Stelrad ELECTRIC Series User manual

ALYNE

Stelrad
UIN Colour Height
mm
Length
mm
Heat output
Power (Watts) Btu/hr
Electric voltage -
Frequency
E02205800580 White 580 580 1000 3414 230V - 50Hz
E02205800820 White 580 820 1500 5121 230V - 50Hz
E02205800980 White 580 980 1800 6145 230V - 50Hz
ALYNE
CLASS 2
INSULATUION
2
Traffic
white
IN STOCK
YEAR WARRANTY
ELECTRIC
COMPONENTS
2
YEAR WARRANTY
HEATING
PARTS
5
ALUMINIUM
ELECTRIC RADIATORS
Integrated control panel
The colour coordinated digital touch screen control is located on the top right hand side of the radiator.
With numerous functions for efficiency, energy saving and safety in mind.
This product is LOT20 compliant.
The Alyne is an oil filled radiator made with slimline and compact vertical flat columns which stylishly
curve at the top. The Alyne is a fluid filled radiator which heats up by using an electrical element immersed
in thermodynamic oil inside. This maintenance free and specially formulated fluid is designed to distribute
the heat quickly and evenly across the radiator, which in turn emits the heat into your room through
radiation.
This aluminium radiator has a high heat transfer and a lower surface temperature, so it is practical, user-
friendly and ensures the maximum flexibility in terms of use. It is then an excellent solution when different
areas of the house have different temperature needs.
Installation
This radiator must be wall mounted and must not be installed immediately below or in front of a power socket or in contact with the wall
or floor. If installed within a bathroom, the radiator must be mounted outside zone 1 and the switch / electric control must be in zone 3.
For further information, please see the technical information pages.

Positioning and installing
•The appliance is designed to heat domestic rooms or similar. It must not be used for other purposes.
•The appliance must be used permanently mounted on a wall as described in the instructions.
•Install the appliance with the control panel at the top.
•In bathrooms (with bath or shower), install the appliance outside zone 1
•The appliance must be installed in such a way that the electronic controls and other control devices
may not be touched by someone in the bath or shower. The electronic controls and other control
devices must always be in zone 3. The appliance must not be connected with a plug.
•This product comes with a 900mm colour coordinated cable (no plug), so it can be spur wired to the
heating circuit.
•Respect the distances shown.
•Never install the appliance:
- immediately below or in front of a power socket or a junction box
- in contact with the wall or floor
- near curtains, flammable or combustible materials or pressure vessels
•Make sure there are no pipes or electric wires in the wall which could be damaged while mounting
the appliance.
•The appliance is equipped with a sensor which can detect an Open Window, if present above the
radiator or within the room. For a proper operation, it is strongly recommended to comply to the
installation directions reported in Ch. 4.3.1 before wall mounting.
•No need to maintain or service this product once installed. However, should any technical problems
arise, contact a qualified professional or your local dealer. All operations on the appliance must be
carried out by a qualified professional who before performing maintenance must make sure the
appliance is turned off, cold and disconnected from the household mains.
ALYNE
50
Zone2 Zone1
FIG. / ABB. 1
FIG. / ABB. 2
FIG. / ABB. 3 FIG. / ABB. 4
FIG. / ABB. 5 FIG. / ABB. 6 FIG. / ABB. 7
A L
I
B
EC D F G H
Zone 2 Zone 3
Dispositivo di comando
IT
Control device
GB
Dispositif de commande
FR
Control device
ELECTRIC RADIATORS

