OWNER’S MANUAL
Q-Back 2.0
Owner’s Manual for AL Series and AFT Series
Q-Back 2.0

i
Customer Satisfaction 1.0
Stealth Products, LLC strives for total customer satisfaction. Your experience as a
customer is important to us. Please contact us with feedback or to suggest
changes that may help improve the quality and usability of our products. You
may reach us at:
General
Read and understand all instructions prior to the use of the product. Failure to
adhere to instructions and warnings in this document may result in property
damage, injury, or death. Product misuse due to failure to adhere to the follow-
ing instructions will void the warranty.
Immediately discontinue use if any function is compromised, if parts are missing
or loose, or if any component shows signs of excessive wear. Consult with your
supplier for repair, adjustment, or replacement.
If this document contains information you do not understand, or if there are
concerns about safety or operation, contact your supplier.
MDSS GmbH
Schiffgraben 41
30175 Hannover, Germany
Stealth Products, LLC
104 John Kelly Drive, Burnet, TX 78611
Phone: [phone] Toll Free: [phone]
Fax: [phone] Toll Free: [phone]
[email protected] www.stealthproducts.com

ii
Important Information 2.0
Important Information!
All persons responsible for fitting, adjustment, and daily use of the devices
discussed in these instructions must be familiar with and understand all safety
aspects of the devices mentioned. In order for our products to be used
successfully, you must:
read and understand all instrucons and warnings;
maintain our products according to our instrucons on care and maintenance; and
ensure devices are installed and adjusted by a trained technician.
Ordering Documentation
You can download additional copies of this manual by accessing the Stealth
website (https://stlpro.site/stealth-docs) and searching “Q-Back 2.0” in the
search bar at the top of the page.

iii
Introduction 3.0
Before you install or begin using this product, it is important that you read and
understand the content of these installation and operating instructions. The in-
stallation instructions will guide you through the options and possibilities with
the product.
Instructions are written with the expressed intent of use with standard
configurations. The instructions contain important safety and maintenance in-
formation and describe possible problems that can arise during use. For further
assistance or for more advanced applications, please contact your supplier or
Stealth Products at [phone] or toll free at [phone].
Always keep these operating instructions in a safe place so they may be
referenced as necessary.
All information, pictures, illustrations, and specifications are based on the
product information that was available at the time of printing. Pictures and
illustrations show in these instructions are representative examples and are not
intended to be exact depictions of the various parts of the product.
CA UT ION
These products are designed to be fitted, applied, and installed exclusively by a
healthcare professional trained for these purposes. The fitting, application and
installation by a non-qualified individual could result in serious injury.

iv
Introduction 3.0
Installation Date:
Dealer:
Dealer Stamp:
Serial Number:

v
Warranty 4.0
No person is authorized to alter, extend, or waive the warranties of Stealth
Products, LLC.
Stealth Products, LLC warrants against failure due to defective materials
or workmanship:
Covers/Soft Goods: 2 years
Hardware: 5 years
Electronics: 3 years
Limitations 4.1
Stealth Products, LLC does not warrant damage due to, but not limited to:
misuse, abuse, or misapplicaon of products, or
modicaon of products without wrien approval from Stealth Products, LLC.
Any alteraon or lack of serial number, where applicable, will automacally void
this warranty.
Stealth Products, LLC is liable for replacement parts only, and is not liable for any labor
costs incurred.
NOTICE
Any substitutions of supplied hardware void the warranty. Misuse of items and “acts of
nature” (e.g., flood, tornado) are not covered by the warranty.

