Sunrise Medical QUICKIE SALSA Manual

Directions for use
QUICKIE SALSA

IMPORTANT:
DO NOT USE YOUR WHEELCHAIR UNTIL THIS
MANUAL HAS BEEN READ AND UNDERSTOOD.
User Information
Intended use power wheel chairs:
Power wheelchairs are exclusively for a user who is unable to
walk or has limited mobility, for their own personal use in-
and outdoor.
When an Attendant Control Module is fitted, the Power
Wheelchair may be operated by an assistant on behalf of the
user.
When a Dual Control Module is fitted the Power Wheelchair
may be operated by the user, or control may be switched to an
assistant to operate on behalf of the user.
The maximum weight limit (includes both the user and any
weight of accessories fitted to the wheelchair) is marked on
the serial number label, which is affixed to the chassis of the
chair.
The chair serial number is affixed also to the front page of the
owners manual supplied with the wheelchair.
Warranty can only be taken on if the product is used under the
specified conditions and for the intended purposes.
The intended lifetime of the wheelchair is 5 years. Please DO
NOT use or fit any 3rd party components to the wheelchair
unless they are officially approved by Sunrise Medical.
Area of application
The variety of fitting variants as well as the modular design
mean that it can be used by those who cannot walk or have
limited mobility e.g. because of:
• Paralysis
• Loss of extremity (leg amputation)
• Extremity defect deformity
• Joint contractures/joint injuries
• Strokes and brain injuries
• Neurological disabilities (e.g. MS, Parkinson…)
• Illnesses such as heart and circulation deficiencies,
disturbance of equilibrium or cachexia as well as for elderly
people who still have the strength in the upper body.
• Persons who are mentally and physically able to control an
input device to operate the chair and its functions in a safe
way.
When considering provision, please also note the body size,
weight including the distribution of body weight, the user’s
physical and psychological constitution, the age of the user,
their living conditions and their environment.
If in doubt a health care professional should be involved to
ensure the user is not exposed to unacceptable risks.
Sunrise Medical is ISO 9001 certied, which ensures quality
at all stages of the development and production of this
wheelchair.
Sunrise Medical declares under its sole responsibility
that this product is in conformity with the
requirements of the directive 93/42/EEC amended
by 2007/47/EEC.”
Sunrise Medical declares that this product fulls the
performance requirements for a “Crash Test” to ISO 7176-19.

Table of contents
1 Your Wheelchair 6
2 How to use this manual 6
2.1 Introduction .................................................................... 6
2.2 Guarantee ...................................................................... 6
2.3 Warranty conditions........................................................ 6
3 Label explanations / Word definitions 7
3.1 Definitions of words used in this manual ........................ 7
3.2 Label explanations.................................................... 7 + 8
4 General safety warning and user tips 9
4.1 General warnings .......................................................... 9
4.2 Features and options .................................................... 9
4.3 Kerbs............................................................................. 9
4.4 Routine service ............................................................. 9
4.5 Emergency freewheel ................................................... 9
4.6 EMC - Radio transmitting devices. ............................... 9
4.7 Emergency braking ....................................................... 9
4.8 Sharp turns ................................................................... 9
4.9 Batteries........................................................................ 9
4.10 Tyres .............................................................................. 9
4.11 Weight limit .................................................................... 9
4.12 Wheelchair motors ...................................................... 10
4.13 Hot surfaces ................................................................ 10
4.14 Wheelchair range ........................................................ 10
4.15 Road caution ............................................................... 10
4.16 Adverse conditions...................................................... 10
4.17 Ramps ......................................................................... 10
4.18 Transfer to and from the chair..................................... 10
4.19 Lift and tilt modules ..................................................... 10
4.20 Anti-tips....................................................................... 10
4.21 Use on a slope ............................................................ 10
4.22 Using a vehicle mounted passenger lift ..................... 11
4.23 Creep mode ................................................................ 11
4.24 Stability of your wheelchair......................................... 11
4.25 Wheels ........................................................................ 11
4.26 Rear view mirror.......................................................... 11
4.27 Crutch holder .............................................................. 11
4.28 Lights and indicators................................................... 11
4.29 Swing away tray.......................................................... 11
4.29.1 Seat stay ..................................................................... 11
4.30 Using a kerb climber ................................................... 12
4.31 Lap belt........................................................................ 13
4.32 VR2 Controller ........................................................... 13
5 Preparing your wheelchair for use 14
5.1 Handling the wheelchair................................................ 14
5.2 Preparation for transportation or storage..................... 14
5.3 Re-Assembling ............................................................ 14
5.4 Emergency freewheel ............................................ 14 - 15
5.5 Drive wheel suspension Salsa...................................... 15
5.6 Control joystick unit position......................................... 15
5.7 Getting ready to drive.................................................... 16
5.8 Armrests................................................................. 16- 18
5.9 Legrests ................................................................ 19 - 20
6 Seating 21
6.1 Firm seat board ........................................................... 21
6.2 Seat cushions ............................................................. 21
6.3 Removable seat covers .............................................. 21
6.4 Standard backrest upholstery..................................... 21
6.5 JAY backrests ............................................................. 21
6.6 Seat Height Adjustment .............................................. 21
6.7 Seat Width Adjustment ............................................... 21
6.8 Seat Depth Adjustment............................................... 22
6.9 Backrest Angle Adjustment ........................................ 22
6.10 Back Height Adjustment ..................................... 22 - 24
6.11 Manual adjustable backrest (manual recline) ............. 24
6.12 Manual setting of the seat angle on the SALSA ......... 24
6.13 Headrest ...................................................................... 24
6.14 Powered Seating ......................................................... 25
7 The VR2 Hand Control series 26 - 28
7.1 VR2 .............................................................................. 26
7.2 VR2-L .......................................................................... 27
7.3 VR2 Dual control unit .................................................. 27
8 Troubleshooting using the VR2 Hand Control 29
9 Controller Mounts 30
9.1 General warnings ........................................................ 30
9.2 Attendant control......................................................... 30
9.3 Parallel swing-away control ........................................ 30
10 Batteries and charging 31
10.1 Batteries ...................................................................... 31
10.2 Safety cut-outs............................................................ 31
10.3 General battery information........................................ 31
10.4 Maintenance free batteries ......................................... 31
10.5 Battery care................................................................. 31
10.6 Maintenance free battery care plan............................ 31
10.7 General charger information....................................... 31
10.8 Charger safety features ...................................... 31 - 32
10.9 Procedure for connecting the charger and charging.. 32
10.10 Charger safety and caution notes............................... 32
10.11 The range of your vehicle............................................ 32
10.12 Common battery statements ...................................... 32
10.13 Battery warranty.......................................................... 32
11 Transportation 33 - 35
11.1 Transportation warnings:............................................. 33
11.2 Occupant restraint instructions ................................... 33
11.3 Crash testing on the SALSA ...................................... 34
11.4 The tie down label and placement ............................. 34
11.5 Securing the wheelchair into the vehicle ................... 34
11.6 Salsa tie downs ........................................................... 35
12 Maintenance and Cleaning 36
12.1 Tyre maintenance and pressures................................ 36
12.2 Tyre wear..................................................................... 36
12.3 Drive wheel tyre repair................................................ 36
12.4 Removing the castor wheel ........................................ 36
12.5 Cleaning your wheelchair ........................................... 36
12.6 Inspection of the upholstery / seating ........................ 36
12.7 Cleaning seating ......................................................... 36
12.8 Cleaning controls ........................................................ 36
12.9 Lighting bulb exchange procedure ..................... 36 - 37
12.10 Electrical connections................................................. 37
12.11 How to connect the cables to the batteries ................ 37
12.12 Controller access ........................................................ 37
12.13 Storage........................................................................ 37
12.14 Authorised Sunrise Medical service agents............... 37
12.15 Recommended maintenance routines................ 37 - 38
12.16 Performance checks ................................................... 38
13 Specification sheets (EN 12184 & ISO 7176-15) 39
14 Service History 40
15 Disposal 41
16 SALSA Battery Wiring Diagram 42

