Sub-Zero Undercounter Ice Machine User manual

Undercounter Ice Machine
I STALLATIO GUIDE

Important Note
To ensure the safe and efficient installation of Sub-Zero
equipment, please take note of the following types of
highlighted information throughout this guide:
IMPORTA T OTE highlights information that is especially
relevant to a problem-free installation.
CAUTIO signals a situation where minor injury or product
damage may occur if instructions are not followed.
WAR I G states a hazard that may cause serious injury or
death if precautions are not followed.
Contents
Undercounter Ice Machine ..................... 3
Ice Machine Specifications ..................... 4
Ice Machine Installation ........................ 8
Installation Checklist ......................... 14
Service Information .......................... 15
Features and specifications are subject to change at any time
without notice. Visit subzero.com/specs for the most up-to-
date information.
IMPORTA T OTE: Throughout this guide, dimensions in
parentheses are millimeters unless otherwise specified.

Undercounter Ice Machine 3
subzero.com/specs
Sub-Zero Undercounter Ice Machine
IMPORTA T OTE: The importance of the installation
of the Sub-Zero ice machine cannot be overemphasized.
Installation must be completed by a qualified installer.
Read this entire installation guide prior to installation.
There are key details that you should observe during the
installation to make the process easier, problem-free and,
most importantly, safe. The homeowner should keep this
installation guide for future reference.
Any questions or problems regarding the installation
should be directed to your authorized Sub-Zero dealer or
Sub-Zero customer care at 800-222-7820. You may also
check the contact & support sectionofour website,
subzero.com.
Important product information, including the model and
serial number of your unit are listed on the product rating
plate, located in the upper left corner of the ice bin and on
the back of the unit. Refer to the illustration below.
Proper installation requires connection to the water
supply, a drain and a dedicated electrical circuit. These
connections are the responsibilities of the installer.
Improper connections can result in personal injury,
property damage and improper operation.
Location of rating plate.
RATING PLATE

Ice Machine Specifications 4
Specifications
Ice Storage Capacity 26 lbs (12 kg)
Shipping Weight 117 lbs (53 kg)
18"
(457)
143/4"(375) 23" (584)
335/8"
(854)
4" (102)
6"
(152)
Ice Machine Specifications
OVERALL DIME SIO S
Overall dimensions do not include panels or handles.
I STALLATIO
IMPORTA T OTE: It is recommended that the electrical
and water supply be placed in an adjacent cabinet. If they
are placed within the opening, additional cabinet depth
may be required.
24" (610)
OPENING
DEPTH
151/4"
(387)
OPENING
WIDTH
24" (610)
OPENING DEPTH
341/2"(876)
OPENING
HEIGHT
TOP VIEW
FRONT VIEWSIDE VIEW

Ice Machine Specifications 5
subzero.com/specs
E
E
E
Location of electrical supply.
The electrical supply for the ice machine must be installed
by a qualified electrician in accordance with all applicable
national and local electrical codes. Observe the following:
•The ice machine must be grounded in accordance with
national and local electrical codes.
•A separate fuse or circuit breaker must be provided for
each ice machine.
•The maximum allowable voltage variation is ±10% of
the rated voltage at ice machine start-up, when the
electrical load is highest.
•The minimum wire size is #14 for less than 100' (31 m)
or #12 for more than 100' (31 m) to 200' (61 m), use solid
copper conductor only. The recommended breaker is
15 amp. Local or state electrical code, length of run or
materials used, can increase the minimum wire gauge
required. A qualified electrician must determine the
proper wire size, although #14 is the minimum size
allowed.
•The minimum circuit requirement is used to help select
the wire size of the electrical supply. Minimum circuit
requirement is not the ice machine’s running amp load.
•Observe correct polarity of incoming line voltage.
Incorrect polarity can lead to erratic ice machine opera-
tion and a safety issue.
Electrical Requirements
The ice machine must be installed with adequate clear-
ance for electrical connection at the rear of the unit. The
electrical supply for the ice machine requires installation of
a grounded receptacle on a separate circuit, servicing only
this appliance. Follow the National Electrical Code and
local codes and ordinances when installing the receptacle.
IMPORTA T OTE: Although it can be located anywhere
on the back wall, it is recommended that the receptacle be
placed in an adjacent cabinet or in the lower right of the
opening. If it is placed within the opening, additional
cabinet depth may be required. Refer to the illustration
below.
Models UC15IO and UC-15IPO are designed and safe for
use in outdoor applications. When installed outdoors, a
ground fault circuit interrupter (GFCI) is required to reduce
the risk of electrical shock. For outdoor models, or if a
ground fault circuit interrupter (GFCI) is required by local
codes, it must be a breaker type, not an outlet type.
Electrical Requirements
Power Supply 115 V AC, 60 z
Receptacle 3-prong grounding-type
Circuit Breaker 15 amp
Minimum Circuit 4.1 amp
Do not use an extension cord or two-prong adapter.
Electrical ground is required on this appliance.

