ATLAS ARCH ASSEMBLY INSTRUCTIONS
Please ensure that you check all component parts
for quantity and quality before you commence
building the product.
If there are any missing parts, please contact the
sales company immediately.
Timber is a natural product. It will shrink and
swell as a result of varying moisture content.
This product has been pressure treated to ensure
protection against all weather conditions. Annual
cleaning and re-treatment with a timber
preservative will help to prolong the life of the
product.
A powerdrill/screwdriver plus tape measure will be
required to assemble this product.
Component supply: Screw fixings supplied:
4 x 35mm screws
6 x 70mm screws
2 x side assemblies 2 x roof sections 2 x finials
Stage 1.
Place the two roof sections together.
Secure the roof sections with 2 x 70mm
screws ensuring the screws locate into the
framing of the roof panel.
Store More Garden Buildings Ltd.
Edward Merton House, Park Gate Close, Bredbury Park Way, Bredbury Industrial Park,
Stockport, Cheshire. SK6 2SN
Company Number: 1093320 VAT Registration Number: 149 4968 14
Tel: [phone] Fax: [phone] E-mail: [email protected]
www.shedbaron.co.uk

Stage 2.
Place the first side panel against the outside
edge of the location batten and fix through the
top of the roof frame into the side posts using
2 x 70mm screws.
Stage 3.
Place the second side panel against the outside
edge of the location batten and repeat stage 2.
Stage 4.
Secure the finials each side to cover the joint
of the roof sections using 2 x 35mm screws
for each finial.
To insert arch into ground prepare the 4 post
Holes to the dimensions shown.
A ‘GARDEN TECHNOLOGY’ PRODUCT FROM ESTONIA
TIMBER SUPPLIED FROM SUSTAINABLE FOREST RESOURCES