4 Quickie SALSA
ENGLISH
Armrest
Legrest
Controller
Cushion
Castor
Footplate
Drive wheel
Skirt Guard
Anti-tips
Backrest
Batteries

Quickie SALSA 5
ENGLISH
Armrest
Legrest
Controller
Cushion
Front castor
Footplate
Drive wheel
Skirt Guard
Backrest
Batteries
Rear castor

6 Quickie SALSA
ENGLISH
1 Your Wheelchair
We at Sunrise Medical want you to get the best out of your
Salsa wheelchair. This Owner’s Manual will familiarise you with
the chair and its features. It contains hints on everyday usage
and general care in addition to information on the high quality
standards which we adhere to and details about the guarantee.
Your wheelchair should be delivered fully assembled for your
use; there are a wide range of components and adjustments
available on the Salsa. For further information about these you
should contact your Sunrise Medical authorised dealer.
Your wheelchair will reach you in excellent condition having
been individually inspected before leaving our factory. Following
the guidelines for maintenance and cleaning your wheelchair
will maintain its first class condition and give you complete
satisfaction.
The Salsa has been designed for use by an individual on a daily
basis. It is suitable for both indoor and outdoor use (Class B). It
is only intended for use as a pavement vehicle, but may also be
used when crossing between pavements.
This vehicle has been designed for a single occupant of limited
mobility up to the weight of 140Kg (dependent on options
chosen for your chair) who has the cognitive, physical and visual
ability to control the vehicle safely on a maximum slope of 16%
(9°). If you are in any doubt as to the suitability of the power
chair, contact your local Sunrise Medical approved supplier for
clarification, prior to commencing use.
It is very important to read the relevant section of the owner’s
manual when making any minor adjustments. Contact your
local Sunrise Medical authorised dealer for more complex
adjustments.
If you have any queries about the use, maintenance or safety
of your wheelchair, please contact your local Sunrise Medical
authorised dealer. If you do not know of an authorised dealer
in your area or have any other questions please write or
telephone:
Sunrise Medical LTD.
Sunrise Business Park
High Street, Wollaston
West Midlands DY8 4PS
England
Phone: [phone]
Fax: [phone]
Sunrise Medical is ISO 9001 certified, which
ensures quality at all stages of the development and
production of this wheelchair.
This product is manufactured to comply with
Medical Device Directive 93/42/EEC amended by
2007/47/EEC.
How to use this manual2
2.1 Introduction
Please keep a note of your local authorised dealer address and
telephone number in the space below.
In the event of a breakdown, contact them and try to give all
relevant details so they can help you quickly.
The wheelchairs shown and described in this manual may not
be exactly the same in every detail as your own model. However,
all instructions are still entirely relevant, irrespective of detail
differences.
The manufacturer reserves the right to alter without notice any
weights, measurements or other technical data shown in this
manual. All figures, measurements and capacities shown in this
manual are approximate and do not constitute specifications. For
visual impaired people we have placed this document as a PDF on
our website, please look at www.sunrisemedical.com.
2.2 Guarantee
The guarantee form is included in the Sunrise Pack. Please fill in
the relevant details and return to us to register your entitlement.
THIS IN NO WAY AFFECTS YOUR STATUTORY RIGHTS.
2.3 Warranty conditions
1) The repair or replacement will be carried out by an authorised
Sunrise Medical dealer/service agent.
2) To apply the warranty conditions, should your wheelchair require
attention under these arrangements, notify the designated Sunrise
Medical service agent immediately giving full information about
the nature of the difficulty. Should you be operating the wheelchair
away from the locality of the designated Sunrise Medical service
agent, work under the “Warranty Conditions” will be carried out by
any other service agent designated by the manufacturer.
3) Should any part of the wheelchair require repair or replacement,
as a result of a specific manufacturing or material defect, within
twenty four months from the date on which the possession of the
wheelchair was transferred to the original purchaser, and subject to
it remaining within that ownership, the part or parts will be repaired
or replaced completely free of charge if returned to the authorised
service agent.
4) Any repaired or replaced part will benefit from these
arrangements for the balance of the warranty period applicable to
the wheelchair.
5) Parts replaced after the original warranty has expired are
covered for a further twelve months.
6) Items of a consumable nature will not generally be covered
during the normal warranty period, unless such items have clearly
suffered undue wear as a direct result of an original manufacturing
defect. These items include amongst others upholstery, tyres,
inner tubes and similar parts. On powered products this will also
include batteries, motor brushes etc
7) The above warranty conditions apply to all wheelchair parts for
models purchased at full retail price.
8) Under normal circumstances, no responsibility will be accepted
where the wheelchair has required repair or replacement as a
direct result of:
a) The wheelchair or part not having been maintained or serviced
in accordance with the manufacturer’s recommendations, as
stated in the Owner’s Manual and/or Service Manual. Or failing
to use only the specified original equipment parts.
b) The wheelchair or part having been damaged by neglect,
accident or improper use.
c) The wheelchair or part having been altered from the
manufacturer’s specifications, or repairs having been attempted
prior to the service agent being notified.
Dealer signature and stamp
*
(
IMPORTANT:
DO NOT USE YOUR WHEELCHAIR UNTIL THIS
MANUAL HAS BEEN READ AND UNDERSTOOD.