Electrical connection
•To be installed by a specialised engineer in accordance with the applicable standards in the country
concerned. When the appliance is installed, make sure the power is off and the mains switch is in the
“O“ position.
•The appliance requires a 230 V ~ 50 Hz power supply. Make sure the power line is appropriate for the
data shown on the appliance’s rating plate.
•Make sure the fixed power line is fitted with a disconnecting switch allowing the appliance to be
disconnected completely from the household mains, included the Pilot Wire, when present, in
accordance with the wiring rules.
•If the appliance is installed in a bathroom, the power line must be fitted with a 30 mA RCD (high
sensitivity residual current protection device). The power supply line and Pilot Wire control unit must be
protected by the same RCD. Permanently connected appliances must be connected using a connector
block placed within a proper junction box.
When installing the appliance in damp rooms (kitchen, bathroom), the point of connection with the
household mains must be at least 25 cm from the floor.
•If the Pilot Wire is not connected to the programming unit, it must be terminated and insulated. Under
no circumstances should the Pilot Wire be connected to the earth.
•Make sure the power cable cannot in any way come into contact with the surface of the appliance.
GB
14
15
3. POSITIONING AND INSTALLING
The appliance is designed to heat domestic rooms
or similar. It must not be used for other purposes.
The appliance must be used permanently mounted
on a wall as described in the instructions.
Install the
appliance with the thermostat at the bottom (Fig. 2).
In bathrooms (with bath or shower), install the ap-
pliance outside zone 1.
The appliance must be installed in such a way that
the electronic controls and other control devices
may not be touched by someone in the bath or
shower.
The appliance must not be connected
with a plug.
For radiators already tted with power
plugs, see the warnings on page 23.
Respect the distances shown in gures 3,4.
Never install the appliance:
– immediately below or in front of a power socket or
a junction box (Fig. 5)
– in contact with the wall or oor
– near curtains, ammable or combustible materials
or pressure vessels.
Make sure there are no pipes or electric wires in the
wall which could be damaged while mounting the
appliance.
2. GENERAL INFORMATION
Unpack the appliance carefully and rest it on the
polystyrene corner pieces or a carpet.
The package contains:
– the appliance
– mounting kit
– instructions
Read all the instructions carefully before installation
and use. Keep for future consultation.
Install and use the appliance as described in these
instructions only.
These instructions do not cover all situations which
might arise. Caution and common sense should be
applied when installing, operating and servicing the
appliance.
Modifying the characteristics of the appliance and
removing any xed component including the caps
is expressly prohibited. Make sure the appliance is
complete and undamaged. If damaged, do not use
the appliance, but contact your local dealer or a
qualied professional.
The materials used for packaging can be recy-
cled. You are therefore recommended to dispose
of them in special differentiated waste collection
containers.
A Brand/Manufacturer
B Model, type, category
C Bidimensional Code (QR)
D Protection class
E CE marking
F Double isolation
G Disposal procedures
H Quality marks
I
Voltage and Power
L Serial number
3.1 WALL MOUNTING
Make sure the screws and anchors included in the
mounting pack are suitable for the type of wall on
which you are mounting the appliance. If in doubt,
contact a qualied professional or your local dealer.
Follow the installation sequence shown on the
folding leaf of the cover (Scheme 1), respecting the
minimum distance between the bottom of the ra-
diator and the oor (Fig. 3).
During installation, make sure the power cable is
disconnected from the power line.
The technical specications of the appliance are indicat-
ed on the rating plate on the side of the radiator (Fig. 1).
1. SPECIFICATIONS OF THE APPLIANCE
Voltage: 230 V ~ 50 Hz
Insulation class: II
Protection class: IPx4
Table 1
The appliance is equipped with a sensor which can
detect an open window, if present above the radia-
tor or within the room. For a proper operation, it
is strongly recommended to comply to the instal-
lation directions reported in Ch. 4.3.2 before wall
mounting.
TYPE Power
[W]
Length
[cm]
Height
[cm]
Weight
[kg]
Rated current
[A]
GYA0610F
1000 56 58 12,3 4,5
GYA0915F
1500 80 58 18,7 6,5
GYA1118F
1800 96 58 22,3 8
ALYNE ELECTRIC RADIATORS

GB
16
USING THE RADIATOR FROM THE CONTROL PANEL:
Days of the Week
Operating
modes
Overdrive (2h)
Standby Mode
“-“ key “+“ key “Mode“
selection
key
ON/Standby
key
Chrono presets
Open Window
Children Safety
Holiday
Adaptive start
control
Keypad
Lock
Heating
element state
COMFORT
The “Comfort“ temperature corresponds to the
temperature desired by the user.
All “Pilot Wire“ commands are disabled.
4.1 ON/STANDBY MODE
In “Standby“ mode the LCD displays the Stan-
dby icon , the hour and day of the week.
All the operating modes are suspended (“Pilot
Wire“ included), but the appliance is powered
and waiting for command reception.
In stand-by mode, click the “+” button for 3 se-
cond on the screen to display: “FUNC” or “OFF”
or “RESET”.
With the “+” button, I can switch from one to
the other.
With “OK”, I enter in the desired mode.
To turn on or off the appliance, press the “Stan-
dby“ key. The radiator turns on in the previously
selected operating mode and emits a sound.
In “Chrono“ mode the display shows the time,
in the other modes the temperature setting is
displayed.
The entry into “Standby“ mode is signalled by
means of a double beep, the exit from “Stan-
dby“ mode by means of a long beep.
The display backlight stays on from 7 am to 9 pm.
Outside this hour it is necessary to press the display
to turn it on.
4.2 OPERATING MODES
The appliance provides 6 operating modes which allow the
user to heat the environment in the most suitable way with
respect to his needs.
Press the “Mode“ selection key to select the
desired operating mode. An icon on the LCD
will show the selected operating mode.
Pilot Wire Comfort
Night/Eco Anti-Freeze
Chrono Energy Saving
PILOT WIRE
The temperature depends on the “Pilot Wire“
command.
All “Pilot Wire“ commands are enabled.
Clock / Temperature set
point
“Open Window” key
Control Panel
Operating modes
Pilot Wire (n/a in the UK) Comfort Night / Eco Anti-freeze Chrono
Energy saving Standby
Functions
Adaptive Start Control Open window Child safety Override Holiday
Keypad lock Reset Changing set point
ALYNE ELECTRIC RADIATORS
