EC Series Crane Manual Revisions

Tabl of Cont nts $
Table of Contents
Introduction..........................................................................................................................ii
Chapter 1 - Operation ......................................................................................................1
General Operation.............................................................................................................1
Pre-Operation Inspection ..................................................................................................1
Job Site Setup .....................................................................................................................2
Step 1: Disengage drive axle and set the parking brake. ............................................2
Step 2: Turn on power to the crane. ................................................................................2
Step 3: Position the stabilizers............................................................................................3
Step 4: Operate the crane................................................................................................3
Step 5: Stow the crane. .....................................................................................................5
Step 6: Stow the stabilizers.................................................................................................5
Step 7: Release the parking brake...................................................................................5
Radio Remote Control eatures .......................................................................................6
Radio Remote Control unctions .....................................................................................7
Wire Rope/Sheave Configurations...................................................................................8
Safety Decals of Note........................................................................................................9
Basic Crane Maintenance Schedule.............................................................................13
General Maintenance Guidelines..................................................................................13
Chapter 2 - Maintenance...............................................................................................13
Recharging the Auxiliary Battery ....................................................................................14
Hydraulic Oil Maintenance .............................................................................................14
Washing the Crane ..........................................................................................................14
Wire Rope Maintenance .................................................................................................14
Winch Maintenance ........................................................................................................14
Extension Boom Maintenance........................................................................................14
Rotation Gear Bearing Maintenance............................................................................15
Gear-Bearing Bolt Maintenance ....................................................................................16
Rotation Gear Bearing Thread Tightening Procedure.................................................16
Torque Data Chart ...........................................................................................................17
Rotation Gear Bearing Tilt Test ........................................................................................18
Rotation Gear Bearing Worm End Play & Backlash .....................................................19
Lubrication Recommendations ......................................................................................20
Chapter 3 - Troubleshooting ..........................................................................................21
Crane Hoist Troubleshooting ...........................................................................................23
5 unction Hetronic Radio Remote Troubleshooting ...................................................24
Transmitter Troubleshooting.............................................................................................25
Receiver Troubleshooting ................................................................................................25
Manual Operation............................................................................................................26
For Technical Questions, Information, Parts, or Warranty, Call Toll-Free at
800-321-3741
Hours: Monday - riday, 8:00 a.m. - 5:00 p.m. CST
or email at the following addresses:
Technical Questions, and Information [email protected]
Order Parts [email protected]
Warranty Information [email protected]

$$ St llar® EC S ri s Cran Own r’s Manual
Stellar®Cranes are designed to provide safe and dependable service for a variety of
operations. With proper use and maintenance, these cranes will operate at peak
performance for many years.
To promote this longevity, carefully study the information contained in this manual before
putting the equipment into service. Though it is not intended to be a training manual for
beginners, this manual should provide solid guidelines for the safe and proper usage of the
crane.
Once you feel comfortable with the material contained in this manual, strive to exercise
your knowledge as you safely operate and maintain the crane. This process is vital to the
proper use of the unit.
A few notes on this manual:
A copy of this manual is provided with every crane and can be found in the hard plastic
manual case that is installed on the chassis. A copy of this manual shall remain with the
crane at all times.
Throughout the manual, three signal words will be used to bring attention to important
items:
A NOTICE signal word indicates a practice not related to physical injury.
A WARNING signal word indicates a hazardous situation which, if not
avoided, could result in death or serious injury.
A DANGER signal word indicates a hazardous situation which, if not
avoided, will result in death or serious injury.
Information contained within this manual does not cover all maintenance, operating, or
repair instructions pertinent to all possible situations. Please be aware that some sections of
this manual contain information pertaining to Stellar®manufactured cranes in general and
may or may not apply to your specific model.
This manual is not binding. Stellar Industries, Inc. reserves the right to change, at any time,
any or all of the items, components, and parts deemed necessary for product
improvement or commercial/production purposes. This right is kept with no requirement or
obligation for immediate mandatory updating of this manual.
In closing:
If more information is required or technical assistance is needed, or if you feel that any
part of this manual is unclear or incorrect, please contact the Stellar Customer Service
Department by phone at 800-321-3741 or email at [email protected].
Introduction
WARNING
DANGER
NOTICE