Quickie SALSA 7
ENGLISH
Label explanations / Word definitions3
3.1 Denitions of words used in this manual
Word Definition
Warning Advice to the user of a potential risk of injury if the advice is not followed
Note General advice or best practice
3.2 Label explanations
Labels and their descriptions
Warning - Do Not Touch - HOT Lever position for the freewheel mechanism.
WARNING – Do Not Touch - Static may damage equipment
Attached to Joystick
WARNING – Do not drive your wheelchair on a slope with the
backrest reclined and/or the seat lifted
WARNING – Danger of finger entrapment WARNING – Maximum user weight for the chair is 140Kg
Indicates battery charge point
Lever position for the freewheel mechanism.
Down – IN DRIVE Up - IN FREEWHEEL
Location of 70Amp circuit breaker
140 Kg
MAX

8 Quickie SALSA
ENGLISH
Labels and their descriptions
Back Rest Recline Seat Lift
Seat Tilt in Space
The power Tilt and power Lift/Tilt modules are factory fitted
for optimum stability and for conformance to strict standard
requirements. Changing the fitted position of the module can
reduce the stability of the product, therefore do not change this
setting
Do not engage free wheel whilst on a slope Ensure drive is engaged before starting off.
Left Leg Rest
Right Leg Rest
Both Leg Rests
WARNING: When the seat is raised you must always
use the seat stay

Quickie SALSA 9
ENGLISH
4 General safety warning and user tips
4.1 General warnings
• Alwaysensurethatyourwheelchairisswitchedoffbefore
attempting to mount or dismount.
• Alwaysensurethatyouareabletooperateallcontrolsfrom
a comfortable position. Paying attention to your posture is
essential to ensure your continued comfort and well being.
• Alwaysmakesurethatyoucanbeseenclearly,especially
if you intend using your wheelchair in poor light.
• This wheelchair has been built to match the needs of a
particular user. If used by another user then it may need to
be adjusted and reprogrammed.
• Donotletchildrenorothersuseyourwheelchair.
• All parts in direct contact with the user comply with EN
1021-1/2.
• Beawarethatthewheelchairmaycometoasuddenstop
during operation.
• Donotoperatethewheelchairifitisbehavingabnormally
or erratically.
4.2 Features and options
Some of the options shown in this manual may not be
available in your country and may also restrict the overall
physical limits of the standard product (e.g. max. speed, user
weight limit, etc.). Those limitations are marked on the order
form, in the technical manual and in this owner’s manual.
For further information please consult your Sunrise Medical
authorised dealer.
4.3 Kerbs
Never descend a kerb Forwards with a RWD chair. Please
read carefully the section 4.30. on kerb climbing in this
manual before attempting to mount and dismount any kerbs in
your wheelchair.
Do not attempt to climb or descend a series of steps. It is unsafe
to do so and could cause personal injury or damage the chair.
The Salsa has only been designed to climb a single step or
kerb.
4.4 Routine service
The recommended service interval is one year. (See
service history table in section 14).
4.5 Emergency freewheel
Please remember that you have no braking facility when
the freewheel levers are moved from the normal drive
position to the freewheel position (Fig. 1, Fig. 2, Fig 3 and Fig 4).
Always ensure an attendant is with you when bringing the chair
into the freewheel mode.
The wheelchair must never be left with one or both levers in the
freewheel position. For an enhanced description of this facility
and its limitations to use please see later section at 5.4.
4.6 EMC - Radio transmitting devices.
When operating two-way radio, walkie-talkies, C.B.,
amateur radio, public mobile radio and other powerful
transmitting devices the wheelchair should be brought to a halt
and turned off.
The operation of cordless, mobile telephones and cell phones
including hands-free devices is permitted but if abnormal
operation of the wheelchair is encountered then the chair must
be brought immediately to a halt and turned off.
Note: the electrical systems of the wheelchair may
disturb the performance of alarm systems in retail shops.
4.7 Emergency braking
There are three ways to stop your wheelchair:
1. Simplest and safest way to stop the wheelchair is to
release the joystick (see Hand Control section 7). This will bring
the chair to a halt in a controlled manner.
2. Pulling back the joystick will brake the chair abruptly with a fast
stop
3. Switching the control system off whilst the chair is in motion
will also bring the chair to a halt. This third method is only to be
used in an emergency situation as the stopping action is very
abrupt.
4.8 Sharp turns
Full speed turns should not be attempted. If you need to
turn sharply you must reduce your speed with the joystick
or speed setting. This is particularly important when travelling
across or down a slope. Disregarding this advice could lead to
your wheelchair tipping over.
4.9 Batteries
Your wheelchair is supplied as standard from Sunrise
Medical with maintenance-free batteries. These only
require regular charging. Before charging, please read section
10 in this manual.
Do not, under any circumstances, tamper with the batteries.
If in any doubt contact your local Sunrise Medical authorised
dealer.
Note: Before using your vehicle for the very first time, please
charge your batteries for a period of 24 hours.
Avoid contact with acid on damaged sealed type batteries or wet
batteries. Battery acid can cause burns to the skin as well as
damage to floors, furniture and your wheelchair. If it comes into
contact with the skin or clothing, wash immediately with soap
and water. If it comes into contact with the eye, immediately
flood the eye with running cold water for at least 10 minutes and
seek medical attention immediately. Acid can be neutralised
with baking soda and water. Take care to keep batteries upright
at all times, especially when transporting your wheelchair.
Battery and charger connector type Salsa R:
24V (2x12V) / 60 Ah/20h. Maintenance free
Dimensions: 197 x 165 x 197 mm.
Battery and charger connector type Salsa M:
24V (2x12V) / 51 Ah/20h. Maintenance free
Dimensions: 228 x 139 x 235 mm.
Connector: 3 pins “Neutrik” type
Fig. 1 Fig. 2
Fig. 4
Fig. 3

