Stil-fit ERGOMETER PRO User manual

Instruction Manual
ERGOMETER PRO

Assembling the Cockpit
Step 2
Assemble the handle bar. We recommend to align
the handle bar parallel to the cockpit as shown in the
picture.

Adjustment of the quick release
To adjust the quick release, open the lever and
tighten the screw until the desired result is achieved.
When the quick release is fastened the saddle should
not turn. Attention: The saddle tube has a mark
-max-. This indicates the maximum possible height
of the saddle.
Adjustment of the saddle
The saddle can be adjusted horizontally and vertically.
To adjust the saddle, loose the screws at the bottom
and adjust the angle. Fix the saddle at the desired
position and tighten the screws again very strong.

Assembling of the transportation wheels
The transportation wheels can be mounted optionally
at the back of the frame.
Adjustable feet
Pedals
all types with standard thread
Seat
all standard types
Seat tube
tube size 31,8 mm

TRAININGS COMPUTER:

Training Screen
RPM
km/h
25
Pulse
WATT
Distance/ km
CAL
130
850
62
120
Level
30 min
12
2.0
12:20 +
-
Heart rate
RPM
Adjustment level
Back
Remaining time
Training level
Distance
Power
Calories
Speed
Home

Start Screen
Screen: Program selection
Quick Start allows you to
start immeditely with
program Manual
RPM
km/h
25
Pulse
WATT
Distance/ km
CAL
130
850
62
120
Level
30 min
12
2.0
12:20 +
-

Screen: Pre-selection
Screen: Data Base

Technical Data
Er
gometer PRO
C
ommercial induction brake system with built-in generator
50 - 400 watt
4,3“ touch screen monitor
2 cardio program
s
Manual mode - adjustable in 32 levels
W
att program - adjustable in steps of 5 watt
5 hill programs
PO
LAR pulse receiver Bluetooth smart
D
ata storage for 5 users
Languages: German, E
nglish, Spain, French
N
o external power supply necessary
W
eight 38 kg
T
ransportation rollers - optional installation
T
ablet holder
L/W/H: 115 x 50 x 120 cm

Make the most out of your training - the STIL-FIT Smart-Package
With the additional Smart-Package, you can unlock your ergometer for the
STIL-FIT App and various other Training Apps.
STIL-FIT APP
• set weekly goals and stay motivated
• track your performance development
• use your Apple Watch as a pulse sensor
• export your workout data to Apple Health and Google Fit
Compatibility with other training apps
With the Smart-Package, our STIL-FIT Ergometer PRO is fully compatible
with the training apps from Kinomap, Zwift, Rouvy and BKool.
Take advantage of the additional training options and enjoy a ride on Mallorca's
coastal roads or compete in global races with thousands of other users. Thanks
to the dynamic resistance adjustment, the resistance automatically adapts to
the track.
possibility to use the console as a gearshift. You can purchase the
Smart-Package at any time in our online shop and thus upgrade your ergome-
ter. (It is not necessary to replace the hardware)
Gearshift
For a free trial, go to the settings in the
console. Go to “Smart Package” and enter the
code 335577. You can then use the STIL-FIT
APP and all other apps for 5 accumulated
hours.

Warranty Guarantee
STIL-FIT international GmbH grants a
2-year guarantee on the ergometer for home
use. If your ergometer is defective, please
contact us or your dealer directly. We repair
the device in an on-site service at your home
through our service partners within Germany
and Austria.
Mail: service@stil-fit.com
Telefon: [phone]
