STC-V450
www.stealthcam.net Toll Free 877-269-8490 2
For Customer Service or Warranty Information Call Toll Free
877-269-8490
Stealth Cam LLC
P.O. Box 539504
Grand Prairie Texas 75053-9504
www.steatlhcam.net
Stealth Cam Limited Warranty
Your Stealth Cam scouting camera is covered by a 90 days Limited Warranty on
parts and labor from the date of original purchase and purchases must be made
through an authorized dealer. The warranty covers defects in workmanship and
materials. The warranty does not apply to units which have been damaged or
abused intentionally or unintentionally. A purchase from individuals or
unauthorized internet sites voids the warranty.
Tampering with or altering the unit will void the warranty. Any unauthorized
service will void warranty. Original sales receipt must be produced for any
warranty service and a Return Authorization (RA) number must be obtained from
customer service at 877-269-8490 prior to returning product
All manuals and user guides at all-guides.com

STC-V450
www.stealthcam.net Toll Free 877-269-8490 3
Manual Contents
Camera overview 4
Camera kit contents 8
Battery and memory Installation 9
Set up and programming 12
Camera use 21
Mounting the camera 22
Viewing & Deleting images 28
Memory compatibility chart 37
Technical Specs 38
General Information 41
All manuals and user guides at all-guides.com

STC-V450
www.stealthcam.net Toll Free 877-269-8490 4
Camera overvie
Front housing image with major parts indication.
All manuals and user guides at all-guides.com

STC-V450
www.stealthcam.net Toll Free 877-269-8490 5
Open view image with major parts indication
For use with Stealth Cam cable
only. (sold separately)
All manuals and user guides at all-guides.com

STC-V450
www.stealthcam.net Toll Free 877-269-8490 6
Side view with major parts indication
All manuals and user guides at all-guides.com
all-guides.com

STC-V450
www.stealthcam.net Toll Free 877-269-8490 7
Picture / Image Capacity
SD card High Low Base AVI
16MB 11 33 130 8
32MB 22 66 260 16
64MB 44 132 520 32
128MB 88 264 1040 64
256MB 176 528 2080 128
512MB 352 1056 4160 256
1 GB 704 2112 8320 512
2 GB 1408 4224 16640 1024
NOTE: Picture / Image Capacity Chart provides approximate number of
images or AVI movies based on resolution setting and the size of
memory card. These figures may vary depending on the amount of
detail in the image.
All manuals and user guides at all-guides.com

STC-V450
www.stealthcam.net Toll Free 877-269-8490 8
Camera kit contents
• Model STC-V450 Digital Scouting Camera
• CDROM (Contains Ulead Photo Express 8 and camera driver)
• User Manual
• USB cable
• TV out cable for TV (RCA Jack)
• TV out cable for handheld TV (Mini Jack)
• Strap
All manuals and user guides at all-guides.com

STC-V450
www.stealthcam.net Toll Free 877-269-8490 9
Battery & memory installation
The Stealth Cam STC-V450 Advanced Digital Scouting Camera is
designed to operate using two different types of battery power
options.
NOTE: Always have camera in OFF position when installing or
removing batteries.
Batteries “C” cell
The internal battery compartment accepts 6 “C” cell batteries. Be
sure to use high quality brand name alkaline batteries. Install
batteries in correct polarity (+/-) as noted inside battery
compartment.
Warning:
Do not use different Voltage lead
acid battery other than the one specified in
this section. Doing so will damage the camera
and will void the warranty.
All manuals and user guides at all-guides.com

STC-V450
www.stealthcam.net Toll Free 877-269-8490 10
12V Lead Acid external battery
The STC-V450 is equipped with an external power jack designed to
accept a barrel plug cable to attach to a sealed lead acid battery.
(sold separately). Battery cable and complete 12V Lead Acid
battery kits are available wherever Stealth Cam scouting cameras
are sold or call toll free 877-269-8490. Only Stealth Cam external
battery accessories are recommended.
• Insert the external battery barrel plug into the DC 12V jack on
the bottom of camera housing
• Turn the camera power on.
 Please make sure the voltage and polarity (+/-) are correct
before connection. Incorrect voltage or polarity (+/-) will
damage the camera.
Memory Options
Your STC-V450 camera is equipped with 32MB built in flash
memory. The camera is also equipped with an expandable
media card slot capable accepting up to 2GB SD card (sold
separately). With no memory card inserted into the slot the
All manuals and user guides at all-guides.com

STC-V450
www.stealthcam.net Toll Free 877-269-8490 11
camera will use the built in 32MB memory. If a SD card is
inserted into the slot then the camera will bypass the built in
memory and utilize the SD memory. The front counter display will
show the number of images on the built in memory unless the
expansion card is inserted at which point the counter will only
show the number of images in the expansion card.
Inserting SD card
ake sure camera is in the OFF position whenever adding or
removing memory.
• Insert SD memory card in to the SD card slot completely and in
the correct direction as shown by the sticker located at the side
of the housing.
• To remove the SD memory card depress the SD card and pull
out the card gently.
 SD cards must be clean (no images from other sources), if
you are using the SD card from other cameras, please
make sure to format the SD card prior use in the STC-V450.
New cards are good to use straight from the package.
All manuals and user guides at all-guides.com
all-guides.com

STC-V450
www.stealthcam.net Toll Free 877-269-8490 12
Set up and Programming
When the camera is first turned on the internal LCD screen
displays the camera status. The follo ing information is present
on this screen.
Set Flash Control:
o Press [UP] button once to turn off the flash.
o Press [UP] button again to turn flash to Auto mode.
If no buttons are pressed after 30 seconds the LCD screen will
power down to conserve battery life and enter 1 minute count
down to enter PIR detection mode. To re-power the display
screen press and hold the UP or DOWN button for at least 5
seconds.
All manuals and user guides at all-guides.com

