Sub-Zero UC-15I Guide

© SUB-ZERO, INC. 2009 ALL RIGHTS RESERVED JOB AID #7014804 Revision A - September, 2009
3
1a
9
1b,c,d,e
5
4
6, 6a,b,c
3
11
15
7
7a
12
13a,b
2
8, 8a-i
14
10
MODEL
MODEL UC-15I UC-15I
(Undercounter Ice Machine)
(Undercounter Ice Machine)
SSeerrvviicceePPaarrttssMMaannuuaall

1#7014804 - Revision A -September, 2009
Model UC-15I (Undercounter Ice Machine) Parts Manual
INTRODUCTION
This Sub-Zero Service Parts Manual (Job Aid Part
#7014804) is a compilation of information and illustra-
tions from Sub-Zero, Inc. and Manitowoc FSG
Operations, Inc. The information in this manual has
been produced for Sub-Zero service training and serv-
ice repair purposes with permission from Manitowoc
FSG Operations, Inc.
NOTE: The following may be listed after some part
descriptions:
“(See SN Breaks)” = See Serial Number Breaks in Price List
Model UC-15I Control Box Area ......................................... 2
Model UC-15I Evaporator and Ice Bin Area
(Inlc. Bin Thermostat and related Parts) ........................... 3
Model UC-15I Refrigeration Compartment
Common Components ...................................................... 4
Model UC-15I Refrigeration Compartment
Condensing Components .................................................. 5
Model UC-15I Panels ........................................................... 6
TABLE OF CONTENTS
Page #
TECHNICAL ASSISTANCE
If you should have any questions regarding a Sub-Zero
appliance and/or this manual, please contact:
Sub-Zero, Inc.
ATTN: Service Department
P.O. Box 44988
Madison, WI 53744 - 4988
Customer Assistance
Phone #: (800) 222 - 7820
Facsimile #: (608) 441 - 5887
Technical Assistance
(For Technicians in Customer’s Homes Only)
Phone #: (800) 919 - 8324
Warranty Claims
Phone #: (800) 332 - 9513
Facsimile #: (608) 441 - 5886
Service Department e-Mail Address:
[email protected]
Office Hours:
7:00 AM to 6:00 PM Central Time
Monday through Friday
This manual is designed to be used by Authorized Service Personnel only. Sub-Zero, Inc. assumes no
responsibility for any repairs made to a Sub-Zero appliance by anyone other than Authorized Service
Technicians.
The information and images contained in this manual are the copyright property of Sub-Zero, Inc. Neither this man-
ual nor any information or images contained herein may be copied or used in whole or in part without the express
written consent of Sub-Zero, Inc. ©, all rights reserved.

1, 1a 7a
6
2
10 93
2a
1b
2
#7014804 - Revision A -September, 2009
Parts Manual Model UC-15I (Undercounter Ice Machine)
UC-15I CONTROL BOX AREA
1 7013048 Control, Board Main Svce
1a 7013089 Control, Board Pkg Svce
(Includes Control Board & User Interface Board)
1b 7013093 Control, Board 10 Amp Fuse Svce
2 7013049 Control, Board User Interface
2a 7013083 Label, Control Board Svce
3 7013047 Transformer, Svce
4NA
5NA
6 7013476 Control Box & Label Svce
7NA
7a 7013107 Screw, Svce
Ref # Part # Description Ref # Part # Description
8a NA
8b NA
9 7013053 Lampholder, Svce
10 7013055 Cover, Bin Light Svce
NOT PICTURED:
11 7013050 W/H, Service
12 7013052 Control, Box Cover Svce
13 7013051 Switch, Proximity Svce
14 7013056 W/H, High Voltage
15 7014846 W/H, Low Voltage
16 7013054 Lamp, Light Bulb Svce
NOT PICTURED
11 Wire Harness - Control Panel to Control Board
12 Control Box Cover
13 Wire Harness - Proximity Switch
14 Wire Harness, High Voltage - Harvest Valve, Water Inlet Valve
15 Wire Harness, Low Voltage - Toggle Switch, Thermistor
16 Light bulb