10 Quickie SALSA
ENGLISH
trigger the self protect mechanism in the control system. If this
occurs the control system will temporarily shut down to prevent
damage to the electronics or the chair.
4.17 Ramps
When using a ramp, please ensure that it is capable of
taking the combined weight of the power chair and yourself. If a
ramp is being used to load a chair into a vehicle, please ensure
the ramp is properly secured to the vehicle. Always approach
the ramp head-on and exercise caution.
Note: Please ensure your ramp is suitable for the product you
are transporting.
4.18 Transfer to and from the chair
Sunrise Medical recommend that you consult your
healthcare professional for assistance in developing your
personal front or side transfer technique to best suit your needs
and avoid any personal injury.
Note: Ensure controller is switched off during transfers to avoid
unintentional movement.
4.19 Lift and tilt modules
Please be aware that the lift and tilt modules present a
trap hazard. Make sure that when operating the tilt and lift it
is free from all clothing, hands, feet and other extremities to
prevent injury.
Do not drive on ramps or slopes with the seat tilted, reclined or
raised. Before attempting to climb or descend a slope, return to
an upright position.
The power Tilt and power Lift/Tilt modules are factory tted
for optimum stability and for conformance to strict standard
requirements. Changing the tted position of the module can
reduce the stability of the product, therefore do not change this
setting.
Risk of trapping ngers:
The protection guard secures the moving parts within the
lift / tilt mechanism. Although protected please be always
carefulnottogetyourngertrappedinthemechanism.It
is mandatory to re-install the protection guards as described in
the Salsa technical manual after any service or repairs ot the lift
/ tilt module.
4.20 Anti-tips
Make sure that anti-tips are not damaged or worn before
using your chair.
Attendants must be aware of the location of the anti-tips
to prevent feet being trapped underneath causing injury.
Attendants - Do not stand on the anti-tips, this could cause the
wheelchair to become unstable.
4.21 Use on a slope
Your wheelchair has been designed and tested to allow
its use on slopes or gradients of up to 9° (16%). However, you
have the option of adjusting your seating position with either
a lift, tilt or recline or a combination of these options, then in
certain circumstances your wheelchair could become unstable.
Before attempting to climb or descend a slope or a kerb, caution
should be taken when using weight shift options (e.g. powered
tilt or recline) of the seat and/or your body for a counter balance
weight. To improve stability lean forward when driving uphill, with
the seat and back in an upright position. Alternatively sit in an
upright position when travelling in a forward, downhill direction
or tilt and/or recline the seat backwards.
We strongly recommend that you return the seat and back
to an upright lowered position before attempting to climb
or descend a slope. Failure to do this may cause the
wheelchair to become unstable.
If you are in any doubt about the capabilities of your wheelchair
on a slope then do not attempt to drive up or down the slope/
kerb; try to find an alternative route.
4.10 Tyres
Your wheelchair tyres can wear depending on use. Check
them regularly in accordance with the service instructions
in this manual, especially the pressure of the tyres.
NEVER inflate the tyres using a garage forecourt airline, always
use the pump provided.
4.11 Weight limit
• The user plus items carried should never exceed a
total weight of 140Kg
• Never use this chair for weight training if the total weight
(user plus additional weights) exceeds a total weight of
140Kg
• Exceeding the weight limit is likely to damage the seat,
frame or fasteners and may cause severe injury to you or
others from chair failure
• Exceedingtheweightlimitwillvoidthewarranty.
4 .1 2 W h e e l c h a i r
motors
After prolonged
use, the motors
will produce heat, which
is radiated through the
motors’ outer casing. Do
not touch the motors’
outer casing for at least
30 minutes after using
the wheelchair, to allow
it to cool. (Fig. 5 /6)
4 . 1 3 H o t
surfaces
Not only the motors
can get hot during the
operation of the chair,
but also the upholstery
material and armrests when standing in the sun.
4.14 Wheelchair range
The range of your wheelchair can be affected by many
factors such as user weight, terrain, ambient temperature, use
of powered options and battery condition. The stated range in
the sales literature should be seen as the theoretical maximum
(ISO 7176; Part 4) and may not be attained by every user (also
see section 11.12. in this manual).
We recommend that every user initially limit their journey to half
the stated range, until they have confidence in the actual range
their wheelchair can attain. If your battery indicator is showing
a low charge then do not attempt a long journey unless you are
confident in reaching your destination and also returning to your
home without the risk of being left stranded.
4.15 Road caution
Please show the utmost consideration for the other traffic
on the road. Remember that the last thing a car or lorry driver
expects to see is a wheelchair backing off the kerb into the road.
If in any doubt, do not risk crossing the road until you are certain
that it is safe. Always cross the road as quickly as possible;
there may be other traffic.
4.16 Adverse conditions
Please be aware that when driving your wheelchair in
adverse conditions, e.g. on wet grass, mud, ice, snow or
other slippery surfaces, you may experience a reduction
in the grip and traction of your wheelchair. We recommend you
take extra precautions in these conditions, particularly on hills
and slopes; your wheelchair could become unstable or skid
causing possible injury. Extreme variances in temperature may
Fig. 5
Fig. 6

