StyleWell Thorncliff HDFP54-58E User manual

THANK YOU
We appreciate the trust and confidence you have placed in StyleWell through the purchase of this electric fireplace/heater. We strive to continually
create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing StyleWell!
Model # HDFP54-58E
# HDFP54-58AE
OMSID # 320084804
# 320084758
ASSEMBLY INSTRUCTIONS
Thor cliff 54” I frared Media Electric Fireplace
Questions, problems, missing parts?
Before returning to the store, call Customer Service
8 a.m. - 7 p.m., EST, onday-Friday, 9 a.m. – 6 p.m., EST, Saturday
1-877-527-0313
HOMEDEPOT.COM

2
Table of Co te ts
Table of Co te ts.......................................................... 2
Safety I formatio ........................................................ 2
aximum Recommended Weight Loads .................................2
Warra ty ..................................................................... 2
Pre-Assembly .............................................................. 2
Planning Assembly ...................................................................2
Tools required ..........................................................................2
Hardware Included ...................................................................3
Package Contents ....................................................................4
Assembly .................................................................... 5
Care a d Mai te a ce................................................. 23
Caring for Wood Furniture ......................................................23
Cleaning the Fireplace Trim ...................................................23
Safety I formatio
Please read and understand these instructions before
assembling and using this console. Save these instructions for
future reference.
MAXIMUM RECOMMENDED WEIGHT LOADS
WARNING: This unit is not intended for use with CRT TVs. Use only
with flat panel TVs and audio/video equipment meeting
recommended size and weight limits. Never use with
larger/heavier than recommended flat panel TVs or equipment. To
avoid instability, place flat panel TV in the centre of the unit; the
base of the television must be able to rest on the supporting
surface of the unit without over-hanging the edges.
Improperly positioned flat panel TVs, or flat panel TVs or other
equipment that exceed recommended size and weight limits could
fall off or break the unit, causing possible serious injury.
Warra ty
We are confident that you will be delighted with this purchase. Should this product be defective in workmanship or materials, or fail under
normal use, we will repair or replace it for a period of up to one (1) year from date of purchase.
This warranty gives you specific rights and you may also have other rights which vary from state to state.
Contact the Customer Service Team at 1-877-527-0313 or visit www.HomeDepot.com.
Pre-Assembly
PLANNING ASSEMBLY
Compare all parts with the Hardware Included and Package Contents list. If any part appears missing or damaged, do not assemble this
product and contact the Customer Service Team at 1-877-527-0313.
TOOLS REQUIRED
Phillips
screwdriver
(not provided)
aximum load 22.7 kg / 50 lb
Place TV behind the stopper
Fits up to most 165.1 cm / 65 in. diagonal flat-panel TVs
aximum load 36.3 kg / 80 lb

3 HO EDEPOT.CO
Please contact 1-877-527-0313 for further assistance.
Pre-Assembly (co ti ued)
HARDWARE INCLUDED
NOTE: Hardware not shown to actual size.
Part Descriptio Qua tity Part Descriptio Qua tity
AA Insert screw 10+1 extra Handle 2
BB Short wood dowel 4+1 extra NN Handle bolt 4
CC Long wood dowel 47+2 extra OO Shelf support 8+1 extra
DD Cam lock 48+2 extra PP Rubber bumper 4+1 extra
EE Cam bolt 48+2 extra QQ Large L-bracket 2
FF Short flat head screw 12+1 extra RR Pan head screw 8+1 extra
GG edium flat head screw 4+1 extra SS Hinge 4
HH Long flat head screw 4+1 extra TT Nickel screw for hinge 24+1 extra
II Washer head screw 36+1 extra UU Glue 2
JJ Small L-bracket 2 VV Touch-up pen 1
KK Paper sticker 30+2 extra WW Tipping restraint hardware kit 2
LL Acrylic stopper 1
LL
AA
NN
OO
GG
II
PP
JJ
QQ
BB
CC
DD
EE
FF
RR
HH
SS
TT
KK
UU
VV
WW

4
Pre-Assembly (co ti ued)
PACKAGE CONTENTS
Part Descriptio Qua tity Part Descriptio Qua tity
A Heater 1 Q Right skirting 1
B Left upright arm 1 R Upper front molding 2
C Right upright arm 1 S Upper side panel 2
D Connector strap 1 T Upper partition molding 1
E Ember bed 1 U Upper partition panel 1
F Left log 1 V Lower side panel 2
G Right log 1 W Left lower partition panel 1
H Firebox wall panel 1 X Right lower partition panel 1
I Firebox glass 1 Y Door 2
J Remote control with battery 1 Z iddle crossbar 1
K Top panel 1 A1 Firebox support 1
L edia shelf 1 B1 Side back panel 2
Bottom panel 1 C1 iddle trim 2
N Rear skirting 1 D1 Upper back panel 1
O Front skirting 1 E1 Adjustable shelf 2
P Left skirting 1