3#7014804 - Revision A -September, 2009
Model UC-15I (Undercounter Ice Machine) Parts Manual
5
1a,b
3a
3b
9
6b
6a
7
7a
7b
10
3c (not shown)
3d
48a,b,c,d
11
3
12
UC-15I EVAPORATOR AND ICE BIN AREAS (Inlc. Bin Thermostat and related Parts)
1a 7013097 Evap Assy, Svce
1b 7013090 Evap Assy, Heat Exchanger Svce
2NA
3 7013200 Bar, Spray Assy Svce
3a 7013101 Nozzle, Insert Svce (each)
3b 7013100 Nozzle, Svce (each)
3c 7013110 Seal, O-Rings Svce (not shown)
3d 7013115 Clamp, Spray Bar
4 7013218 Support, Ice Ramp Svce SVCE
5 7013057 Tube, Standpipe Svce
6a 7013217 Guard,Curtain Paddle Svce (6 per unit)
6b 7013059 Rod, Curtain Svce
7 7013219 Bin, Water Trough Svce
7a 7013060 Tube, Drain Trough Svce
7b 7013112 Clamp, Svce
8a 7013207 Fitting, Evap Water Inlet Svce
Ref # Part # Description Ref # Part # Description
8b 7013208 Tube, Evap Water Svce
8c 7013111 Seal, O-Rings Svce
8d 7014847 Bracket, Retaining Svce
9 7013220 Cover, Evap Svce
10 7013726 Foam, Insert Svce
11 7013659 Enclosure, Evap/Spray Bar Svce
12 7013477 Guard, Splash Shield Svce
NOT PICTURED:
13a 7013489 Bin, Thermostat Svce
(Includes Bin Thermostat Tube)
13b 7013482 Clip, Bin Svce
13c 7013209 Bracket, Svce
14 7013400 Cleaner, Metal Safe
15 7013401 Sanitizer
NOT PICTURED
13a Bin Thermostat Control
13b Bin Thermostat Clip
13c Bin Thermostat Bracket
14 Ice Machine Cleaner
15 Ice Machine Sanitizer

4
#7014804 - Revision A -September, 2009
Parts Manual Model UC-15I (Undercounter Ice Machine)
3
1a
9
1b,c,d,e
5
4
6, 6a,b,c
3
11
15
7
7a
12
13a,b
2
8, 8a-i
14
10
UC-15I REFRIGERATION COMPARTMENT - COMMON COMPONENTS
1a 7013091 Compressor, Drier Assy, Svce
1b 7013061 Relay, Start Svce
1c 7013204 Cover, Start Relay Svce
1d 7013062 Capacitor Start Svce
1e 7013063 Overload Protector, Svce
2 7013201 Valve, Harvest Svce
3 7013065 Heat Exchanger, Svce
4 7013202 Drier, Line Svce
5 7013196 Pump, Water (Circulating Pump)
6 7013066 Valve , Water Inlet Svce
6a 7013068 Valve, Water Inlet Bracket Svce
6b 7013067 Valve, Water Inlet Nut Svce
6c 7013069 Valve, Water Inlet Sleeve Svce (Cmprsn)
7 7013070 Cord, Power Svce
7a 7013094 Bushing, Strain Relief Svce
8 7014848 Filter, Water (Sales Accessory)
8a 7013725 Tube, Water Inlet Svce
8b 7013490 Filter, Head Svce
8c 7013046 Fitting, Svce
8d 7013071 Clamp, Svce
8e 7013205 Enclosure, Svce
8f 7013058 Tube, Adapter (Quick-Connect)
Ref # Part # Description Ref # Part # Description
8g 7013046 Fitting, Svce
8h 7013045 Tube, Holder 90 Degree Svce
8i 7013099 Tube, Water Line Svce (Filter & Evap)
9 7013197 Pump, Drain Svce
10 7013092 Thermistor, Svce
11 7013505 Tube, Spray Housing Svce
12 7013102 Fitting, Drain Svce
13a 7013114 Clip, Compressor Svce (Hairpin)
13b 7013064 Grommet, Comp Rubber Svce
14 7013487 Tube, Vent Svce
15 7013113 Leg, Leveler Svce
NOT PICTURED:
16 7013198 Tube, Drain, w/Drain Pump Svce
17 7013199 Tube, Drain, w/o Drain Pump Svce
18 7013488 Tube, Drain Svce
19a 7013479 Clamp, Spring Svce
19b 7013480 Clamp, Spring Svce
19c 7013481 Clamp, Spring Svce
20 7013095 Tube, Drain Svce
NOT PICTURED
16 Bin Drain Tube (w/Drain Pump)
17 Bin Drain Tube (w/o Drain Pump)
18 Drain Pump Discharge Tube
19a Drain Pump Clamp, 12mm ID
19b Drain Pump Clamp, 13mm ID
19c Drain Pump Clamp, 22mm ID
20 Drain Tube (19mm ID X 5’ Long)