Quickie SALSA 11
ENGLISH
4.21.1 Gradients: ascents
When going uphill, keep the chair moving. Steer by
moving the joystick from side to side. If you have stopped on a
hill, you should start slowly. If necessary lean forward to prevent
the tendency for the front wheels to lift.
4.21.2 Gradients: descents
On descents, it is important not to let the wheelchair accelerate
beyond its normal level of ground speed. In fact, it is safer to
proceed slowly down steep descents (below the speed of 5kph)
and stop, if any anxiety arises regarding directional control. If
the chair picks up speed, centre the control to slow it or to stop
all forward movement, then restart slowly and do not allow the
speed to increase. The solid state controller has the benefit of
a logic system that will help compensate when driving along
a camber or up a hill. This is an added safety feature on your
wheelchair. In addition of course, you may control the wheelchair
speed by using the speed control.
4.22 Using a vehicle mounted passenger lift
Wheelchair lifts are used in vans, buses and buildings to
help you move from one level to another. Ensure that the user
and all carers fully understand the lift manufacturer’s instructions
for using the passenger lift.
Never exceed the lift manufacturer’s recommended safe working
load and load distribution guidance.
Always turn off all power when you are on the lift. If you fail to do
so, you may touch the joystick by accident and cause your chair
to drive off the platform. Be aware that a rollstop at the end of
the platform may not prevent this.
Always position the user securely in the chair to help avoid falls
while on the lift. Always ensure the chair is in drive mode when
using passenger lift (wheels locked not in freewheel mode).
4.23 Creep mode
Please ensure your backrest recline angle relative to floor
level, which is a combination of the back recline itself and the
tilt angle, does not exceed 12° to drive the chair safely. If the
tilt angle exceeds 9° the chair will the chair will automatically
convert into “creep mode” which will allow you a maximum of
10% of the speed programmed in the profile.
WARNING - If you have a manual recline backrest on your
wheelchair, please be aware that there will be no feedback
system to the controller that tells it that the seat is in a reclined
position. If you recline your backrest and attempt to drive, it will
not go into ‘creep mode’, it will instead drive at full speed. This is
especially dangerous when attempting to drive up a slope.
4.24 Stability of your wheelchair
Please follow the user instructions in this manual
regarding the use of seat lift and tilt modules and the use
of your chair on a slope, other variables can affect your chair
stability, including:
- Movement of the user
- Effects of the addition of accessories or other equipment
- Inappropriate adjustments or modifications to the wheelchair
In some cases these issues are further compounded by the
effects of the local environment such as:
- Hills, Slopes, Ramps, Sloping pavements, Dropped kerbs.
Furthermore different body proportions of a wheelchair user
affect stability for example:
- Lower limb wasting or amputation, Obesity
- Increased upper torso mass, Upper torso height
The power Tilt and power Lift/Tilt modules are factory tted
for optimum stability and for conformance to strict standard
requirements. Changing the tted position of the module can
reduce the stability of the product, therefore do not change this
setting.
4.25 Wheels
Always use the pump that is supplied with the chair,
Never use a forecourt pump.
Inspect all tyres regularly for signs of wear.
Do not drive over anything that could cause punctures in the
tyres.
Ensure that there are no objects in your path that could possibly
become lodged in your chair mechanism or in the spokes of the
rear wheels. This could cause the chair to come to a sudden
stop.
Riding over drains or grids could cause the wheelchair castors
or wheels to become lodged, causing the chair to come to a
sudden stop.
Always maintain the correct pressure for the tyre. These are
listed in section 12 of this manual.
Pneumatic Tyres with OKO uid.
The OKO fluid is only meant as a temporary repair to the tyre. It
must be replaced or repaired as soon as possible.
The OKO fluid is classified as non hazardous but may cause
irritation to the skin with prolonged contact.
4.26 Rear view mirror
To avoid injury to people around you please be aware that the
mirror protudes outside the space envelope of the chair and
could cause injury to someone when driving past.
The mirror must be used on the 10KPH model on UK roads.
Always make sure that when using the mirror that it is clean and
unbroken so that it does not impair your visibility.
4.27 Crutch holder
Make sure that the crutch is securely fastened to the
crutch holder.
Make sure that the crutch is not interfering with the mechanisms
of the chair.
Make sure that the crutch does not protrude from the chair.
Do not attempt to remove the crutch whilst the chair is in motion.
Always come to a complete stop and turn off the power to the
controls before attempting to remove the crutch. This will avoid
accidentally operating the chair.
4.28 Lights and indicators
Ensure that the lights and indicators are functioning
correctly and lenses are clean before going outdoors at
night. Light assemblies can become very hot - Care must
be taken if removing them for repair.
4.29 Swing away tray
The maximum weight allowed for the tray is 2.5kg.
Do not overload the tray, this could cause the tray to break
or could cause the chair to become unstable.
Do not leave lit cigarettes or other heat sources on the tray as
this could cause the tray to deform and mark.
Ensure that all extremities and clothing are free when positioning
the tray for use.
4.29.1 Seat stay
A seat stay is provided on your powerchair to provide access for
service and maintenance. (see section 10 for additional info)
WARNING - do not move the wheelchair with the seat stay in
place and make sure you are on flat stable ground. Make sure
that the plastic cap is securely fitted over the seat height tube.
First Aid measures for OKO fluid
Skin - Wash skin with plenty of water
Eyes - Immediately flood the eye with plenty of water for at
least 5 minutes holding the eye open.
Ingestion - Drink lots of water - Seek medical attention
immediately.