Op ration 
Before operating the equipment, make sure all regular maintenance has been performed.
Each day, inspect the crane for all of the following:
• Vehicle for standard checks such as proper tire inflation and fluid levels.
• Parking brake operation.
• Hydraulic reservoir for proper oil level.
• Hoses and gearboxes for evidence of oil leaks.
• Crane controls for excessive wear, cleanliness and proper operation.
• Operational aids such as decals for placement and legibility.
• All securing hardware such as cotter pins, snap rings, hairpins, and pin keepers for proper
installation.
• Crane hook and other loose parts for damage to structures or weld.
• Anti-two block switch for proper function.
• Wire rope for broken wires, extensive wear, distortion, and heat damage.
• All safety guards for proper installation.
• Auxiliary crane battery (If used) for adequate charge. See Chapter 2: Maintenance for
Pre-Operation Inspection
It is the responsibility of the owner to instruct the operator in the safe operation of the
equipment and to provide the operator with properly maintained equipment.
Stellar®Crane operators must conform to the qualifications specified in
ANSI B30.5 - Chapt r 5-3 Op ration. Trainees or untrained persons shall be under the
direct supervision of qualified persons.
Operators shall consult with the owner of the equipment regarding current safety
regulations and required personal protective equipment.
Please take note that Stellar Industries, Inc. is not liable for accidents incurred by the crane
because of non-fulfillment from the operator’s side of current rules, laws, and regulations.
General Operation
WARNING
Safety should be the n umber one thought on every operator’s mind. Three factors should
exist for safe operation: a qualified operator, well-maintained equipment, and the proper
use of this equipment.
This chapter contains information regarding the safety and operation of Stellar®
manufactured EC Series Telescopic Cranes and should be read and understood
completely by everyone working with or near the crane before putting the unit into
operation.
ailure to follow operating, maintenance, or safety instructions can
result in death or serious injury.
Chapter 1 - Operation
WARNING

St llar® EC S ri s Cran Own r’s Manual
The drive axle must be disengaged and the parking brake must be set before operating
any of the equipment.
To initiate electrical power to the crane, activate the button labeled ‘Main Power’, usually
located in the cab of the truck.
Step 2: Turn on power to the crane.
Step 1: Disengage drive axle and set the parking brake.
Thoroughly plan the lift by understanding the work site area and your loads before
positioning the vehicle. or a complete and detailed description of job site setup, please
refer to the AEM Safety Manual ( orm C-70-2). Consider the following:
• The vehicle should be positioned in an area free from bystanders and overhead
obstructions. Use a signal person if necessary.
• Always maintain safe clearance from high voltage power lines in
accordance with ANSI B30.5: 5-3.4.5 Op rating N ar El ctric Pow r Lin s. Death or
serious injury will result from inadequate clearance if crane, load, or vehicle becomes
electrically charged.
• Make certain that the vehicle is parked on stable, flat ground as close to the job as
possible. The surface under the service truck must be able to support the weight of the
machine and its load.
• Use wheel chocks if parking the vehicle on a slope.
•Always park the vehicle with the grade. If cross-grade parking is required, the load
capacity must be decreased appropriately to mitigate tipping risk.
• Do not operate the crane during electrical storms.
• In dusty work areas, every effort must be taken to keep dust and sand out of the moving
parts of the machinery.
• In high humidity work areas, keep parts as dry as possible and well lubricated.
Job Site Setup
DANGER
WARNING
auxiliary battery recharge instructions.
Replace/repair as necessary prior to operation. or a more detailed checklist of
scheduled inspection points, refer to the Stellar®Crane Inspection Log. This document is
an essential guide for the daily, monthly, quarterly and annual inspection tasks that will
help maintain the quality of your Stellar product.

