STODDART Standard Security SPPL.HSD.STS.001 User manual

Rev: A - 01/02/2018
This is a multi-purpose secure liquid dispensing system suitable for a variety of liquids for personal use e.g. Hand
Sanitiser, Hand Wash or Sun Screen.
It is the responsibility of the responsible person at the facility where these dispensers are being used to establish
a system to control the contents and manage the risk of use including appropriate labelling in accordance with
Australian/NZ Standards.
Do not leave the refillable bottle separate from its locked enclosure and only remove for refilling. When refilling,
rinse out old contents completely then refill following the instructions of the liquid manufacturer. Note that residue
from oil based liquids will be difficult to completely remove. Do not mix contents from different sources. Thoroughly
clean the bottle and pump if changing the liquid source and/or content e.g. Hand Sanitiser to Sunscreen. The
responsible person for the facility must maintain a system to retain details of contents including ingredients, the
manufacturer and their use, care, first aid and storage instructions.
SPPL.HSD.STS.001
Model:
Installation Manual
Multi Purpose Liquid / Hand Sanitiser - Dispenser
Standard Security

Due to continuous product research and development,
the information contained herein is subject to change without notice.
Page 1 www.stoddart.com.au
Hand Sanitiser Dispenser - Standard Security
Assembly - Mounting to Stand (SPPL.HSS.01)
Assembly - Wall Mounting
• Using a Phillips head screwdriver and shifting spanner, secure
the dispenser to the stand with the supplied M5 mushroom
head screws, M5 washers and M5 nylock nuts
• For wall mounting, position the dispenser case on the wall and
mark hole positions (it is recommended that the dispenser unit
be mounted no higher than 1200mm from the ground)
• Drill marked locations
• Secure dispenser case to wall using screws and appropriate
wall fixings (screws and fixings not supplied)
• Fill the dispenser bottle with hand sanitiser, hand wash or
sunscreen. (refer to manufacturers guidelines on correct use)
• Screw the pump mechanism to the bottle
• Adhere the appropriate dispenser label (describing what
chemical is being used) to the forward facing surface of the
dispenser
1.
3.2.
Standard Security - SPPL.HSD.STS.001
In the box
1 x Stainless Steel Dispenser Case
1 x Stainless Steel Dispenser Bottle
2 x Dispenser Bottle Labels
1 x Pump Mechanism*
1 x Pump Cover
2x Lock Key
4 x M5 12mm Mushroom Phillips Head Screws
4 x M5 Flat Washers
4 x M5 Nylock Nuts
Tools Required
Phillips Head Screwdriver #2
Socket Set and/or Shifting Spanner
*Note: Pump Mechanism not covered by warranty.
Replacement pumps can be sourced by:
Calling 1300 79 1954
Emailing [email protected]

Due to continuous product research and development,
the information contained herein is subject to change without notice.
Page 2
www.stoddart.com.au
Hand Sanitiser Dispenser - Standard Security
5.4.
7.6.
• Place the bottle inside the dispenser case • Close the case door and lock with key
• Adhere the appropriate dispenser label (describing what
chemical is being used) to the front of the dispenser case door
• Close the dispenser case door and lock with key• To prevent after hours use, with the key unlock and open the
case, place the pump cover into the top slot covering the pump