Ice Machine Specifications 6
Plumbing Requirements
The ice machine must be installed with adequate clear-
ance for water and drain connections at the rear of the
unit. Prepare the water supply line and drain connection
before installing the ice machine.
Plumbing Requirements
Water Supply Line 1/4" OD copper, braided stainless steel
or PEX tubing
Water Pressure 20–80 psi (1.4–5.5 bar)
Water Temperature 50°F (10°C) – 80°F (27°C)
Water Outlet (gravity drain) 3/4"(19) hose
Water Outlet (drain pump) 3/8"(10) hose
WATER SUPPLY LI E
For all ice machine models, locate the water supply line as
shown in the illustration below.
IMPORTA T OTE: It is recommended that the water
supply be placed in an adjacent cabinet within the shaded
area shown in the illustration. If placed within the opening,
additional cabinet depth may be required.
The water supply line should be connected to the house
supply with an easily accessible shut-off valve between
the water supply and the ice machine. A reverse osmosis
system can be used, provided there is constant water
pressure of 20 psi (1.4 bar) to 80 psi (5.5 bar) supplied to the
unit at all times. A copper line is not recommended for this
application.
•A cold water supply line must be supplied to the ice
machine. Use 1/4"(6) OD copper, braided stainless steel
or PEX tubing and compression fitting (not included).
The incoming water temperature must remain between
50°F (10°C) and 80°F (27°C).
•Do not connect the ice machine to a hot water supply.
Be sure all hot water restrictors installed for other
equipment are working, such as check valves on sink
faucets, dishwashers, etc.
•If water pressure exceeds the maximum recommended,
install a water pressure regulator.
•Insulate the water supply line to prevent condensation.
Improper water supply and drain connections can
result in personal injury and property damage.
TOP VIEW
3"(76)
12"
(305)
3"(76)
12"
(305)
LOCATION OF
WATER LINE
8"
(203)
1/2"
(13)
Location of water supply line.

Plumbing Requirements
DRAI CO ECTIO
Models UC-15I and UC-15IO are gravity drain models that
require a drain tube that is pitched down from the outlet at
the back of the unit to the sanitary sewer connection.
Models UC-15IP and UC-15IPO have a built in drain pump
that will pump water up to a drain point, such as a sink.
Gravity drain models are supplied with a drain hose for
gravity draining. A pump model must be used if a gravity
drain is not possible. Both drain methods require routing
to an open site drain. Do not connect directly to a drain
line as bacteria from the drain line may contaminate the
ice machine. Locate the drain in an adjacent cabinet.
Refer to the illustrations below. For installations that will
not allow the drain to be placed in an adjacent cabinet,
the drain must be located within 1/2"(13) of the back wall.
Ice Machine Specifications 7
subzero.com/specs
Improper drainage can lead to water flowing back into
ice machine and poor performance.
SHUT-OFF
VALVE
WATER
SUPPLY
DRAIN
TUBE
Gravity drain models. Drain pump models.
DRAIN TUBE
SHUT-OFF
VALVE
AIR GAP
WATER
SUPPLY
•The ice machine drain connection is approximately
5" (127) from the floor.
•For the gravity drain, all horizontal runs of drain lines
must have a 1/4"(6) per 12" (305) fall.
•Drain pump models have a maximum rise of 12' (4 m)
and a maximum run of 100' (31 m).
•Drain pump models will likely require an air gap
between the unit and the drain receptacle.
•The floor drain must be large enough to accommodate
drainage from all drain lines.
•The drain pump discharge line must terminate at an
open site drain.
•If there is not adequate room behind the ice machine
for the drain or waste water receptacle, the drain can
be located below the floor.
WATER FILTER
The water filter provided with the ice machine is designed
to inhibit scale formation, filter sediment, and remove
chlorine odor and taste. The life expectancy of the water
filter is approximately six months during normal usage.
The ice machine control board will monitor water usage
and indicate when replacement is required.
Replacement water filters are available through your
authorized Sub-Zero dealer. For local dealer information,
visit the find a showroom section of our website,
subzero.com.