Op ration 
Step 4: Operate the crane.
Operators should have a firm understanding of ANSI B30.5 - S ction 5-3.2 Op rating
Practic s and AEM Saf ty Manual (Form C-70-2) prior to operating of the crane.
The truck should always remain running while operating the crane to
maintain battery charge. Stellar recommends the use of an auxiliary battery when
operating the crane indoors or in an environment that prevents to the truck from running.
Using the Radio Remote:
To operate the crane using the radio remote control, activate the desired toggle function.
The radio remote allows for simultaneous functions. With practice, it is possible to use more
than one toggle at the same time (Extension Out/Winch Down for example). See the
Radio Remote Control unctions and eatures pages later in this chapter for more
information.
Unstowing the Crane:
To unstow the crane and prepare it for a lift:
• Winch down slightly.
• Raise the boom high enough to clear the boom rest and any other obstructions from the
chassis.
• Rotate the crane until it clears the side of the truck body.
• Lower the crane boom down far enough so that the snatch block is within comfortable
reach.
• Winch down to create slack in the wire rope and unhook the snatch block.
NOTICE
Lower the stabilizer(s) using the hand crank located at the rear of the truck.
Keep clear of stabilizer legs during operation. Moving stabilizers can
cause serious crushing injuries. Make certain that all personnel are clear of the stabilizer
and the ground contact point before operating.
Do not raise the rear tires of the truck off the ground with the stabilizers.
Confirm that the stabilizers are positioned on stable, flat ground and that the truck is as
level as possible both front to rear and side to side. Use stabilizer pads to ensure the
proper distribution of weight.
Step 3: Position the stabilizers.
WARNING
WARNING

St llar® EC S ri s Cran Own r’s Manual
Attaching the load:
• Position the crane with the hook centered directly over the load avoid side loading.
• Attach the load to the hook by means of slings or other approved devices.
Never use a sling bar or anything larger than the hook throat that
could prevent the hook latch from closing. This would negate the safety feature.
• Maintain a minimum of 3 full wraps of wire rope on the winch drum at all times.
Do not wrap the wire rope around the load.
Lifting the load:
Lift the load slightly off the ground to check the safety of the cargo. Consider the
following:
• Make certain that the stabilizers are positioned on flat, stable ground.
• Never exceed manufacturer’s load charts and ratings. These ratings
are based on the machine’s hydraulic, mechanical, and structural design rather than
stability.
• It is the responsibility of the operator to know the weight of both the rigging and the
handled load to avoid overloading the crane. Do not rely on the overload device to
determine maximum rated loads. If the crane is picking more than the maximum rated
load, the overload protection device may be malfunctioning. Discontinue use
immediately and contact Stellar Customer Service for support.
• Do not use a crane to lift personnel.
• Do not attempt to lift fixed loads.
Moving the load:
Ensure that the load is secure and balanced within the sling before moving. Consider the
following:
• Be sure that the crane is level and stable before moving the load.
• Always look for any changes to the surroundings since the job site setup. Be aware of
any new or missed overhead obstructions (branches, power lines, etc) and bystanders.
Use a signal person if necessary.
• Never operate the crane with personnel under any part the boom or
load. Do not extend or rotate a load over anyone. Never allow personnel to place
themselves under any part of the boom or load.
• Never leave a crane load suspended or unattended.
WARNING
WARNING
WARNING
WARNING
WARNING
WARNING

