Mounting instructions dustbin „papyrus 2A with top“
Item-No. 57 3021 403
State: 07.05.2021 p. 1
Dirgram 1: Overall view

© stilum GmbH, Gewerbegebiet Larsheck, D-56271 Kleinmaischeid • Tel. [phone] • All rights and product modications reserved.
Mounting instructions dustbin „papyrus 2A with top“
Item-No. 57 3021 403
State: 07.05.2021 p. 2
Diagram 2: Foundation plan
560
150
200
1537
AA
300
500
200 200
A-A
OHNE SCHRIFTLICHE ZUSTIMMUNG DER CONRADI+KAISER GMBH DARF DIESE
TECHNISCHE UNTERLAGE WEDER VERVIELFÄLTIGT, NOCH DRITTEN MITGETEILT ODER
ZUGÄNGLICH GEMACHT WERDEN, NOCH IN SONSTIGER WEISE MISSBRÄEUCHLICH VER-
WENDET WERDEN. ZUWIDERHANDLUNGEN WERDEN URHEBERRECHTLICH VERFOLGT.
1
papyrus 2A mit Deckel
Benennung
Gepr.
Blatt
Datum
Projekt
Gez.
Zeichnungsnummer
1:10
A3
Name
Name
Fundamentplan
3023-00-00
Maßstab
Simonis 03.05.21
Gewerbegebiet Larsheck
56271 Kleinmaischeid
Deutschland
Beton
concrete
gewachsenes Erdreich
natural ground
Legende
DatumÄnderungRev
Boden
floor
1. Set the location.
2. Carry out excavation work for the foundations as shown in diagram 2.
After excavation compress the foundation oor.
3. Set up the concrete foundations acc. to diagram 2 in the quality class C20/25
with central, horizontal reinforcement.
4. After a setting period of 10 – 14 days, depending on weather conditions and
foundation size, ll up and compress the holes between the foundation and
the foundation hole with excavation.
5. Clean the foundation surface. Align the dustbin and screw the base plates to
the foundation using the included heavy-duty dowels.
6. Create top soil with an even ground level.
7. Do not allow anyone to use the urban furniture before the installation has
been nished.
Attention: If the urban furniture has been incompletely installed or partly dis-
mantled when carrying out maintenance and repair work, this may lead to par-
ticular risks of injury for the user. For this reason, make clearly visible that the
equipment shall not be used in such cases.
NOTE: Urban furniture, which contain components made of stainless steel should
not come with „normal“ steel parts in contact. Those steel parts may rub o󰀨 and
leave small steel particles in combination with moisture brown rust stains. If such
corrosion occur on stainless steel parts, they are ne with an abrasive (240 grit)
to remove.
Please take care when transporting and setting up the fact that the components
are made of stainless steel with no „normal“ steel parts in contact.
