Stone STAD150WT-15 Technical Document
Android industrial control LCD display
Model
STAD150WT-15
Equipment Manual
All rights reserved by STONE
Technologies
STAD150WT-15 Equipment Manual www.stoneitech.com
Release 01/2019 2
Contents
1 Android LCD Specification Introduction................................................................3
1.1 Introduction........................................................................................................ 3
1.2 Technical Parameters...................................................................................... 4
2 Interface Description................................................................................................6
2.1 Serial Ports.........................................................................................................6
2.2 USB-HOST Interface........................................................................................6
2.3 USB-DEVICE Interface.................................................................................... 7
2.4 LED Interface.....................................................................................................7
2.5 Network Interface..............................................................................................7
2.6 Button..................................................................................................................7
2.7 TF Card Holder..................................................................................................8
2.8 Audio Interface.................................................................................................. 8
2.9 WIFI and Bluetooth Module.............................................................................8
2.10 4G Module....................................................................................................... 8
2.11 GPS Module.................................................................................................... 9
3 Accessories............................................................................................................ 10
3.1 Antenna Selection...........................................................................................10
3.2 Speaker............................................................................................................ 10
4 Physical Dimensions............................................................................................. 11
5 International Certification......................................................................................12
6 Naming Rule...........................................................................................................14
All rights reserved by STONE
Technologies
STAD150WT-15 Equipment Manual www.stoneitech.com
Release 01/2019 3
1Android LCD Specification Introduction
1.1 Introduction
STAD150WT-15 Android LCD is a new model Android LCD by STONE Tech.
It is equipped with 1.2GHz Quad-core Coretex A7, capacitive touch frame.
Recommended power supply is DC 12V, the PCB board integrates a variety
of peripheral interfaces.
All rights reserved by STONE
Technologies
STAD150WT-15 Equipment Manual www.stoneitech.com
Release 01/2019 4
1.2 Technical Parameters
Main Parameters
Parameter
Description
CPU
Quad-core 1.2Ghz
ARM Cortex™-A7
System
Android 4.4.2
Rooted
RAM
1GB
2pcs 512MB DDR3
eMMC
8GB
eMMC
GPU
Mali400MP2
OpenGLES2.0 VG1.1
Display Parameters
Parameter
Description
Interface
LVDS
Single
eight-way
Resolution
1024x768
16:9 Ratio
Touch Type
Capacitive
10 points touch
Luminance
400 cd/m2
Viewing Angles
80/80/80/80
Peripheral Interfaces
Interface
Quantities
Description
Power
1
DC 5.5*2.1MM
Serial port
4 RS-232, 2 RS-485(Optional)
2 RS-485 multiplex with RS-232
USB
3 HOST, 1 DEVICE
External 3 USB HOST,
another HOST connects capaciti
ve touch
Audio
1 MIC, 1 HPO, 1 SPK
8R/3W Amplifier, SPK connector
is CON2X1-PH2.0mm
TF Slot
1
TF Card slot
SIM Slot
1
SIM,Micro SIM slot
Ethernet
1
10/100Mbps self-adaptive
network interface
4G
1 (Optional)
7 Mode full Netcom
WIFI
1 (Optional)
8188EU or 8723BU Bluetooth &
WIFI 2-in-1
Bluetooth
1 (Optional)
8723BU Bluetooth & WIFI 2-in-1
Support Bluetooth 4.0
GPS
1 (Optional)
GPS Global positioning, Quectel
4G module with GPS
All rights reserved by STONE
Technologies
STAD150WT-15 Equipment Manual www.stoneitech.com
Release 01/2019 5
Buttons
2
1 programming button,1
User-defined
Power Supply
Parameter
Min
Typical
Max
Unit
Operating Voltage
11.5
12
12.5
V
Operating Current
1560
mA
Reliability Test
Min
Typical
Max
Unit
Operating Temperature
-10
25
70
℃
Storage Temperature
0
50
℃
Operating Humidity
5
95
RH%
Structure
Size
Description
External Dimensions
347.30mm*271.30mm*56.2mm
All rights reserved by STONE
Technologies
STAD150WT-15 Equipment Manual www.stoneitech.com
Release 01/2019 6
2Interface Description
2.1 Serial Ports
STAD150WT-15 is integrated with 4 serial ports. UART0, UART1, UART2,
UART3 are RS-232 level converted. All have been treated with anti-static
treatment.
UART2, UART3 are an RS-232 and RS-485 hardware multiplex interface,
can be connected to an external RS-485 level device. The serial ports are
all brought out through male DB9 a connectors.