Op ration 
Once you have performed your lift and are ready to shut down the work site:
• Retract all extensions.
• Winch up to bring the snatch block within 3 feet of the boom tip.
• Lower the crane boom down far enough so that the snatch block is within comfortable
reach.
• Hook the snatch block to the stow hook on the main boom. Maintain control to avoid
personal injury or damage to any equipment.
Never use the stow hook for anything other than stowing the snatch
block.
• Tighten the winch line so that the snatch block comes within a few inches of the main
boom. Avoid activating the anti-two block switch when tightening slack.
• Raise the boom slightly above the boom rest.
• Rotate the boom counter-clockwise until it aligns with the boom rest.
• Lower the boom gently into the boom rest.
• Store the radio remote control, preferably in the cab of the truck.
After stowing the crane, return to the stabilizer crank and fully retract the stabilizer(s).
The parking brake must be released before moving the truck.
Make certain that any air tanks are completely drained before moving
the truck.
• Do not use the boom or the winch to drag a load.
• Do not use the crane boom to push downward onto anything.
• Avoid sudden starts and stops when moving a load.
• Do not drag loads with the crane.
Step 7: Release the parking brake.
Step 6: Stow the stabilizers.
Step 5: Stow the crane.
WARNING
WARNING

St llar® EC S ri s Cran Own r’s Manual
Radio Remote Sleep Mode
The radio remote control enters sleep mode after about 15 seconds of inactivity. Activate
a toggle switch to re-link the transmitter to the receiver. After re-linking, activate the
desired toggle to continue operation.
E-Stop Button
The Radio remote control is equipped with an emergency stop button. If a situation arises
that requires the immediate stoppage of crane functionality, press down on the red
Emergency Stop button located in the center of the remote control.
The E-stop button is not intended to be an on/off switch. This is also the
first item to check if the crane is not responding to toggle and trigger activation. Make
sure the red E-Stop button is in the up or disengaged position.
Radio Remote Battery Replacement
Occasionally the batteries in the handheld transmitter will
need to be changed. The AA Alkaline batteries are
located in the handle portion of the radio transmitter.
Release the button and slide the battery holder out.
Replace the batteries and return the holder back into
the handheld transmitter until the button latches.
Radio Remote Backup Cord
If the handheld transmitter has a system problem that makes the radio function un-usable,
use of the back-up cord may be necessary.
Death or serious injury will result from touching tethered remote if the
crane, load, or vehicle becomes electrically charged. Always maintain safe clearance
from high voltage power sources.
1. Locate the backup control cord. Most likely it is in the crane compartment, or in the
cab behind the seat.
2. Remove the battery holder from the remote handle and
place the similar looking end of the back-up cord in the
bottom of the transmitter handle.
3. Attach the other end of the back-up cord to the connector
currently used by the antenna on the control receiver. The
control receiver is located on the back of the crane mast.
Radio Remote Control Features
DANGER
NOTICE

Op ration 
AB
CG
EF
Option1
Option2
Radio Remote Control Functions
A. E-Stop Button: Push in/down to immediately stop all crane functionality. Pull up/out to
restore functionality.
B. Option1/Option2: Provides signal for optional equipment
C. Boom Up/Down Toggle: Push up to raise the boom. Push down to lower the boom.
D. Extension In/Out Toggle: Push up to extend the extension. Push down to retract the
extension.
F. Winch Up/Down Toggle: Push up to raise the winch. Push down to lower the winch.
G. Rotate Clockwise/Counterclockwise: Push up to rotate the boom clockwise. Push
down to rotate the boom counterclockwise.

St llar® EC S ri s Cran Own r’s Manual
Standard 2-Part Line
Capacities as shown on load chart.
Single Part Line
1) Remove PIN “A” from boom tip.
2) Route wire rope through snatch block.
3) Pin wire rope to snatch block as shown with PIN “A”
PIN "A"
PIN "A"
Wire Rope/Sheave Configurations