Ice Machine Installation 8
Installation Requirements
•Installation must allow removal of the ice machine for
cleaning and service. Service diagnostics are per-
formed from the top of the ice machine.
•If the ice machine is installed in a corner, the door
swing may be limited due to handle contact with the
adjacent wall or cabinet. A 90° door stop is provided.
•Do not install the ice machine within 18" (457) of a trash
container, compactor or recycling container.
•Do not install the ice machine near heat-generating
equipment.
•The installation location must not obstruct airflow
through the kickplate.
•The installation location must be free of airborne and
other contaminants.
•The ambient air temperature must be between 50°F
(10°C) and 100°F (38°C) for indoor models and between
50°F (10°C) and 110°F (43°C) for outdoor models.
IMPORTA T OTE: Failure to follow installation require-
ments of the ice machine may affect warranty coverage.
The ice machine must be protected if it will be
exposed to ambient temperatures below 32°F (0°C).
Component failure caused by exposure to freezing
temperatures is not covered by the warranty.
Installation
Before moving the ice machine into position, make sure all
opening dimensions, electrical and plumbing requirements
are complete and accurate. The floor under the ice
machine must be at the same level as the surrounding
finished floor.
Move the ice maker into position near the installation
opening. Remove and discard all packing materials.
Remove the literature packet and drain hose from inside
the ice machine. The bin thermostat clip is shipped with
tape holding it in position. Remove the tape. Also, remove
the tape securing the water shutters.
Although the ice machine has been designed to be
serviced in place, in some cases it may be necessary to
slide the unit out for service or cleaning. The installation
must allow for removal of the unit.
Before moving the ice machine into position, protect
any finished flooring to avoid damage.

Ice Machine Installation 9
subzero.com/specs
Installation
I STALL THE ICE MACHI E
1) Adjust the leveling legs close to the desired height.
Refer to the illustration below.
2) Reverse the door swing if needed. Refer to steps
outlined on the following pages.
3) Gravity drain models: Install the drain hose (provided)
onto the drain fitting on the back of unit and route to
the open site drain. Refer to the illustration below and
plumbing requirements on pages 6–7.
Pump models: Route drain tubing through the drain
fitting on the back of the unit and install the drain hose
(provided) on the drain pump. Route the other end of
the drain tubing to the drain site. Refer to the illustra-
tion below and plumbing requirements on pages 6–7.
4) Use a compression fitting to connect the water inlet on
back of ice machine to the prepared 1/4"(6) OD cold
water line. Refer to the illustration below.
5) Open the shut-off valve on the water line. Check all
plumbing connections for leaks. Failure to do so could
result in flooding.
6) Plug the power cord into the grounded receptacle.
7) Level the ice machine to assure that the door closes
and seals properly. Place a level on top of the unit and
turn each leveling leg to raise or lower as needed.
8)Move the ice machine into its final position.
9) Secure the ice machine by installing two #8 x 1/2" flat
head screws through each hinge. Refer to the illustra-
tion below.
10) Add 4 oz (115 ml) of undiluted ice machine cleaner to a
container that will fit under the lifted water shutters.
Refer to the illustration below for location of the water
shuttters.
11) Press the CLEAN key pad. Wait three minutes until
the CLEAN light flashes, then add the prepared sani-
tizer by lifting the water shutters and pouring directly
into the spray area. The ice machine will automatically
time out a ten-minute sanitizing cycle, followed by
eight rinse cycles, and stop. The CLEAN light will turn
off to indicate that the sanitizing cycle is complete.
This entire cycle lasts approximately 30 minutes.
12) Add one gallon (3.8 L) of cold water to a container that
will easily fit under the lifted water shutters. Lift the
water shutters and pour the water directly into the
spray area. Watch for proper drainage.
13) Press the POWER button.
14) At initial start-up, the ice machine will need approxi-
mately 30 minutes to freeze ice and up to five minutes
to harvest the ice. Wait for first cycle of cubes to drop
to ensure proper installation.
WATER INLET
DRAIN FITTING
Drain connection.Leveling.
LEVELING
LEG
Location of water shutters.Secure ice machine.
HINGE
SCREWS
WATER
S UTTERS

