Server CerealServ DFD-C User manual

CerealServ™
CEREAL DISPENSERS
MODELS:
DFD-C
DFD-C-ST
DFD-C-2
DFD-C-3
...for purchasing our CerealServ™ Dispensers.
Eliminate the waste of single-serve cereal packages.
These robust dispensers easily dispense favorites with
an ADA compliant handle – no twisting wrist motion or
tight grasping required.
SERVE CEREAL—BETTER
Configurations vary.
See page 3.
Thank You

Page 2
SAFETY
According to food and safety regulations,
most foods must be stored and/or served at
certain temperatures or they could become
hazardous. Check with local food and safety
regulators for specific guidelines.
Be aware of the product you are serving
and the temperature the product is required
to maintain. Server Products, Inc. cannot
be responsible for the serving of potentially
hazardous product.
IMPORTANT
Clean, rinse, sanitize, and dry parts daily or regularly
to comply with local sanitization requirements.
CAUTION
Keep fingers clear of all moving parts to prevent
operator injury when dispensing product, during
cleaning, assembly and disassembly.
CLEANING
CLEAN
After disassembling,
clean all washable parts
with soap and hot water.
RINSE
fully with clear water.
1
SANITIZE
all parts according to local sanitization
requirements. All parts in contact with
food must be sanitized.
AIR DRY
all parts fully.
2
3
4
Use dishwashing
soap and hot water
Care of Countertop Stand
& Drip Tray:
YES!
• External surfaces may be wiped clean with
a clean damp cloth.
• Glass and surface cleaners approved for
use in food contact areas may be used.
• Do not use abrasive, caustic or ammonia
based cleansers.
• Do not use metal scrapers or cleaning
pads that could scratch surfaces.
NSF International listed.
Does not require a
twisting wrist motion
or tight grasping to dispense.
Plastic Drip Tray:
HAND WASH ONLY

Page 3
CONFIGURATIONS
WALL-MOUNTED
DFD-C-2 | DFD-C-3
COUNTERTOP
DFD-C-ST
1.5 LITER DISPENSERS
88930 Double with mounting bracket
88950 Triple with mounting bracket
1.5 LITER DISPENSERS
88890 Double with countertop stand
88910 Triple with countertop stand
3 LITER DISPENSERS
88940 Double with mounting bracket
88960 Triple with mounting bracket
3 LITER DISPENSERS
88900 Double with countertop stand
88920 Triple with countertop stand

Page 4
ATTACH FRICTION PAD
1
Slide cylinder into the opening of
dispenser body.
INSTALL CYLINDER
2
ASSEMBLY
Slide pivot pin into center hole on left side
of handle.
Align arrow on
the pin with the
unlock position.
Push pin in.
Rotate to the
locked position.
INSTALL PIVOT PIN
4
PRACTICE SAFETY. WASH ALL PARTS
PROPERLY BEFORE USE. See page 2.
Insert four triangular tabs
on friction pad into
matching slots in cylinder.
Slide handle over both sides of body and cylinder.
Snap handle centers into holes on each side.
INSTALL HANDLE ONTO BODY & CYLINDER
3

Page 5
FILL UNIT WITH CEREAL
PUT THE LID ON TOP OF HOPPER
6
7
MOUNTING
Select wall location or sturdy vertical surface
for mounting.
Determine proper mounting hardware you
will need to supply.
Secure bracket to wall stud(s), anchor bolts
in wall, or sturdy vertical surface.
Slide dispenser into bracket of stand.
YOU WILL NEED:
• Screwdriver
• (4) screws &
• (4) anchor bolts (if needed)
or
WALL BRACKET INSTALLATION
COUNTERTOP STAND
ADD HOPPER TUBE
5
Insert tabs of hopper into slots on body.
Turn clockwise until secure.
Hopper snaps into place.

Page 6
SWING
HANDLE
UP FULLY
to load the
cylinder chamber.
Handle CLICKS above side notch.
SWING
HANDLE
DOWN FULLY
to dispense
the serving.
Angled tabs inside
handle TAP bottom.
USE
TROUBLESHOOTING
Make sure there is enough product remaining to
dispense and that the product is free to move to
the bottom.
Make sure you are dispensing the right kind of
product. The CerealServ™ dispenser is designed
for free-flowing foods. Don’t use it for sticky,
gummy or powdered ingredients.
Make sure the handle is installed correctly with
the pivot pin locked in place.
Make sure the friction pad and cylinder
are properly installed.
For cylinder to advance and
serve a portion, the handle
must travel its full range of
motion up and down.

Page 7
DISASSEMBLY
REMOVE LID
1
EMPTY INGREDIENTS
FROM UNIT
2
REMOVE PIVOT PIN
4
Use the pull-tab
on right side to assist.
Rotate pin to the unlock position
and take it out.
REMOVE HOPPER
3
Turn hopper counterclockwise to remove
tabs from slots on body.
Lift handle upward to the position just
before it would click. This makes the
handle easier to remove.
REMOVE FRICTION PAD
7
REMOVE CYLINDER
6
REMOVE HANDLE
5

Page 8 Manual #01937-RevA 021919
NEED HELP?
CEREALSERV
™
Please be prepared with your Model and Series
Number. These are found on the side of the
dispenser body and the stand or bracket.
Certain components are also marked with
individual Part Numbers.
262.628.5600 | 800.558.8722
[email protected]
Server Products Inc.
3601 Pleasant Hill Road
Richfield, WI 53076 USA
MOUNTING PARTS DISPENSER PARTS
LID
89002
HOPPER TUBE,
1.5 LITER
88963
HOPPER TUBE,
3 LITER
89001
BODY
88964
HANDLE
88754
PIVOT
PIN
88776
CYLINDER
88753
FRICTION PAD
88761
SERVER PRODUCTS
LIMITED WARRANTY
GENERAL SERVICE,
REPAIR OR RETURNS
Server Products equipment is backed by a
two-year limited warranty against defects in
materials and workmanship.
For complete warranty information go to:
www.Server-Products.com
Before sending any item to Server Products
for service, repair, or return, contact Server
Products customer service to request a Return
Authorization Number. Merchandise must be
sent to Server Products with this number. Service
is extremely prompt. Typically, units are repaired
and ship out within 48 hours of receipt.
Merchandise being returned for credit must be in new
and unused condition and not more than 90 days
old and will be subject to a 20% restocking charge.
DOUBLE
WALL MOUNTING
BRACKET
89003
DOUBLE
CEREALSERV™
STAND
88918
INCLUDES
DRIP TRAY ASSEMBLY
89014 &
RUBBER FEET
84393
INCLUDES
DRIP TRAY ASSEMBLY
89015 &
RUBBER FEET
84393
TRIPLE
WALL MOUNTING
BRACKET
89005
TRIPLE
CEREALSERV™
STAND
88919