Stabilizers
Safety decals serve to inform the viewer of the hazard type, how to avoid the hazard, and
the consequences of not avoiding the hazard.
Decals are considered safety equipment. They must be maintained, as would other safety
devices. All safety instruction plates, notices, load charts and any other decal applied to
the crane or service body must be kept legible and in good condition. Replace any
decals that are missing, damaged, or illegible.
Detailed below are a number of key safety decals related to this equipment. Use the
decal placement drawing in the Installation, Ass mbly Drawings, and Parts Manual to note
the actual location of the safety decals on the equipment.
Op ration 
WARNING
Crush Hazard
Keep clear of stabilizer legs during
operation.
Failure to keep clear of moving
stabilizer legs can result in death or
serious injury. C4795
Decal Part umber: C4795
Decal Location: Each stabilizer leg
Hazard Type: Crush Hazard
Consequences: Can result in death or serious injury.
Avoidance: Keep clear of stabilizer legs during
operation.
DANGER
Electrocution Hazard
Death or serious injury will result from inadequate
clearance if crane, load, or vehicle becomes electrically
charged.
0DLQWDLQVDIHFOHDUDQFHIURPKLJKYROWDJHSRZHUVRXUFHV
1HYHUDSSURDFKYHKLFOHRUORDGLIHTXLSPHQWLVQHDUD
KLJKYROWDJHSRZHUVRXUFH
C4545
Decal Part umber: C4545
Decal Location: our corners of the body/chassis
Hazard Type: Electrocution Hazard
Consequences: Will result in death or serious injury.
Avoidance: Maintain safe clearance from high
voltage power sources. Never approach vehicle
or load if equipment is near a high voltage
power source.
Body/Chassis
Safety Decals of ote

 St llar® EC S ri s Cran Own r’s Manual
Decal Part umber: 4186
Decal Location: Crane Compartment
Hazard Type: Electrocution Hazard
Consequences: Will result in death or serious injury.
Avoidance: Maintain safe clearance from high
voltage power sources.
DANGER
Death or serious injury will
result from touching tethered
remote if crane, load, or vehicle
becomes electrically charged.
Maintain safe clearance from
high voltage power sources.
Electrocution Hazard
4186
Decal Part umber: 4189
Decal Location: Crane Compartment
Hazard Type: Movement Hazard
Consequences: Can result in death or serious injury.
Avoidance: Do not exceed equipment load charts
and ratings.
Decal Part umber: 68024
Decal Location: Crane Compartment
Hazard Type: Untrained Operator Hazard
Consequences: Can result in death or serious injury.
Avoidance: Read and understand all manuals and
safety signs before operating or servicing
equipment.
WARNING
4189
Do not exceed equipment load charts and ratings.
Failure to follow equipment load charts and ratings
can result in death or serious injury.
Overload Hazard
WARNING
Read and understand all
manuals and safety signs
before operating or servicing
this equipment.
Failure to follow operating,
maintenance, or safety
instructions can result in
death or serious injury.
Untrained Operator Hazard
68024
Crane Compartment

Op ration 
Decal Part umber: 12452
Decal Location: Main Boom
Hazard Type: ree alling Boom Hazard
Consequences: Can result in death or serious injury.
Avoidance: Properly install retention pins prior to
operation. Do not stand in front of extension
when removing retention pin. Do not allow
extensions to free fall.
Decal Part umber: 12451
Decal Location: Main Boom
Hazard Type: all Hazard
Consequences: Can result in death or serious injury.
Avoidance: Never use the crane to hoist personnel.
Never ride the boom, hook, load, or any device
attached to the crane boom or load line.
Decal Part umber: 24712
Decal Location: Main Boom
Hazard Type: Misuse Hazard
Consequences: Can result in death or serious injury.
Avoidance: Do not use stow hook for any lifting
applications.
12452
WARNING
Free falling manual boom
extensions can result in death or
serious injury.
3URSHUO\LQVWDOOUHWHQWLRQSLQV
SULRUWRRSHUDWLRQ
'RQRWVWDQGLQIURQWRI
extension when removing
UHWHQWLRQSLQ
'RQRWDOORZH[WHQVLRQVWR
free fall.
Free Falling Boom Hazard
12451
WARNING
Hoisting personnel on boom,
hook, load, or loadline can result
in death or serious injury.
1HYHUXVHFUDQHWRKRLVW
personnel.
1HYHUULGHWKHERRPKRRN
ORDGRUDQ\GHYLFHDWWDFKHG
to crane boom or load line.
Fall Hazard
WARNING
24712
Do not use stow hook for any lifting applications.
Using the stow hook for anything other than hook
stowage can result in death or serious injury.
Misuse Hazard
DANGER
Electrocution Hazard
Death or serious injury will result from
inadequate clearance if crane, load,
or vehicle becomes electrically
charged.
0DLQWDLQVDIHFOHDUDQFHIURPKLJK
voltage power sources.
1HYHUDSSURDFKYHKLFOHRUORDGLI
equipment is near a high voltage
power source.
C1179
Decal Part umber: C1179
Decal Location: Main Boom
Hazard Type: Electrocution Hazard
Consequences: Will result in death or serious injury.
Avoidance: Maintain safe clearance from high
voltage power sources. Never approach vehicle
or load if equipment is near a high voltage
power source.
Main Boom