vi
Table Of Contents 5.0
1.0 Customer Satisfaction ............................................................................. i
2.0 Important Information .......................................................................... ii
3.0 Introduction........................................................................................... iii
4.0 Warranty .................................................................................................. v
4.1 Limitations ............................................................................................................... v
5.0 Table Of Contents .................................................................................. vi
6.0 Warning Labels..................................................................................... vii
6.1 Warning Labels................................................................................................... vii
6.2 Limited Liability .................................................................................................. vii
6.3 Testing ................................................................................................................... vii
7.0 Parts And Accessories ........................................................................ viii
7.1 Tools Required For Installation & Adjustment ..................................... viii
7.2 Parts List ............................................................................................................... viii
8.0 Design And Function............................................................................ ix
8.1 Intended Use ........................................................................................................ ix
8.2 Contours and Profiles ....................................................................................... ix
8.4 Available Sizes...................................................................................................... ix
9.0 Installation Instructions........................................................................ 1
9.1 Q-Back 2.0 Installation Instructions.............................................................. 1
9.2 Contour Support Adjustment Instructions ................................................ 1
10.0 WC20 Information............................................................................... 2
10.1 WC20 Hardware ............................................................................................... 2
10.2 Before Transit .................................................................................................... 2
10.3 Belt Placement .................................................................................................. 3
10.4 User Safety.......................................................................................................... 6
11.0 First-Time Use ...................................................................................... 8
11.1 Dealer Assistance............................................................................................. 8
11.2 User Testing ....................................................................................................... 8
11.3 Conditions of Use ............................................................................................ 8
12.0 Maintenance......................................................................................... 9
11.1 Cleaning............................................................................................................... 9
11.2 Disinfection ........................................................................................................ 9

vii
Warning Labels 6.0
DA NGER Identifies an imminent situation which, if not avoided,
may result in severe injury, death, and/or property damage.
WARNING Identifies a potential situation which, if not avoided, may
result in severe injury, death, and/or property damage.
CA UT ION Identifies a potential situation which, if not avoided, may
result in minor to moderate injury and/or property damage.
NOTI CE
Identifies important information not related to injury, but
possible property damage.
SAFETY
Indicates steps or instructions for safe practices, reminders of
safe procedures, or important safety equipment that may
be necessary.
Warning Labels 6.1
Warnings are included for the safety of the user, client, operator and property.
Please read and understand what the signal words DANGER, WARNING,
CAUTION, NOTICE and SAFETY mean, and how they could affect the user,
those around the user, and property.
Limited Liability 6.2
Stealth Products, LLC accepts no liability for personal injury or damage to
property that may arise from the failure of the user or other persons to follow
the recommendations, warnings, and instructions listed in this manual.
Testing 6.3
Initial setup and driving should be done in an open area free of obstacles until
the user is fully capable of driving safely.
The ADI Q-Back 2.0 should always be tested without any person sitting in
the wheelchair until every alteration of the physical installation or adjustment
is complete.

viii
Parts And Accessories 7.0
Tools Required for Installation & Adjustment 7.1
4mm hex key
Parts List 7.2
Fabric Cover (A)
Foam Cushion (B)
Back Support Shell (C) [Aluminum]
Shells with Laterals or Contour Supports include T-Nuts, M6 FWs, and
M6x1x12mm Buon Head Screws.
Label (D)
NOTICE
Only use the hardware supplied with the ADI Q-Back 2.0. Do not substitute any other
screws, brackets, or clamps. Use of alternative hardware or mounting brackets voids all
warranty.
C
D
AB

ix
Design And Function 8.0
Active
2.5” Deep 4” Extra
Deep
6”
Intended Use 8.1
The purpose of the ADI Q-Back 2.0 is to provide rehab-style seat back sup-
ports compatible with Quantum True Balance (TB3 and TB4) seating systems.
The back comes equipped with mounting holes to easily match the True
Comfort Back keyhole attachment system.
Contours and Proles 8.2
Standard Available Sizes 8.3
Widths
12” �13” �14” �15” �16” �17” �18” �19” �20” �22” �24”
Heights
M = 13” �S=16” �T=18” �X=20” �XX=22”
�4” and 6” adjustable lateral supports are compatible with the Active shell
�AL Series features a scapular cut-out
�AFT Series features a flat top
�4” and 6” contour supports are underneath cover and foam.