5#7014804 - Revision A -September, 2009
Model UC-15I (Undercounter Ice Machine) Parts Manual
10
4
3
7
5
11
8
92
6
12
UC-15I REFRIGERATION COMPARTMENT - CONDENSING COMPONENTS
1NA
2 7013203 Condenser, Air Svce
3 7013072 Motor, Fan Svce (Outdoor Use Only)
7014173 Motor, Fan Indoor Svce (Indoor Only)
4 7013096 Fan Blade, Svce
5 7013065 Heat Exchanger, Svce
6 7013117 Shroud, Fan Svce
Ref # Part # Description Ref # Part # Description
7 7013116 Bracket, Condenser Fan Svce
8 7013118 Bracket, Wire Mount Svce
9 7013105 Screw, Svce (Bracket to Shroud)
10 7013073 Baffle, Air Svce
11 7013106 Screw, Svce (Motor to Bracket)
12 7013108 Screw, Svce

6
#7014804 - Revision A -September, 2009
Parts Manual Model UC-15I (Undercounter Ice Machine)
13a
13b
14
11
4
10
6
2
3
9
1
7
5
8
UC-15I PANELS
1 7013080 Cover, Top Svce
2 7013086 Panel, Back Svce
3 7013087 Panel, Back Utility Svce
4 7013216 Door Assy, Front Svce
5 7013660 Cover Assy, Lower Svce
6 7013399 Kickplate, Black Svce
7013395 Kickplate, Stainless Steel Svce
7 7013081 Frame, Top Front Rail Svce
8 7013082 Frame, Bottom Front Rail Svce
9 7013206 Slide, Bottom Svce
10 7013077 Trim, Door Bottom Svce
11 7013084 Seal, Door Svce
12 NA
13a 7013485 Hinge, Outdoor Svce (Top RH, Bot LH)
13b 7013486 Hinge, Outdoor Svce (Bot RH, Top LH)
14 7013475 Door, Ice Scoop Svce
NOT PICTURED
15 Bin Front with Heater Assy
16 Door Panel Drilling Template
17 Hinge Stop
18 Right Hinge Cover
19 Left Hinge Cover
20 Vertical Door Panel Mounting Bracket
21 Filler Panel for 18” Opening (Sales Accessory)
22 Stainless Steel Front Panels (Sales Accessory)
Ref # Part # Description Ref # Part # Description
NOT PICTURED:
15 7013478 Kit, Heater & SS Panel Svce
16 7014849 Template, Door Panel Svce
17 7013076 Hinge, Stop Svce
18 7013078 Cover, Hinge Right Svce
19 7013079 Cover, Hinge Left Svce
20 7013413 Bracket, Door Panel Svce
21 7012363 Filler, 15” to 18” (Sales Accessory)
22 7006800 Pnl, 15X30.375, PH
7006801 Pnl, 17.75X30.375, PH
7006876 Pnl, 15X30.375, CH
7006877 Frnt Pnl, 18” 315I SS CH
7007198 Pnl, 15X30.375,OBR,CLSC,TH
7007199 Pnl, 17.75X30.375,OBR,CLSC,TH