 St llar® EC S ri s Cran Own r’s Manual
Valve Bank
Main Cylinder
Decal Part umber: 25159
Decal Location: Valve Bank
Hazard Type: Movement Hazard
Consequences: Can result in death or serious injury.
Avoidance: After stowing the crane, always return
the valve bank manual overrides to the neutral
position.
Decal Part umber: 28256
Decal Location: Main Cylinder
Hazard Type: Overload Hazard
Consequences: Can result in death or serious injury.
Avoidance: Never tamper with the overload
device.
WARNING
25159
After stowing the crane, always return the valve
bank manual overrides to the neutral position.
Failure to return the manual overrides to the neutral
position can result in death or serious injury.
Movement Hazard
Decal Part umber: 12300
Decal Location: Crane Horse Head
Hazard Type: Misuse Hazard
Consequences: Can result in death or serious injury.
Avoidance: Never allow the hook block to contact
the boom tip by hoisting up, extending or
lowering the boom.
WARNING
Misuse Hazard
Two blocking the crane can result in death
or serious injury.
Never allow the hook block to contact the
boom tip by hoisting up, extending or
lowering the boom.
12300
Winch Pull
Boom Extending
Boom
Down
WARNING
28256
Overload Hazard
Bypassing the overload condition
by tampering with the overload
device can result in death or
serious injury.
Never tamper with overload
device.
Crane Horse Head

Maint nanc 
Before performing any maintenance to the crane, consider the following:
• Only qualified service personnel are to perform maintenance on the
crane. Never modify or alter any of the equipment, whether mechanical, electrical, or
hydraulic, without explicit approval from Stellar Industries.
• Position the crane where it will be out of the way of other operations or vehicles in the
area.
• Lower the boom fully or stow in the cradle to prevent uncontrolled movement.
• Place all controls in the off position and secure operating features from inadvertent
motion.
• Before any service or repair is performed, shut off the engine.
• Before performing any maintenance on electrical components, disconnect the power
source.
• Before performing any maintenance on hydraulic components, relieve hydraulic oil
pressure from all hydraulic circuits. Move pedals and control levers repeatedly through
their operating positions to relieve all pressures.
Chapter 2 - Maintenance
WARNING
General Maintenance Guidelines
Maintenance Operation Daily Weekly Monthly Hourly
Check hydraulic reservoir oil level. X
Grease rotation gear inner race bearings. X
Grease rotation gear worm drive bearings. 3 months
Grease rotation gear open gear teeth. X
Grease all cylinder pivot points. X
Lubricate extension booms. X
Check winch gear grease level. X
Drain and replace hydraulic oil. 6500
Tighten all hydraulic lines. 6 months
* or a more detailed outline of scheduled inspection points, refer to the Stellar® Crane Inspection Log. The
Stellar® Crane Inspection Log is an essential guide for the daily, monthly, quarterly and annual inspection
tasks that will help maintain the quality of your Stellar product.
Maintenance is an important part of extending the life of any Stellar®Telescopic Crane.
Performing key maintenance items on a scheduled program will prevent unnecessary
downtime.
Basic Crane Maintenance Schedule*