Ice Machine Installation 10
Reverse Door Swing
The hinged side of the door may be reversed to the other
side if needed.
The ice machine is shipped with the door hinged at the
right. The door and hinges are designed for placing the
hinges on either the right or the left side of the unit.
Moving the hinges to the left in the pre-drilled holes,
allows the door to pivot from the left side.
IMPORTA T OTE: The plastic molding which covers the
top area of the door, packaged with the ice machine, is
required for this procedure.
1) To begin, remove the four screws that secure the door
hinges to the ice machine. Refer to the illustration
below. Remove the door. Remove the shim located
between the cabinet and bottom hinge, this shim will
transfer to the left side bottom hinge.
Remove hinges and trim.
UPPER
TRIM (RH)
HINGE
HINGE
2)Remove the hinges from the door by removing the four
screws (two per hinge) that secure the hinges to the
door. Refer to the illustration below.
3) Remove the right-hand upper trim (shaded area) from
the door by removing the two screws that secure it to
the door. Refer to the illustration below. Replace it with
the left-hand upper trim.
4) Transfer the hinges to the left side of the door and
reinstall. The upper hinge will now be in the lower hinge
position and the lower hinge will now be in the upper
hinge position. Refer to the illustration below.
HINGE
HINGE
UPPER
TRIM (LH)
Transfer hinges.
Remove door.
HINGE
SCREWS

Ice Machine Installation 11
subzero.com/specs
Reverse Door Swing
5)Remove the ice machine top cover by removing the
two screws along the back of the unit. Refer to the
illustration below.
6) Remove four screws from the front top rail. Refer to the
illustration below.
7) Pivot the top rail end for end to expose the two left-
hand top hinge screw holes and reinstall.
8)Remove two screws from the lower edge of the bottom
trim plate and slide the trim plate to the right, to cover
the right-hinge mounting screw holes. The left-hinge
mounting screw holes will now be exposed. Refer to
the illustration below.
9) Reinstall the door by mounting hinges using the left-
hinge mounting holes. Reinstall the shim removed in
step 1, between the cabinet and bottom hinge. Check
operation of the door by opening it.
TOP RAIL
SCREWS
Remove front top rail.Remove top cover.
TOP COVER
SCREWS
Bottom trim plate.
TRIM PLATE
SCREWS

Ice Machine Installation 12
Panel Installation
DOOR PA EL I STALLATIO
You should be sure of the door panel size and placement
before proceeding with the installation. Refer to the chart
for panel specifications. If you have questions, contact
your authorized Sub-Zero dealer or cabinet supplier.
For door handle hardware, a D-style pull, centered on the
edge opposite the door hinge side is recommended.
Screw heads may need to be countersunk to ensure that
the hardware does not interfere with the panel fitting flush
with the door.
Remove the handle side bracket attached to the front of
the door and set aside. Place the door panel lying face
down on a protected surface to ensure that the front will
not be scratched or damaged.
On the back of the panel, position the plastic template
(provided) flush with the top and side edges. Be sure you
are following the exact position for right-hand or left-hand
door swing. Refer to the illustration below.
Panel dimensions in the chart are the minimum necessary
to cover the door. The exact dimensions of your door
panel may vary depending on your particular installation.
Once you have located the proper position for the
hardware, mark the holes, remove template, and drill
pilot holes for mounting the hardware. It is best to start the
first few holes, position the hardware and then drill the
remaining pilot holes. Secure the mounting brackets with
#8 x 1/2" screws. Refer to the illustrations below.
Install the door panel by engaging the tabbed bracket to
the door first and then sliding the hinge side hardware
over the positioning screws. You will have a 1/4"(6) adjust-
ment, up and down, and side to side.
Once you have the door in place, attach the remaining
#8 x 1/2" screws to the hinge side mounting bracket and
install the hinge covers. Refer to page 14.
Right-hand door panel. Left-hand door panel.
Door Panel Specifications
Panel Width 15" (381)
Panel eight 303/8"(772)
Minimum Thickness 5/8"(16)
Maximum Weight 15 lbs (7 kg)
Dimensions based on 1/8"(3) reveal.
Template position.

