Stealth Cam STC-BT14 User manual

Page 1
STC-BT14
Instruction Manual
R0

Page 2
To ensure the product is being utilized to its full potential, we recommend checking
our website for new product updates. If your camera is having an issue, please check
our website to determine you are using the latest rmware or software version.
Notice
TECHNICAL SUPPORT
EMAIL:
[email protected]
Please allow 48 hours for email
response.
GSM, LLC
P.O. Box 535189
Grand Prairie, TX 75053-9504
CUSTOMER SERVICE
CONTACT & HOURS
Toll Free: 877-269-8490
CALL CENTER HOURS
Mon – Fri / 8 AM – 5 PM (CST)
WEBSITE
www.stealthcam.com
Contact Us
BT14

Page 3
Table of Contents
About Your Camera 4
Quick Setup Guide 5
Camera Overview 6
Camera Setup 8
Camera Conguration 9
Viewing and Deleting Images 12
Frequently Asked Questions 13
Camera Care 14
FCC COMPLIANCE 15
Limited Warranty Information 16

Page 4
About Your Camera
60 Foot Detection and Flash Range
See farther with long-distance PIR sensor and LEDs.
0.7 Second Trigger Speed
Never miss a shot with lightning fast 0.7 second trigger
speed.
Quick Set Options
Set up in seconds with pre-programmed options.
Burst Rapid-Fire Mode
Rapid-re Burst Mode, multiple exposures per triggering.
18 IR LEDs
Perfectly illuminate your nighttime photos with 18 IR LED
lights.

Page 5
Quick Setup Guide
Insert Batteries and SD Card
Install 8 AA batteries and a class 10 SD card into camera.
Mount Camera
Mount the camera at the desired location using the strap
mount, Python Lock cable, Articulating Ball Joint Mount, or
other desired mounting mechanism. Position the camera so
that it does not face East or West directly as the rising and
setting of the sun can cause false positive triggers.
Activate Camera
Set camera to desired Quick Set (QSET) or to custom
conguration and place in desired vantage point to start
capturing photos of game.

Page 6
Camera Overview
Menu Down Up Enter
Mode Switch
MENU ENTER
Universal
¼ - 20 thread
SD Card
Slot
Battery
Release Switch

Page 7
Python Cable
Lock Hole
Strap
Mounts
Universal
¼ - 20 thread

Page 8
Camera Setup
Battery Installation
To remove batteries from unit, simply open camera and slide the
battery release switch to the left. Once the battery compartment is
open, insert batteries into camera, being careful to match the orien-
tation marked on your camera. After batteries are inserted, close the
battery compartment and secure the battery release switch.
SD Card Installation
SD card slot is located on the
bottom of the camera, above the
battery compartment. Insert SD
card with the label facing back of
camera. Only minimal resistance
should be felt as card is inserted
and a click when the card is fully
inserted.

Page 9
Camera Conguration
This camera features 4 distinct modes of operation:
QSET 1 | QSET 2 | QSET 3 | CUSTOM |.
Each setting is activated based upon the position of the switch inside the unit.
Name Type Quality Timeout
Delay Detail
QSET 1 Photo Medium 30 sec 3 Photos
QSET 2 Photo Medium 30 sec 1 Photo
QSET 3 Video 640 x 360 30 sec 10 sec video
Quick Sets
Once selected, the screen will display the Quick Set (QSET) that has been
chosen and then count down from 9to 0 seconds. When countdown has
been completed camera is ready and in an active state.
See table for breakdown of Quick Set modes.
O
QSET 1
QSET 2
QSET 3
Custom
MENU ENTER

Page 10
Custom Conguration
The CUSTOM setting on your camera allows you to customize every
setting to t your exact needs. To begin, move the slider to the CUSTOM
position and press the menu button on the camera.
Once inside the custom settings menu, use the Up and Down arrows to
scroll through the di󰀨erent settings. To change a setting that is displayed,
press the Enter key and the setting will begin ashing. At this point use
the Up and Down arrows to change the setting. When nished press the
Enter button to save the change or press Menu to cancel change.
When you are nished conguring your camera’s settings, press the
Menu button to return your camera to an active state.