1
Installation Instructions 9.0
Q-Back 2.0 Installation Instructions 9.1
    
        
     
  
      Q-Back 2.0 
       
  Q-Back 2.0    
       
       
       
    
  Q-Back 2.0   Figure A: Spacer ts between chair
spine and the seat back.
Contour Support/ Lateral Adjustment Instructions 9.2
              
        Q-Back 2.0
             
            

             
        
         
WARNING
Protect the back and, if included, contour or lateral supports from blunt forces
that may cause damage and/or breakage.
WARNING
Do not use Laterals without proper installation. Always use foam with Laterals.

2
WC20 Information 10.0
WC20 Hardware 10.1
Q-Back 2.0 has met the requirements for ANSI/RESNA WC
-4:2017, Section 20 - Wheelchair Seating Systems for Use
in Motor Vehicles, commonly shortened to WC20 and
ISO16840-4 for international transportation requirements.
The back must have the thumb screw inserted and
tightened to be WC-20 approved.
WC20 establishes design and performance requirements and test methods for
complete seating systems that consist of a seat, back support, and attachment
hardware.
Before Transit 10.2
Clients who use wheelchairs should transfer to the vehicle seat and use the vehicle-
installed occupant-restraint systems.
Prior to transporng, always double check the e-downs and hardware.
On e-downs and restraints, look for tears or worn webbing straps. Replace as necessary
and never use torn straps.
Look for damaged hooks or loose e-down hardware.
On the seang system, check for loose screws aaching the hardware to the seat. These
should be snug and not over ghtened.
CA UT ION
The WC20 approved Q-Back 2.0 should only be used as detailed in
these instructions, and only meet WC20 requirements when used in
conjunction with a WC20 approved back and wheelchair.
DA NGER
The WC20 approved Q-Back 2.0 is designed specifically for
occupancy when used on wheelchairs that are facing forward in
motor vehicles.

3
WC20 Information 10.0
Belt Placement 10.3
 The pelvic belt restraint should be worn low, across the front of the pelvis near the
juncons of the pelvis and the thighs.
 The belt restraint buckle of three-point belt restraints should be placed in contact with the
occupant’s body and away from wheelchair components.
 The juncon of the shoulder belt and pelvic belt of three-point-belt restraints should be
located near the hip opposite the shoulder over which the diagonal belt crosses and not
near the midline of the occupant.
Proper Positioning of Belts on Occupant
 Upper torso belt restraints should t directly over, and in contact with, the middle of the
shoulder.
Shoulder Belt
Restraint
Pelvic Belt
Restraint
DA NGER
The WC-20 approved Q-Back 2.0 has been designed to accommodate
the proper use of vehicle-anchored belt restraints and the ratings of the
seating systems, with regard to a) ease of properly positioning vehicle-
anchored belt restraints on the wheelchair passenger, and b) the degree
to which proper positioning of belt restraints can be achieved.
DA NGER
Alterations or substitutions should not be made to the seating system or
to its parts and components without consulting the manufacturer.

4
WC20 Information 10.0
CAUTION
Belt restraints should be adjusted to fit as snugly as possible,
consistent with user comfort.
Improper Positioning of Belts on Occupant
Belt restraints should not be routed outside of the wheelchair wheels or over the
wheelchair arm supports and should not be held away from the body by wheelchair
components or parts.
SAFETY
Belt restraints should not be worn twisted or in a manner that reduces
the area of contact of the belt webbing with the occupant.

5
WC20 Information 10.0
Both pelvic-belt and shoulder-belt restraints that comply with RESNA
WC-4:2012, Section 18 and/or 4.6,5.2,5.3 or RESNA WC-4:2012, Section 19
should be used to limit occupant movement in a crash and reduce the
likelihood of occupant ejection from the vehicle and/or injurious contact of the
occupant with the vehicle interior.
The pelvic belt should be angled between 30° to 75° horizontally when viewed
from the side, and ideally between 45° to 75° horizontally, as shown in the
figure below.
WARNING
If the back support must be adjusted to an angle greater than 30° to the
vertical during travel, the upper shoulder belt anchor point should be
adjusted rearward to maintain belt contact with the wheelchair
occupant’s shoulder and chest.
WARNING
Back supports with adjustable recline angles should not be tilted back
more than 30° to the vertical during travel in vehicles unless necessary
for the medical and postural needs of the occupant.