5 HO EDEPOT.CO
Please contact 1-877-527-0313 for further assistance.
Assembly
1
Prepari g media shelf a d base assembly
NOTE: Do not fully tighten all bolts until you finish assembling all parts. Once assembled, go back and fully tighten all bolts. This will make
the assembly easier.
□ Unpack the unit and confirm that you have all the hardware and required parts. Assemble the unit on a carpeted floor or the empty
carton to avoid any scratches.
□ Securely screw the cam bolts (EE) into the designated small holes on the media shelf (L), bottom panel ( ), front skirting (O), side
skirtings (P and Q) using a Phillips screwdriver. DO NOT overtighten the cam bolts.
2
Glui g wood dowels
□ Glue the long wood dowels (CC) into the designated holes on the middle crossbar (Z) and skirting boards (N, O, P and Q) as shown.
NOTE: Refer to the dowel assembling guide drawings in this step for further clarification on how to properly glue in the wooden dowels. Apply this
method whenever instructed to install wood dowels. It is very important to use a small amount of glue on both ends of dowels and wipe off the excess
glue immediately with a damp cloth.

6
Assembly (co ti ued)
3
Attachi g middle crossbar
□ Attach the middle crossbar (Z) to the media shelf (L) by engaging three cam locks (DD).
NOTE: Refer to the cam lock assembling guide drawings in this step for further clarification on how to properly install cam locks. Apply this method
whenever instructed to install cam locks .
4
Attachi g rear skirti g
□ Attach rear skirting (N) between the side skirtings (P and Q) by engaging two cam locks (DD).

7 HO EDEPOT.CO
Please contact 1-877-527-0313 for further assistance.
Assembly (co ti ued)
5
Attachi g fro t skirti g
□ Align and attach the front skirting (O) to both side skirtings (P and Q) using two cam locks (DD).
6
I stalli g base
□ Using the wood dowels (CC) as a guide, align and attach the previous assembly to the bottom panel ( ) by engaging eleven
cam locks (DD).

8
Assembly (co ti ued)
7
Prepari g bottom pa el assembly
□ Securely screw four cam bolts (EE) into the designated small holes on the top of bottom panel ( ) using a Phillips screwdriver.
8
Attachi g middle trims
□ Glue two short wood dowels (BB) into the inner holes on each middle trim (C1).
□ Fasten the middle trims (C1) to the lower partition panels (W and X) respectively, using two medium flat head screws (GG) per trim.

9 HO EDEPOT.CO
Please contact 1-877-527-0313 for further assistance.
Assembly (co ti ued)
9
Glui g wood dowels
□ Glue the long wood dowels (CC) into the inner holes on both lower side panels (V) and the lower partition panels (W and X) as
shown.
10
Attachi g side pa els
□ Align and attach two lower side panels (V) to the bottom panel ( ) by engaging four cam locks (DD).

10
Assembly (co ti ued)
11
Attachi g lower partitio pa els
□ Using the wood dowels as a guide, firmly press the assembled lower partition panels (W and X) to the bottom panel ( ) and
fasten them in place with four long flat head screws (HH).
12
Attachi g media shelf
□ Place the media shelf (L) onto the inserted long wood dowels (CC) on the vertical panels (V, W and X) properly and fasten it in place
by engaging eight cam locks (DD).

11 HO EDEPOT.CO
Please contact 1-877-527-0313 for further assistance.
Assembly (co ti ued)
13
Screwi g cam bolts
□ Ask for assistance to stand the previous unit upright, securely screw the cam bolts (EE) into the designated small holes on the
media shelf (L) using a Phillips screwdriver.
14
Prepari g top pa el a d upper moldi gs assembly
□ Securely screw the cam bolts (EE) into the designated small holes on the top panel (K) and upper moldings (R and T) using a Phillips
screwdriver.

12
Assembly (co ti ued)
15
Glui g wood dowels
□ Glue the long wood dowels (CC) into the inner holes on the upper front moldings (R), upper side panels (S) and upper partition
panel (U) as shown.
16
Combi i g upper pa els with the moldi gs
□ A ttach one upper front molding (R) to one upper side panel (S) by engaging two cam locks (DD) as shown.
□ Complete this step two times to assemble two upper side panels (S).
□ A ttach the upper partition molding (T) to the upper partition panel (U) by engaging two cam locks (DD) as shown.
x 2

13 HO EDEPOT.CO
Please contact 1-877-527-0313 for further assistance.
Assembly (co ti ued)
17
Attachi g upper side pa els a d partitio pa el
□ Align and attach the assembled upper side panels (S) and upper partition panel (U) to the media shelf (L) by engaging two cam
locks (DD) in each panel.
18
Attachi g top pa el
□ Align and attach the top panel (K) to the assembled upper side panels (S) and upper partition panel (U) by using six cam locks (DD).

