TECHNICAL SPECIFICATIONS
Voltage: 120 V, 60 Hz
Amperage: 0.34 A
Lumens: 4,000
Watts: 40 (2 x 20 W)
Surface Mounted Diodes: 80 (2 x 40)
IP rating: IP-44
SMD Lifetime Estimate: 30,000 hours
TRIPOD:
Max Height: 65"
Min. Height: 30"
Base: 19" centre tube to outside of leg
POWER SUPPLY
Your STARTECH work light must be connected to a 120 V 60 Hz
15 A power supply protected by a circuit breaker. FAILURE TO
CONNECT THIS WAY MAY CAUSE ELECTRICAL SHOCK OR FIRE.
Work light must be grounded; consult a quali ed electrician if
you are not sure if your outlet is properly grounded. FAILURE
TO USE A PROPERLY GROUNDED OUTLET MAY CAUSE
ELECTRICAL SHOCK.
Your STARTECH work light is IP-44 rated for use outdoors.
For outdoor wet locations the use of a Ground Fault Circuit
Interrupter (GFCI) provides additional safety.
DO NOT REMOVE OR ALTER THE GROUNDING PRONG
EXTENSION CORDS
Using an extension cord will
result in the loss of voltage
between the outlet and the
tool. Use chart below to
determine minimum AWG
wire size for the length of
cord you require. If used
outdoors ensure extension
cord is suitably rated.
Length Gauge
0 – 25 Feet 16 ga
26 – 50 Feet 14 ga
51 – 100 Feet 12 ga
Assembly and Operation
ASSEMBLY
1. Attach carrying handle (E) to base (A) with bolts
2. Place base on at work surface.
3. Attach lights using 2 lock knobs (B) inserted through holes
in brackets (C) into threaded holes in base (see gure 1).
Fasten with at washers and lock washers.
4. Use long knob (D) to fasten power cord to handle through
hole in Y connection.
5. Loosen tripod lock knob (F, gure 2).
6. Push down leg connector (G) until legs are fully extended,
then tighten knob (F).
7. Adjust height by loosening twist collars (H, gure 3) and
raising centre poles. Tighten both collars rmly when
desired height is reached.
8. Place assembled work light on top of tripod. Centre bar of
base must be seated in Quick Release latch (J, gure 4.).
9. Place two buckles (K) of quick release latch over base
centre bar, place buckle (L) over both buckles (K) and push
down lever (M) to secure.
Figure 1
A
B
E
C
D