6
WC20 Information 10.0
Trays
Wheelchair-mounted rigid trays that are not specifically designed for use during
travel in motor vehicles should be:
 Removed and secured separately in the vehicle.
 Secured to the wheelchair so they will not break free in a crash.
 Be posioned with a gap of at least 75mm (3in.) between the back edge of the tray and the
wheelchair occupant’s abdomen and/or chest so as not to interfere with proper
belt-restraint use.
 Have energy absorbing padding placed between the back edge of the tray and the
wheelchair occupant.
User Safety 10.4
The use of a postural pelvic belt attached to the wheelchair base or seat frame is
encouraged during travel, but these belts should be positioned so that they do
not interfere with the proper positioning of crashworthy belt restraints, and they
should not be relied upon for occupant protection in crash situations unless the
postural belt has been designed to comply with, and perform to, the require-
ments in 4.6, 5.2, and 5.3 of RESNA WC-4:2012, Section 19.
Sufficient forward and rearward clear space should be provided around the
wheelchair occupant.
The forward clear-space zone (FCZ) needs to be larger when a shoulder-belt
restraint is not used.

7
WC20 Information 10.0
When mounting the WC20-approved Q-Back 2.0 to your wheelchair, refer to the
installation instructions on page 1.
DA NGER
The WC20-approved Q-Back 2.0 is designed only for use with
wheelchair frames that have been successfully crash-tested to the frontal
impact requirements of RESNA WC-4:2012, Section 19
WARNING
The WC-20 approved Q-Back 2.0 must be used on a wheelchair frame
that provides four securement points and pelvic belt anchor points that
conform to the requirements of RESNA WC-4:2012, Section 19.

8
First-Time Use 11.0
Dealer Assistance 11.1
During first-time use by the client, it is advised that the dealer or service
technician assist and explain the setup to the customer (i.e., the user and/or the
attendant). If needed, the dealer can make final adjustments.
User Testing 11.2
It is important that the customer is fully aware of the installation, how to use it,
and what can be adjusted in order to gain as much mobility as possible. As a
dealer, complete the following steps and checks.
Explain and show the customer how you have executed the installaon, and explain the
funcon of the hardware.
If needed, adjust the hardware to the proper posion.
Explain possible problems to the customer and how to address them.
Conditions of Use 11.3
The Q-Back 2.0 is intended for use as installed by the dealer, in accordance
with the installation instructions listed in this manual.
The foreseen condions of use are communicated by the dealer or service technician to the
user and/or aendant during the rst use.
If the usage condions change signicantly, please contact your dealer or a qualied service
technician to avoid excessive wear and tear or unintended damage.
CA UT ION Do not attach the Q-Back 2.0 with the user in the chair.

9
Maintenance 12.0
Cleaning 12.1
 Use a so cloth to clean the back shell.
 Hand wash the foam pad cover with mild, soapy water or detergent and let dry.
 Foam pad should not get wet.
Disinfection 12.2
 Wipe gently with a cloth dampened with a household disinfectant.
CA UT ION
Institutions must clean and disinfect this product between multiple patient
uses.
WARNING Do not machine wash or dry.
WARNING Do not hand wash in water temperatures above 160°F (70°C).
WARNING Do not immerse the foam in water.
SAFETY
Always check all mounting hardware, making sure each fastener is properly
tightened, before using the back support.
WARNING
User Weight Limits:
Pediatric - 175 lbs. (79.37 kg.)
Adult - 350 lbs. (158.76 kg.)
22” or wider - 500 lbs. (226.8 kg.)
NOTICE
Altering an ADI back in any way and/or improper installation will void
the warranty.

Stealth Products, LLC. • [e-mail] • www.stealthproducts.com
[phone] | [phone] | 104 John Kelly Drive, Burnet TX 78611
P116D623 Revision Date 2020-02-11
