée aux deux conditions suivantes:
(1) l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi,
même si le brouillage est susceptible d’en compromettre le fonctionnement.
Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols
This manual may make reference to trademarks, registered trademarks, and other protected names and/or symbols of third-
party companies not related in any way to StarTech.com. Where they occur these references are for illustrative purposes only
and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which
this manual applies by the third-party company in question. StarTech.com hereby acknowledges that all trademarks, registered
trademarks, service marks, and other protected names and/or symbols contained in this manual and related documents are the
property of their respective holders.
Warranty Information
This product is backed by a two year warranty.
For further information on product warranty terms and conditions, please refer to www.startech.com/warranty.
Limitation of Liability
In no event shall it be the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their ocers, directors, employees or
agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of prots, loss
of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product.
Some states do not allow the exclusion or limitation of incidental or consequential damages. If such laws apply, the limitations
or exclusions contained in this statement may not apply to you.
Safety Measures
• If product has an exposed circuit board, do not touch the product under power.
Mesures de sécurité
• Si l’un des circuits imprimés du produit est visible, ne pas touchez le produit lorsqu’il est sous tension.
安全対策
• 製品に露出した状態の回路基盤が含まれる場合、電源が入っている状態で製品に触らないでください。
Misure di sicurezza
• Se il prodotto ha un circuito stampato visibile, non toccare il prodotto quando è acceso.
Säkerhetsåtgärder
• Rör aldrig vid enheter med oskyddade kretskort när strömmen är påslagen.
FR: fr.startech.com
DE: de.startech.com
ES: es.startech.com
NL: nl.startech.com
IT: it.startech.com
JP: jp.startech.com
StarTech.com Ltd.
45 Artisans Cres
London, Ontario
N5V 5E9
Canada
StarTech.com Ltd.
Unit B, Pinnacle 15
Gowerton Rd,
Brackmills
Northampton
NN4 7BW
United Kingdom
StarTech.com LLP
2500 Creekside
Parkwy
Lockbourne, Ohio
43137
U.S.A.
Install the Driver (macOS)
1. On your computer, open an Internet browser and navigate to www.startech.com/
ST10GSPEXNB.
2. Click the Support tab.
3. Under Driver(s), download the driver for your operating system.
4. Follow the on-screen instructions to nish installing the driver.
Verify Driver Installation (macOS)
1. On your computer, in the nderbar, click the Apple icon.
2. Click About This Mac > System Report > PCI Cards.
3. Check to make sure that Yes is listed next to Driver Installed.
5. Click the Extract All link and follow the on-screen instructions.
6. On the keyboard press the Windows and R keys and type devmgmt.msc and press
Enter to open the Device Manager screen.
7. Right-click ethernet control device, which will have a ! or ? next to it indicating a driver
issue.
8. Click Update Driver > Browse my computer for driver software.
9. Select the Let me pick from a list of device drivers on my computer link.
10. on the select your device’s type from the list below screen, Click the Show All
Devices button, and click the Next button.
11. Select the Hard Disk option and browse to the Windows folder.
12. Click the TN40xxmp_le.
13. Click OK > Next.
Verify Driver Installation (Windows)
1. On your computer, navigate to Device Manager.
2. Under Network adapters, right-click TN4010 10GBase-T Ethernet Network Card and
click Properties.
3. Conrm that the driver is installed and working as expected.