 St llar® EC S ri s Cran Own r’s Manual
While operating the crane, extend and retract the extension booms. If the extension
weldments are noisy during operation, it is necessary to lubricate the booms. Stellar®
Model Cranes feature a metal coating which will require an aerosol lubricant. Stellar
Industries recommends aerosol style lubricant Stellar PN 44512.
Extension Boom Maintenance
Refer to winch manual supplied with crane.
Winch Maintenance
Proper maintenance is key in ensuring a long lasting rope. Refer to ANSI B30.5 for details on
maintaining your wire rope.
Wire Rope Maintenance
Washing the Crane
Important: Prior to washing the Stellar crane, the radio remote receiver located on the
crane mast must be covered to prevent any water from entering the plastic housing.
Avoid any direct water pressure to the radio remote receiver.
Add hydraulic oil as needed. Stellar Industries recommends the hydraulic oil be changed
after 6,500 hours.
• Do not disconnect hydraulic hoses while there is still pressure in those
components.
• Replace parts with Stellar® approved parts only.
• Keep the crane and service body clean and free from grease build-up, oil and dirt to
prevent slippery conditions.
• Label or tag parts when disassembling.
• Immediately repair or have repaired any components found to be inadequate.
Hydraulic Oil Maintenance
Recharging the Auxiliary Battery
To recharge the auxiliary battery, engage the battery charge switch (located in the truck
cab or the crane box) while the truck is running. When operating the crane while the
truck is not running, disengage the battery charge switch to prevent the crane from
draining the main truck battery.
WARNING

Maint nanc 
Rotation Gear Bearing Maintenance
Rotation Worm Gear and Open Gear Teeth
Use a heavy Moly Lube grease (Stellar PN
4460) to lubricate the worm gear and open
gear teeth of the rotation bearing. Slowly
rotate the crane while pumping the grease
between the worm and rotation gear. This
should be greased every month or sooner
depending on the usage of the crane.
Another way of applying the grease would
be to remove the gear guard and brush the
Molube grease between the gear teeth of
the rotation bearing.
Do not lubricate the worm
and rotation gear teeth with EP2 grease. EP2
grease will wipe the Molube grease clean
causing excessive wear.
Worm Gear Bearings and Races
Apply three (3) pumps of EP2 grease to the
two grease zerks located on the side of the
Rotation Gear bearing; every three months.
After adding the EP2 grease, rotate the
crane fully.
Inner Gear Bearing Race
To lubricate the inner race of the large rota-
tion gear bearing, open the compartment
door just below the crane. The grease zerk
for the inner race bearing is located on the
compartment drip tray. The inner race will
need to be lubricated with EP2 Grease
weekly. The first week grease the inner race
bearing at the one (1), three (3), five (5),
seven (7), nine (9), and eleven (11) o’clock
positions. The following week, grease the
inner race bearing in the two (2), four (4), six
(6), eight (8), ten (10) and twelve (12)
o’clock positions. Rotate lubrication points
every week.
NOTICE

 St llar® EC S ri s Cran Own r’s Manual
Step 1: Refer to the Torque Data Chart on the previous page to determine the proper
torque value based on the size of bolt used.
Step 2: Torque all bolts to approximately 40% of the specified torque value using the
tightening sequence shown above. Note: The number of bolts may be different
than shown in the diagram but the sequence will work using the same pattern in
relation to Bolt #1.
Step 3: Torque all bolts to 75% of the specified torque value using the tightening sequence
shown above.
Step 4: Torque all bolts to the listed torque value using the tightening sequence shown
above.
Rotation Gear Bearing Thread Tightening Procedure
1
2
3
4
5
6
7
8
9
24
10
11
1213
14
15
16
17
18
19
20
21
22
23
Once a bolt has been torqued to 75% of its proof load and then removed, the torque
coefficient may no longer be the same as when the bolt was new thus giving
indeterminate damp loads after torquing.
Anytime a gear-bearing bolt is removed, it must be replaced with a
new bolt of the identical grade and size.
Always use Red Loctite Threadlocker sealant to secure the new bolt.
Gear-Bearing Bolt Maintenance
WARNING
NOTICE