12 Quickie SALSA
ENGLISH
4.30 Using a kerb climber
4.30.1 Mounting a kerb or step (Fig 9)
Always approach a kerb at 90° (Fig 7 & Fig 8)
• Approach the kerb (step)
head on driving forwards
slowly and steadily and
always at a 90° angle.
Salsa R (RWD)
• Asthekerbclimberorcastor
makes contact with the
kerb (step), the wheelchair
should be moving slowly. Small kerbs can be climbed from
a standstill.
Salsa M (MWD)
Approach the kerb in a 90° angle and stop the chair as soon as
the castor wheels touch the kerb.
• Applysufficientpowertothe motorstoliftthe frontof the
chair up onto the kerb (step) and then apply slightly more
power and speed so that the drive wheels climb the kerb
(step) smoothly and without hesitation and the rear castor
wheels come up as well. As far as possible, keep the
joystick in the straight forward position.
Note: In accordance to the ground clearance, the maximum
obstacle height possible to climb is 5 cm (10 cm with kerb
climber) for Salsa R and 7.5 cm for Salsa M.
WARNING: The approach speed and process can vary
depending on your wheelchair performance and castor wheel
choice.
4.30.2 Dismounting the kerb (Fig. 9)
Salsa R (RWD)
• Reversethechairslowlyandcarefullyuntilbothrearwheels
are on the edge of the kerb, again in a 90° position to the
kerb.
• Reverse as slowly as possible off the kerb with the rear
wheels. You will feel more secure if you can lean forward,
but if you can’t, don’t worry, the wheelchair is extremely
stable. As long as you stay within its limitation, you will be
quite safe.
• Thefrontofthechairwillnaturallyfollowdownthekerbas
you continue to drive slowly backwards.
• We recommend to use the lap strap to feel more secure
during declining the kerb
Salsa M (MWD)
•Move the chair slowly and carefully in a forward direction un-
til both front wheels are on the edge
of the kerb, again in a 90° position to
the kerb. (Fig 7 and Fig 8)
•Drive as slowly as possible off the
kerb with the drive wheels. Don’t stop
the chair durin declining the kerb.
You will feel more secure if you can
lean bac wards, but if you can’t, don’t
worry,
the wheelchair is extremely stable. As
long as you stay within its limitation,
you will be quite safe.
•The rear of the chair will naturally follow down the kerb as
you continue to drive slowly forwards.
•All powered seating options need to be in home position.
Your powered legrests may need to be adjusted to give
enough clearance to mount or dismount the kerb.
•We recommend to use the lap strap to feel more secure dur-
ingdecliningthekerb.Forextraprotectionwerecommendtot
every chair with the legrests.
4.30.3 Kerb climber tting and removal
procedure
(RWD base only)
• Locatethekerbclimber bar
into the left hand location
bracket and push it into the
right hand receiver bracket
(Fig. 10 & Fig 11).
• Hold the kerb climber with
your left hand in the receiver
bracket.
• Align the holes of the
receiver bracket and the
kerb climber tube and plug
in the locking pin from the
top.
• Reversetheproceduretoremovethekerbclimber.
Warnings
1. Please show the utmost consideration for the other traffic
on the road. Remember that the last thing a car or lorry driver
expects to see is a wheelchair backing off the kerb into the road.
If in any doubt, do not risk crossing the road until you are certain
that it is safe.
2. Always cross the road as quickly as possible; there may be
other traffic.
3. Do not attempt to go up or down more than a 10 cm (4”) high
kerb (Salsa only with kerb climber fitted).
4. Do not attempt to use the kerb climber on a series of steps.
5. Do not attempt kerbs if on steep slopes or cambers.
6. Do not attempt any kerbs in the vicinity of drain covers,
uneven or gritty road surfaces.
7. You should not attempt to dismount a kerb any higher than 5
cm (2”) in the forwards direction.
8. Do not mount or dismount kerbs at an angle other than straight
on (90 degrees) to the edge of the kerb.
9. Prior to climbing ensure your legrests will clear the
kerb.
10. Take care of the anti-tips which
might interfere with the kerb or the
ground when mounting or dismounting
a kerb.
WARNING - This wheelchair
is designed to be repaired and
assembled by a Sunrise Medical
authorised dealer and not the end
user. The end user has to disassemble
and assemble the chair only for
transportation (see section 5.2).
Fig. 7 Fig. 8
Fig. 11
Fig. 10
Fig. 9
Fig. 12

Quickie SALSA 13
ENGLISH
4.31 Lap belt
The lap belt kit. (Fig. 13).
Fastening the lap strap.
Insert the 3 prong male buckle
into the female buckle until a
click is heard (Fig. 14)
To fit the lap strap.
Place the strap loosely across
the seat with the buckle closed..
(Fig. 15)
Pass the other ends of the strap
through the gap between the
backrest posts and the backrest
upholstery as shown. (Fig. 16)
Ensure that the adjusters &
buckles can be accessed & the
strap is not twisted. Fit the eyelet
over the rearmost bolt. Fit the
plain washer, sprung washer
& nut. Tighten with a 13.0mm
spanner. Repeat for the other
side. (Fig 17)
Ensure that the lap strap is tight
enough to provide comfortable
support. A simple measure is to
keep a hands thickness between
the body and lap strap. For
safety, check the tension on the
lap strap at least once day. (Fig
18)
Generally, the lap belt should be
fixed so that the straps sit at an
angle of approximately 45° (Fig.
19), and when correctly adjusted
should not allow the user to slip
down in the seat.
Warning - Always make sure that the lap
strap is correctly secured and adjusted
prior to use.
A loose strap could cause the user to slip
down and cause serious injury.
Check lap strap and securing components
at regular intervals for any signs of fray
or damage. Replace if necessary
When servicing, check for correct
operation of the release buckle and for any signs of wear on the
material or plastic brackets
4.32 VR2 Controller (Fig. 20)
Avoid knocking your control system and especially the joystick.
Be careful not to strike obstacles with the control system or
joystick when you drive. Never drop the control system.
When transporting your wheelchair, make sure that the control
system is well protected. Avoid damage to cables.
To improve the reliability of the control system keep exposure to
extreme conditions to a minimum.
Do not expose your control system or its components to damp for
prolonged periods. If your control system becomes contaminated
with food or drink clean it off as soon as possible.
Controller precautions for use
In the event of the wheelchair moving in an unexpected way
RELEASE THE JOYSTICK. This action will stop the wheelchair
under any circumstances
Do not operate the control system if the wheelchair behaves
erratically or shows abnormal signs of heating, sparks or smoke.
Turn the control system off at once and consult your Sunrise
Medical Authorised Dealer.
Fig. 13
Fig. 14
Fig. 15
Fig. 16
Fig. 19
Battery Level Indicator On/Off Button
Horn
Speed Indicator
Speed Buttons
Joystick
Fig. 17
Fig. 18
Fig. 20