Serial port definition as table below:
Interface
Pin
Pin Defination
Device Node
Level
Serial Port
COM1
2
RXD0
/dev/ttyS0
RS232
UART0
3
TXD0
5
GND
COM2
2
RXD1
/dev/ttyS1
RS232
UART1
3
TXD1
5
GND
COM3
232
2
RXD2
/dev/tty S2
RS232
UART2
3
TXD2
5
GND
485
8
A
RS485
9
B
COM4
232
2
RXD3
/dev/ttyS3
RS232
UART3
3
TXD3
5
GND
485
8
A
RS485
9
B
2.2 USB-HOST Interface
STAD150WT-15 is integrated with 3-way USB-HOST, to connect various
USB peripherals, such as USB mouse and keypad, flash drive, USB
All rights reserved by STONE
Technologies
STAD150WT-15 Equipment Manual www.stoneitech.com
Release 01/2019 7
camera, etc
2.3 USB-DEVICE Interface
OTG interface is USB-DEVICE interface. This interface can only be used
for system programming and ADB debugging.
2.4 LED Interface
There are two LEDs on the STAD150WT-15.The POWER LED is always
on when the display is powered. The USER LED is user defined, which
function can be customized by user.
2.5 Network Interface
The ETH is a 100M adaptive Ethernet interface that is brought out via
RJ45. If you want to use Android's Ethernet function, you need to plug the
network cable into the ETH interface and then turn on the Ethernet
function by setting. The default Ethernet is DHCP-assigned IP. If you want
to manually configure the IP address, you can configure it in the advanced
settings.
2.6 Button
There are two buttons on the STAD150WT-15. Button functions as below:
1. UBOOT button: Normally used when programming
2. USER button: Function reserved
If you need to program img with UBOOT button, please refer to STAD
series User Guide.
All rights reserved by STONE
Technologies
STAD150WT-15 Equipment Manual www.stoneitech.com
Release 01/2019 8
2.7 TF Card Holder
The TF card holder supports large-capacity storage. It is designed for
hot-swap detection, supports eMMC protocol 4.3 and SD Memory Card
protocol v2.0.
2.8 Audio Interface
The HPO is the headphone jack, the MIC is the microphone jack, and the
SPK is the left channel speaker jack. The SPK interface is an 8R/3W
amplifier circuit.
PIN
Definition
1
-OUT_L
2
+OUT_L
2.9 WIFI and Bluetooth Module
If you only want to use the WIFI function, you can use RTL8188EUS as
the WIFI module. If you also want to use the Bluetooth function, you can
choose the Bluetooth WIFI 2-in-1 RTL8723BU module. The 8723BU can
support the Bluetooth 4.0 protocol, which supports the function of
transferring files to and from devices such as mobile phones after pairing.
2.10 4G Module (Optional)
The mother board supports the 4G module of the MINI-PCIE interface. If
you need to use the 4G function, you only need to insert the module into
the mother board, then put the SIM card into the card slot to use the 4G
function.
All rights reserved by STONE
Technologies
STAD150WT-15 Equipment Manual www.stoneitech.com
Release 01/2019 9
The mother board card slot supports only the Micro SIM card.
The 4G module supports
TD-LTE/FDD-LTE/TD-SCDMA/WCDMA/EVDO/CDMA1X/GSM mode,
please refer to chart below and confirm with your network operator first.
Note: The SIM card is slanted to the outside.
Supported Band
Frequency
TD-LTE
B34/B38/B39/B40/B41
FDD-LTE
B1/B3/B5/B8
TD-SCDMA
B34/B39
WCDMA
B1/B8
CDMA1X
BC0
GSM
900/1800MHz
2.11 GPS Module (Optional)
The STAD150WT-15 is equipped with a GPS-enabled 4G module to
support fast and accurate positioning. If you need this function, you need
to put the GPS antenna in the open space. When you turn on the
Android positioning function, you can get the latitude and longitude
coordinates of the device at this time.
All rights reserved by STONE
Technologies
STAD150WT-15 Equipment Manual www.stoneitech.com
Release 01/2019 11
4Physical Dimensions
Speaker 8R5W 100*45
Stereo Speaker PH2.0-4P
Cable length 80 cm
External,Optional
Speaker 8R5W 100*45
Stereo Speaker PH2.0-2P
Cable length 80 cm
External,Optional
Speaker 4R3W
TS7033BOX-01-L350
PH1.25-2P/ Speaker 2040
4R2W Rectangle Full-band
Mono Speaker
Cable length 20 cm
External/Internal,Optional
All rights reserved by STONE
Technologies
STAD150WT-15 Equipment Manual www.stoneitech.com
Release 01/2019 14
6Naming Rule
This chapter contains the naming rule:
As sample STAD070WC-01
Code
Explain
ST
Company Code
AD
Android
070
TFT Panel Dimension: 7 inch
W
W=Wide Voltage
C
C=With Capacitive Touch Screen
T=Tempered Glass Touch Screen
R=Infrared Touch Screen
0
0= Standard Configuration 1= High Configuration
1
1=Without Case 5=Metal Case