14
Assembly (co ti ued)
19
Faste i g middle crossbar
□ Using the pilot holes as a guide, attach the small L-bracket (JJ) at the joints where the middle crossbar (Z) meets the partition
panels (W and X) with two short flat head screws (FF) per bracket.
20
I stalli g back pa els
□ Now, go back and securely tighten all the cam locks and screws. ake sure all the parts are tight and there are no gaps between
the parts. This will help keep the unit square.
□ Pick up the upper back panel (D1) and align the pre-drilled holes against the upper long edge with the pilot holes on the back of
top panel (K). Fasten it in place with the provided washer head screws (II).
□ Using the pilot holes as a guide, align and attach the side back panels (B1) to the mantel frame with the washer head screws (II).
NOTE: We recommend attaching back panel with the screws at the corners first.

15 HO EDEPOT.CO
Please contact 1-877-527-0313 for further assistance.
Assembly (co ti ued)
21
I stalli g door hi ges a d ha dles
□ Extend two door hinges (TT) and rest the hinge cups onto the cutouts of each door (Y). Secure the door hinges (TT) in place by using
two nickel screws (SS) in each hinge.
□ Attach one handle ( ) to the front side of each door (Y) with two handle bolts (NN).
22
Attachi g door pa els
□ Ask for assistance to lift the assembly unit upright and position it near the final location.
□ Pick up one door (Y) and fasten the hinge bases onto the left side panel (V), using the pilot holes as a guide.
□ Repeat the same process to attach the other door (Y) to the right side panel (V).
□ Open and close the doors to make sure they are aligned and shut correctly. If necessary, adjust the screws for a good fit. Refer to
the hinge sticker on door for adjustment.

16
Assembly (co ti ued)
23
Attachi g adjustable shelves
□ Insert four shelf supports (OO) in the holes at the desired height inside each side compartment. ake sure you place the four shelf
supports in the same level to make the shelf level.
□ Tilt and rest the adjustable shelves (E1) onto the shelf supports and fasten them in place with the short flat head screws (FF).
24
Attachi g paper stickers a d rubber bumpers
□ Put the paper stickers (KK) onto the visible cam locks and screws.
□ Stick the rubber bumpers (PP) on the outer corners of doors where the partition panels (W and X) are in contact with.

17 HO EDEPOT.CO
Please contact 1-877-527-0313 for further assistance.
A
C
B
C
AA
A
AA
C
A
AA
Assembly (co ti ued)
25
Attachi g upright arms
□ See figure A: Fasten upper 2 screws (AA) through the upright arm (C) into the heater (A) until tight.
□ See figure B: Fasten lower 2 screws (AA) into the upright arm (C) until tight.
□ Fully tighten all 4 screws (AA) one final time.
□ Repeat the same process with upright arm (B).
WARNING: Do not lift or transport the heater by using the upright arms.
NOTE: Use hand screwdriver, not power driver to assemble fireplace insert . See BILT for video instructions.
26
Attachi g logs to ember bed
1. I stall left log (F) i to left hole of ember bed (E) by i serti g fro t edge of the log base i to fro t otches of ember
bed hole.
2. The tilt the log back to i sert the rear edge of the log base i to rear otches of ember bed hole (press dow log
firmly to lock i to positio ).
□ Repeat the above process for the right log (G).
IMPORTANT: Carefully follow the 2 steps below for inserting each log.
Figure A
Figure
B
G
EE
12
E

18
C
B
H
H
A
Assembly (co ti ued)
27
Positio i g ember bed
□ Set the ember bed (E) onto the heater (A) as shown.
□ Push ember bed forward against the front flange of heater.
□ Position the USB cable as shown below.
28
Attachi g wall pa el
□ Fold the wall panel (H) as shown. Then position yourself at back side of heater (A).
□ Hold wall panel (H) at the angle shown below and insert lower back edge into metal slots on back of heater (A).
□ Tilt wall panel (H) forward until bottom corner inserts into lower U-channels on both upright arms (B and C).
□ Continue to tilt wall panel (H) forward until the top corner inserts into upper U-channels on both upright arms (B and C).
U
SB cable
U
-
channels
A
E
E
A

19 HO EDEPOT.CO
Please contact 1-877-527-0313 for further assistance.
Assembly (co ti ued)
29
Co ecti g ember bed cable to heater
□ Fully plug the USB connector of the ember bed (E) into the back port of heater (A).
30
I serti g the glass
□ Slide the glass (I) into the inner U-channels on both upright arms (B and C) until the glass sits onto the heater (A). If needed, push
top of upright arms in or out to accommodate glass. ake sure the top of the glass (I) is flush with the top of both upright arms
(B and C).
The warning labels on glass
should face outward
E
A
A
A
II
B
C

20
Assembly (co ti ued)
31
Positio i g co ector strap
□ Position top connector strap (D) over the glass (I) and upright arms (B and C). Follow orientation shown below.
32
Attachi g co ector strap
□ Fasten connector strap (D) to both upright arms (B and C) using two screws (AA) as show below. Holes must be in line for screw
to pass through.
The bevel edge faces inside the unit.
D
I
H
C
B
D
H
D
AA H
D
H
C
B