14 Quickie SALSA
ENGLISH
5 Preparing your wheelchair for use
5.1 Handling the wheelchair
Note: To dismantle the chair for transport or storage no tools are
required.
List of components when dismantled (components below are
related to the maximum detachable parts and dependent on the
type of seating system chosen):
1 pair of armrests
1 pair of legrests,
1 backrest (Std. Rehab/comfort seat only)
1 drive unit with seat frame
5.2 Preparation for transportation or storage
First remove the legrests if swing away legrests are attached.
Leave the armrests in the fold down position. (Fig.21,23)
disconnect the Hand Control,
(Fig.22), if necessary. Release
and lift off the backrest at the
frame. Now you can store the
chassis part. By releasing the
freewheel mechanism on the left
and right side of the chassis you
can move the drive unit as close
as possible to the place you want
to store it.
You can also drive the base
with the joystick up or down a
ramp into and out of a car for
transportation. Make sure,
when the chair is stored or left
in the car or anywhere else, the
controller is switched off and
the freewheel mechanisms
are engaged.
If there is a need to lift the drive
unit the big side frame tubes
should be used. Caution
should be taken if the chair
is in freewheel.
To remove the control pod.
To remove the control pod
you have to access the
motor controller through the
plastic cover between the
castor wheels and remove
the square remote control connector.
Place the control pod & arm in a safe place until required.
To reconnect the hand control just use the process in reverse.
5.3 Re-Assembling
Replace the backrest into the receivers and tighten the lever
screws carefully. If required reconnect the remote controller.
Attach the hangers. Make sure your
freewheel mechanisms are engaged.
Now you are ready to drive the chair.
WARNING - Never lift the wheelchair by
the armrests or the leg rests, since they
are detachable and harm could be done
to the user or to the wheelchair.
5.4 Brake release
(Fig. 24+25) By pulling the release levers on both sides of the
base into the up position the brakes are released from the
motors.
(Fig. 24a, 25a) By rotating the red lever outwards on both sides
of the motor the brakes are released from the motors.
Please ensure the controller is switched off before you engage
the freewheel levers – Failure to do so will increase the force
needed to push the chair.
This may only be used in an
emergency, or if you need to
manually push your wheelchair. It
is not intended for permanent use
or to push the wheelchair up/down
a slope with the user sitting in it.
Note: The chair’s automatic
braking system will not work
unless the brake release levers
are in the “drive” or down position.
WARNING - Motor surfaces can
be hot after use. Be careful not
to touch the motor casing when
disengaging the freewheel.
WARNING - Never attempt
to disengage the freewheel
mechanism whilst sitting on a
slope.
WARNING - Always ensure the
freewheel levers are returned to
the down / drive position.
Emergency Freewheel device
NOTE:
Incaseyourpowerchairistted
with the Emergency freewheel
device the following instruction
applies:
When switched off the powerchair
remains immobile due to the posi-
tive locking action of the automatic electromagnetic brakes built
onto the motors.
If you need to move the powerchair without the use of battery
power then operate the brake release levers (Section 4.5 - Fig 1
& 2) as described in section x.
However if the force needed to push the powerchair to too high
for you to manage then the Emergency Freewheel device may
be used. It should only be used with a user in the powerchair
in Emergency situations as the automatic brakes will become
inoperable.
WARNING
The automatic brakes become inoperative when the Emergency
Freewheel (in rear wheel drive mechanism) is disengaged al-
lowing the power chair to run free if left on an inline.
There is an independent device in each wheel that have to be
disengaged separately. DO NOT disengage the Emergency
Freewheel devices if the powerchair is located on a slope.
Disengaging one side may result in the chair turning on the
slope and disengaging both may result in the chair rolling down
the slope.
DO NOT disengage both the Brake releases and
Emergency Freewheel devices at the same time.
Fig. 24
Fig. 25
Fig. 21
Fig. 22
Fig. 23
Fig. 25a
Fig. 24a
Fig. 25b

EASY 160, 160 HP 15
DEUTSCH
DO NOT switch on and operate the powerchair control
system whilst the Emergency freewheel is disengaged.
Always re-engage the drive mechanism on the rear wheels
when the chair is not being pushed.
To Disengage the Emergency freewheel pull out and push
over the operating cam lever –
see Fig A.
To Engage the Emergency
freewheel pull out and push
over the operating cam lever.
The drive and brakes will NOT
become operable until the
internal parts are re-aligned.
To re-align the part push the powerchair forwards or
backward in a straight line until the parts automatically
re-engage and the brakes comes on. The LH and RH side
may not re-engage at the same time so make sure that
both are re-engaged before turning the powerchair on.
5.5 Drive wheel suspension Salsa
The SALSA M/R has an
effective and adjustable drive
wheel suspension system as
a standard feature. To match
your requirements on drive
comfort, the tension of the
springs at the damper can be
adjusted.
Turning the aluminium ring
away from the spring will
soften your ride, adjusting the
aluminium ring in a position
towards the spring will harden
it. This option is to be used to
match the different user weights
to the suspension system. (Fig.
26/27). We recommend the
suspension adjustments are
done equally on the left and
right side of the chair.
5.6 Control joystick unit position
Make sure that the control system is mounted securely and
that the joystick position is correct. The hand or limb you use
to operate the joystick should be supported for example by the
arm pad.
Do not use the joystick as the sole support for your hand or limb
- wheelchair movements and bumps could upset your control.
The remote is mounted on a sliding mechanism which enables
the control to be moved forwards and backwards. When the
most comfortable position has been selected, secure the slider
by tightening the locking screw. Ensure the locking screw is fully
tightened prior to use and especially when transporting your
wheelchair.
Fig. 26
Fig. 27
ENGLISH
Fig. 25c

16 Groove
5.7 Getting ready to drive
• Operatetheon/offswitch.Thebatterygaugewillblinkthen
remain on after a second
• Checkthatthemaximumspeedissettoalevelwhichsuits
you.
• Pushthejoysticktocontrolthespeedanddirectionofthe
wheelchair
5.8 Armrests
5.8.1 Armrests-removing and replacing (Fig. 28)
The armrests on both sides of the wheelchair can be flipped up
to allow side transfer.
For side transfer flip the armrest all the
way up until it goes into its mechanical
stop. This frees your space for side
transfer.
To bring the armrests back into their
position flip it all the way down until it sits on its mechanical
stop. Guide it in its downward movement and do not let it fall on
its own.
5.8.2 Armrest Height Adjustment (Fig. 29 - 44)
The following section outlines armrest height adjustment. In the
case of either fine or gross adjustment, it is a two-part process:
PART I: Adjust the armrest height through rotation
PART II: Adjust armpad angle. (See section 5.8.3)
1. Basic fine adjustment (up to one inch) of the armrest height
can be achieved using the 5mm fine height adjustment screw
(Fig. 31,B). To fine tune the armrest’s height:
• Firstloosenthe6mmrotationboltsonbotharmrests(A).
• Turntheadjustmentscrews(B)counter-clockwisetoraise
the armrest or clockwise to lower.
• Retightenbothrotationbolts(A).
(Use 20 N/m or 177 in/lb of torque.)
Refer to armpad realignment if desired armrest height is
achieved.(Fig. 30)
NOTE– The fine-tune adjustment screws provide up to one
inch of armrest height adjustment. For more than one inch of
height adjustment, continue to Number 2. Each armrest can
also be adjusted independently for individuals who require an
asymmetrical configuration.
NOTE– The factory preset is 10” from the seat pan to the top of
the armpads.
PART 1: ARMREST HEIGHT ADJUSTMENT
2. To achieve more than one inch of adjustment, remove the
6mm armrest rotation bolts on both sides of the seat.
3. Remove both armrest assemblies. (Fig 32,33)
4. Remove both sets of 4mm armrest adjustment ring bolts.
(Fig.34)
5. Rotate the armrest height adjustment rings to match the
desired height designated in the Configuration Chart. (Fig.35)
6. Replace both sets of armrest adjustment ring bolts according
to the configuration chart. (Fig.36,37)
(Use 10 N/m or 88.5in/lb of torque.)
7. Replace both armrest assemblies. (Fig.38)
Fig. 28
Fig. 29
Fig. 30
Fig. 31
Fig. 32
Fig. 33
Fig. 34
Fig. 35