Ice Machine Installation 13
subzero.com/specs
Panel Installation
Exercise caution when drilling holes for mounting
hardware. This is especially critical with inset panels.
If the reveal on the hinge side of the door panel is less
than 1/4", and the panel has a square corner, severe
finger pinching or damage to the unit may occur.
Installation
I STALL KICKPLATE
Once the ice machine is in position, install the kickplate
using the screws provided. The kickplate must be
removed for servicing. The floor cannot interfere with
removal. Do not cover the vents of the kickplate to allow
proper airflow. The door panel may hang in front of the
vents, but a decorative kickplate must not cover the vents.
If you choose, the kickplate may be painted another color.
Follow these steps: Rough up the surface to be painted
with fine grit sandpaper. Wipe with alcohol to ensure that
the surface is clean and dry. Use an appliance or industrial
grade, oil base, high gloss enamel paint.
SIDE PA EL I STALLATIO
With the ice machine, you must securely fasten side
panels to adjacent cabinets and floor. Brackets and
screws are provided for mounting the unit to adjoining
cabinets and side panels.
Side panels should be fastened to the floor and walls
using L-shaped brackets (not included). To help move the
unit into place, rout out an area in the floor so the bracket
will sit flush with the floor.

Installation
90° DOOR STOP
Door stop pins provided with the ice machine will limit the
door swing to 90°. Follow these steps to install:
1) Open the door to approximately 80°.
2) Insert the stop pin into the bottom door hinge (pin
enters from the top). Refer to the illustration below. The
pin must be inserted until the head has made contact
with the hinge body.
3) Insert the stop pin into the top door hinge (pin enters
from the bottom).
4) Check for proper operation.
HI GE COVER I STALLATIO
Install the hinge covers after installation of the ice machine
is complete. The 90° door stop must be installed prior to
installing the hinge covers. It will be necessary to remove
the knock-out in the hinge cover when the 90° door stop
is used.
Make sure hinges are free of dirt or grease before applying
covers. To install, remove backing paper from the adhesive
pads and bond to the hinge. Attach the magnetic center
covers. Refer to the illustration below.
Ice Machine Installation 14
DOOR STOP PIN
90° door stop. Hinge cover installation.
KNOCK-OUT
Installation Checklist
To ensure a safe and proper installation, the following
checklist should be completed by the installer to ensure
that no part of the installation has been overlooked.
I STALLATIO CHECKLIST
ave all electrical and water connections been made?
Is the power cord plugged into a properly grounded
3-prong outlet, which has been installed in accordance
with all applicable electrical codes?
Is the water supply turned on? ave water supply and
drain connections been examined for leaks?
Is the ice machine drain line routed to an open site
drain for gravity drains and according to instructions
for drain pump models?
as all packing materials and tape been removed?
Is the ice machine level? Are all leveling legs making
contact with the floor?
as the kickplate been installed properly? Is there
proper clearance in front of the kickplate for airflow?
If applicable, is the door panel installed properly?
If applicable, has the 90° door stop been installed?
ave hinge covers been installed?
as the ice machine and bin been sanitized?
Does the customer understand the unit's operation and
maintenance? ave you given the customer the
warranty package?
ave any installation or service problems been noted
on the product registration card? as the registration
card been mailed in?
If applicable, has the stainless steel door panel been
inspected for any imperfections? This is to be done by
the dealer or installer with the customer upon comple-
tion of the installation. Stainless steel panels are
covered by a limited 60-day parts and labor warranty
for cosmetic defects.

Service Information 15
subzero.com/specs
Service Information
If service is necessary, maintain the quality built into your
ice machine by calling Sub-Zero factory certified service.
For the name and number of Sub-Zero factory certified
service nearest you, check the contact & support section
of our website, subzero.com or call Sub-Zero customer
care at 800-222-7820.
When calling for service, you will need the model and
serial numbers of your unit. Both numbers are listed on the
product rating plate, located in the upper left corner of the
ice bin and on the back of the unit. Refer to the illustration
below.
If you are storing or disposing of your old refrigerator
or freezer, please do it
safely. Remove the
doors or tightly secure
the doors closed.
Child entrapment
accidents can be tragic.
The information and images in this guide are the copyright property of Sub-Zero, Inc. Neither this guide nor any information or images contained herein may be
copied or used in whole or in part without the express written permission of Sub-Zero, Inc. ©Sub-Zero, Inc. all rights reserved.
Wolf, Wolf & Design, Wolf Gourmet, W & Design and the color red as applied to knobs are registered trademarks and service marks of Wolf Appliance, Inc.
Sub-Zero, Sub-Zero & Design, Dual Refrigeration, Constant Care and The Living Kitchen are registered trademarks and service marks of Sub-Zero, Inc.
(collectively, the “Company Marks.”) All other trademarks or registered trademarks are property of their respective owners in the United States and other countries.
Location of rating plate.
RATING PLATE

SUB-ZERO, I C. P. O. BOX 44848 MADISO , WI 53744 SUBZERO.COM 800.222.7820
7024818 REV-A 2/2012
