Stealth Products ADI Q-Back 2.0 User manual

Backs &
Support
Q-Back 2.0
Owner’s Manual - Maintenance Guide
Q-Back 2.0, AL and AFT Series

i
Table of Contents
Customer Satisfaction ..................................................................... ii
Important Information.............................................................. iii-iv
Warranty ..................................................................................................... iii
Supplier Reference.................................................................................. iii
Warning Labels......................................................................................... iv
Limited Liability........................................................................................ iv
Testing ......................................................................................................... iv
Parts and Accessories ...................................................................... 1
Tools Required for Installation and Adjustment .......................... 1
Parts List....................................................................................................... 1
Design and Function ........................................................................ 2
Intended Use.............................................................................................. 2
Contours and Proles............................................................................. 2
Available Sizes ........................................................................................... 2
Installation Instructions .................................................................. 3
Q-Back 2.0 Installation Instructions .................................................. 3
Contour Support Adjustment Instructions..................................... 3
WC20 Information ....................................................................... 4-8
WC20 Hardware........................................................................................ 4
Before Transit............................................................................................. 4
Belt Placement........................................................................................... 5
Trays............................................................................................................... 7
User Safety.................................................................................................. 7
First-Time Use................................................................................... 9
Dealer Assistance ..................................................................................... 9
User Assistance ......................................................................................... 9
Conditions of Use .................................................................................... 9
Care and Maintenance...................................................................10
Cleaning.....................................................................................................10
Disinfection...............................................................................................10

ii
Customer Satisfaction
Stealth Products is committed to 100% customer satisfaction. Your complete
satisfaction is important to us. Please contact us with feedback or suggestions to
help us improve the quality and usability of our products.
You may reach us at:
Stealth Products, LLC
104 John Kelly Drive
Burnet, TX 78611
Phone: [phone] Toll Free: [phone]
Fax: [phone] Toll Free: [phone]
[email protected]
www.stealthproducts.com
MDSS GmbH
Schigraben 41
30175 Hannover, Germany
General
Read and understand all instructions prior to the use of the product. Failure to
adhere to instructions and warnings in this document may result in property
damage, injury, or death. Product misuse or failure to follow instructions will
void the warranty.
Immediately discontinue use if any function is compromised, if parts are missing
or loose, or if any component shows signs of excessive wear. Consult with your
supplier for repair, adjustment, or replacement.
All persons responsible for fitting, adjustment, and daily use of the devices
discussed in the these instructions must be familiar with and understand all
safety aspects of the devices mentioned. In order for our products to be used
successfully, you must read and understand all instructions and warnings, and
maintain our products according to our instructions on care and maintenance.
The installation instructions will guide you through this product’s options and
possibilities.
Instructions are written with the expressed intent of use with standard
congurations. They also contain important safety and maintenance
information, as well as describe possible problems that can arise during use. For
further assistance, or more advanced applications, please contact your supplier
or Stealth Products at [phone] or toll free at [phone].
Always keep the operating instructions in a safe place so they may be referenced
as necessary.
All information, pictures, illustrations, and specications are based on the product
information that was available at the time of printing. Pictures and illustrations
shown in these instructions are representative examples and are not intended to
be exact depictions of the various parts of the product.

iii
Important Information
CAUTION
These products are designed to be tted, applied, and
installed exclusively by a healthcare professional trained for
these purposes. The tting, application, and installation by a
non-qualied individual could result in serious injury.
Warranty
Our products are designed, manufactured, and produced to the highest of standards.
If any defect in material or workmanship is found, Stealth Products will repair or
replace the product at our discretion. Any implied warranty, including the implied
warranties of merchantability and tness for a particular purpose, shall not extend
beyond the duration of this warranty. Stealth Products does not warrant damage
due to, but not limited to: misuse, abuse, or misapplication of product, and/or
modication of product without written approval from Stealth Products, LLC. Any
alteration or lack of serial number, where applicable, will automatically void all
warranty.
Stealth Products, LLC is liable for replacement parts only. Stealth Products, LLC
is not liable for any incurred labor costs.
Stealth Products warrants against failure due to defective materials or
workmanship:
Covers: 2 years
Hardware: 5 years
Electronics: 3 years
In the event of a product failure covered by our warranty, please follow the
procedures outlined below:
Call Stealth Products at [phone] or toll free at [phone].
Request a Return Authorization (RA) form from the Returns Department and follow
the documentation instructions.
Additional warranty information may be found by visiting the website at https://
stlpro.site/returns-n-warranty. Copies of this manual may be downloaded by
accessing the Stealth website (https://stlpro.site/stealth-docs) and searching “Q-
Back 2.0” in the search bar at the top of the page.
Supplier Reference
Supplier:
Telephone:
Address:
Purchase Date:
Model:
NOTICE
Any substitutions of supplied hardware void the warranty.
Misuse of items and "acts of nature" (e.g., ood, tornado)
are not covered by the warranty.

iv
Important Information
Warning Labels
Warnings are included for the safety of the user, client, operator, and property.
Please read and understand what the signal words DANGER,WARNING,
CAUTION,NOTICE, and SAFETY mean, and how they could aect the user, those
around the user, and property.
Limited Liability
Stealth Products, LLC accepts no liability for personal injury or damage to property
that may arise from the failure of the user or other persons to follow the
recommendations, warnings, and instructions in this manual.
Stealth Products does not hold responsibility for nal integration of nal assembly
of product to end user. Stealth Products is not liable for user death or injury.
Testing
Initial setup and driving should be done in an open area free of obstacles until the
user is fully capable of driving safely.
CAUTION Identies a potential situation which, if not avoided, may result
in minor to moderate injury and property damage.
WARNING Identies a potential situation which, if not avoided, may result
in severe injury,death, and property damage.
DANGER Identies an imminent situation which, if not avoided, may
result in severe injury,death, and property damage.
NOTICE Identies important information not related to injury, but
possible property damage.
SAFETY
Indicates steps or instructions for safe practices, reminders of
safe procedures, or important safety equipment that may be
necessary.