Quickie SALSA 17
ENGLISH
8. Replace the armrest pivot bolts on both sides of the seat.
Do not tighten completely. (Fig.39)
PART II: ARMPAD ANGLE ADJUSTMENT
9. Loosen the 4mm armpad angle pivot bolts (A) on both
armrests. Remove the 4mm angle index bolts (B) on both
armrests.
10. Use the 5mm fine height adjustment screw (C) to finish fine
tuning the height. Turn counter-clockwise to increase height or
clockwise to lower.
11. Tilt both armpads down (or up in the case of a lowered
armrest) until the armpads are in the preferred angle. Check
to see if the height is correct. (Refer to Number 10 for further
height adjustment.)
12. Retighten both armrest pivot bolts. (Use 20 N/m or 177 in/lb
of torque.)
13. Retighten both armpad angle pivot bolts (A). Replace both
armpad angle index bolts (B). (Use 10 N/m or 88.5 in/lb of torque
for both sets of bolts.)
Fig. 36
Fig. 37
Fig. 38
Fig. 39
Fig. 40
Fig. 41
Fig. 42
Fig. 43

18 Quickie SALSA
ENGLISH
5.8.3 Armpad Position Adjustment (Fig. 45 - 48)
1. Fine armpad position adjustments (one to two inches) are
possible by loosening the 4mm armpad adjustment bolts (E)
and sliding the armpad forward or backward as required.
Access to the rear adjustment bolt may require pivoting the
armpad
NOTE– If more than one to two inches of adjustment is required,
refer to chart below and continue to Number 3.
2. Retighten both adjustment bolts (E). (Use 10 N/m or 88.5 in/
lb of torque.)
3. For larger adjustments, remove both sets of armpad
adjustment bolts.
4. Slide both armpads to the next set of attachment holes
(refer to the chart). Retighten both sets of armpad adjustment
bolts. (Use 10 N/m or 88.5 in/lb of torque.)
5.9 Legrests
WARNING - Be aware of your environment to make sure you
Fig. 44
Fig. 45
Fig. 46
Fig. 47
Fig. 48

Quickie SALSA 19
ENGLISH
do not injure your legs when legrests are extended.
WARNING - Always ensure that the legrests or footplates do not
come into contact with the castors before driving the wheelchair.
WARNING - Legrests are not to be used for lifting or carrying the
wheelchair with an occupant.
5.9.1 Fitting legrest
Offer the legrest assembly at right angles to the frame (Fig. 51),
locate the stem into the legrest and swing the assembly forward
to lock in position. To swing away the footrest, depress
the retaining catch and turn the footrest out. This can
now be lifted out if required, (Fig. 50).
5.9.2
Footplates
The footplates may be
flipped up to aid entry and exit
from the chair.
WARNING - Do not use the footplates to stand on as the full
weight of your body may cause the chair to tip forwards. This
could result in injury and could damage the footrests.
5.9.3 Adjusting the footrest length
To adjust the footrest length remove the screw assembly on the
footrest stem as shown in (Fig. 52), adjust the length to suit.
Ensure the bolts are firmly located and tightened prior to use.
Note: The internal footrest stem may require cutting down in
length to allow the footplate position to be raised.
5.9.4 Hanger depth adjustment (Fig. 53 - 55)
1. Remove both sets of 5mm hanger depth adjustment bolts.
2. Slide both hanger receivers to the desired location. See bolt
pattern seat depth position settings (B)
3. Replace both sets of depth adjustment bolts. (Use 20 N/m
or 177 in/lb of torque.)
Fig. 50 Fig. 51
Screws
Fig. 52
Fig. 53
Fig. 54
Fig. 55

20 Quickie SALSA
ENGLISH
5.9.5 Manual Articulating / Elevating Legrest (ALR/
ELR)
To elevate:
Pull the legrest upwards and stop at the desired height. The
legrest will automatically lock in the chosen position.
To lower:
Push the release lever slowly forward. The legrest will lower
the angle. As soon as you release the lever, the legrest will be
locked in the current position.
WARNING - Keep hands clear of the adjustment mechanism
between the frame and the movable parts of the legrest while
elevating or lowering the legrest.
5.9.6 Powered Elevating or Articulating Legrest
(Fig. 56)
Note: Both legrests can be operated simultaneously.
VR2 Control:
The actuator buttons can operate any factory approved actuator.
Operation is dependent on what options are fitted to your
wheelchair. To operate the legrests, seat tilt, seat lift or back
rest recline.
• Pushoneoftheactuatorbuttonsthathastheseaticononit
to select actuator mode
• Operate the joystick left or right to select the actuator
required (actuator 1 or actuator 2). Selection is indicated via
the lighting of the red LED adjacent to the desired actuator
button.
• Operatethejoystickintheforwardorrearwarddirectionto
move the leg rest/seat lift/tilt or recline up or down.
• Releasethejoystickwhenthedesiredangleisreached.
• To return to drive mode press the actuator button again.
(Fig 57)
Once the legrest is fully lifted or in its lowest position do not hold
the joystick in its operating position as this could damage the
actuator.
Quickie Direct Actuator Control Box:
The direct actuator switches can operate any factory approved
actuator. Operation is dependent on what options are fitted
to your wheelchair. To operate the legrest, seat tilt, seat lift or
backrest recline;
• Push the toggle switch for the relevant actuator forward
until you reach the required angle/height.
• Releasethetoggleswitchandtheactuatorwillstop.
When the actuator reaches its maximum/minimum position do
not hold the toggle switch in its operating position as this could
damage the actuator. (Fig. 58)
Fig. 57
Fig. 58
Fig. 56
