StarTech.com DS81000 Manual

5/8 Port Gigabit Ethernet Switch
DS51000
DS81000 Instruction Guide
The Professionals’ Source For Hard-to-Find Computer Parts
GIGABIT EETHERNET
SWITCH
* Actual product may vary from photo

FCC COMPLIANCE STATEMENT
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.

1
Table of Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Technical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Warranty Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

2
Introduction
Thank you for purchasing a StarTech.com Gigabit Ethernet switch. Thanks to dedicated
bandwidth of 1000 Mbits/sec for each port, your network will enjoy faster response
times and fewer bottlenecks. This Gigabit Ethernet switch automatically establishes the
fastest transfer speed for each device (1000, 100, or 10 Mbits/sec) and use half- and full-
duplex capabilities to optimize your network performance. Each port automatically
detects and adjusts for MDI (straight) or MDI-X (crossover) cables so there is no need for
a separate uplink port.
Features
• Complies with 802.3ab Gigabit Ethernet, 802.3u Fast Ethernet, and 802.3 Ethernet
standards
• Migrates smoothly between 1000Mbits/sec, 100 Mbits/sec, and 10 Mbits/sec network
devices
• Capable of half- and full-duplex communication
• Auto-negotiation function determines the optimal transmission rate for each node
• Auto MDI/MDI-X detection allows straight or crossover cables to be used in any port
• Supports store-and-forward switching architecture and full wire speed forwarding and
filtering rates
•Supports flow control: IEEE 802.3x for full-duplex mode, back pressure for half-duplex
mode
• Backed by StarTech.com’s two-year warranty
Before You Begin
To ensure a quick and easy Gigabit Ethernet switch installation, please read through this
section carefully before attempting to install the switch.
WARNING! The Gigabit Ethernet switch must be installed and operated in an
environment with temperatures between 50-131ºF (10-55ºC) and humidity levels of 0-
90% (non-condensing). Make sure that the switch is kept away from heating sources and
that the vents at the side of the device are not blocked. Do not place any objects on top of
the device. Make sure that no water or moisture enters the unit. If necessary, use a
dehumidifier to reduce humidity near the device.
Contents
This package should contain:
• 1 x Gigabit Ethernet switch
• 1 x external power adapter

3
System Requirements
This Gigabit Ethernet switch can be connected to PC computers with Ethernet
networking cards, or other compatible switches, hubs, or servers.
Note: For each Gigabit network device you want to attach to the switch, you will need
UTP network cables that comply with EIA/TIA 568 specifications and Category 5e
(minimum for Gigabit transfer rates) patch cable. StarTech.com offers a wide range of
these cables in various lengths and colors to suit your network needs. StarTech.com also
carries a wide range of Ethernet cards for both PC and notebook computers. For product
information, as well as tips and ideas for setting up and running your network, visit
http://www.startech.com and click on the Networking tab near the top of your screen.
Installation
This section will guide you through the installation of your Gigabit Ethernet switch.
Please read through the instructions carefully and complete each step in the order listed.
1. Plug one end of your network cable into an open port at the rear of the switch.
2. Plug the other end of the cable into the RJ-45 port on your network device.
3. Repeat steps 1 and 2 for any other devices you want to connect.
4. Plug one end of the the power adapter into an open outlet and plug the other end
into the DC connector at the rear of the device. The green Power LED on the front
of the switch should now be lit.
Monitoring Your Fast Ethernet Switch
The LEDs on the front of the switch are the best indication of the switch’s activity.
LED Color Status Description
PWR Green Lit Power is supplied
Power Off No power
LNK/ACT Green Lit Valid link established
Link/Activity Flashing Data packets received
Off No link
Speed Green Lit Port running at 1000 Mbits/sec
Yellow Lit Port running at 100 Mbits/sec
Off Port running at 10 Mbits/sec

4
Troubleshooting
Power LED is not lit.
• Check that the power cord is properly connected at both ends.
Link/Activity LED is not lit when connected to a 1000 or 100 Mbits/sec device.
• Make sure the device is turned on.
• Make sure the network cable is properly connected at both ends.
• Make sure that your network cables comply with EIA/TIA 568 and Category
5e specifications.
If problems persist, power down all devices and disconnect all plugs from the switch.
Wait at least ten seconds and plug the power adapter back into the switch. Then plug the
devices back into the switch and power them back up.
Technical Specifications
Standards IEEE 802.3ab, 802.3u, and 802.3
10/100/1000 Mbits/sec DS51000 RJ-45 x 5 Auto MDI/MDI-X
Ports DS81000 RJ-45 x 8 Auto MDI/MDI-X
Switching Architecture Store and Forward
MAC Address 8K
Buffer 256 Kbytes
NWay Auto-negotiation All ports
Full/Half Duplex All ports
Max. Cable Length 300ft (100m)
LEDS Power, LNK/ACT (Link/Activity), Speed
Dimensions 7.4 x 3.94 x 1.18 in. (187x100x30 mm)
Power 12V DC, 1.5A (positive center)
Operating Temperature 50-131ºF (10-55ºC)
Operating Humidity 10-95% (Non-condensing)
Emission FCC Class B, CE Mark & C-Tick

5
Technical Support
The following technical resources are available for this StarTech.com product:
On-line help:
We are constantly adding new information to the Tech Support section of our web site. To
access this page, click the Tech Support link on our homepage, www.startech.com. In the
tech support section there are a number of options that can provide assistance with this
product.
Knowledge Base - This tool allows you to search for answers to common issues using
key words that describe the product and your issue.
FAQ - This tool provides quick answers to the top questions asked by our customers.
Downloads - This selection takes you to our driver download page where you can
find the latest drivers for this product.
Call StarTech.com tech support for help:
USA/Canada: 1-519-455-4931
UK/Ireland/Europe: 00-800-7827-8324
Support hours: Monday to Friday 9:00AM to 5:00PM EST (except holidays)
Warranty Information
This product is backed by a one-year warranty. In addition, StarTech.com warrants its
products against defects in materials and workmanship for the periods noted,
following the initial date of purchase. During this period, the products may be
returned for repair, or replacement with equivalent products at our discretion. The
warranty covers parts and labor costs only. StarTech.com does not warrant its products
from defects or damages arising from misuse, abuse, alteration, or normal wear and
tear.
Limitation of Liability
In no event shall the liability to StarTech.com Ltd. (or its officers, directors, employees or
agents) for any damages (whether direct or indirect, special, punitive incidental,
consequential, or otherwise), loss of profits, loss of business, or any pecuniary loss,
arising out of related to the use of the product exceed the actual price paid for
the product.
Some states do not allow the exclusion or limitation of incidental or consequential
damages. If such laws apply, the limitations or exclusions contained in this statement
may not apply to you.

Revised: October 17, 2003