STC-V450
www.stealthcam.net Toll Free 877-269-8490 13
Definition
• Time out: To set the amount of time in minutes the camera will
sleep between PIR triggering.
• Flash:
o Auto - In low light conditions the flash will automatically
activate.
o Off – Turn off the flash.
• Capture mode: The capture mode that you have selected.
o 1P ~ 9P: 1 to 9 burst mode image capturing per PIR
triggering.
o Video: 5 to 90 seconds adjustable video per PIR triggering.
• Resolution: The resolution selection that you have selected.
o 4.0M : Select this option to capture a 4.0M pixels image.
(High image quality)
o 1.3M : Select this option to capture a 1.3M pixels image.
(Medium image quality)
o 0.3M : Select this option to capture a 0.3M pixels image.
All manuals and user guides at all-guides.com

STC-V450
www.stealthcam.net Toll Free 877-269-8490 14
(Low image quality)
o Video resolution (320 x 240): This is the resolution during
video capturing.
• Batteries Status: It shows the battery status.
o Full: It shows the batteries are full.
o Half: It shows the batteries are half.
o Lo : It shows the batteries are low and front battery
indicator will be on also.
 When the camera has detected low batteries, (Batteries are
lower then 6.6 +/-0.2Volts) the camera unit will power off
within 30 seconds automatically. Please replace with new
batteries; otherwise the camera will not work properly.
• Day and Time: It shows the date and time that you have set.
All manuals and user guides at all-guides.com

STC-V450
www.stealthcam.net Toll Free 877-269-8490 15
Programming the Stealth Cam STC-V450
Switch the camera to the ON position. Once the Camera status screen
is visible press the MENU button. This will bring up the SETTING
screen. Capture mode / Resolution / Time out / TV System / Date &
Time settings are all performed in this menu.
* NOTE: If no buttons are pressed within 30 seconds during any of
the programming mode, the unit will return to 1-minute count
down mode then start PIR capturing.
All manuals and user guides at all-guides.com

STC-V450
www.stealthcam.net Toll Free 877-269-8490 16
Set the Capturing sequence. The Stealth Cam STC-V450 can be
programmed to shoot 1-9 pictures per triggering or 5 to 90
seconds of adjustable video.
• Power on the unit press the [MENU] button to bring up the
menu on the LCD screen.
• Press [UP] or [DN] to highlight CAPTURE
• Then press the [OK] button to enter capture setting.
• Press the [UP] or [DN] button to select the desired capture
setting (number of pictures per triggering or video clip) If burst
mode is selected press the [OK] to save and it will exit to
SETTING SCREEN. If VIDEO is selected press the [OK] to
enter video time setting. Use [UP] or [DN] button to enter the
desired video length in 5 second increment. Press [OK] to
save the setting and exit to the SETTING SCREEN.
• Use the UP and DOWN buttons to select additional program
settings or press [MENU] again to exit the SETTING SCREEN.
All manuals and user guides at all-guides.com
all-guides.com

STC-V450
www.stealthcam.net Toll Free 877-269-8490 17
Set the Resolution:
• Press the [UP] or [DN] to highlight RESOLUTION
• Then press the [OK] button to enter the resolution settings.
• Press the [UP] or [DN] button to select the desired resolution
and press [OK] to save
• Use the UP and DOWN buttons to select additional program
settings or press [MENU] again to exit the SETTING SCREEN.
Set the Time out:
• Press the [UP] or [DN] button to highlight TIME OUT.
• Press [OK] to enter the setting.
• Press [UP] or [DN] button to set the desired time out in minutes
• Press [OK] again to save the setting. This will return you to the
SETTING SCREEN menu.
• Use the UP and DOWN buttons to select additional program
All manuals and user guides at all-guides.com

STC-V450
www.stealthcam.net Toll Free 877-269-8490 18
settings or press [MENU] again to exit the SETTING SCREEN.
Set TV System: NTSC is the correct setting for all of North
America. Your Stealth Cam STC-V450 comes pre-programmed for
NTSC.
• Press the [UP] or [DN] button to highlight TV System.
• Press [OK] to enter the setting.
• Press the [UP] or [DN] to set the TV output in NTSC or PAL
system.
• Press [OK] to save the setting and will exit to Camera Status
Screen.
All manuals and user guides at all-guides.com

STC-V450
www.stealthcam.net Toll Free 877-269-8490 19
Set Date and Time:
• Press the [UP] or [DN] button to move to highlight DATE AND
TIME.
• Press [OK] to enter the TIME & DATE setting menu.
• Press [UP] or [DN] to select the TIME
• Using the UP and DOWN buttons set the appropriate hour then
press OK. This will highlight the minutes. Using the UP and
DOWN buttons select the appropriate minute.
• Press the [OK] to save the time and this will return you to the
TIME & DATE setting menu.
• Press [UP] or [DN] to select DATE and press the [OK]
• Using the UP or DOWN buttons select the appropriate month
then press OK. This will bring you to the day setting. Using the
UP or DOWN buttons select the appropriate day then press OK.
This will bring you to the year setting. Using the UP or DOWN
All manuals and user guides at all-guides.com

STC-V450
www.stealthcam.net Toll Free 877-269-8490 20
buttons select the appropriate year then press OK. This will
return you to the DATE & TIME setting menu.
• Press the [MENU] to return to the main setting menu.
Once all settings have been completed press the MENU button to
return to CAMERA STATUS screen.
All manuals and user guides at all-guides.com
